Sivantos GmbH - R&D PSA WLS L DE ERL - Richard Rose Page 1 of 3 Erlangen, 2026-07-14 Restricted Integration manual for RF Module 22 (RFM022) The module is for use in our own products only and will not be sold to third parties The “RFM022” radio module contains two radio transceivers running at 3.27 MHz and 2.45 GHz which are implemented in a single hardware platform. The 3.27 MHz radio consists of a nearfield inductive magnetic transceiver. It uses time division duplex and runs on a single channel with phase modulation. The signal is transmitted by a coil antenna. The intended use of this radio is to exchange data between two hearing aids or to communicate with a proprietary accessory. The 2.45 GHz radio is mainly used for Bluetooth® Low Energy Radio communication. In addition to that, the receiver is also capable of proprietary communication modes. The transceiver is connected to a PCB-integrated antenna. The intended use of this radio is to exchange data between hearing aids and Bluetooth accessories. The main part of the module is a set of analog and digital ASICs which contain both radios. These ASICs are mounted on a flex PCB. In addition to that the module comprises the coil antenna for the nearfield inductive magnetic system, one crystal and an EEPROM memory. The antenna for the 2.45 GHz radio is integrated in the flex PCB of the module. The matching circuitry between the radio ASIC and the antenna is also on the flex PCB. On the flex PCB additional components are mounted and connected to the radio module. These include microphones, the connector to the external speaker, push buttons, the telecoil and the battery connector. The system is powered by a lithium ion battery, all necessary voltage regulators are included in the module. The PCB with the module and all other components of the hearing aid are arranged in a plastic frame that is not user serviceable or user modifiable. The outer housing may be replaced by field service, but this is not relevant for the wireless module. The module is thus not installed but instead assembled at the same time as the host is. The position of components and interconnection through the PCB are decided during the project phase for the different hosts and following the best practice of the engineering team in order to assure an optimal integration of the module. Several validation steps are done through the development to assure the full compliance with all the regulatory requirements. Sivantos GmbH - R&D PSA WLS L DE ERL - Richard Rose Page 2 of 3 Erlangen, 2026-07-14 Restricted The user guide must contain the HVIN, the FCC ID and the IC ID: HVIN: RFM022 Contains FCC ID: 2AXDT-RFM022 Contains IC ID: 26428-RFM022 and following statements: (English version) This Class B digital apparatus complies with Canadian ICES‑003. Changes or modifications made to this equipment not expressly approved by the legal manufacturer may void the FCC authorization to operate this equipment. This device complies with Part 15 of the FCC Rules and with ISED's licence-exempt RSSs. Operation is subject to the following conditions: • this device may not cause harmful interference, and • this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The radiated output power of the device is far below the FCC and ISED radio frequency exposure limits. Sivantos GmbH - R&D PSA WLS L DE ERL - Richard Rose Page 3 of 3 Erlangen, 2026-07-14 Restricted For body worn operation, this device has been tested and meets the FCC RF exposure guidelines when used with the legal manufacturer’s accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. (French version) Cet appareil numérique de classe B est conforme à la norme canadienne ICES‑003. Un changement ou une modification apporté à cet appareil sans être expressément approuvé par le fabricant légal peut annuler l'autorisation FCC d'utilisation de l'appareil. Cet appareil est conforme à la partie 15 des règlements FCC et aux normes RSS d'exemption de licence de l'organisme canadien ISDE. Son fonctionnement est soumis aux conditions suivantes : • cet appareil ne doit pas causer d'interférences nuisibles, et • cet appareil doit supporter toutes les interferences reçues, y compris celles susceptibles de perturber son bon fonctionnement. Cet appareil a été testé et déclaré conforme aux valeurs limites d'un appareil numérique de classe B selon la partie 15 des règlements FCC. Ces limites sont destinées à garantir une protection raisonnable contre les interférences nuisibles en milieu résidentiel. Cet appareil génère, utilise et peut rayonner de l'énergie radiofréquence et, s'il n'est pas installé et utilisé dans le respect des instructions, peut produire des interferences nuisibles aux liaisons radio. Cependant, rien ne garantit que ces interférences ne se produiront …

Text truncated - open the document above for the full version.

