2AXCJ-VANW4F01VANTAGE WIRELESS CHARGER FOR FURNITURE APPLICATION

15-25mm Mounting hole for Wireless charger VAN-W4F-5W/LI 64mm diameter Cable hole 25mm diameter Wireless charger VAN-W4F-5W/LI USB HUB TYPE A/LI Air jack connector should be disconnected before mounting 500mm Round cable diameter 3.6mm Step 1 Recommended top panel thickness Please twist this knob in CCW direction till you feel resistance Vantage DC power supply VAN-050250PS-A 1000mm MOUNTING INSTRUCTION "CONCEALED FURNITURE" VAN-W4F-5W/LI+VAN-USB-C-W4F-5W01/LI+VAN-050250PS-A VANTAGE WIRELESS CHARGER VAN-W4F-5W/LI PAGE-1 Install VAN-W4F-5W/LI wireless charger into prepared hole (diameter 64mm) Cable hole 25mm diameter VANTAGE WIRELESS CHARGER VAN-W4F-5W/LI PAGE-2 Step 2 If wireless charger device fits properly to the hole and you feel that device can not be pushed deeper pease twist this part in CW direction to lock Connect air jack connector after mounting in furniture VANTAGE WIRELESS CHARGER VAN-W4F-5W/LI Step 3 PAGE-3 Locker should look like picture shown when in the closed postion VANTAGE WIRELESS CHARGER VAN-W4F-5W/L PAGE-4 Step 4 Mounted properly Vantage wireless charger VAN-W4F-5W/LI Blue indicator Screw in the USB HUB using a Philips screwdriver VANTAGE WIRELESS CHARGER VAN-W4F-5W/L I PAGE-5 Step 5 Light description: -One blink at power on -Constant blinking when Wireless charger is charging phone -The blue light disappears when phone is charged fully -Constant blinking-error This deYice complies with Part 1 of the FCC Rules. Operation is subject to the following two conditions 1 This deYice may not cause harmful interference and 2 this deYice must accept any interference receiYed including interference that may cause undesired operation Warning Changes or modifications to this unit not e[pressly approYed by the party responsible for compliance could Yoid user¶s authority to operate the eTuipment. The eTuipment complies with FCC RF radiation e[posure limits set forth for an uncontrolled enYironment. This eTuipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. VANTAGE WIRELESS CHARGER VAN-W4F-5W/L I PAGE-6

Picture 1 Picture 2 Picture 3 Picture 4 Picture 5 Picture 6 Picture 7 Picture 8 Picture 9

Picture 1 Picture 2 Picture 3 Picture 4 Picture 5 Picture 6

Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Page 1 of 9 TEST REPORT Reference No. .................... : WTF20F08055378-2W FCC ID ................................ : 2AXCJ-VANW4F01 Applicant ........................... : VANTAGE CITY GROUP LIMITED Address ............................. : RM701, 7/F, World-Wide House, 19 Des Voeux Road, Central, HK Product Name ................... : VANTAGE WIRELESS CHARGER FOR FURNITURE APPLICATION Test Model. ........................ : VAN-W4F-5W/LI+VAN-USB-C-W4F-5W01/LI+VAN-050250PS-A Standards .......................... : KDB 680106 D01 V03 Date of Receipt sample .... : Sept.27, 2020 Date of Test........................ : Sept.27, 2020 to Sept.30, 2020 Date of Issue ..................... : Sept.30, 2020 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Tested by: Reviewed By: Approved & Authorized By: Jason Su / Project Engineer Lion Cai / RF Manager Silin Chen / Manager Reference No.: WTF20F08055378-2W Page 2 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 5 2. RF EXPOSURE TEST REPORT ............................................................................................................................ 6 2.1 STANDARD APPLICABLE ......................................................................................................................................... 6 2.2 TEST CONDITIONS .................................................................................................................................................. 6 2.3 TEST PROCEDURE ................................................................................................................................................... 7 2.4 TEST RESULT.......................................................................................................................................................... 7 2.4 TEST PHOTOS ......................................................................................................................................................... 9 Reference No.: WTF20F08055378-2W Page 3 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Report version Version No. Date of issue Description Rev.00 Sept.30, 2020 Original / / / Reference No.: WTF20F08055378-2W Page 4 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: VANTAGE CITY GROUP LIMITED Address of applicant: RM701, 7/F, World-Wide House, 19 Des Voeux Road, Central, HK Manufacturer: VANTAGE CITY GROUP LIMITED Address of manufacturer: RM701, 7/F, World-Wide House, 19 Des Voeux Road, Central, HK General Description of EUT Product Name: VANTAGE WIRELESS CHARGER FOR FURNITURE APPLICATION Trade Name: / Model No.: VAN-W4F-5W/LI+VAN-USB-C-W4F-5W01/LI+VAN- 050250PS-A Adding Model(s): / Power adapter: VAN-050250PS-A Input: AC 100-240V, 50/60Hz, 0.5A Output: DC 5V, 2.5A Note: The test data is gathered from a production sample, provided by the manufacturer. Technical Characteristics of EUT Frequency Range: 110~205kHz Antenna Type: Coil Antenna Rated Voltage: DC 5V, 2.5A, (USB input) Rated Current: ≤1A (Wireless output) Rated Power: ≤5W (Wireless output) Reference No.: WTF20F08055378-2W Page 5 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn 1.2 Test Equipment List and Details Description Manufacturer Model Serial No. Cal Date Due Date MPE Measuring Instrument Narda ELT-400 M-0155/M-0170 2020-07-15 2021-07-14 Broadband Field Meter Narda NBM-520 D-1699 2020-06-21 2021-06-20 Reference No.: WTF20F08055378-2W Page 6 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn 2. RF Exposure Test Report 2.1 Standard Applicable According to § 1.1310 system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. 2.2 Test Conditions Test Mode Description Remark Power Supply Mode TM1 Wireless charging Transmit DC 5V (with an adapter input AC 120V/60Hz) Measurement Distance: 15 cm Reference No.: WTF20F08055378-2W Page 7 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn 2.3 Test Procedure a. The measurement probe was placed at test distance(15 cm for A,B,C,D,F and 20 cm for E) which is between the edge of the charger and the geometric center of probe. b. The highest emission level was recorded at the measurement points(A, B, C, D, E, F). c. The EUT was measured according to the distance of KDB 680106 D01 V03. 2.4 Test Result The EUT dose comply with item 5.2 of KDB 680106 D01V03 1. Power transfer frequency is less that 1 MHz Yes, the device operate in the frequency range from 110kHz to 205kHz. 2. Output power from each primary coil is less than or equal to 1 5 watts Yes, the maximum output power of the primary coil is less than 15W. 3. The transfer system includes onl…

