2AYCQ-TE-304B-A12GEM-OX-GU

User Manual TE-304B-A12 GEM-OX-GU Product manuals Packing list Product model listing subsidiary note TE-304B-A12 1 PCS GPS device 1 copy of user manual American version TE-304B-E12 1 PCS GPS device 1 copy of user manual European version Introduction GPS device connects to car battery. Do not jump over the fuse to connect to car battery directly(see figure). Note: THE ACC must be connected, otherwise the device will go to sleep. Battery TE304B Device ACC ACC(Red) ON START OFF GND(Black) B+(Yellow) SIM card Introduction Guide Open the back card cover, insert the SIM card into the slot, and then close the buckle.( You need to buy the card by yourself) Type of card supported: Nano SIM card. Unplug The SIM Card Open the black card cover with the disassembly tool,pull out the card slot cover by hand,remove the sim card,and then close the card cover. Statements and Warnings: The device card cover is locked with special screws, and can only be opened by professional installation tools and installation personnel. LED Indications After the device is successful power on,the current device status can be checked through the LED indicator of the device. Indicator light Indicator status Status Green GSM indicator FLICKER SLOWLY （200MS ON/1800MS OFF） NETWORK SEARCHING FLICKER SLOWLY （1800MS ON/200MS OFF） IDLE FLICKER QUICKLY （125MS ON /125MS OFF） DATA TRANSFER IS ONGOING ALWAYS ON VOICE CALLING Blue GPS indicator FLICKER QUICKLY （200MS ON/200MS OFF） GPS IS NOT FIX FLICKER SLOWLY （1000MS ON/4000MS OFF） GPS FIX ALWAYS OFF GPS FAULTY Signal Line Connector 12 Pin Signal Line Wire Name Remarks colour 1 B+ 9-90V DC 黄色 2 GND GND 黑色 3 Din1(ACC) 0 up to 90V tolerance Din1 0-8V is logic '0', ACC off Din1 8-90V is logic '1', ACC on 红色 4 Dout1 Open-drain with Imax = 350mA 灰色 5 Din2 0 up to 90V tolerance Din2 0-8V is logic '0' Din2 8-90V is logic '1' 橙色 6 12V out 12V output Imax = 120mA 粉黑色 7 Din3 0 up to 90V tolerance Din3 0-8V is logic '0' Din3 8-90V is logic '1' 蓝色 8 RS232_TX1 橙白色 9 RS232_RX1 蓝白色 10 Dout2 - Open-drain with Imax = 350mA 棕色 11 1-wire 紫色 12 Ain1 0V to B+ (90V) 98.5% accuracy 12bit ADC. 绿色 Install The Device 1.Installation Precautions （a）Do not install the device near the source of interference; （b）No metal objects above the device; 2.The recommended installation position is shown in the figure Device Parameter Setting 1. Send a text message to the device through a mobile phone; The parameter setting is completed after the mobile phone receives a feedback SMS from the device. 2. Setup accepted:SMS prompt "IMEI,executed,conf" Setup failed: SMS prompt "IMEI,failed,conf" Setting Failure Solution 1.If the wireless signal is low, the setting may fail.please check GSM LED indicator. 2.please check the sent SMS content according to device feedback SMS. 3.Please try to reset the device by pressing the Reset button,and set the parameter again. Set Parameters by SMS Setting Parameters Send short message content SOS conf set sos *** SOS1 conf set sos1 *** SOS2 conf set sos2 *** SOS3 conf set sos3 *** apnname conf set apnname *** apnusername conf set apnusername *** apnpassword conf set apnpassword *** reportoninterval conf set reportoninterval val(val range 5-86400) gsensorxsens conf set gsensorxsens val(val range 0- 10000) gsensorysens conf set gsensorysens val(val range 0- 10000) gsensorzsens conf set gsensorzsens val(val range 0- 10000) gsensorcrashsens conf set gsensorcrashsens val(val range 0-10) protocoltype conf set protocoltype val(0-wialon,2- GEM) ipaddr conf set ipaddr *** port conf set port *** Other SMS Commands 1.update app: device firmware upgrade 2.reset: restart the device 3.factory: restore factory settings （Please contact Thinkpower for more SMS commands.） Precautions 1. The main body of the product contains batteries, please do not approach the fire source or cast it Into the water to avoid the risk of fire. 2. The product may cause damage when it is put into the water. Basic Parameters Battery: Li-Polymer，400mAh Operating Voltage: 9V to 90V DC Dimensions: 108.4*58.9*18.7mm Weight: 160g（Contains the tail line） Waterproof Grade: IP67 Operating Temperature: -20~60°C FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment should be installed and operated with minimum distance 20cm between the radiator&your body. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co- located or operating in conjunction with any other antenna or transmitter.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2020-12-14> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AYCQ-TE-304B-A12 TE-304B-A12 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Sander Loosveld/ Chief Product Officer Company: GEM ONE NV Address: Brabantstraat 15, 8790 Waregem Belgium Phone: +32 (0) 56 43 64 00 Fax: N/A E-Mail: [email protected]

