2AYAF-P20Dog Training Collar

Important Safety Information Safety during on-leash training.It is vitally important that you and your dog remain safe while learning during on-leash training. Your dog should be on a strong leash, long enough for him to attempt to chase an object, but short enough for him not to reach a road or other unsafe area. You must also be physically strong enough to restrain your dog when he tries to chase. -1- Risk of skin damage. Please read and follow the instructions in this manual. Proper fit of the collar is important. A collar worn for too long or made too tight on the pet's neck may cause skin damage. Ranging from redness to pressure ulcers; this condition is commonly known as bed sores. • Avoid leaving the collar on the dog for more than 12 hours per day. • When possible re-position the collar on the pet's neck every 1 to 2 hours. • Check the fit to prevent excessive pressure; follow the instructions in this manual. • Never connect a leash to the electronic collar; it will cause excessive pressure on the contacts. • When using a separate collar for a leash, don't put pressure on the electronic collar. • Wash the dog's neck area and the contacts of the collar weekly with a damp cloth. -2- How the System Works -5- The Remote Training Collar is easy to use with an advanced digital display that tells you exactly what level of stimulation you are using. The Remote Training Collar assists you in controlling your pet without a leash. At the push of a button,your Remote Transmitter sends a signal activating your dog's Receiver Collar. He receives a safe but annoying stimulation. He'll quickly learn the association between his behavior and your correction in no time, you'll have a better-behaved pet. The Remote Training Collar has proven safe, comfortable, and effective for both small and large dog breeds at least 6 months of age and over 8 lbs. Using the Remote Trainer consistently and correctly, any basic obedience commands can be taught and will help to correct many misbehaviors that your pet exhibits. Operating Guide Step 1 To turn the Remote Transmitter on To turn the Receiver Collar on Press and Hold the power button for 2 seconds, the Receiver Collar will vibrate and indicator will start to blink in green. -7- Press and Hold the channel button for 2 seconds to power off the Remote Transmitter. 1.Press and Hold the channel button for 2 seconds to power on the Remote Transmitter. The backlight will be on. 2.Backlight will be off at 15 seconds if there is no operation. 3.LCD display will be turned off at 2 minutes if there is no operation.Any press on the button of the Remote Transmitter will activate the Remote Transmitter. Press and Hold the power button for 2 seconds, the Receiver Collar will beep and GREEN LED indicator turns off. Step 2 How the Transmitter Buttons Work Step 3 How to Fit the Receiver Collar -8- 1.Press / / once to send a vibration,shock and warning tone command to Receiver Collar. 2.Press and Hold / / ,Receiver Collar will have a consecutive warning tone ,shock and vibration and stop after 10 seconds. Notes: Do not suggest to press and hold / / for long time to avoid physical or psychological hurt to your pet. Press the Shock Button,then adjust Shock level by pressing the Up & Down Button. Press the Vibration Button, then adjust Vibration level by pressing the Up & Down Button. Press the Warning Tone Button, then select Tone types by pressing the Up & Down Button. Notes: You can also press button select the stimulation you want, then adjust the levels by pressing the Up & Down Button. Step 4 -10- Step 6 Indicates battery level Indicates stimulation levels of Shock/Vibration and types of Warning Tone Remote Transmitter Function Indicates Shock Mode is on Indicates Warning Tone Mode is on Indicates Vibration Mode is on Remote Transmitter Indicator Light Response Press , deliver warning tone command to Receiver Collar Charging the Remote Transmitter Remote Transmitter is fully charged -12- Indicates keypad is locked. Red LED on when pressing the button FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

(Shenzhen Smartpet Technology Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AYAF-P20 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ( Jia Yaya) Rev 11/20/07

Shenzhen Smartpet Technology Co., Ltd. Model Difference 2020-11-30 EUT NAME: Dog Training Collar FCC ID: 2 AYA F-P20 MODEL : P20 P30 、P40、P50、P60、 OT2 、OT3 All the model are the same circuit and RF module, except model names. . Regards Sincerely Client’s signature Client’s name / title : Jia Yaya / Manager Contact information / address: Floor 3, B Building, No. 25, Xingda Road, Egongling Community, Pinghu Street,Longgang District, Shenzhen,Guangdong, China

(Shenzhen Smartpet Technology Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for FCC ID: 2AYAF-P20 To Whom It May Concern: We, the undersigned, hereby authorize Alan Mei at Shenzhen BCTC Testing Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Alan Mei of Shenzhen BCTC Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, ( Jia Yaya)

External Photos

Label & label location Size:40*20mm Dog Training Collar FCC ID: 2 AYA F-P20 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Label location

