PETRACKR ® Owner’s Booklet1 Veterinary Blood Glucose Monitoring System for Cats and Dogs Owner’s Booklet 2 PETRACKR ® Owner’s BookletPETRACKR ® Owner’s Booklet 3 Thanks for choosing PETRACKR ® ! The PETRACKR ® Veterinary Blood Glucose Monitoring System is one of the latest product innovations from Universal Biosensors. Every PETRACKR ® Analyzer is designed to make it easy to test your patients/pets blood glucose and help you manage your pet’s diabetes. This Owner’s Booklet offers a complete explanation of how to use your new analyzer and testing supplies. It reviews the important steps of testing your pet’s blood glucose level. Please keep your Owner’s Booklet in a safe place; you may want to refer to it in the future. Compatible wireless devices For information on which wireless devices are compatible with your PETRACKR ® Analyzer, and where/how to download the PETRACKR ® mobile app on your compatible wireless device, visit www.universalbiosensors.com/products/petrackr/ or scan the QR code below. 4 PETRACKR ® Owner’s BookletPETRACKR ® Owner’s Booklet 5 Analyzer symbols and icons Low Battery Battery Empty Bluetooth ® On Error Above Range (blood glucose result) In Range (blood glucose result) Below Range (blood glucose result) Morning Afternoon Evening Night Sound On Sound Off Meal Insulin blood glucose result below 20 mg/dL (1.1 mmol/L) blood glucose result above 600 mg/dL (33.3 mmol/L) Control solution result High In Range Low LO HI LOT SN REF IVD STERILE R Other symbols and icons Cautions and Warnings Direct current Consult Instructions for Use Manufacturer Date of manufacture Lot Number Serial Number Catalog Number Storage Temperature Limits In Vitro Diagnostic Device Do Not Re-use Sterilized by irradiation Not for general waste Use By Date (TSYFNSXXZKܪHNJSYKTWSYJXYX 6 PETRACKR ® Owner’s BookletPETRACKR ® Owner’s Booklet 7 Before you begin Before using this product to test your patient’s/pet’s blood glucose, carefully read this Owner’s Booklet, and the inserts that come with the PETRACKR ® Blood Glucose Test Strips, PETRACKR ® Mid Control Solution and the PETRACKR ® Lancing Device. IMPORTANT SAFETY INSTRUCTIONS: • The lancing device is for single patient/pet use only. DO NOT share with additional patients/pets. DO NOT use on multiple cats or dogs. • After use and exposure to blood, all parts of this kit are considered biohazardous. A used kit may potentially transmit infectious diseases even after you have performed cleaning and disinfection. WARNING: • Use of this device on multiple cats and dogs may lead to transmission of infectious disease or other bloodborne pathogens. • For testing on cats and dogs only. Not for human use. Table of Contents 1. Getting to know your system 11 2. Setting up your system 15 Setting up your analyzer 15 First time setup 16 &IOZXYFSFQ^_JWXJYYNSLXFKYJWܪWXYYNRJXJYZU Bluetooth ® 31 3. Conduct a test 35 Test your patient’s/pet’s blood glucose 35 .SYJWUWJYNSLZSJ]UJHYJIYJXYWJXZQYX   9JXY\NYMHTSYWTQXTQZYNTS 4. Meal and insulin dose tagging 55 Add meal from main menu 55 &IINSXZQNSITXJKWTRRFNSRJSZ Add meal or insulin dose from test result 60 5. Review past results and averages 62 Review your patient’s/pet’s past results 62 View your patient’s/pet’s averages 65 )F^FSI)F^XZRRFW^ 6. Care and maintenance 70 8YTWNSL^TZWX^XYJR (QJFSNSLFSIINXNSKJHYNTS &SFQ^_JWINXUTXFQ 7JUQFHNSLYMJGFYYJWNJX 7. Troubleshooting 76 *WWTWFSITYMJWRJXXFLJX 8. Reviewing the accuracy of your system 85 (TRUFWNSLFSFQ^_JWWJXZQYXYTQFGTWFYTW^WJXZQYX 9. References 86 9JHMSNHFQXUJHNܪHFYNTSX 7JLZQFYTW^ 8FKJY^3TYNHJX 10. Index 89 8 PETRACKR ® Owner’s BookletPETRACKR ® Owner’s Booklet 9 Intended use The PETRACKR ® Veterinary Blood Glucose Monitoring System is intended to be used for the quantitative measurement of glucose (sugar) in fresh capillary whole blood samples drawn from the pinna or paw pad samples. The system is intended to be used by a single pet and should not be shared. The PETRACKR ® Veterinary Blood Glucose Monitoring System is intended for in vitro diagnostic use for blood glucose monitoring of cats and dogs as part of diabetes management, to be used by veterinary professionals and pet owners. The PETRACKR ® Veterinary Blood Glucose Monitoring System is not for use on critically ill patients/pets, patients/pets in shock, dehydrated patients/pets or hyperosmolar pets. Te s t p r i n c i p l e Glucose in the blood sample mixes with the enzyme FAD - GDH (8JJUFLJ) in the test strip and a small electric current is produced. The strength of this current changes with the amount of glucose in the blood sample. Your analyzer measures the current and calculates the blood glucose level. It then displays the blood glucose result and stores it in the analyzer memory. Bluetooth ® wireless technology Bluetooth ® wireless technology is used by some smartphones and many other devices. Your PETRACKR ® Analyzer uses Bluetooth ® wireless technology to pair and to send your patients/pets glucose results to compatible wireless devices. The PETRACKR ® Analyzer is designed to work with the PETRACKR ® Analyzer Mobile App. Visit www.universalbiosensors.com/products/petrackr/ for information on which wireless devices are compatible with your PETRACKR ® Analyzer, and where/how to download the PETRACKR ® Analyzer Mobile App on your compatible wireless device. When using the PETRACKR ® System, we suggest you pair your PETRACKR ® Analyzer with a compatible wireless device and track your results. See page 31 for pairing instructions. If you experience analyzer interference problems, try moving your analyzer away from the source of the interference. You can also move the electronic device or its antenna to another location to solve the problem. 10 PETRACKR ® Owner’s BookletPETRACKR ® Owner’s Booklet 11 These guidelines help ensure that your analyzer will not affect the operation of other nearby electronic devices. Additionally, …

