2AXZD4861490500WiFi-extension for handheld elctronic pipettes of Eppendorf Xplorer family

Eppendorf AG

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Feb 10, 2021
Application Purpose: Original Equipment
Date of Application: Feb 10, 2021
Equipment Note: WiFi-extension for handheld elctronic pipettes of Eppendorf Xplorer family
Frequency Range: 2412.00000000 - 2462.00000000
Company: Eppendorf AG
Country: Germany

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Installation guide Eppendorf Xplorer® connect English (EN) 4861 901 012-02/022021 Installation guide Eppendorf Xplorer® connectseeon p.Fig.Tab.p. English (EN) This document is a supplement to the operating manual for the "Eppendorf Xplorer" and "Eppendorf Xplorer plus" electronic pipettes and does not replace it. To operate the pipettes, read the operating manual. The current version can be found on the Internet under www.eppendorf.com/manuals . 1Intended use The "Eppendorf Xplorer connect" radio module is designed as a modification kit for the Eppendorf Xplorer and Eppendorf Xplorer plus electronic pipettes with a USB port and an On/Off key. 2Other applicable documents The following documents also apply: • Eppendorf Xplorer/Xplorer plus operating manual • VisioNize pipette manager installation guide • VisioNize pipette manager operating manual 3Features The radio module enables wireless data exchange between the electronic pipette in Opt operating mode and the "VisioNize pipette manager" control panel. 4Product overview Abb. 1:Radio module for Eppendorf Xplorer and Xplorer plus Fig. 1:Radio module for Eppendorf Xplorer and Xplorer plus 1Contact pins 2Labeling Product name, HVIN, FCC-ID, IC-ID, serial number and CE logo 3Cutout for plug 4Recess for cable 5Li-polymer rechargeable battery  700 mAh Short design 6Rubber foam protection 7Pin For opening the USB cover 4861 490.055 12.2019 Li-Po 3.7V/700mAh (2.49Wh battery Only Charge with eppendorf power supply 4 3 1 2 5 76 2 Installation guide Eppendorf Xplorer® connect English (EN) 5Delivery package 6Inserting the radio module QuantityDescription 1"Eppendorf Xplorer connect" radio module 1Lithium polymer rechargeable battery 700 mAh (short design) 1Pin (for opening the USB cover) 1Eppendorf Xplorer connect installation guide 1. Open the rechargeable battery compartment lid. 2. Remove the long rechargeable battery (750 mAh). 3. Insert the short rechargeable battery (700 mAh) with the cable pointing to the right. Installation guide Eppendorf Xplorer® connect English (EN) 3 7Charging the rechargeable battery 1. Fully charge the rechargeable battery before performing the software update. 4. Place the radio module loosely on the PCB. The contact pins only touch the contact points on the PCB. 5. Route the rechargeable battery cable at the side of the radio module and insert the plug. The cable fixes the radio module. 6. Close the rechargeable battery compartment lid. 7. Set the Date and Time (Xplorer plus only). The pipette is prepared for radio communication with the control panel (VisioNize pipette manager). WARNING! Personal injury due to incorrect handling of the rechargeable battery. Only use rechargeable batteries supplied by Eppendorf. Never pierce, crush or throw the rechargeable battery. Only use the rechargeable battery in the supplied device. Do not touch a leaking rechargeable battery. Do not use a damaged rechargeable battery. Dispose of rechargeable batteries in accordance with the legal requirements. How to charge the rechargeable battery is described in the pipette's operating manual (chapter 5.1 Charging the rechargeable battery). Installation guide Eppendorf Xplorer® connect English (EN) Your local distributor: www.eppendorf.com/contact Eppendorf AG · Barkhausenweg 1 · 22339 Hamburg · Germany [email protected] · www.eppendorf.com ©2021 · Eppendorf ® and the Eppendorf logo are registered trademarks of Eppendorf AG, Germany. 4861 901 012-02/022021 8Pipette software update After the radio module has been installed, the pipette software must be updated. After the firmware has been successfully updated, the Option menu is extended by the Wi-Fi submenu. 9Technical data 9.1Radio module 9.2Rechargeable battery The software update process is described in the VisioNize pipette manager installation guide. MenuSubmenuDescription Wi-Fi Wi-Fi on/offEnables or disables the radio interface. Connect AUTOThe settings for the radio network are determined and entered automatically. Connect MANThe settings for the radio network must be entered manually. Recent connectionsLists the recent radio connections. Delete connectionDeletes a radio connection. StatusDisplays the current connection data. VersionDisplays the software version and the hardware version of the radio module. Transmit peak powermax. 0.088 W Power level19 dBm Frequency band2412 Hz – 2462 Hz Radio channel1 – 11 ApprovalFCC, IC Standard802.11 b/g/n TypeLi-polymer rechargeable battery Designshort Rated capacity700 mAh Nominal voltage3.2 V Charging time1 h Weight16 g Regulatory Information Eppendorf Xplorer ® connect English (EN) 4861 901 020-01/022021 Regulatory Information Eppendorf Xplorer® connectseeon p.Fig.Tab.p. English (EN)Regulatory Information 1Regulatory information Regulatory information, certification, and compliance marks specific to "Eppendorf Xplorer connect" are available on the internet under www.eppendorf.com/manuals . 2EU compliance statement Hereby, Eppendorf AG declares that the radio equipment type "Eppendorf Xplorer connect" is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available on the internet under www.eppendorf.com/manuals . 2.1Body worn operation The device complies with RF specifications when used at a distance of 0 cm from your body. Ensure that the device accessories, such as a device case and holster, are not composed of metal components. Keep the device away from your body to meet the distance requirements. 2.2Certification information This device meets guidelines for exposure to radio waves. Your device is a low-power radio transmitter and receiver. As recommended by international guidelines, the device is designed not to exceed the limit for exposure to radio waves. These guidelines were developed by the International Commission on Non-Ionizing Radiation Protection (ICNIRP), an independent scientific organization, and include safety measures designed to ensure the safety of all users, regard…

