2AXZJ-CTX0710W3Telematics Control Unit

Lucid USA, Inc
Telematics Control Unit - FCC ID 2AXZJ-CTX0710W3 - Lucid USA, Inc
Click to zoom

Application Details

Equipment Class
NII - Unlicensed National Information Infrastructure TX
Date of Grant
May 09, 2023
Application Purpose
Original Equipment
Date of Application
May 08, 2023
Equipment Note
Telematics Control Unit
Frequency Range
5745.00000000 - 5825.00000000
Company
Lucid USA, Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗
↗
↗
↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗
↗

RF Exposure Info

↗

Test Report

↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TCU User Manual TCU (Telematics Control Unit) P11-K290G0-02 is manufactured by ASKEY Corp. for Lucid USA, Inc (aka Lucid Motors) and provides wireless connectivity to LTE/UMTS and Wi-Fi networks for vehicle’s Infotainment and Telematics systems. The device also provides location-based services and is capable to download OTA software updates for different functional units of the vehicle. TCU is installed in the vehicle during manufacturing as a fully pre-configured device, which starts working as soon as power the power is turned on. The device is completely hidden from the vehicle user and does not require any additional configuration. TCU is mounted in the rear right location of the vehicle and is connected to the vehicle’s wiring harness (an assembly of electric cables used for transmission of electric signals and electric power in a vehicle). The device can be accessed for repair and maintenance purposes only by qualified technical service personnel. TCU location in the vehicle is shown on the drawing below. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. For Outdoor access point operating in the band 5.15-5.25 GHz Professional Installation instruction 1. Professional installer: this product is designed for specific application and needs to be installed by trained personnel. The general user shall not attempt to install or change the setting. 2. External Antenna: use only the antenna(s) that have been approved by the manufacturer. The non-approved antenna(s) may produce unwanted spurious or excessive RF transmitting power that may lead to the violation of FCC limit and is prohibited. Waring: Please carefully select the installation position and ensure that the final output power does not exceed the limit set forth in relevant rules. This radio transmitter FCC ID: 2AXZJ-CTX0710W3 has been approved by FCC to operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device. Ant. Brand Model Name Antenna Type Connector 1 Amphenol P11-J67E00-02 FPC FARKA 2 Amphenol P11-J67200-02 FPC FARKA 3 nextium P11-J44000-00 FPC FARKA 4 nextium P11-J44100-00 FPC FARKA Ant. Port 2.4G Gain (dBi) 2400 2420 2440 2460 2480 2500 Remark (Note. 1) 1 1 3.1 3.0 2.8 2.9 3.0 3.5 w/o cable 0.6 0.5 0.3 0.4 0.5 1.0 with cable Ant. Port 5G Gain (dBi) 5150 5250 5750 5850 Remark (Note. 2) 1 1 1.5 2.2 4.1 4.3 w/o cable -1.8 -1.1 0.7 0.9 with cable 2 2 1.7 2.3 3.9 4.1 w/o cable -1.6 -1.0 0.5 0.7 with cable Ant. Port WWAN 2G/3G Gain (dBi) GSM 850 PCS 1900 WCDMA Band 2 WCDMA Band 4 WCDMA Band 5 Remark (Note. 3) 3~4 1~2 1.0 4.5 4.5 4.5 1.0 w/o cable -0.2 2.7 2.7 2.7 -0.2 with cable Ant. Port WWAN 4G Gain (dBi) LTE Band 2 LTE Band 4/66 LTE Band 5 LTE Band 7 LTE Band 12 LTE Band 13 Remark (Note. 3) 3~4 1~2 4.5 4.5 1.0 5.7 1.0 1.0 w/o cable 2.7 2.7 -0.2 2.7 -0.2 -0.2 with cable Note 1: WLAN 2.4G cable loss = 2.5 dB. Note 2: WLAN 5GHz Band 1 cable loss = 3.3 dB, and 5GHz Band 4 cable loss = 3.4 dB. Note 3: WWAN cable loss = 1.2 dB (GSM 850, FDD V, LTE Band 5, 12, 13) WWAN cable loss = 1.8 dB (PCS 1900, FDD II, FDD IV, LTE Band 2, 4/66) WWAN cable loss = 3.0 dB (LTE Band 7) Note 4: The EUT has four antennas. For 2.4GHz function: For IEEE 802.11 b/g/n/VHT/ax mode (1TX/1RX) Ant. 1 (port 1) could transmit/receive. For 5GHz function: For IEEE 802.11 a mode (1TX/1RX) Support diversity function and pre-tested on each single chain, the worst case was Ant. 2 (port 2) and it was recorded in this report. For IEEE 802.11 n/ac/ax mode (2TX/2RX) Ant. 1 (port 1) and Ant. 2 (port 2) could transmit/receive simultaneously. For WWAN 2G function (1TX/1RX): Ant. 3 (port 1) could transmit/receive. For WWAN 3G/ 4G function (1TX/2RX): Ant. 3 (port 1) could transmit, and Ant. 3 (port 1) and Ant. 4 (port 2) could receive simultaneously. This device contains licence-exempt transmitter(s)/receiver(s) that c…