Text truncated - open the document above for the full version.

Universal Biosensors 1 Corporate Avenue, Rowville Victoria, Australia 3178 Date: 03/14/23 Federal Communications Com mission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXRY-UBSPTKR Attestation Statements Part 2.911(d)(5)(ii) Filing To whom it may concern, Universal Biosensors certifies that, as of the date of the filing of the application, Universal Biosensors is not identified on the “List of Equipment and Services Covered by Section 2 of the Secure Networks Act,” as an entity producing “covered” equipment. Sincerely, Signature: Nosheen Hameed Regulatory and Clinical Manager

Universal Biosensors 1 Corporate Avenue, Rowville Victoria, Australia 3178 Date: 03/14/23 Federal Communications Com mission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXRY-UBSPTKR US Agent – Attestation Statement / Part 2.911(d)(7) Universal Biosensors certifies, that as of 03/03/2023, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AXRY-UBSPTKR. Universal Biosensors accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Universal Biosensors for FCC ID: 2AXRY-UBSPTKR. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: Universal Biosensors Designated Agent: FCC US Agent, LLC Company Representative: Nosheen Hameed Designated Agent Representative: Tim Payne Signature: Signature:

Universal Biosensors 1 Corporate Avenue, Rowville Victoria, Australia 3178 Date: 03/14/23 Federal Communications Com mission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXRY-UBSPTKR Attestation Statements Part 2.911(d)(5)(i) Filing To whom it may concern, Universal Biosensors, certifies that the equipment is seeking authorization is not on the “List of Equipment and Services Covered by Section 2 of the Secure Networks Act,” which it is prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: Nosheen Hameed Regulatory and Clinical Manager

Universal Biosensors 1 Corporate Avenue, Rowville Victoria, Australia 3178 Date: 03/14/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXRY-UBSPTKR Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of the information accompanying this application as outlined below: ☒Block Diagram ☐Tune-Up Information ☒Operational Description ☐Security Information ☒Schematics ☐Software Defined Radio (SDR) Information ☒Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature: Nosheen Hameed Regulatory and Clinical Manager

