2AYAQ-T1006Smart padlock

（TT LOCK APP） Fingerprint Padlock User Manual Funtion：TT LOCK APP Matching products：padlock，traffic lock,U-shaped glass lock,drawer lock,cabinet lock Battery：Lithium battery Fingerprint capacity：20pcs working temperature：-10°C-45°C Working humidity：40％RH-90％RH USB Charging：5v，Micro USB Interface 1.2 Product Technical Parameters Fingerprint reading speed≤0.5 Seconds 1. Connect the APP Before you do the following, make sure your phone's Bluetooth is turned on and your phone and padlock are within a reasonable distance. It is recommended to operate within 5 meters. Search for "TT LOCK" APP in the application market and download it. Open the APP. 1.2 Find the type of lock and click. 1.3 Meanwhile,place your finger on the padlock fingerprint area and turn on Bluetooth 1.5 Prompt connection success 2. Fingerprint management 1.1 Click the "三" icon in the upper right corner of the app home page， click”+”icon add lock. 1.4 Enter the Bluetooth search interface, wait a few seconds, the device name appears, click "OK" to connect. 1.6 Bluetooth unlock, click the unlock button on the device interface to unlock. In the initial state, the device has no fingerprint information. Any finger can unlock.After adding APP,using fingerprint requires mobile phone operation to add . 2.2 Delete fingerprint information Enter the device management interface and click Fingerprint picture-,click in the upper right corner “ ”-click add fingerprint-name fingerprint- setting time effectine.Place your finger on the fingerprint area to start fingerprint recognition according to the APP prompt. The sampling is successful, the blue light is on, the red light is faulty, and the continuous sampling is successful 6 times, indicating that the entry is successful. He can send the key to others and specify the time limit,select the time limit premanent or single Bluetooth key permission . After entering the fingerprint successfully, you can unlock it with the corresponding fingerprint. The green light is on and the buzzer sounds when unlocking is successful. Failure lights up red. 2.1 Add fingerprint settings Open the app, click the corresponding device on the homepage, enter the management interface, click fingerprint picture and click the fingerprint name to be deleted. After adding a lock successfully ,the lock administrator will have the highest management authority of the lock. 4.Product initialization 3. Fingerprint lock charging instructions 3.3 Low voltage protection: 3.1 When charging, the red light is on; when fully charged, it lights up in green. 4.2 Click delete in the red bar in the bottom,click delete on the pop up interface,enter the password when adding the app.press ok ,initialization successful. After unlocking operation, if the battery voltage is lower than 3.6V. The low- voltage alarm time is about 5 s, the red light flashes once per second, and the buzzer sounds. 4.1 Open the app,enter the unlock interface ,click settings,enter the next interface 。 When the battery voltage is lower than 3.2 V, it will enter a low-voltage protection state. No matter if you touch the fingerprint or the button, there will be no response. Now you need to plug in USB to charge to restore normal working status. You can query the unlocking record. 3.2 Low voltage alarm FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

ZHEJIANG BAlMA LOCK CO., LTD Model Difference Product Name: Smart padlock Model Number: T1006, T1004 FCC Identifier: 2AYAQ-T1006 All the models are the same circuit and RF module, except the mode names and outlook color. Regards Sincerely Client’s signature Client’s name / title: Yongkui Xu/ Manager Contact information: Pudong lndustrial Area, Pujiang, Zhejiang, China

ZHEJIANG BAlMA LOCK CO., LTD 1/1 Letter of Authorization Company: ZHEJIANG BAlMA LOCK CO., LTD Address: Pudong lndustrial Area, Pujiang, Zhejiang, China Product Name: Smart padlock Model Number: T1006, T1004 FCC Identifier: 2AYAQ-T1006 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Yongkui Xu Date: 2020-11-25 Title: Manager Signature of applicant:

ZHEJIANG BAlMA LOCK CO., LTD 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020-11-25 Subject: Request for Confidentiality FCC ID: 2AYAQ-T1006 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Yongkui Xu Title: Manager

Model: T1006

Size:15*10mm M/N: T1006 FCC ID: 2AYAQ-T1006 Label location

antenna location Model: T1006

Global United Technology Services Co., Ltd. Report No.: GTSL202011000209 Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 29 + TEST REPORT Applicant: ZHEJIANG BAlMA LOCK CO., LTD Address of Applicant: Pudong lndustrial Area, Pujiang, Zhejiang, China Manufacturer: ZHEJIANG BAlMA LOCK CO., LTD Address of Manufacturer: Pudong lndustrial Area, Pujiang, Zhejiang, China Equipment Under Test (EUT) Product Name: Smart padlock Model No.: T1006 T1004 Trade Mark: N/A FCC ID: 2AYAQ-T1006 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 Date of sample receipt: Nov. 20, 2020 Date of Test: Nov. 20, 2020 - Nov. 25, 2020 Date of report issued: Nov. 25, 2020 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202009000161 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 29 2 Version Version No. Date Description 00 Nov. 25, 2020 Original Prepared By: Date: Nov. 25, 2020 Project Engineer Check By: Date: Nov. 25, 2020 Reviewer Report No.: GTS202009000161 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 29 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 7 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.4 DEVIATION FROM STANDARDS ............................................................................................................ 7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................. 7 5.6 TEST FACILITY ................................................................................................................................... 8 5.7 TEST LOCATION ................................................................................................................................. 8 5.8 ADDITIONAL INSTRUCTIONS ................................................................................................................ 8 6 TEST INSTRUMENTS LIST ..................................................................................................................... 9 7 TEST RESULTS AND MEASUREMENT DATA .................................................................................... 11 7.1 ANTENNA REQUIREMENT ................................................................................................................... 11 7.2 CONDUCTED EMISSIONS ................................................................................................................... 12 7.3 RADIATED EMISSION METHOD ........................................................................................................... 15 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 17 7.3.2 Spurious emissions .................................................................................................................... 18 7.3.3 Bandedge emissions .................................................................................................................. 23 7.4 20DB OCCUPY BANDWIDTH .............................................................................................................. 24 8 TEST SETUP PHOTO ............................................................................................................................ 26 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 28 Report No.: GTS202009000161 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 29 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 Pass Field strength of the fundamental signal 15.249 (a) Pass Spurious emissions 15.249 (a) (d)/15.209 Pass Band edge 15.249 (d)/15.205 Pass 20dB Occupied Bandwidth 15.215 (c) …
