2AY2P-WMF51Wireless Multiview Presentation Switcher

WMF51 QUICK REFERENCE GUIDE Contact: [email protected] | [email protected] | [email protected] WMF51 Quick Reference Guide The WMF51 is a 4K multi-format presentation switch featuring AirPlay, Miracast® and Chromecast® inputs to a single HDMI output. The WMF51 provides enhanced features including multi-view presentation, video scaling, a web-GUI for control and configuration, localised 2.4/5G WiFi hotspot and dual LAN connectivity. The WMF51 also features OSD control, USB touch-back to connected host device, whiteboard and screen overlay annotation, with manual or automated source selection. The WMF51 can be controlled via front panel, RS-232 or TCP/IP. The WMF51 is also compatible with Blustream WMF-USBC and WMF-HDMI plug and play wireless dongles, providing an ideal BYOD solution for your boardroom, classroom, or huddle-space application. Introduction FEATURES: • 4K multi-format multi-view presentation switch • Features AirPlay, Miracast®, Chromecast® and Blustream wireless dongle support which can be switched to a single HDMI output • Multiview presentation with up to 4 concurrent video signals with configurable screen layout • In-built video scaler with output timing up to 4K 60Hz 4:4:4 • Localised 2.4G/5G WiFi hotspot to host AirPlay, Miracast® and Chromecast® local point-to-point mode (up to 1080p) • Dual LAN connection for integration to existing network infratructures • Supports USB touch-back feature via WMF-USBC and WMF-HDMI dongles and Miracast®* • Audio breakout to analogue L/R audio • Web interface module for control and configuration of unit • OSD control with preview function • Whiteboard and screen overlay annotation feature • Control via front panel, RS-232 and TCP/IP with manual or auto source selection • Features Class 0 IEEE 802.3af PoE for powering of product from a PoE switch *Miracast touch-back compatibility subject to Windows features C M Y CM MY CY CMY K WMF51_QRG_REVA2_Print.pdf 1 28/02/2024 11:00 WMF51 QUICK REFERENCE GUIDE www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk02 Front Panel Description 1 USB-A / USB-C Dongle Pairing Ports - Connect Blustream WMF-HDMI or WMF-USBC wireless dongles to corresponding port to pair with the WMF51. WMF51 video output will display information regarding the automatic pairing and firmware update process. Please note: wireless dongles sold separately 2 Standby Button - Press to turn on or o¡ the WMF51 3 Power LED Indicator - Illuminates when the device is powered on 231 Rear Panel Description 25167834 1 WiFi Antenna Connection (1) - Connect supplied WiFi antenna 2 RS-232 Port - 3-pin Phoenix connector for control of the WMF51 3 Analogue L/R Output - 3.5mm stereo jack for analogue audio break out (2ch PCM audio only) 4 USB 3.0 Connector - Connect to USB mouse/keyboard 5 Reset button - Press and hold reset button for 10 seconds to return the WMF51 to factory default settings 6 HDMI Output - Connect to HDMI display equipment 7 WiFi Antenna Connection (2) - Connect supplied WiFi antenna 8 TCP/IP Port 1 - 100Mbps RJ45 connector to connect to LAN for TCP/IP control of device and to access web-GUI 9 TCP/IP PoE Port 2 - 1Gbps RJ45 connector to connect to LAN for TCP/IP control of device and to access Web GUI, includes PoE function to power device q Power Port – Use included 12v/1.5A DC adaptor w WiFi Antenna Connection (3) - Connect supplied WiFi antenna NOTE: The distance between user and products should be no less than 20cm. WARNING: 5.2 GHz band is restricted to indoor use only. La distance entre l’utilisateur et le produit ne doit pas être inférieure à 20 cm. La bande de 5.2 GHz est réservée à l’usage intérieur. 91011 C M Y CM MY CY CMY K WMF51_QRG_REVA2_Print.pdf 2 28/02/2024 11:00 WMF51 QUICK REFERENCE GUIDE Contact: [email protected] | [email protected] | [email protected] Configuration and Web-GUI Control The WMF51 features an in-built web-GUI which is required for control and configuration of the device. This configuration includes features such as source EDID management, output scaler resolution, network / WiFi configuration, and user control. You can connect to the WMF51 either via hardwired LAN connection, or via local WiFi hotspot. Connecting via LAN: By default this device is set to DHCP, however if a DHCP server (eg: network router) is not installed or you connect directly from your PC to the WMF51, the IP address will revert to the below details: Default Username is: blustream Default Password is: 1234 Default IP Address is: 192.168.0.200 If the WMF51 is connected to a pre-existing network then it will be provided an IP Address via DHCP. There are several ways in which you can find the IP address of the device as follows: • The On Screen Display shows the IP address of the product in the lower le¦ corner of the screen (item A in the image below). • Use a 3rd party IP scanning tool on your PC to find the IP address of the WMF51. Connecting via Local WiFi Hotspot: This device can broadcast its own local WiFi hotspot which users can connect to in order to stream content to the device, or control and configure it. The default local WiFi hotspot settings are as follows: Default Device ID / SSID is: Blustream_WMF51 Default SSID Password is: 1234 Default BYOD PIN is: N/A It is also possible to disable the local WiFi hotspot and hardwire the WMF51 into a pre-existing data network. You would then use the pre-existing WiFi access points to connect to the network and communicate with the WMF51. BYOD (Bring Your Own Device) Connectivity The on screen display shows a connection guide when no input devices are being viewed. This illustrates how to connect your laptop, wireless dongles, tablet or smartphone (BYOD device) to the unit. There are various technologies utilised to ensure your smart device is capable of broadcasting a video to the WMF51 without any apps required. These are: • AirPlay (Apple devices) • Miracast®, SmartView or ScreenCast (Android devices) • Chromec…
