2AXYO-TBUDWAllSafe Gateway

TBUDW is a Wi-Fi, and Bluetooth Low Energy (BLE) 5.0 gateway developed for the contact tracing and social distancing solution. It collects and transfers the interaction data from the BLE tags to the cloud. This device is powered using a 5V / 3A USB C-type power adapter also comes with a Gigabit Ethernet. TBUDW 2 Table of Contents 1. Features ................................................................................................................................................................ 3 2. Specifications ........................................................................................................................................................ 3 3. Device Dimensions .............................................................................................................................................. 4 4. Use Case ............................................................................................................................................................... 5 5. Warning ................................................................................................................................................................. 6 6. Ordering Information ............................................................................................................................................ 6 TBUDW 3 1. Features  Wi-Fi / BLE 5.0 Gateway providing ubiquitous connectivity to BLE devices  Dual-band 2.4GHz and 5GHz wireless LAN  Transfer the tag data to local Wi-Fi or ethernet network  Helps to monitor the status and real time location of the BLE tags  Support 802.11 b/g/n/ac modes  Unit powered by 5V/3A USB-C type adapter  Gigabit ethernet  Automatically uploads contact tracing records 2. Specifications Electrical Symbol Min. Typ. Max. Unit Remarks Input voltage Vin 5 V USB-C type Input current 3 A Bluetooth Min. Typ. Max. Unit Remarks Frequency range 2402 2480 MHz TX power 5 dBm Receiver sensitivity -97 dBm TX current 9.6 mA @5 dBm RX current 6.9 mA Mechanical Min. Typ. Max. Unit Remarks Dimensions 92.00×67.00×27.00 mm L x W x H Dimensions 3.62×2.64×1.06 inch L x W x H Net weight 177.00 g Net weight 6.24 ounce Environmental Min. Typ. Max. Unit Remarks Operating temperature 0 50 ºC TBUDW 4 3. Device Dimensions Case material: Aluminium alloy All dimensions are in mm TBUDW 5 4. Use Case TBUDW 6 5. Warning 1. To prevent the device from any defect, please handle and store it with care. - Do not drop or give shock. - Do not store in very humid location or at extreme temperature. - Do not open or disassemble the product. 2. Avoid input voltage exceeds the maximum rating, which will cause damage to the circuit and result in malfunction. 3. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 4. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 5. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 6. To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus. 6. Ordering Information Product Code Product Name Communication Voltage Rating TBUDW Wi-Fi / BLE Gateway BLE 5.0 / Wi-Fi 5V FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. ISED Statement ‐ English: This device complies with Industry Canada license‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, a nd (2) This device must accept any interference, including interference that may cause undesired operation of the device. The digital apparatus complies with Canadian CAN ICES‐3 (B)/NMB‐3(B). ‐ French: Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes: (1) l'appareil n…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021/2/18> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AXYO-TBUDW TBUDW For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Dennis Kwan/CEO Company: TraceSafe Technologies Inc. Address: 401 Ryland Street, Suite 200-A, Reno, Nevada 89502 USA Phone: (949) 397-9330 Fax: (949) 397-9330 E-Mail: [email protected]

TraceSafe Technologies Inc. 401 Ryland Street, Suite 200-A, Reno, Nevada 89502 USA Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021/2/18 To whom it may concern: We, TraceSafe Technologies Inc. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AXYO-TBUDW including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Dennis Kwan/CEO Company: TraceSafe Technologies Inc. Address: 401 Ryland Street, Suite 200-A, Reno, Nevada 89502 USA Phone: (949) 397-9330 Fax: (949) 397-9330 E-Mail: [email protected]

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW 1. EXTERIOR PHOTOGRAPHS Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Fig.9 Fig.10

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 1 LABEL AND LOCATION (Size: L3.0cm x 3.0cm) Material: Tagboard Glue: adhesive sticker Font color: white Label color: Black AllSafe Gateway HVIN: TBUDW Contains FCC ID: 2ABCB-RPI4B Contains IC: 20953-RPI4B FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Label Location

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW 1. INTERIOR PHOTOGRAPHS Fig.1 Fig.2 BT Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Fig.9 Fig.10