Text truncated - open the document above for the full version.

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Page 1 of 26 TEST REPORT Reference No. .................... : WTF20F08055378-1W FCC ID ................................ : 2AXCJ-VANW4F01 Applicant ............................ : VANTAGE CITY GROUP LIMITED Address .............................. : RM701, 7/F, World-Wide House, 19 Des Voeux Road, Central, HK Manufacturer .................... : The same as above Address .............................. : The same as above Product Name .................... : VANTAGE WIRELESS CHARGER FOR FURNITURE APPLICATION Model No. ........................... : VAN-W4F-5W/LI+VAN-USB-C-W4F-5W01/LI+VAN-050250PS-A Standards........................... : FCC Part 18 Date of Receipt sample .... : 2020-08-13 Date of Test ....................... : 2020-09-01 Date of Issue ...................... : 2020-09-17 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group (Foshan) Co., Ltd. Address: No.13-19, 2/F., 2nd Building, Sunlink International Machinery City, Chencun, Shunde District, Foshan, Guangdong, China Tel:+86-757-23811398 Fax:+86-757-23811381 E-mail:[email protected] Compiled by: Approved by: Roy Hong / Project Engineer Danny Zhou / Manager Reference No.: WTF20F08055378-1W Page 2 of 26 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn 1 Revision History Test Report No. Date of Issue Description Status WTF20F08055378-1W 2020-09-17 Original Valid Reference No.: WTF20F08055378-1W Page 3 of 26 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 REVISION HISTORY ................................................................................................................................. 2 2 CONTENTS ............................................................................................................................................... 3 3 GENERAL INFORMATION ....................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T ................................................................................................... 4 3.2 TECHNICAL CHARACTERISTICS OF EUT ........................................................................................... 4 3.3 STANDARDS APPLICABLE FOR TESTING ............................................................................................ 4 3.4 TEST FACILITY ................................................................................................................................ 5 3.5 SUBCONTRACTED ........................................................................................................................... 5 3.6 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................ 5 4 EUT SETUP AND TEST MODE ................................................................................................................ 6 5 EQUIPMENT USED DURING TEST ......................................................................................................... 7 5.1 EQUIPMENT LIST ............................................................................................................................. 7 5.2 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ......................................................................... 8 5.3 MEASUREMENT UNCERTAINTY ......................................................................................................... 8 6 SUMMARY OF TEST RESULT ................................................................................................................ 9 7 CONDUCTED EMISSIONS ..................................................................................................................... 10 8 RADIATED SPURIOUS EMISSIONS ..................................................................................................... 13 9 PHOTOGRAPHS TEST SETUP ............................................................................................................. 18 9.1 PHOTOGRAPHS - RADIATED EMISSION TEST SETUP ........................................................................ 18 9.2 PHOTOGRAPHS – CONDUCTED EMISSION TEST SETUP ................................................................... 19 10 PHOTOGRAPHS - CONSTRUCTIONAL DETAILS ............................................................................... 20 10.1 EUT - EXTERNAL PHOTOS ............................................................................................................. 20 10.2 EUT - INTERNAL VIEW ................................................................................................................... 24 Reference No.: WTF20F08055378-1W Page 4 of 26 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn 3 General Information 3.1 General Description of E.U.T Product Name ............................... : VANTAGE WIRELESS CHARGER FOR FURNITURE APPLICATION Model No. ..................................... : VAN-W4F-5W/LI+VAN-USB-C-W4F-5W01/LI+VAN-050250PS-A Model Description ........................ : --- Rated Voltage................................ : DC 5V, 2.5A, Wireless power: 5W, USB port power: 7.5W Battery Capacity ........................... : --- Power Adapter .............................. : VAN-050250PS-A 3.2 Technical Characteristics of EUT Frequency Range ......................... : 110-205kHz Antenna Type ................................ : Coil Antenna 3.3 Standards Applicable for Testing The tests were performed according to following standards: FCC Part 18 Industrial, Scientific, and medical equipment ANSI C63.4-2014 American Natio…

Text truncated - open the document above for the full version.

Test Setup For Radiated Emission (9kHz to 30MHz) Test Setup For Radiated Emission (30MHz to 1GHz) Test Setup For Conducted Emission