Text truncated - open the document above for the full version.

Cover Letter(s)

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 02 February 2021 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, we request confidentiality for the following products: FCC ID Model name 2AXZD1004000001 VisioNize® pipette manager 2AXZD4861490500 Eppendorf Xplorer® connect For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Description The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device, which is planned for 01. Feb. 2021 If you have any questions, please feel free to contact me at the address shown below. Sincerely, Lutz Metterhausen Head of Regulatory Affairs Eppendorf AG Barkhausenweg 1 22339 Hamburg Germany Phone: +49 40 538 01 88949 Email: [email protected]

External Photos

Xplorer pipette Front view View from the right View from the back View from the left Top view Top view (with open USB connector cover) Micro USB connector Barrel connector for charging Xplorer connect Top view Bottom View Position of Xplorer connect module in the Xplorer pipette

ID Label/Location Info

Eppendorf Xplorer connect HVIN: 4861 490 500 00 FCC ID: 2AXZD4861490500 IC: 26635-4861490500 SN: A12345A Eppendorf Xplorer connect HVIN: 4861 490 500 00 FCC ID: 2AXZD4861490500 IC: 26635-4861490500 SN: A12345A Eppendorf Xplorer connect HVIN: 4861 490 500 00 FCC ID: 2AXZD4861490500 IC: 26635-4861490500 SN: A12345A Font: Arial Bold Font Size: 5 pt/ 1.26 mm Font: Arial Regular Font Size: 4 pt/ 1.00 mm 4 mm 16 mm 5 mm 4 mm Font: epHelvetica Bold Font Size: 5 pt/ 1.26 mm Font: epHelvetica Regular Font Size: 4 pt/ 1.00 mm centered Xplorer connect labelling Top View of the Packaging with packaging label First view of the customer of the Hardware (labelling on the Back of the Xplorer connect is visible)

Internal Photos

Mounting of the Xplorer connect in the Xplorer pipette Xplorer pipette (internal views) Internal view of the Housing cover Internal view of the upper body Main PCBA Top view Bottom view Internal view of the lower body Xplorer connect (internal views) Internal view 1 Internal view 2 PCBA without shield Antenna