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD FCC ID: 2AXYO-TBUDW This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 11 Maximum Permissible Exposure Report 1. Product Information EUT : AllSafe Gateway Test Model : TBUDW Power Supply : For AC Adapter: Input: 100-240V, 50/60Hz, 0.5A Max Output: DC 5V, 3A Hardware Version : v1.3 Software Version : v6.0.24 Bluetooth : Frequency Range : 2402MHz ~ 2480MHz Channel Number : 79 channels for Bluetooth V5.0(BDR/EDR) 40 channels for Bluetooth V5.0(BT LE) Channel Spacing : 1MHz for Bluetooth V5.0 (BDR/EDR) 2MHz for Bluetooth V5.0(BT LE) Modulation Type : GFSK, π/4-DQPSK, 8-DPSK for Bluetooth V5.0 (BDR/EDR) GFSK for Bluetooth V5.0 (BT LE) Bluetooth Version : V5.0 WIFI(2.4G Band) : Frequency Range : 2412MHz-2462MHz Channel Spacing : 5MHz Channel Number : 11 channels for 20MHz bandwidth (2412~2462MHz) 7 channels for 40MHz bandwidth (2422~2452MHz) Modulation Type : IEEE 802.11b: DSSS (CCK,DQPSK,DBPSK); IEEE 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) WIFI 5GWLAN (U-NI-1) : Frequency Range : 5180MHz-5240MHz Channel Number : 4 channels for 20MHz bandwidth (5180-5240MHz) 2 channels for 40MHz bandwidth (5190~5230MHz) 1 channels for 80MHz bandwidth (5210MHz) Modulation Type : IEEE 802.11a/n/ac: OFDM (64QAM, 16QAM, QPSK, BPSK) WIFI 5GWLAN (U-NI-2A) : Frequency Range : 5260MHz-5320MHz Channel Number : 4 channels for 20MHz bandwidth (5260-5320MHz) 2 channels for 40MHz bandwidth (5270~5310MHz) 1 channels for 80MHz bandwidth (5290MHz) Modulation Type : IEEE 802.11a/n/ac: OFDM (64QAM, 16QAM, QPSK, BPSK) WIFI 5GWLAN (U-NI-2C) : Frequency Range : 5500MHz-5700MHz Channel Number : 11 channels for 20MHz bandwidth (5500-5700MHz) 5 channels for 40MHz bandwidth (5510~5670MHz) 1 channels for 80MHz bandwidth (5530MHz) Modulation Type : IEEE 802.11a/n/ac: OFDM (64QAM, 16QAM, QPSK, BPSK) SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD FCC ID: 2AXYO-TBUDW This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 11 WIFI 5GWLAN (U-NI-3) : Frequency Range : 5745MHz-5825MHz Channel Number : 5 channels for 20MHz bandwidth (5745-5825MHz) 2 channels for 40MHz bandwidth (5755~5795MHz) 1 channels for 80MHz bandwidth (5775MHz) Modulation Type : IEEE 802.11a/n/ac: OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Description : one Internal Antenna for WiFi and Bluetooth, and another External Antenna for Bluetooth(BT LE) ANT0 used for WIFI/Bluetooth TX/RX, 3.5dBi (Max.) for 2.4G and 2.3dBi (Max.) for 5GHz Band; ANT1 used for Bluetooth(BT LE) 2.0dBi (Max.) Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Device 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer evaluation method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz. FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD FCC ID: 2AXYO-TBUDW This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 11 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD FCC ID: 2AXYO-TBUDW This report shall not be reproduced except in full, without the wr…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 1 of 16 Appendix A RF Test Data for BLE V5.0(BDR/EDR) (Conducted Measurement) Product Name: AllSafe Gateway Trade Mark: TraceSafe Technologies Inc. Test Model(HVIN): TBUDW Environmental Conditions Temperature: 24.5C Relative Humidity: 54.3% ATM Pressure: 100.0 kPa Test Engineer: Ken He Supervised by: Li Huan A.1 Duty Cycle Test Mode Test Channel Ant Duty Cycle[%] Verdict BT LE 2440 Ant1 100 PASS #im grbble1hchnnav SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 2 of 16 A.2 Maximum Conducted Peak Output Power Mode Channel Conduct Peak Power[dBm] Limit [dBm] Verdict BT LE LCH 6.281 30 PASS BT LE MCH 6.991 30 PASS BT LE HCH 6.495 30 PASS Test Graphs LCH MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 3 of 16 HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 4 of 16 A.3 Maximum Power Spectral Density Mode Channel PSD [dBm/3KHz] Limit [dBm/3KHz] Verdict BT LE LCH -6.056 8 PASS BT LE MCH -1.538 8 PASS BT LE HCH -6.597 8 PASS Test Graphs LCH MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 5 of 16 HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 6 of 16 A.4 6dB Bandwidth Mode Channel 6dB Bandwidth [MHz] Limit [MHz] Verdict BT LE LCH 0.7047 ≥0.5 PASS BT LE MCH 0.6957 ≥0.5 PASS BT LE HCH 0.7345 ≥0.5 PASS Test Graphs LCH MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 7 of 16 HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 8 of 16 A.5 Occupied Bandwidth Mode Channel 99% Bandwidth [MHz] Limit [MHz] Verdict BT LE LCH 1.229 ≥0.5 PASS BT LE MCH 1.250 ≥0.5 PASS BT LE HCH 1.231 ≥0.5 PASS Test Graphs LCH MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 9 of 16 HCH A.6 RF Conducted Spurious Emissions SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 10 of 16 Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdict BT LE LCH 5.77 -37.419 -14.230 PASS BT LE MCH 6.57 -37.041 -13.430 PASS BT LE HCH 6.079 -36.398 -13.921 PASS BT LE_LCH_Graphs Pref/BT LE/LCH Puw/BT LE/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 11 of 16 BT LE_MCH_Graphs Pref/BT LE/MCH Puw/BT LE/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 12 of 16 BT LE_HCH_Graphs Pref/BT LE/HCH Puw/BT LE/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 13 of 16 A.7 Band-edge for RF Conducted Emissions Mode Channel Carrier Power[dBm] Max.Spurious Level [dBm] Limit [dBm] Verdict BT LE LCH 5.387 -50.003 -14.61 PASS BT LE HCH 5.791 -49.287 -14.21 PASS Test Graphs LCH HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 14 of 16 A.8 Restrict-band band-edge measurements Test Mode Test Chann el Ant Freq. Power [dBm] Gain Ground Factor E [dBuV/m] Detector Limit [dBuV/ m] Verdi ct BT LE 2402 Ant1 2310.0 -41.07 2.0 0 56.19 PEAK 74 PASS Ant1 2310.0 -53.45 2.0 0 43.81 AV 54 PASS Ant1 2390.0 -43.53 2.0 0 53.73 PEAK 74 PASS Ant1 2390.0 -53.01 2.0 0 44.25 AV 54 PASS 2480 Ant1 2483.5 -39.63 2.0 0 57.63 PEAK 74 PASS Ant1 2483.5 -51.13 2.0 0 46.13 AV 54 PASS Ant1 2500.0 -41.22 2.0 0 56.04 PEAK 74 PASS Ant1 2500.0 -52.34 2.0 0 44.92 AV 54 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 15 of 16 Restrict-band band-edge measurements_BT LE_2402_Ant1_PEAK Restrict-band band-edge measurements_BT LE_2402_Ant1_AV SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW Page 16 of 16 Restrict-band band-edge measurements_BT LE_2480_Ant1_PEAK Restrict-band band-edge measurements_BT LE_2480_Ant1_AV

