2AY5GMK020011002115LED Lamp

”ONLY USE THE CONTROL PROVIDED WITH OR SPECIFIED BY THESE INSTRUCTIONS TO CONTROLTHIS LAMP.THIS LAMP WILL NOT OPERATE PROPERLY WHEN CONNECTED TO ASTANDARD(INCANDESCENT)DIMMER OR DIMMING CONTROL.” RISK OF ELECTRIC SHOCK - DO NOT USE WHERE DIRECTLY EXPOSED TO WATER NOT FOR EMERGENCY LIGHTING CAUTION -Stable Wi-Fi network which could access to the device. -A smart phone is running iOS 8 or higher or Android 4.1 or higher. -Install the bulb in an E26 socket ® TM E26 socket Need help? We're here for you every day from 7 a.m.- 9 p.m. CST. Give us a call at 18885162630 Register Your Account But Wait....There’s More But Wait....There’s More A smart light bulb is easily dim or brighten, change color, turn on or o via remote control with onn. Smart Home app. No hub needed. It is also available to be controlled by voice and be compatible with Google/Alexa/Siri to build your smart home. TM Get to Know Your Smart Bulb The Specs Multi-Color LED light Size: 60x118mm(2*4in 15,000 hour life WiFi:IEEE 802 11 N, 2 4GHz 110130V AC, 60Hz Scan the QR code below to download the Smart Home app or download the it from APP Store or Google Play. Open the Smart Life app, tap "Register" to register an account, then sign in the app. Add the device, as the following picture shows. Make your router, cellphone, and device are as close as possible. Before connecting, enable bluetooth of cellphone. Make sure you're connecting to a 2.4GHz Wi-Fi network. (lt can't connect to 5GHz networks) Turn on the bulb 3 times(on-o-on-o-on), conirm light bulb is lickering rapidly. (2 times per second). Note: if network coniguration takes more than 8 minutes or fails. Reset the bulb(turn on the bulb 3 times again as mentioned above). There are two ways to connect with the bulb, one is Add manually, the other is Auto scan Also, you can choose dierent scene in scene mode. In music model, the color is available to be This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Any changes or modiications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Federal Communication Commission Interference Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) this device may not cause harmful interference, (2) this device must accept any interference received, including interference that may cause undesired operation. 1567 8910234 Let’s Get Started Here’s what you’ll need to get set up Add Your Device 0102 Add Your Device 02 The Fine PrintThe Fine Print Create Connection 03 Way one Add manually Tap + to add Way two Auto scan Follow the pictures to create connection for the bulb You can control the brightness and change color in Dimmer model. FCC Radiation Exposure Statement: Non-modiication Statement: FCC Compliance Statement: Smart Light Bulb Multi-Color LED Light USER MANUAL FPO

ZhejiangMEKAElectricCo.,Ltd AgentAuthorization Company:ZhejiangMEKAElectricCo.,Ltd Address:NO.8CanghaiRoad,LihaiTown,BinhaiNew City,Shaoxing,zhejiangProvince,China ProductName:LEDLamp ModelNumber(s):MK-020011002115,MK-020011002118 ProductDescription:LEDLamp WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date: 2021.03.09 Name:Ansonbao Title:Manager Company:ZhejiangMEKAElectricCo.,Ltd

DifferencesDescription WeZhejiangMEKAElectricCo.,Ltdstate: Product： LEDLamp ModelName： MK-020011002115,MK-020011002118 BrandName： MKOPTO FCCID： 2AY5GMK020011002115 Onlythemodelname,appearance,sizeandpoweraredifferent,theothersarethe same. Sincerely, Company:ZhejiangMEKAElectricCo.,Ltd Title:Manager E-mail:[email protected] Name:Ansonbao Signature

ZhejiangMEKAElectricCo.,Ltd OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2021.03.09 Subject;RequestforConfidentiality FCCID:2AY5GMK020011002115 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:Ansonbao Title:Manager

4789738938.2-A14 External Photos Model: MK-020011002115 4789738938.2-A14 4789738938.2-A14

FCC ID: 2AY5GMK02001002115 11W, E26,110-130V, 60Hz RGBW, 850LM, 2700-6500K FCC ID: 2AY5GMK02001002115 11W, E26,110-130V, 60Hz RGBW, 850LM, 2700-6500K FCC ID: 2AY5GMK02001002115 11W, E26,110-130V, 60Hz RGBW, 850LM, 2700-6500K Location 1

4789738938.2-A15 Internal Photos Model: MK-020011002115 4789738938.2-A15 4789738938.2-A15 4789738938.2-A15