RF Exposure Info

Report No.: BTL-FCC SAR-1-2012C085_Appendix A. Page 1 of 1 Test Laboratory: BTL Inc. Date: 2021/1/13 System Check_H2450_0113 DUT: Dipole 2450 MHz D2450V2;SN:919; Communication System: UID 0, CW (0); Frequency: 2450 MHz; Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2450 MHz; σ = 1.82 S/m; εr = 38.48; ρ = 1000 kg/m 3 Ambient Temperature：23.1 °C; Liquid Temperature：22.2 °C DASY Configuration: • Probe: EX3DV4 - SN3974; ConvF(7.98, 7.98, 7.98) @ 2450 MHz; Calibrated: 2020/12/18 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), z = 1.0, 31.0 • Electronics: DAE4 Sn1423; Calibrated: 2020/12/11 • Phantom: ELI v5.0_Left; Type: QDOVA002AA; Serial: TP:1222 • DASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Area Scan (8x8x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 17.1 W/kg Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 101.4 V/m; Power Drift = 0.17 dB Peak SAR (extrapolated) = 25.7 W/kg SAR(1 g) = 12.9 W/kg; SAR(10 g) = 6.01 W/kg Maximum value of SAR (measured) = 21.3 W/kg

RF Exposure Info

Report No.: BTL-FCC SAR-1-2012C085_Appendix B. Page 1 of 1 Test Laboratory: BTL Inc. Date: 2021/1/13 W08_802.11b_CH11_Rear Face_0cm DUT: Xplorer connect; Communication System: UID 0, WI-FI (2412-2472) (0); Frequency: 2462 MHz; Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2462 MHz; σ = 1.833 S/m; εr = 38.443; ρ = 1000 kg/m 3 Ambient Temperature：23.1 °C; Liquid Temperature：22.2 °C DASY Configuration: • Probe: EX3DV4 - SN3974; ConvF(7.98, 7.98, 7.98) @ 2462 MHz; Calibrated: 2020/12/18 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), z = 1.0, 31.0 • Electronics: DAE4 Sn1423; Calibrated: 2020/12/11 • Phantom: ELI v5.0_Left; Type: QDOVA002AA; Serial: TP:1222 • DASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Area Scan (9x8x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.0170 W/kg Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 0 V/m; Power Drift = 0.00 dB Peak SAR (extrapolated) = 0.0230 W/kg SAR(1 g) = 0.003 W/kg; SAR(10 g) = 0.001 W/kg Maximum value of SAR (measured) = 0.0147 W/kg

RF Exposure Info

Asset No.： E-434 Model No.： D2450V2 Serial No.： 919 Environmental 22.9°C, 52 % Original Cal. Date： June 11, 2018 Next Cal. Date： June 11, 2021 1IEEE Std 1528-2013 2IEC 62209-2 3KDB865664 Equipment：Manufacturer：Model No.：Serial No.：Cal.Organization：Cal. Date： Power AmplifierMini-CircuitsZHL-42W+QA1333003N/AMarch 10, 2020 DC Source metterlteckIT6154006104126768201001N/AJuly 25, 2020 Signal AnalyzerR&SFSV7103120N/AJuly 25, 2020 Vector Network AnalyzerAnritsuMS46522B1538101N/AJuly 25, 2020 Signal GeneratorR&SSMF100A101214N/AFebruary 29, 2020 Smart Power SensorR&SNRP-Z21102209N/AMarch 7, 2020 Dielectric Assessment KitSpeagDAK-3.51226N/AN/A Directional CouplerWokenTS-PCC0M-05107090019N/AMarch 1, 2020 CouplerWoken0110A05601O-10COM5BNW1A2N/AMarch 1, 2020 Digital ThemometerLKMDTM30003519N/A July 2, 2020 Model No ItemOriginal Cal. Result Verified on 2020/11/26DeviationResult Impedance, transformed to feed point 53Ω+2.85jΩ52.4Ω+2.83jΩ<5ΩPass Return Loss(dB)-27.9-28.150.9%Pass SAR Value fo r 1g(mW/g) 13.113.63.8%Pass SAR Value fo r 10g(mW/g) 6.176.180.2%Pass D2450V2 Dipole Internal Calibration Record For Head Tissue Impedance Test-HeadReturn Loss-Head Standard List IEEE Recommended Practice for Determining the Peak Spatial-Averaged Specific Absorpiton Rate(SAR) in the Human Head from Wireless Communication Devices: Measurement Texhniques, June 2013 Procedure to determine the Specific Absorption Rate (SAR) for wireless communication devices used in close proximity to the human body(frequency range of 30 MHz to 6 GHz), March 2010 SAR Measurement Requirements for 100 MHz to 6 GHz Equipment Information Calibrator:Approver: Validation Report for Head TSL

