2AXCJ-VANW4F02VANTAGE WIRELESS CHARGER FOR FURNITURE APPLICATION

15-25mm Mounting hole for wireless charger VAN-W4F-5W2/LI 64mm diameter Recommended top panel thickness Cable hole 25mm diamete r Wireless charger VAN-W4F-5W2/LI USB 500mm Air jack connector should be disconnected before mounting 500mm 1000mm Vantage power supply 9V 2.5A VAN-USAD-2209-F-AJC Step 1 VAN-USB-C-W4F-5W02/LI Please twist this knob in CCW direction till you feel resistance VANTAGE WIRELESS CHARGER VAN-W4F-5W2/LI MOUNTING INSTRUCTION "CONCEALED FURNITURE" VAN-W4F-5W2/LI+VAN-USB-C-W4F-5W02/LI+VAN-USAD-2209-F-AJC PAGE-1 Cable hole 25mm diameter Connect USB plug into wireless VAN-W4F-5W2/LI charger USB socket Install VAN-W4F-5W2/LI wireless charging device into prepared hole (diameter 64mm) PAGE-2 Step 2 VANTAGE WIRELESS CHARGER VAN-W4F-5W2/LI If wireless charger device fits properly to the hole and you feel that device can not be pushed deeper please twist this part in CW direction to lock Connect air jack connector after mounting in furniture PAGE-3 Step 3 VANTAGE WIRELESS CHARGER VAN-W4F-5W2/LI Locker should look like picture shown when in the closed position VANTAGE WIRELESS CHARGER VAN-W4F-5W2/LI PAGE-4 Step 4 Blue indicator Screw in the USB HUB using a Philips screwdriver Mounted properly Vantage wireless charger VAN-W4F-5W2/LI Step 5 Light description: -One blink at power on -Constant lighting when wireless charger is charging phone -The blue light disappears when phone is charged fully -Constant blinking-error PAGE-5 VANTAGE WIRELESS CHARGER VAN-W4F-5W2/LI This device complies with Part 18 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. VANTAGE WIRELESS CHARGER VAN-W4F-5W2/LI PAGE-6

Picture 1 Picture 2 Picture 3 Picture 4 Picture 5 Picture 6 Picture 7 Picture 8

Picture 1 Picture 2 Picture 3 Picture 4 Picture 5 Picture 6

Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Page 1 of 9 TEST REPORT Reference No. .................... : WTF20F08055379-2W FCC ID ................................ : 2AXCJ-VANW4F02 Applicant ........................... : VANTAGE CITY GROUP LIMITED Address ............................. : RM701, 7/F, World-Wide House, 19 Des Voeux Road, Central, HK Product Name ................... : VANTAGE WIRELESS CHARGER FOR FURNITURE APPLICATION Test Model. ........................ : VAN-W4F-5W2/LI+VAN-USB-C-W4F-5W02/LI+VAN-USAD-2209-F-AJC Standards .......................... : KDB 680106 D01 V03 Date of Receipt sample .... : Sept.27, 2020 Date of Test........................ : Sept.27, 2020 to Sept.30, 2020 Date of Issue ..................... : Sept.30, 2020 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Tested by: Reviewed By: Approved & Authorized By: Jason Su / Project Engineer Lion Cai / RF Manager Silin Chen / Manager Reference No.: WTF20F08055379-2W Page 2 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 5 2. RF EXPOSURE TEST REPORT ............................................................................................................................ 6 2.1 STANDARD APPLICABLE ......................................................................................................................................... 6 2.2 TEST CONDITIONS .................................................................................................................................................. 6 2.3 TEST PROCEDURE ................................................................................................................................................... 7 2.4 TEST RESULT.......................................................................................................................................................... 7 2.4 TEST PHOTOS ......................................................................................................................................................... 9 Reference No.: WTF20F08055379-2W Page 3 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Report version Version No. Date of issue Description Rev.00 Sept.30, 2020 Original / / / Reference No.: WTF20F08055379-2W Page 4 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: VANTAGE CITY GROUP LIMITED Address of applicant: RM701, 7/F, World-Wide House, 19 Des Voeux Road, Central, HK Manufacturer: VANTAGE CITY GROUP LIMITED Address of manufacturer: RM701, 7/F, World-Wide House, 19 Des Voeux Road, Central, HK General Description of EUT Product Name: VANTAGE WIRELESS CHARGER FOR FURNITURE APPLICATION Trade Name: / Model No.: VAN-W4F-5W2/LI+VAN-USB-C-W4F-5W02/LI+VAN -USAD-2209-F-AJC Adding Model(s): / Power adapter: VAN-USAD-2209-F-JAC Input: AC 100-240V, 50/60Hz, 0.5A Output: DC 9V, 2.5A Note: The test data is gathered from a production sample, provided by the manufacturer. Technical Characteristics of EUT Frequency Range: 110~205kHz Antenna Type: Coil Antenna Rated Voltage: DC 9V, 2.5A, (USB input) Rated Current: ≤1A (Wireless output) Rated Power: ≤5W (Wireless output) Reference No.: WTF20F08055379-2W Page 5 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn 1.2 Test Equipment List and Details Description Manufacturer Model Serial No. Cal Date Due Date MPE Measuring Instrument Narda ELT-400 M-0155/M-0170 2020-07-15 2021-07-14 Broadband Field Meter Narda NBM-520 D-1699 2020-06-21 2021-06-20 Reference No.: WTF20F08055379-2W Page 6 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn 2. RF Exposure Test Report 2 .1 Standard Applicable According to §1.1310 system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. 2.2 Test Conditions Test Mode Description Remark Power Supply Mode TM1 Wireless charging Transmit DC 9V (with a adapter input AC 120V/60Hz) Measurement Distance: 15 cm Reference No.: WTF20F08055379-2W Page 7 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn 2.3 Test Procedure a. The measurement probe was placed at test distance(15 cm for A,B,C,D,F and 20 cm for E) which is between the edge of the charger and the geometric center of probe. b. The highest emission level was recorded at the measurement points(A, B, C, D, E, F). c. The EUT was measured according to the distance of KDB 680106 D01 V03. 2.4 Test Result The EUT dose comply with item 5.2 of KDB 680106 D01V03 1. Power transfer frequency is less that 1 MHz Yes, the device operate in the frequency range from 110kHz to 205kHz. 2. Output power from each primary coil is less than or equal to 1 5 watts Yes, the maximum output power of the primary coil is less than 15W. 3. The transfer sys…