RF Exposure Report FCC ID: 2AY5GMK020011002115 RF Exposure Measurement The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) F= Frequency in MHz Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. EUT Operation condition EUT was enabled to transmit and receive at lowest, middle and highest channels. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Wi-Fi + BLE Mode BLE: 2402-2480MHz Wi-Fi: 2412-2462MHz BLE and WIFI do not support simultaneous transmission Detector PEAK BLE 6±1dBm 11b 17±1dBm 11g 22±1dBm 11n20 21±1dBm ANT Gain (G) Antenna gain: 1dBi (gain of antenna in linear scale=1.259) GFSK1.2592402 75.01190.00126 1 11b1.2592437 1863.09570.01581 1 11g1.2592412 23199.52620.05000 1 11n201.2592437 22158.48930.03972 1 Power Density (mW/cm²) Limit (mW/cm ²) Protocol ANT Gain(gain of antenna in linear scale) Channel Frequenc y (MHz) Output Power to Antenna (dBm) Output Power to Antenna (mW) According to the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value 0.05 distance 20cm. This is less than the limit 1, so compliance the RF exposure requirement..

10-EM-F0878 – Issue 2.0 The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. This report does not imply that the product(s) has met the criteria for certification. FCC PART 15 SUBPART C CERTIFICATION TEST REPORT For LED Lamp MODEL NUMBER: MK-020011002115, MK-020011002118 FCC ID: 2AY5GMK020011002115 REPORT NUMBER: 4789738938.2-14 ISSUE DATE: Mar 06, 2021 Prepared for Zhejiang MEKA Electric Co.,Ltd NO.8 Canghai Road,Lihai Town,Binhai New City,Shaoxing,zhejiang Province Prepared by UL-CCIC COMPANY LIMITED No. 2, Chengwan Road, Suzhou Industrial Park, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4789738938.2-14 Page 2 of 52 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. 10-EM-F0878 – Issue 2.0 Revision History Rev. Issue Date Revisions Revised By -- 03/06/2021 Initial Issue -- REPORT NO.: 4789738938.2-14 Page 3 of 52 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. 10-EM-F0878 – Issue 2.0 Summary of Test Results Clause Test Items FCC Rules Test Results 1 6dB Bandwidth FCC Part 15.247 (a) (2) Pass 2 Peak Conducted Output Power FCC Part 15.247 (b) (3) Pass 3 Power Spectral Density FCC Part 15.247 (e) Pass 4 Conducted Band edge And Spurious emission FCC Part 15.247 (d) Pass 5 Radiated Bandedge and Spurious Emission FCC Part 15.247 (d) FCC Part 15.209 FCC Part 15.205 Pass 6 Conducted Emission Test For AC Power Port FCC Part 15.207 Pass 7 Antenna Requirement FCC Part 15.203 Pass Remark: 1) The measurement result for the sample received is <Pass> according to < CFR 47 FCC PART 15 SUBPART C, when <Accuracy Method> decision rule is applied. REPORT NO.: 4789738938.2-14 Page 4 of 52 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. 10-EM-F0878 – Issue 2.0 TABLE OF CONTENTS ATTESTATION OF TEST RESULTS ............................................................................................ 6 1. TEST METHODOLOGY .......................................................................................................... 7 2. FACILITIES AND ACCREDITATION ..................................................................................... 7 3. CALIBRATION AND UNCERTAINTY .................................................................................... 8 3.1. MEASURING INSTRUMENT CALIBRATION .................................................................. 8 3.2. MEASUREMENT UNCERTAINTY ................................................................................... 8 4. EQUIPMENT UNDER TEST ................................................................................................... 9 4.1. DESCRIPTION OF EUT ................................................................................................... 9 4.2. MAXIMUM OUTPUT POWER .......................................................................................... 9 4.3. CHANNEL LIST ................................................................................................................ 9 4.4. TEST CHANNEL CONFIGURATION ............................................................................. 10 4.5. THE WORSE CASE POWER SETTING PARAMETER ................................................ 10 4.6. DESCRIPTION OF AVAILABLE ANTENNAS ................................................................ 10 4.7. WORST-CASE CONFIGURATIONS ............................................................................. 10 4.8. DESCRIPTION OF TEST SETUP .................................................................................. 11 5. MEASURING INSTRUMENT AND SOFTWARE USED ...................................................... 12 6. MEASUREMENT METHODS ............................................................................................... 14 7. ANTENNA PORT TEST RESULTS ...................................................................................... 15 7.1. ON TIME AND DUTY CYCLE ........................................................................................ 15 7.2. 6 dB BANDWIDTH .......................................................................................................... 17 7.3. PEAK CONDUCTED OUTPUT POWER ....................................................................... 20 7.4. POWER SPECTRAL DENSITY ..................................................................................... 21 7.5. CONDUCTED BANDEDGE AND SPURIOUS EMISSIONS ......................................... 24 8. RADIATED TEST RESULTS ................................................................................................ 29 8.1. LIMITS AND PROCEDURE ........................................................................................... 29 8.2. RESTRICTED BANDEDGE ........................................................................................... 35 8.3. SPURIOUS EMISSIONS 30MHz-1GHz ......................................................................... 39 8.4. SPURIOUS EMISSIONS Above 1 GHz ......................................................................... 41 8.5. SPURIOUS EMISSIONS BELOW 30M .......................................................................... 47 9. AC POWER LINE CONDUCTED EMISSIONS .................................................................... 48 REPORT NO.: 4789738938.2-14 Page 5 of 52 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. 10-EM-…

Text truncated - open the document above for the full version.

