2AXOJ-R1Payment Card Reader

Power Charging Interface Product DetailsMain SpecificationsSafety Alert Certificate Warning CPU Memory BT NFC 13.56MHz BT3.0 ＆ BLE4.2 4M flash , 128K RAM 32-bit RISC Core（ARMv7-M） Magnetic Card Reader Track 1/2/3 ISO7816 IC Card Reader Battery 3.7V,550mAh 1.NFC Recognition Area: to recognize NFC card 2.Indicators: indicating terminal working status 3.Power: long press to power on/off; short press to activate or shut down the screen 4.IC Card Slot IC: to swipe IC card 5.Magnetic Card Reader: to swipe magnetic Card 6.Charging Interface: to insert micro USB 5 pin plug of charger · Do not place the terminal in extremely hot or cold conditions. · Do not place terminal together with computer disc, credit card, travel card or any other magnetic items; otherwise, the information stored in magnetic cards will be affected. · Do not place the terminal in fire. · Do not disassemble the terminal or any accessories by yourself. · Please use a moist and anti-static cloth to clean the terminal screen. · Warning: Please replace the batteries with the same type and rating to avoid battery explosion. · Do not expose the battery in strong direct sunlight, near heat sources or any similar conditions. · Please recycle or dispose of old, weak, or worn batteries in accordance with local, regional, or national law or regulation. · Do not use detergent with chemical or scrub particle which may damage the terminal body or screen. · Please keep the terminal in a safe place and avoid crush or squeeze that may cause a damage on screen or camera. · When the user use the third party’s root tool or update with unauthorized operation system, it will bring risk to the normal operation system. FCC Statement Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: The device has been evaluated to meet general RF exposure requirment. The device can be used in portable exposure condition without restriction. NFC Recognition Area Indicators Magnetic Card Reader IC Card Slot IC ISED RSS Warning: This device complies with Innovation, Science and Economic Development Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'ISED applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1)l'appareil ne doit pas produire de brouillage, et (2)l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. ISED RF exposure statement: This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment.The device has been evaluated to meet general RF exposure requirement. Le matériel est conforme aux limites de dose d'exposition aux rayonnements énoncés pour fac un autre environnement.ce dispositif a été évalué à satisfaire l'exigence générale de l'exposition aux rf. QUICK START GUIDE Wiseasy R1 1. Install the WPOS APP on the terminal product connected to R1. 2. Bluetooth connect: open the APP and click ”Bluetooth” on the main interface to the Bluetooth connection, and click “Refresh” to refresh the list of Bluetooth device. 3. Then click the name of the device to be connected in the list to connect. After the connection is successful, the device name will be displayed. 4. After the connection is successful, the blue light on the far right of the device is on. Bluetooth Disconnect 1. Click "DeviceName" and a dialog box will pop up. Click "OK" and the Bluetooth connection will disconnect. 2. After the connection is disconnected, the blue light on the far right is blinking. Transaction 1. Click "Pruchase" on the main interface. If there is no Bluetooth connection, it will jump to the Bluetooth connection interface; otherwise, it will enter the input amount interface。After entering the amount, click "OK" to enter the card reading interface. 2. Hold your bank card close to the card reader. 3. Online trading, showing trading results. Click "OK" to return to the main interface. Bluetooth Connection

Company: Beijing Wiseasy Technology CO., Ltd. Address: 7th Floor, Bl ock B, Wangxin Mansion,No.28 Xi aoyun Road, Chaoyang District, Beijing, China Tel: 010-86398333 FAX: 010-56301689 Email: [email protected] FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022-07-26 Attestation Letter Dear Sir or Madam: The chip MH8200H installed in our product Payment Card Reader (model name: R1 FCC ID: 2AXOJ-R1), which only support BT in BDR mode and BLE 1M for this product. Please contact me if there is need for any additional clarification or information. Best Regards, Sincerely Yours, Signature: Typed or Printed Name: Chao Xing Title : Senior Project Director

QA-FR-170-B Beijing Wiseasy Technology CO., Ltd. Address: 7th Floor, Block B, Wangxin Mansion,No.28 Xiaoyun Road, Chaoyang District, Beijing, China Tel: 010-86398333 FAX: 010-56301689 Email: [email protected] FCC Authorization Date: 2022-07-26 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , Beijing Wiseasy Technology CO., Ltd., Hereby authorizes China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Printed Name: Chao Xing Title : Senior Project Director