GEM ONE NV Brabantstraat 15, 8790 Waregem Belgium Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2020-12-14 To whom it may concern: We, GEM ONE NV the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AYCQ-TE-304B-A12 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Sander Loosveld/Chief Product Officer Company: GEM ONE NV Address: Brabantstraat 15, 8790 Waregem Belgium Phone: +32 (0) 56 43 64 00 Fax: N/A E-Mail: [email protected]

FCC ID: 2AYCQ-TE-304B-A12 FCC ID: 2AYCQ-TE-304B-A12 FCC ID: 2AYCQ-TE-304B-A12

FCC ID: 2AYCQ-TE-304B-A12 Label and Location Label and Location

FCC ID: 2AYCQ-TE-304B-A12 FCC ID: 2AYCQ-TE-304B-A12 FCC ID: 2AYCQ-TE-304B-A12

RF Exposure evaluation FCC ID: 2AYCQ-TE-304B-A12 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information TE-304B-A12 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: Bluetooth / FPC Antenna 0.0dBi for 2402-2480MHz; WCDMA&LTE / FPC Antenna 3.0dBi for WCDMA Band II; 2.0dBi for WCDMA Band IV; 1.0dBi for WCDMA Band V; 1.0 dBi for LTE Band 5/12/13/14/71; 2.0 dBi for LTE Band 4/66; 3.0 dBi for LTE Band 2; 5. Manufacturing Tolerance < WCDMA > Band Mode The Tune-up Maximum Power (Customer Declared)(dBm) W-B2 AMR 12.2kbps 23.0±1 RMC 12.2Kbps 23.0±1 HSDPA Subtest-1 22.0±1 HSDPA Subtest-2 21.0±1 HSDPA Subtest-3 21.0±1 HSDPA Subtest-4 20.0±1 HSUPA Subtest-1 22.0±1 HSUPA Subtest-2 21.0±1 HSUPA Subtest-3 21.0±1 HSUPA Subtest-4 20.0±1 HSUPA Subtest-5 20.0±1 HSUPA+ 21.0±1 AMR 12.2kbps 23.0±1 RMC 12.2Kbps 23.0±1 W-B4 HSDPA Subtest-1 22.0±1 HSDPA Subtest-2 21.0±1 HSDPA Subtest-3 21.0±1 HSDPA Subtest-4 20.0±1 HSUPA Subtest-1 22.0±1 HSUPA Subtest-2 21.0±1 HSUPA Subtest-3 21.0±1 HSUPA Subtest-4 20.0±1 HSUPA Subtest-5 20.0±1 HSUPA+ 21.0±1 W-B5 AMR 12.2kbps 23.0±1 RMC 12.2Kbps 23.0±1 HSDPA Subtest-1 22.0±1 HSDPA Subtest-2 21.0±1 HSDPA Subtest-3 21.0±1 HSDPA Subtest-4 20.0±1 HSUPA Subtest-1 22.0±1 HSUPA Subtest-2 21.0±1 HSUPA Subtest-3 21.0±1 HSUPA Subtest-4 20.0±1 HSUPA Subtest-5 20.0±1 HSUPA+ 21.0±1 < LTE > Mode Target Power QPSK 1RB 50%RB 100%RB LTE BAND 2 22.0±2.0 22.0±2.0 22.0±2.0 LTE BAND 4 22.0±2.0 22.0±2.0 22.0±2.0 LTE BAND 5 22.0±2.0 22.0±2.0 22.0±2.0 LTE BAND 12 22.0±2.0 22.0±2.0 22.0±2.0 LTE BAND 13 22.0±2.0 22.0±2.0 22.0±2.0 LTE BAND 14 22.0±2.0 22.0±2.0 22.0±2.0 LTE BAND 66 22.0±2.0 22.0±2.0 22.0±2.0 LTE BAND 71 22.0±2.0 22.0±2.0 22.0±2.0 Mode Target Power 16QAM 1RB 50%RB 100%RB LTE BAND 2 21.0±2.0 21.0±2.0 21.0±2.0 LTE BAND 4 21.0±2.0 21.0±2.0 21.0±2.0 LTE BAND 5 21.0±2.0 21.0±2.0 21.0±2.0 LTE BAND 12 21.0±2.0 21.0±2.0 21.0±2.0 LTE BAND 13 21.0±2.0 21.0±2.0 21.0±2.0 LTE BAND 14 21.0±2.0 21.0±2.0 21.0±2.0 LTE BAND 66 21.0±2.0 21.0±2.0 21.0±2.0 LTE BAND 71 21.0±2.0 21.0±2.0 21.0±2.0 <BT> GFSK (Peak)1Mbps Channel Channel 00 Channel 19 Channel 39 Target (dBm) 0.0 0.0 0.0 Tolerance ±(dB) 1.0 1.0 1.0 GFSK (Peak)2Mbps Channel Channel 00 Channel 19 Channel 39 Target (dBm) 0.0 0.0 0.0 Tolerance ±(dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of WIFI antenna is 0dBi, the gain of BT antenna is 0dBi.the RF power density can be obtained. [BT] Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW BLE 1Mbps 1.0 1.2589 0.00 1.000 0.0003 1.0000 BLE 2Mbps 1.0 1.2589 0.00 1.000 0.0003 1.0000 [WCDMA&LTE] Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW WCDMA B2 24.0 251.1886 3.00 1.9953 0.0998 1.0000 WCDMA B4 24.0 251.1886 2.00 1.5849 0.0792 1.0000 WCDMA B5 24.0 251.1886 1.00 1.2589 0.0629 0.5493 LTE B2 24.0 251.1886 3.00 1.9953 0.0998 1.0000 LTE B4 24.0 251.1886 2.00 1.5849 0.0792 1.0000 LTE B5 24.0 251.1886 1.00 1.2589 0.0629 0.5493 LTE B12 24.0 251.1886 1.00 1.2589 0.0629 0.4660 LTE B13 24.0 251.1886 1.00 1.2589 0.0629 0.5180 LTE B14 24.0 251.1886 1.00 1.2589 0.0629 0.5253 LTE B66 24.0 251.1886 2.00 1.5849 0.0792 1.0000 LTE B71 24.0 251.1886 1.00 1.2589 0.0629 0.4420 Remark: 1. Output power (Peak) including turn-up tolerance; 2. Output power was adjust to duty cycle at 100% if measured duty cycle less than 98%; 3. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. Summary simultaneous transmission results The sample supports 2 antennas for BT and WCDMA&LTE. The antenna 0 and antenna 1 can transmit simultaneous. According to KDB447498 for Transmitters used in mobile exposure conditions for simultaneous transmission operations; ∑ of MPE ratios ≤ 1.0 Antenna 0 for BT and Antenna 1 for WCDMA&LTE Modulation Type MPE ant0 (mW/cm 2 ) MPE ant1 (mW/cm 2 ) ∑MPE ratios Limit Results BT&WCDMA&LTE 0.0003 0.0998 0.1001 1.0 PASS 8. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for th…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20201201009-1-1 2AYCQ-TE-304B-A12 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Dec.01, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : GEM ONE NV Address ............................................ : Brabantstraat 15, 8790 Waregem, Belgium Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: GEM-OX-GU Trade Mark ....................................... : GEM One Manufacturer ................................... : Shenzhen Think Power Technology Co., Ltd. Model/Type reference....................... : TE-304B-A12 Listed Models .................................. : N/A Ratings ............................................. : DC 3.7V From Battery and DC 9-90V from External circuit Modulation ....................................... : GFSK Hardware version ............................. : TE304B_V1.2 Software version .............................. : TE304B-1.0.8.20201020 Frequency .......................................... From 2400MHz to 2483.5MHz Result................................................ : PASS Report No.: GTS20201201009-1-1 Page 2 of 34 T E S T R E P O R T Test Report No. : GTS20201201009-1-1 Dec.01, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : GEM-OX-GU Model /Type : TE-304B-A12 Listed Models : N/A Applicant : GEM ONE NV Address : Brabantstraat 15, 8790 Waregem, Belgium Manufacturer : Shenzhen Think Power Technology Co., Ltd. Address : 6 /F, Bldg A, Jian Xing Technology Building, Shahe Xi Rd 3151#, Nanshan District, Shenzhen, GD Province, China. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20201201009-1-1 Page 3 of 34 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 SUM M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Special Accessories 6 2.8 Related Submittal(s) / Grant (s) 6 2.9 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 11 4.3 Maximum Peak Output Power 17 4.4 Power Spectral Density 18 4.5 6dB Bandwidth 21 4.6 Out-of-band Emissions 24 4.7 Antenna Requirement 28 5 T E S T S E T U P P H OT O S O F T H E E U T ......................................... 29 6 P H O T O S O F T H E E U T ........................................................... 30 Report No.: GTS20201201009-1-1 Page 4 of 34 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03r05: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: GTS20201201009-1-1 Page 5 of 34 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Nov. 03, 2020 Testing commenced on : Nov. 03, 2020 Testing concluded on : Dec. 01, 2020 2.2 Product Description Product Description: GEM-OX-GU Model/Type reference: TE-304B-A12 Power supply: DC 3.7V From Battery and DC 9-90V from External circuit Testing sample ID： GTS20201201009-1-1#(Engineer sample), GTS20201201009-1-2#(Normal sample) Bluetooth BLE Supported type: Bluetooth low Energy Modulation: GFSK Operation frequency: 2400MHz to 2483.5MHz Channel number: 40 Channel separation: 2 MHz Antenna type: FPC antenna Antenna gain: 0.00 dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 3.7V From Battery and DC 9-90V from External circuit 2.4 Short description of the Equipment und…

Text truncated - open the document above for the full version.

FCC ID: 2AYCQ-TE-304B-A12