RF Exposure Info

Report No.: BTL-FCC SAR-1-2012C085 Page 1 of 29 FCC SAR Test Report Project No. : 2012C085 Equipment : Eppendorf Xplorer® connect Brand Name : N/A Test Model : Wi-Fi extension module für Xplorer® and Xplorer® Plus Series Model : N/A Date of Receipt : Dec. 15, 2020 Date of Test : Jan. 13, 2021 Issued Date : Jan. 20, 2021 Report Version : R00 Test Sample : Engineering Sample No.: DG20201228195 Standard(s) : Please refer to page 2. Applicant : Eppendorf Liquid Handling GmbH Address : Barkhausenweg 1 22339 Hamburg Deutschland Manufacturer : Eppendorf Liquid Handling GmbH Address : Barkhausenweg 1 22339 Hamburg Deutschland Factory : Eppendorf Liquid Handling GmbH Address : Barkhausenweg 1 22339 Hamburg Deutschland The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Seven Lu Approved by : Herbort Liu Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCC SAR-1-2012C085 Page 2 of 29 Standard(s) : ANSI Std C95.1-1992 Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz - 300 GHz. (IEEE Std C95.1-1991) IEEE Std 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques KDB447498 D01 General RF Exposure Guidance v06 KDB248227 D01 802.11 Wi-Fi SAR v02r02 KDB865664 D01 SAR measurement 100 MHz to 6 GHz v01r04 KDB865664 D02 SAR Reporting v01r02 KDB690783 D01 SAR Listings on Grants v01r03 Report No.: BTL-FCC SAR-1-2012C085 Page 3 of 29 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCC SAR-1-2012C085 Page 4 of 29 Table of Contents Page REPORT ISSUED HISTORY 6 1 . GENERAL INFORMATION 7 1.1 STATEMENT OF COMPLIANCE 7 1.2 LABORATORY ENVIRONMENT 7 1.3 GENERAL DESCRIPTION OF EUT 7 1.4 MAIN TEST INSTRUMENTS 8 2 . RF EMISSIONS MEASUREMENT 9 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . SAR MEASUREMENTS SYSTEM CONFIGURATION 10 3.1 SAR MEASUREMENT SET-UP 10 3.1.1 TEST SETUP LAYOUT 10 3.2 DASY5 E-FIELD PROBE SYSTEM 11 3.2.1 EX3DV4 PROBE SPECIFICATION 11 3.2.2 E-FIELD PROBE CALIBRATION 12 3.2.3 OTHER TEST EQUIPMENT 13 3.2.4 SCANNING PROCEDURE 14 3.2.5 SPATIAL PEAK SAR EVALUATION 15 3.2.6 DATA STORAGE AND EVALUATION 16 3.2.7 DATA EVALUATION BY SEMCAD 17 4 . SYSTEM VERIFICATION PROCEDURE 19 4.1 TISSUE VERIFICATION 19 4.2 SYSTEM CHECK 20 4.3 SYSTEM CHECK PROCEDURE 20 5 . SAR MEASUREMENT VARIABILITY AND UNCERTAINTY 21 5.1 SAR MEASUREMENT VARIABILITY 21 6 . OPERATIONAL CONDITIONS DURING TEST 22 6.1 SAR TEST CONFIGURATION 22 6.1.1 WIFI TEST CONFIGURATION 22 6.2 TEST POSITION 23 7 . TEST RESULT 24 7.1 CONDUCTED POWER RESULTS 24 7.1.1 CONDUCTED POWER MEASUREMENTS OF WIFI 24 7.2 SAR TEST RESULTS 25 Report No.: BTL-FCC SAR-1-2012C085 Page 5 of 29 Table of Contents Page 7.2.1 SAR MEASUREMENT RESULT 26 7.3 MULTIPLE TRANSMITTER EVALUATION 27 APPENDIX 28 1. TEST LAYOUT 28 Appendix A. SAR Plots of System Verification Appendix B. SAR Plots of SAR Measurement Appendix C. Calibration Certificate Appendix D. Photographs of the Test Set-Up Report No.: BTL-FCC SAR-1-2012C085 Page 6 of 29 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Jan. 20, 2021 Report No.: BTL-FCC SAR-1-2012C085 Page 7 of 29 1. GENERAL INFORMATION 1.1 STATEMENT OF COMPLIANCE Mode Highest Reported Body SAR-1g (W/kg) 2.4G WLAN 0.003 Note: The device is in compliance with Specific Absorption Rate (SAR) for general population uncontrolled exposure limits according to the FCC rule §2.1093, the ANSI C95.1:1992/IEEE C95.1:1991, the NCRP Report Number 86 for uncontrolled environment, and had been tested in accordance with the measurement methods and procedures specified in IEEE Std 1528-2013 1.2 LABORATORY ENVIRONMENT Temperature Min. = 18ºC, Max. = 25ºC Relative humidity Min. = 30%, Max. = 70% Ground system resistance < 0.5Ω Ambient noise is checked and found very low and in compliance with requirement of standards. Reflection of surroundin…