QA-FR-171-A Beijing Wiseasy Technology CO., Ltd. Address: 7th Floor, Block B, Wangxin Mansion,No.28 Xiaoyun Road, Chaoyang District, Beijing, China Tel: 010-86398333 FAX: 010-56301689 Email: [email protected] FCC Confidential Authorization Date: 2022-07-26 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2AXOJ-R1 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, (Beijing Wiseasy Technology CO., Ltd.) hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Chao Xing Title : Senior Project Director

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Port

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS NFC Antenna Chip Chip BT Antenna

China Certification ICT Co., Ltd (Dongguan) Report No.: CR21120035-00B Page 48 of 49 5. RF EXPOSURE EVALUATION 5.1 SAR Exclusion 5.1.1 Applicable Standard FCC §15.247 (i) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See §1.1307(b)(1) of this chapter. 5.1.2 Procedure According to KDB447498 D01 General RF Exposure Guidance v06: The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 5.1.3 Measurement Result Radio Frequency (MHz) Conducted Output Power Including Tolerance Distance (mm) Calculated value Threshold (1-g) SAR Test Exclusion (dBm) (mW) BT 2402-2480 4 2.51 5 0.79 3 Yes BLE 2402-2480 4 2.51 5 0.79 3 Yes Result: Compliance. The stand-alone SAR test is not necessary.

TEST REPORT Applicant: Beijing Wiseasy Technology CO.,Ltd. Address: 7th Floor, Block B, Wangxin Mansion,No.28 Xiaoyun Road,Chaoyang District,100027,Beijing,China. FCC ID: 2AXOJ-R1 IC: 28320-R1 HVIN: P2 Product Name: Payment Card Reader Model Number: R1 Standard(s): 47 CFR Part 15, Subpart C(15.247) RSS-247 Issue 2, February 2017 RSS-Gen, Issue 5, February 2021 Amendment 2 ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR21120035-00B Date Of Issue: 2022-09-02 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR21120035-00B Page 2 of 49 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR21120035-00B Page 3 of 49 CONTENTS TEST FACILITY .......................................................................................................................................... 2 DECLARATIONS .......................................................................................................................................... 2 1. GENERAL INFORMATION .................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 5 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 6 1.2.2 Support Equipment List and Details .............................................................................................................. 6 1.2.3 Support Cable List and Details ...................................................................................................................... 6 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 7 1.3 MEASUREMENT UNCERTAINTY .......................................................................................................... 8 2. SUMMARY OF TEST RESULTS ............................................................................................ 9 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 10 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 10 3.1.1 Applicable Standard ..................................................................................................................................... 10 3.1.2 EUT Setup .................................................................................................................................................... 11 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 12 3.1.4 Test Procedure ............................................................................................................................................. 12 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 12 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 13 3.2.1 Applicable Standard ..................................................................................................................................... 13 3.2.2 EUT Setup .................................................................................................................................................... 13 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 14 3.2.4 Test Procedure ............................................................................................................................................. 14 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 15 3.3 20 DB BANDWIDTH ............................................................................................................................. 16 3.3.1 Applicable Standard ..................................................................................................................…

Text truncated - open the document above for the full version.

R1 Antenna Test Report Model: R1 antenna Antenna band: BT 2400-2500MHz Test Equipment: Agilent E5071C & Satimo test Antenna position: BT passive test result: Frequency Efficiency Gain (dBi) Frequency Efficiency Gain (dBi) 2.4GHz 31.40% 1.33 2.5GHz 35.30% 3.5 2.41GHz 31.30% 2.21 2.51GHz 36.00% 3.63 2.42GHz 32.30% 2.42 2.52GHz 40.80% 3.66 2.43GHz 34.40% 3.25 2.53GHz 41.10% 3.78 2.44GHz 31.40% 1.32 2.54GHz 41.30% 3.76 2.45GHz 32.60% 2.65 2.55GHz 41.10% 3.53 2.46GHz 32.90% 2.73 2.56GHz 41.50% 3.59 2.47GHz 34.30% 3.14 2.57GHz 45.50% 3.89 2.48GHz 34.80% 3.28 2.58GHz 45.50% 3.85 2.49GHz 33.20% 3.04 2.59GHz 47.90% 3.94 BT return loss BT smith original BT standing wave ratio E1 side E2 side H side E1 side

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions Front View Conducted Emissions Side View Radiated Emission Below 1GHz View Radiated Emission Above 1GHz View