WSAudiology WSAUD A/S Nym0llevej 6 3540 Lynge Denmark Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-06-03 Attestation Statement according to 2.911(d)(5)(i) and 2.911(d)(5)(ii) FCC ID: 2AXDT-RFM022 FRN:0029767068 TO WHOM IT MAY CONCERN: Hereby we certify that the equipment for which authorization is sought is not "covered" equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Furthermore, we certify that, as of the date of filing the application, WSAUD A/S is not identified on the Covered List (either as a specifically named entity or as any of its subsidiaries or affiliates) as an entity producing "covered" equipment. Sincerely, Erika Radick Head of Wireless Platform Sivantos GmbH Henri-Dunant-Str. 100 91058 Erlangen Germany [email protected] Sivantos GmbH Henri-Dunant-Str. 100 91058 Erlangen Germany [email protected] WSAUD A/S Nym0llevej 6 3540 Lynge Denmark Rhone: +45 44 35 56 00 www.wsa.com

WSAUD A/S Nym0llevej 6 3540 Lynge Denmark Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA April 29th, 2026 Attestation Statement according to 2.911(d)(7) FCC ID: 2AXDT-RFM022 TO WHOM IT MAY CONCERN: We, WSAUD A/S, designate WS Audiology USA Inc., to act as U.S. agent for service of process. WS Audiology USA Inc. hereby acknowledges the Obligation of the U.S. agent for service of process. Fürther WSAUD A/S accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission- related proceeding involving the equipment. Sincerely WSAUD A/S FRN:0029767068 Nym0llevej 6 3540 Lynge, Denmark Dr. Bernd Matschkai Head of Head of Wireless Platform Core Development +49 9131308 3012 [email protected] WS Audiology USA, Inc. FRN:0033434770 101 Wood Avenue South 7th Floor Iselin, NJ 08830, United States Isabel Restivo Head of Business Quality, Americas +1 551579 9581 [email protected] Nym0llevej 6 3540 Lynge Denmark WSAUD A/S phone+45 44 35 56 00 www.wsa.com

WSAij< üology Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Certification and Engineering Bureau Innovation, Science and Economic Development Canada Spectrum Engineering Branch 3701 Carling Avenue, Building 94 Ottawa, Ontario K2H 8S2 2026-06-03 Modular Transmitter Declaration TO WHOM IT MAY CONCERN Pursuant to KDB Publication 996369 D03 and RSP-100, we, WSAUD A/S, hereby declare and ensure that the modular transmitter FCC Certification Number: IC Certification Number: PMN: Model Name/HVIN: 2AXDT-RFM022 26428-RFM022 RF Module 22 RFM022 will only be used in our own products and is not intended for sale to third parties. The user manual Integration instructions are internal confidential manufacturing documents. Sincerely, Erika Radick Head of Wireless Platform Sivantos GmbH Henri-Dunant-Str. 100 91058 Erlangen Germany [email protected] Sivantos GmbH Henri-Dunant-Str. 100 91058 Erlangen Germany [email protected] WSAUD A/S Nym0llevej 6 3540 Lynge Denmark Page 1 of 1www.wsa.com

WSAudiology Federal Communication Commission Equipment Authorization Division, Application Processing Branch 2026-06-03 7435 Oakland Mills Road Columbia, MD 21048 TO WHOM IT MAY CONCERN CONFIDENTIALITY REQUEST for Certification Service in USA Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the following product: FCC ID Model 2AXDT-RFM022 RFM022 For the product stated above, we request permanent confidentiality for exhibits which contain Operational Description, Block Diagram, Schematics, Parts Lists orTune Up Information. The above exhibits contain our trade secrets and proprietary Information that could be of benefit to our competitors. Sincerely, Erika Radick Head of Wireless Platform Sivantos GmbH Henri-Dunant-Str. 100 91058 Erlangen Germany [email protected] Head of QA (System) Sivantos GmbH Henri-Dunant-Str. 100 91058 Erlangen Germany [email protected] WSAUD A/S Nym0llevej 6 3540 Lynge Den mark Rhone: +45 44 35 56 00 www.wsa.com Page 1 of 1