Universal Biosensors 1 Corporate Avenue, Rowville Victoria, Australia 3178 Unaliwear, Inc. 3410 Cherry Lane Austin, TX, 78703 Date: 06/03/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXRY-UBSPTKR E-label Declaration We, Universal Biosensors, hereby declare that the E-label meets the following FCC requirements: 1. The FCC ID can be found in the APP through the following steps: a) Go to the Settings screen b) Select the Meter Info tab c) Once in the Meter info tab, scroll to view the FCC ID is on the screen. 2. The product does not require the use of special access codes or accessories (e.g. SIM/USIM cards) to access the FCC ID. 3. The user manual shows the FCC ID and directs the user where to find the FCC ID information and the FCC ID is displayed electronically in manner that is clearly legible without the aid of magnification. 4. Both regulatory information and dedicatedexclusive application(s) or script(s) aresecured and implemented in a factory-set unalterable format. The regulatory information is capable of being retrieved and is played locally, and under the control of the end user in possession of the product. The method is secure, such that the application or scrip ensures that the regulatory information correctly displayed. The FCC regulatory information will not change for any reasons, like system upgrade, etc, also that the end user cannot modify it. 5. There is a physical label on the product packaging box of the product, as show below: Sincerely, Signature: Nosheen Hameed Regulatory and Clinical Manager

Universal Biosensors 1 Corporate Avenue, Rowville Victoria, Australia 3178 Date: 03/14/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXRY-UBSPTKR Declaration of Authorization To whom it may concern, I, the undersigned, hereby authorize, Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) on our behalf shall have the same effects as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Dr ug Abuse Act of 1988, 21 U.S.C 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Signature: Nosheen Hameed Regulatory and Clinical Manager

Reference No.: WTX23X02031700W001 Page 2 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX23X02031700W001 Page 3 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX23X02031700W001 Page 4 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6

Reference No.: WTX23X02031700W001 Page 1 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format E-Label Packaging Label Specifications: Users must be able to access the regulatory information without requiring special access codes or permissions, and in all cases the information must be accessible in no more than three steps from a product’s main or home menu. Products must not require special accessories or supplemental plug-ins (e.g., the installation of a SIM/USIM card) to access the information. The FCC ID or other information must be displayed electronically in a manner that is clearly legible without the aid of magnification. Both regulatory information and dedicated exclusive application(s) or script(s) must be secured and implemented in a factory-set-unalterable format. When e-labeling is used, a physical temporary label is also required on the product, or a label on the packaging, at the time of importation, marketing, and sales. The physical label can be a summary version of the required regulatory information, such that the product can be identified as complying with the FCC’s equipment authorization requirements, etc. The way to view the e-Label: 1. Go to the Settings screen; 2. Select the Meter Info tab; 3. Once in the Meter info tab, scroll to view the FCC ID is on the screen. Proposed Label Location on EUT FCC ID Label Location E-label in APP Packaging Label Location

Reference No.: WTX23X02031700W001 Page 5 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTX23X02031700W001 Page 6 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT Housing and Board View 3 Solder Board-Component View 1 Reference No.: WTX23X02031700W001 Page 7 of 9 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Antenna View

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Universal Biosensors Address of applicant: 1 Corporate Avenue, Rowville, Victoria 3178, Australia Manufacturer: Universal Biosensors Address of manufacturer: 1 Corporate Avenue, Rowville, Victoria 3178, Australia General Description of EUT: Product Name: PETRACKR Trade Name / Model No.: A0381 Adding Model(s): / Rated Voltage: Battery:DC3V Power Adapter: / FCC ID: 2AXRY-UBSPTKR Equipment Type: Portable device Technical Characteristics of EUT: Bluetooth Bluetooth Version: V5.0 (BLE mode) Frequency Range: 2402-2480MHz RF Output Power: 1Mbps: -2.76dBm (Conducted) 2Mbps: -2.76dBm (Conducted) Data Rate: 1Mbps, 2Mbps Modulation: GFSK Quantity of Channels: 40 Channel Separation: 2MHz Type of Antenna: PCB Antenna Antenna Gain: 2.89dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) Bluetooth 2402 -2.76 2.89 100 -2.00 -1.26 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 B 0.5 -1.26 0.75 2.788 0.27 Pass Note: 1. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail -- -- -- -- -- -- Result: Pass