Text truncated - open the document above for the full version.

Test Report

The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory © Copyright: All rights reserved by CETECOM Annex 1: Measurement diagrams to Test Report 19-1-0202601T10a-C1-A1 Number of pages: 10 Date of Report: 2021-Jan-26 Testing company: CETECOM GmbH Im Teelbruch 116 45219 Essen Germany Tel. + 49 (0) 20 54 / 95 19-0 Fax: + 49 (0) 20 54 / 95 19-150 Applicant: Eppendorf AG Product: WiFi-extension for handheld electronic pipettes of Eppendorf Xplorer® family Model: Eppendorf Xplorer® connect FCC ID: 2AXZD4861490500 IC: 26635-4861490500 Testing has been carried out in accordance with: Title 47 CFR, Chapter I FCC Regulations, Subchapter A §15.247 (DTS) ISED-Regulations RSS-Gen, Issue 5 RSS 247, Issue 2 Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". 19-1-0202601T10a-C1-A1 CETECOM_TR19_1_0202601T10a_C1_A1 2 / 10 Table of Contents 1Measurement diagrams ...........................................................................................................................................................3 19-1-0202601T10a-C1-A1 CETECOM_TR19_1_0202601T10a_C1_A1 3 / 10 1Measurement diagrams 1.1Radiated measurements 2.01a_n-mode_ch06 Common Information Test Description: Magnetic Field Strength Measurement related to 30/300 m distance Test Site Location: Ref.-Nr. 441 Semi Anechoic Chamber (SAC1) with 3 m measurement distance Version of Testsoftware: EMC32 V10.50.0 Distance correction: used accord. table, pls. see test report Technical Data: Please see page 2 for detailed data of measurement setup Rec. antenna (pre-scan): height 1.00 m, parallel and 90° to EUT polarisation Used Filter: bypass Test Standard: FCC 15.205 § 15.209; RSS-Gen: Issue 5 Operator: npe Operating Mode: n-mode | MCS0| ch06 Power during tests: full loaded battery Comment 1: EUT laying Comment 2: - Environmental Conditions:: Humidity : 40%rH; Temperature: 21°C EUT Setup: 1 Verdict: Passed Comment: Including 19-1-02026S08_C01 EUT Information PMT number: 19-1-02026S22_C01 Manufacturer: Eppendorf AG -40 -20 0 20 40 60 9k20 3050100k200 300 5001M2M 3M5M10M20 30M L e v e l i n d B μ V / m Frequency in Hz Full Spectrum FCC15.209_Magnetic_Field 17,240 kHz -23,452 dBμV/m 35,400 kHz -32,878 dBμV/m 25,346000 MHz 19,564 dBμV/m 19-1-0202601T10a-C1-A1 CETECOM_TR19_1_0202601T10a_C1_A1 4 / 10 2.01b_n-mode_ch06 Common Information Test Description: Magnetic Field Strength Measurement related to 30/300 m distance Test Site Location: Ref.