Internal Photos Antenna

No.：BCTC/RF-EMC-005 Page: 1 of 35 Edition：A.2 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2010000764E Applicant: Shenzhen Smartpet Technology Co., Ltd. Product Name: Dog Training Collar Model/Type Ref.: P20 Tested Date: Oct. 20, 2020 to Nov. 09, 2020 Issued Date: Nov. 09, 2020 Report No.: BCTC2010000764E No.：BCTC/RF-EMC-005 Page: 2 of 35 Edition：A.2 FCC ID : 2AYAF-P20 The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: Dog Training Collar Trademark: N/A Model/Type Ref.: P20 P30、P40、P50、P60、 OT2 、OT3 Prepared For: Shenzhen Smartpet Technology Co., Ltd. Address: Floor 3, B Building, No. 25, Xingda Road, Egongling Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Manufacturer: Shenzhen Smartpet Technology Co., Ltd. Address: Floor 3, B Building, No. 25, Xingda Road, Egongling Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Sample Received Date: Oct. 20, 2020 Sample tested Date: Oct. 20, 2020 to Nov. 09, 2020 Issue Date: Nov. 09, 2020 Report No.: BCTC2010000764E Test Standards FCC Part15.231 ANSI C63.10-2013 Test Results PASS Tested by: Approved by: Sam zeng/Project Handler Zero Zhou/Reviewer Report No.: BCTC2010000764E No.：BCTC/RF-EMC-005 Page: 3 of 35 Edition：A.2 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ............................................................ 5 2. TEST SUMMARY ..................................................... 6 3. MEASUREMENT UNCERTAINTY ....................................... 7 4. PRODUCT INFORMATION AND TEST SETUP ........................... 8 4.1 Product Information ..................................................... 8 4.2 Test Setup Configuration ................................................ 8 4.3 Support Equipment ..................................................... 9 4.4 Channel List ........................................................... 9 4.5 Test Mode ............................................................. 9 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 10 5.1 Test Facility ........................................................... 10 5.2 Test Instrument Used .................................................. 10 6. CONDUCTED EMISSIONS ............................................ 13 6.1 Block Diagram Of Test Setup ........................................... 13 6.2 Limit ................................................................. 13 6.3 Test procedure ........................................................ 13 6.4 EUT operating Conditions .............................................. 13 6.5 Test Result ........................................................... 14 7. RADIATED EMISSIONS .............................................. 16 7.1 Block Diagram Of Test Setup ........................................... 16 7.2 Limit ................................................................. 17 7.3 Test procedure ........................................................ 18 7.4 EUT operating Conditions .............................................. 19 7.5 Test Result ........................................................... 20 8. BANDWIDTH TEST .................................................. 24 8.1 Block Diagram Of Test Setup ........................................... 24 8.2 Limit ................................................................. 24 30KHZ .................................................................. 24 8.3 Test procedure ........................................................ 24 8.4 EUT operating Conditions .............................................. 24 8.5 Test Result ........................................................... 25 9. CALCULATION OF AVERAGE FACTOR ................................ 26 10. DWEELL TIME ...................................................... 28 10.1 Block Diagram Of Test Setup .......................................... 28 10.2 Limit ................................................................ 28 10.3 Test procedure ....................................................... 28 10.4 Test Result .......................................................... 29 11. ANTENNA REQUIREMENT ........................................... 30 11.1 STANDARD REQUIREMENT .......................................... 30 11.2 EUT ANTENNA ...................................................... 30 12. EUT PHOTOGRAPHS ................................................ 31 Report No.: BCTC2010000764E No.：BCTC/RF-EMC-005 Page: 4 of 35 Edition：A.2 13. EUT TEST SETUP PHOTOGRAPHS ................................... 33 (Note: N/A means not applicable) Report No.: BCTC2010000764E No.：BCTC/RF-EMC-005 Page: 5 of 35 Edition：A.2 1. VERSION Report No. Issue Date Description Approved BCTC2010000764E Nov. 09, 2020 Original Valid Report No.: BCTC2010000764E No.：BCTC/RF-EMC-005 Page: 6 of 35 Edition：A.2 2. TEST SUMMARY The Product has been tested according to the following specifications: No. Test Parameter Clause No Results 1 Conducted Emission §15.207 PASS 2 Fundamental &Radiated Spurious Emission Measurement 15.209,15.231b PASS 3 Occupy Bandwidth 15.231c PASS 4 Dwell time 15.231a PASS 5 Antenna Requirement 15.203 PASS Report No.: BCTC2010000764E No.：BCTC/RF-EMC-005 Page: 7 of 35 Edition：A.2 3. MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the Product as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level usi…

Text truncated - open the document above for the full version.

Report No.: BCTC2010000764E 1. EUT TEST SETUP PHOTOGRAPHS Spurious emissions Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 1 of 2 Report No.: BCTC2010000764E Conducted emissions ※※※※※ END OF REPORT ※※※※※ Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 2 of 2