WSAudiology Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Certification and Engineering Bureau Innovation, Science and Economic Development Canada Spectrum Engineering Branch 3701 Carling Avenue, Building 94 Ottawa, Ontario K2H 8S2 Name Department Rhone E-mail Website Richard Rose R&D PSA WLS L DE ERL Henri-Dunant-Strasse 100 91058 Erlangen, Germany +49 9131 308 3727 [email protected] www.wsa.com Date 2026-07-02 Subject: FCC / ISED Modular Approval Statement FCC Certification Number: 2AXDT-RFM022 IC Certification Number: 26428-RFM022 PMN: RF Module 22 Model Name/HVIN: RFM022 TO WHOM IT MAY CONCERN Pursuant to Paragraphs RSP-100, Issue 12 and CFR § 15.212, we herewith declare for our module: Modular approval requirement YesNo (a) The radio elements shall have the radio frequency circuitry shielded. Physical/discrete and tuning capacitors may be located external to the shield but shall be on the module assembly. X The model above referred does not have its own RF shielding. This limitation is one of the reasons why Sivantos requests only the Limited Modular Approval. The module is to be used exclusively by Sivantos, integrated under controlled conditions and always assuring the total emission and immunity are within specifications. The module is a fully integrated radio module for short ränge wireless data exchange, including radio circuitry on board and is intended for Sivantos wireless hearing aids only. Therefore, the module cannot be used directly by end users. The behavior of the wireless module is locked by design and can only be changed by Sivantos, so the compliance of the end product is always ensured. (b) If the module has modulation/data input(s), they shall be buffered in order to ensure that the module will comply with the requirements set out in the applicable Radio Standards Specification (RSS) and Part 15 under conditions of excessive data rates or over-modulation. X (c) The module shall have its own power supply regulation on the module itself. This is to ensure that the module will comply with the requirements set out in the applicable Standard regardless of the design of the power supplying circuitry in the host product that houses the module. X The wireless parts of the radio module share the power supply with other digital parts, like Digital ASIC. As producer and integrator of the radio module, it is assured that the power supplied will not affect its correct functioning. We apply for a Limited Modular Approval also due to this constraint. WSAUDA/S Nym0llevej 6 3540 Lynge Denmark Phone:+45 44 35 56 00 www.wsa.com Page 1 of 2 Restricted WSAudiology If you have any questions, please feel free to contact us at the address shown below. (d) The module shall comply with the provisions for external power amplifiers and antennas detailed in the applicable RSS and rule part. The equipment certification application shall contain: i. a detailed description of the configuration of highest antenna gain for each type of transmitting antenna for licence-exempt modules; ii. the maximum transmitting antenna gain for licence modules; and iü. a detailed description of the configuration of lowest antenna gain for each type of receiving antenna for Dynamic Frequency Selection (DFS) modules with removable antenna(s). X (e) The module shall be tested for compliance with the applicable Standard in a stand- alone configuration (i.e., the module shall not be inside another product during testing). X The modular transmitter has been tested integrated on a typical host, a hearing aid instrument that best represents all the future hosts where the module will be used by WS Audiology. Due to the size limitations of the hearing aid Instruments, the radio module is in the same PCB of the host making impossible to test it on a standalone configuration. (f) The module complies or will comply with applicable RSS-102 exposure requirements and any applicable FCC RF exposure requirement (§§1.1307(b), 1.1310, 2.1091, and 2.1093) in its intended configuration/integration in a host. X (g) The module must be labeled with its permanently affixed label (indicating ISED certification number, HVIN and FCC identifier), or use an electronic display (see KDB Publication 784748 and RSP-100, section 5). X The size of the module is too small for the regulatory FCC/ISED label in its short form to be placed any, which are therefore displayed in the user manual and on the package. (h) The module must comply with all specific rules applicable to the transmitter, including all the conditions provided in the Integration instructions by the grantee. X Only applicable for FCC certification: (i) The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per §§ 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b). For further information concerning antenna connectors see: DA-00-1087. X Best regards, Erika Radick Head of Wireless Platform [email protected] • Udo Reitinger Head of QA (System) [email protected] WSAUD A/S Nym0llevej 6 3540 Lynge Denmark Rhone:+45 44 35 56 00 www.wsa.com Page 2 of 2 Restricted