-Nr. 441 Semi Anechoic Chamber (SAC1) with 3 m measurement distance Version of Testsoftware: EMC32 V10.50.0 Distance correction: used accord. table, pls. see test report Technical Data: Please see page 2 for detailed data of measurement setup Rec. antenna (pre-scan): height 1.00 m, parallel and 90° to EUT polarisation Used Filter: bypass Test Standard: FCC 15.205 § 15.209; RSS-Gen: Issue 5 Operator: npe Operating Mode: n-mode | MCS0| ch06 Power during tests: full loaded battery Comment 1: EUT standing Comment 2: - Environmental Conditions:: Humidity : 42%rH; Temperature: 20°C EUT Setup: Including 19-1-02026S08_C01 Verdict: Passed Comment: - EUT Information PMT number: 19-1-02026S22_C01 Manufacturer: Eppendorf AG -40 -20 0 20 40 60 9k20 3050100k200 300 5001M2M 3M5M10M20 30M L e v e l i n d B μ V / m Frequency in Hz Full Spectrum FCC15.209_Magnetic_Field 17,320 kHz -23,635 dBμV/m 35,400 kHz -30,661 dBμV/m 52,600 kHz -37,058 dBμV/m 23,430000 MHz 19,521 dBμV/m 19-1-0202601T10a-C1-A1 CETECOM_TR19_1_0202601T10a_C1_A1 5 / 10 3.01a_n-mode_ch06 Common Information Test Description: Radiated field strength emission in 3m distance Test Site: CETECOM GmbH Essen Test Standard: FCC 15.205&15.209 RSS Gen Issue 5 Intentional Radiator Antenna polarisation: horizontal/vertical Environmental Conditions:: Humidity : 42%rH; Temperature: 20°C Operator Name: npe EUT: Including 19-1-02026S08_C01 Operating Mode: n-mode | MCS0| ch06 Power supply: Battery Comment: EUT laying Verdict: Passed EUT Information PMT number: 19-1-02026S22_C01 Manufacturer: Eppendorf AG 0 10 20 30 40 50 60 30M 5060 80 100M200300400 500 8001G L e v e l i n d B μ V / m Frequency in Hz Full Spectrum FCC15.209 795,780000 MHz 33,971 dBμV/m 928,470000 MHz 39,052 dBμV/m 282,300000 MHz 22,028 dBμV/m 980,490000 MHz 34,170 dBμV/m Remark: The peaks at 795 and 928 MHz are known external distrubances and do not come from EUT. 19-1-0202601T10a-C1-A1 CETECOM_TR19_1_0202601T10a_C1_A1 6 / 10 3.01b_n-mode_ch06 Common Information Test Description: Radiated field strength emission in 3m distance Test Site: CETECOM GmbH Essen Test Standard: FCC 15.205&15.209 RSS Gen Issue 5 Intentional Radiator Antenna polarisation: horizontal/vertical Environmental Conditions:: Humidity : 40%rH; Temperature: 22°C Operator Name: npe EUT: Including 19-1-02026S08_C01 Operating Mode: n-mode | MCS0| ch06 Power supply: Battery Comment: EUT standing Verdict: Passed EUT Information PMT number: 19-1-02026S22_C01 Manufacturer: Eppendorf AG 0 10 20 30 40 50 60 30M 5060 80 100M200300400 500 8001G L e v e l i n d B μ V / m Frequency in Hz Full Spectrum FCC15.209 796,380000 MHz 35,774 dBμV/m 928,410000 MHz 38,960 dBμV/m 982,620000 MHz 33,359 dBμV/m 280,710000 MHz 21,932 dBμV/m Remark: The peaks at 796 and 928 MHz are known external distrubances and do not come from EUT. 19-1-0202601T10a-C1-A1 CETECOM_TR19_1_0202601T10a_C1_A1 7 / 10 4.01a_n-mode_ch06 Common Information Test Description: Radiated field strength emission in 3m distance Test Site: Fully Anechoic Chamber (FAC1) - EMC32 V10.50.0 Test Standard: FCC 15.247&15.209 Intentional Radiator / RSS-Gen, Issue 5 Antenna polarisation: horizontal/vertical Operating Mode: n-mode | MCS0| ch06 Operator: TFra Comment: Channel no. mid Comment2: Including 19-1-02026S08_C01 EUT Setup: 1 Verdict: Passed EUT Information PMT number: 19-1-02026S22_C01 Manufacturer: Eppendorf A…