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW Report No.: LCS210101043AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 33 FCC TEST REPORT For TraceSafe Technologies Inc. AllSafe Gateway Test Model: TBUDW Prepared for : TraceSafe Technologies Inc. Address : 401 Ryland Street, Suite 200-A, Reno, Nevada 89502 USA Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : January 19, 2021 Number of tested samples : 2 Sample number : 210101043A-1(Engineer sample), 210101043A-2(Normal sample) Serial number : Prototype Date of Test : January 19, 2021 ~ January 28, 2021 Date of Report : January 29, 2021 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW Report No.: LCS210101043AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 33 FCC TEST REPORT FCC CFR 47 PART 15 C (15.247) Report Reference No. ................. : LCS210101043AEA Date of Issue ................................... : January 29, 2021 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ........................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ........... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : TraceSafe Technologies Inc. Address ........................................... : 401 Ryland Street, Suite 200-A, Reno, Nevada 89502 USA Test Specification Standard.......................................... : FCC CFR 47 PART 15 C (15.247) Test Report Form No. ................... : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. ........................... : AllSafe Gateway Trade Mark .......................................................................................................................................... : TraceSafe Technologies Inc. Test Model .......................................................................................................................................... : TBUDW Ratings ................................................................................................................................................ : For AC Adapter: Input: 100-240V, 50/60Hz, 0.5A Max Output: DC 5V, 3A Result ........................................... : Positive Compiled by: Supervised by: Approved by: Vera Deng/ File administrators Jin Wang/ Technique principal Gavin Liang/ Manager SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW Report No.: LCS210101043AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 33 FCC -- TEST REPORT Test Model........................... : TBUDW EUT......................................... : AllSafe Gateway Applicant............................... : TraceSafe Technologies Inc. Address.................................. : 401 Ryland Street, Suite 200-A, Reno, Nevada 89502 USA Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Electronic Controls and Discharge Systems Pvt Ltd Address................................... : Plot No. 16A Garment Complex, Cochin Special Economic Zone Kakkanad, Kochi, Kerala. INDIA 682037 Telephone............................... : / Fax.......................................... : / Factory................................... : Electronic Controls and Discharge Systems Pvt Ltd Address................................... : Plot No. 16A Garment Complex, Cochin Special Economic Zone Kakkanad, Kochi, Kerala. INDIA 682037 Factory................................... : Longjiang Circuit International Limited Address................................... : No 5 building, WanXia Industry Park, ShaJing Town,Bao'An District, ShenZhen, China Factory................................... : LangDe Electronics Ltd Address................................... : Room 502, huashang industrial and trade zone, shajing 98 industrial zone, baoan district, shenzhen, China Telephone............................... : / Fax.......................................... : / Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCS210101043AEA January 29, 2021 Date of issue SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW Report No.: LCS210101043AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 33 Revision History Revision Issue Date Revisions Revised By 000 January 29, 2021 Initial Issue Gavin Liang SHENZHEN LCS COMPLIANCE TESTING …

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW _______________________________________________________________________________________________ 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AXYO-TBUDW IC: 26632-TBUDW _______________________________________________________________________________________________ Photo of Conducted Emissions Measurement Fig. 3