10-EM-F0878 – Issue 2.0 The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. This report does not imply that the product(s) has met the criteria for certification. FCC PART 15 SUBPART C CERTIFICATION TEST REPORT For LED Lamp MODEL NUMBER: MK-020011002115, MK-020011002118 FCC ID: 2AY5GMK020011002115 REPORT NUMBER: 4789738938.2-15 ISSUE DATE: Mar 10, 2021 Prepared for Zhejiang MEKA Electric Co.,Ltd NO.8 Canghai Road,Lihai Town,Binhai New City,Shaoxing,zhejiang Province Prepared by UL-CCIC COMPANY LIMITED No. 2, Chengwan Road, Suzhou Industrial Park, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.:
4789738938.2-15 Page 2 of 93 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. 10-EM-F0878 – Issue 2.0 Revision History Rev. Issue Date Revisions Revised By -- 03/10/2021 Initial Issue -- REPORT NO.:
4789738938.2-15 Page 3 of 93 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. 10-EM-F0878 – Issue 2.0 Summary of Test Results Clause Test Items FCC Rules Test Results 1 6 dB Bandwidth FCC 15.247 (a) (2) Pass 2 Peak Conducted Output Power FCC 15.247 (b) (3) Pass 3 Power Spectral Density FCC 15.247 (e) Pass 4 Conducted Bandedge and Spurious Emission FCC 15.247 (d) Pass 5 Radiated Bandedge and Spurious Emission FCC 15.247 (d) FCC 15.209 FCC 15.205 Pass 6 Conducted Emission Test For AC Power Port FCC 15.207 Pass 7 Antenna Requirement FCC 15.203 Pass Remark: 1) The measurement result for the sample received is <Pass> according to < CFR 47 FCC PART 15 SUBPART C, when <Accuracy Method> decision rule is applied. REPORT NO.:
4789738938.2-15 Page 4 of 93 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. 10-EM-F0878 – Issue 2.0 TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 6 2. TEST METHODOLOGY .......................................................................................................... 7 3. FACILITIES AND ACCREDITATION ..................................................................................... 7 4. CALIBRATION AND UNCERTAINTY .................................................................................... 8 4.1. MEASURING INSTRUMENT CALIBRATION .................................................................. 8 4.2. MEASUREMENT UNCERTAINTY ................................................................................... 8 5. EQUIPMENT UNDER TEST ................................................................................................... 9 5.1. DESCRIPTION OF EUT ................................................................................................... 9 5.2. MAXIMUM OUTPUT POWER .......................................................................................... 9 5.3. CHANNEL LIST ................................................................................................................ 9 5.4. TEST CHANNEL CONFIGURATION ............................................................................. 10 5.5. THE WORSE CASE CONFIGURATIONS ..................................................................... 10 5.6. DESCRIPTION OF AVAILABLE ANTENNAS ................................................................ 10 5.7. DESCRIPTION OF TEST SETUP .................................................................................. 11 6. MEASURING INSTRUMENT AND SOFTWARE USED ...................................................... 12 7. MEASUREMENT METHODS ............................................................................................... 14 8. ANTENNA PORT TEST RESULTS ...................................................................................... 15 8.1. ON TIME AND DUTY CYCLE ........................................................................................ 15 8.2. 6 dB DTS BANDWIDTH ................................................................................................. 18 8.2.1. 802.11b MODE ........................................................................................................ 19 8.2.2. 802.11g MODE ........................................................................................................ 21 8.2.3. 802.11n HT20 MODE .............................................................................................. 23 8.3. PEAK CONDUCTED OUTPUT POWER ....................................................................... 25 8.3.1. 802.11b MODE ........................................................................................................ 26 8.3.2. 802.11g MODE ........................................................................................................ 26 8.3.3. 802.11n HT20 MODE .............................................................................................. 26 8.4. POWER SPECTRAL DENSITY ..................................................................................... 27 8.4.1. 802.11b MODE ........................................................................................................ 28 8.4.2. 802.11g MODE ........................................................................................................ 30 8.4.3. 802.11n HT20 MODE .............................................................................................. 32 8.5. CONDUCTED BANDEDGE AND SPURIOUS EMISSIONS ......................................... 34 8.5.1.…

Text truncated - open the document above for the full version.

4789738938.2-A13 Setup Photos Model: MK-020011002115 Conducted Emission Radiated Spurious Emission 9KHz ~ 30MHz 4789738938.2-A13 Radiated Spurious Emission 30MHz ~ 1000MHz Radiated Spurious Emission Above 1GHz X 4789738938.2-A13 Y Z