Text truncated - open the document above for the full version.

Test Report

PARTIAL Test Report 19-1-0202601T10a-C1 Number of pages: 28 Date of Report: 2021-Jan-27 Testing company: CETECOM GmbH Im Teelbruch 116 45219 Essen Germany Tel. + 49 (0) 20 54 / 95 19-0 Fax: + 49 (0) 20 54 / 95 19-150 Applicant: Eppendorf AG Product: WiFi-extension for handheld electronic pipettes of Eppendorf Xplorer® family, Model: Eppendorf Xplorer® connect FCC ID: 2AXZD4861490500 IC: 26635-4861490500 Testing has been carried out in accordance with: Title 47 CFR, Chapter I FCC Regulations, Subchapter A §15.247 (DTS) ISED-Regulations RSS-Gen, Issue 5 RSS 247, Issue 2 Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Tested Technology: 2.4GHz W-LAN (IEEE 802.11) Test Results: ☒ The EUT complies with the requirements in respect of selected parameters subject to the test. The test results relate only to devices specified in this document Test report 19-1-0202601T10a-C1 is replacing original test report 19-1-0202601T10a, dated 2021-Jan-25. The replaced test report gets invalid herewith. Signatures: Dipl.-Ing. Ninovic Perez M. Sc. Patrick Marzotko Test Lab Manager Test manager Authorization of test report Responsible of test report Test Report 19-1-0202601T10a-C1 CETECOM_TR19_1_0202601T10a_C01 2 / 28 Table of Contents Table of Annex .................................................................................................................................................................................. 3 1 General information ................................................................................................................................................................ 4 1.1 Disclaimer and Notes ......................................................................................................................................................... 4 1.1. Summary of Test Results ................................................................................................................................................... 5 1.2. Summary of Test Methods ................................................................................................................................................ 6 2 Administrative Data ................................................................................................................................................................. 7 2.1 Identification of the Testing Laboratory ............................................................................................................................ 7 2.2 General limits for environmental conditions ..................................................................................................................... 7 2.3 Test Laboratories sub-contracted ...................................................................................................................................... 7 2.4 Organizational Items ......................................................................................................................................................... 7 2.5 Applicant’s details ............................................................................................................................................................. 7 2.6 Manufacturer’s details ...................................................................................................................................................... 7 2.7 EUT: Type, S/N etc. and short descriptions used in this test report .................................................................................. 8 2.8 Auxiliary Equipment (AE): Type, S/N et…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Oliver Jucha-Schade(Manager Regulatory Affairs)

[email protected]00491707969Fax: 00494053801840

Test Firm

cetecom advanced GmbHGerald Schmidt

[email protected]+49 681 598 0Fax: +49 681 598 8775

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	76.00 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is peak conducted. Body-worn operations are allowed at 0 cm separation distance between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR value is: Body-worn <0.1 W/kg.