2026-06-02 │ R&D PFD WLS C │ W. Pirzer Restricted Integrated Module RFM022 – Host: D12+ IF MC R FCC ID: 2AXDT-RFM022 IC: 26428-RFM022 e Top-view: Bottom-view: 2026-06-02 │ R&D PFD WLS C │ W. Pirzer Restricted Hearing Aid with exploded enclosures: Side views: Antenna 2026-06-02 │ R&D PFD WLS C │ W. Pirzer Restricted

Annex A101 - Photographs No. 1-9373-25-02-01_TR1-A101-R02 April 27, 2026 DescriptionExternal photos of EUT This document is electronically signed and valid without handwritten signature. Public keys for verifcation of the electronic signatures can be requested at the testing laboratory. Michael Dorongovski Lab Manager/ Telecommunication Certification Body (USA/CAN/ JPN) Regulatory Services Radio / Assessment &Approvals authorized by cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9373-25-02-01_TR1-A101-R02 Page 1 of 5 Photo 1 Photo 2 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9373-25-02-01_TR1-A101-R02 Page 2 of 5 Photo 3 Photo 4 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9373-25-02-01_TR1-A101-R02 Page 3 of 5 Photo 5 Photo 6 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9373-25-02-01_TR1-A101-R02 Page 4 of 5 Document History End of document ReleaseApplied changesRelease date R01initial releaseApril 10, 2026 R02New photosApril 27, 2026 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9373-25-02-01_TR1-A101-R02 Page 5 of 5

WSAi To whom it may concern Manufacturer's Statement FCC ID location justification FCC ID: 2AXDT-RFM022 2026-06-03 We, the undersigned, hereby submit the justification for placing the FCC-ID in the associated User Manual for the Hearing Aids containing the module with the above-mentioned FCC-ID. According to KDB Publication 784748 D01, when the device is so small, or for such use that it is impracticable to label with a font size that is four points or larger (and the device does not utilize electronic labeling), then the FCC-ID shall be placed in the User Manual and the device packaging or on a removable label attached to the device. Hearing Aids having the above-mentioned FCC-ID are so small and considering the dimensions of the equipment and the label area, it is impracticable to label FCC-ID with a font size required on the devices. Therefore, the FCC-ID label is placed in the User Manual of the end product. Instruction for module integration regarding the FCC-ID labelling is included in the Integration manual. If you have any questions, feel free to contact us at the address shown above. Yours sincerely, Erika Radick Head of Wireless Platform [email protected] Udo Reitinger Head of QA (System) [email protected] WSAUD A/S Nymallevej 6 3540 Lynge Denmark Rhone: +45 44 35 56 00 www.wsa.com

2026-06-02 │ R&D PSA WLS L DE ERL │ W. Pirzer Restricted Module pictures RFM022 mounted on a Host: D12+ IF MC R FCC ID: 2AXDT-RFM022 IC: 26428-RFM022 Text Host pictures with implemented RF-Module RFM022: Top view: Bottom view: RFM022 RF-Module 22 2026-06-02 │ R&D PSA WLS L DE ERL │ W. Pirzer Restricted RF-Module RFM022:

© cetecom advanced GmbH Page 1 of 4 RF Exposure Evaluation according to KDB 447498 D01 v06 Report identification number: 1-9373-25-01-04_TR1-R03_SAR_FCC Certification numbers and labeling requirements FCC ID 2AXDT-RFM022 This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorised: Alexander Hnatovskiy Eric Tuettmann Lab Manager Testing Manager Radio Labs Radio Labs Report no.: 1-9373-25-01-04_TR1-R03 © cetecom advanced GmbH Page 2 of 4 1. SAR test exclusion (KDB 447498 D01 General RF Exposure Guidance v06) 4.3.1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops and tablets, etc. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. b) For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following (also illustrated in Appendix B): 1) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·(f (MHz) /150)]} mW, for 100 MHz to 1500 MHz 2) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·10]} mW, for > 1500 MHz and ≤ 6 GHz c) For frequencies below 100 MHz, the following may be considered for SAR test exclusion (also illustrated in Appendix C): 1) For test separation distances > 50 mm and < 200 mm, the power threshold at the corresponding test separation distance at 100 MHz in step b) is multiplied by [1 + log(100/f (MHz) )] 2) For test separation distances ≤ 50 mm, the power threshold determined by the equation in c) 1) for 50 mm and 100 MHz is multiplied by ½ 3) SAR measurement procedures are not established below 100 MHz. Report no.: 1-9373-25-01-04_TR1-R03 © cetecom advanced GmbH Page 3 of 4 The following table from KDB 447498 D01 gives an fast overview of the applicable limits: Report no.: 1-9373-25-01-04_TR1-R03 © cetecom advanced GmbH Page 4 of 4 2. EUT technologies Technologies: Max. power: [dBm] Antenna gain max.: [dBi] * Max EIRP for RF Exposure # conducted EIRP NFMI 3.27 MHz -/- -12.76 < 0.0 -12.76 dBm A BT LE 2450 MHz 4.1 2.9 N/A 6.0 dBm B *) worst case of all antenna types, channels and modulations (overrated) Referenced Documents: # Information from External Annexes: Kind of information used: A Customer declaration -/- Max p Diss (53 uW) B 1-9373-25-01-03_TR1-R01 cetecom advanced GmbH test report Pg 19, 23 (4.1 dBm cond, -1.2 dBi Gain) 3. Exclusion for EUT technologies according clause 4.3.1.c)2): Standalone SAR test exclusion below 100 MHz at test separation distances ≤ 50mm frequency Powerlimit [MHz] [mW] [dBm] [mW] NFMI 3.27 3 474.34 589.48 -12.76 0.1 yes 0.01% Thres- hold 1-g;10-g Thres- hold 100MHz,50mm P max-declared Exclusion Share of Limit % technology 4. Exclusion for EUT technologies according clause 4.3.1.a): Standalone SAR test exclusion below 100 MHz at test separation distances ≤ 50mm frequency d separation Powerlimit [MHz] [mm] [mW] [dBm] [mW] BTLE 2450.00 5 3 9.58 4.10 2.57 yes 26.82% Thres- hold 1-g P max-declared Exclusion Share of Limit % technology 5. Collocation: NFMI 0.01% BT LE 26.82% Technology Share of Limit Sum 26.83% 6. Conclusion This prediction demonstrates the following: The power density levels for FCC at a distance of 0 mm are below the maximum levels allowed by regulations. Conclusion: RF exposure evaluation is not required.

WS Audiology Internal Document - Confidential Restricted Antenna Datasheet – D12+ IF MC R (Signia) including RF-Module RFM022 Information Antenna Type PCB Loop Antenna Frequency in MHz 2402 2440 2480 Modulation Type CW CW CW Conducted Power in dBm -2.4 -0.2 -2.6 EIRP in dBm 1.3 1.2 -3.8 Gain in dBi 3.7 1.4 -1.2 Where Gain = EIRP – Conducted Power, CW = Continuous Wave Antenna Location The BLE Antenna is routed on the frame of the hearing aid as shown in the photo below: Antenna WS Audiology Internal Document - Confidential Restricted Antenna Radiation Pattern Orientation of Device under test: 2402 MHz Y Z X WS Audiology Internal Document - Confidential Restricted 2440 MHz 2480 MHz
