2AYFPOUT-PIPillar outdoor 3 CCT

Made in China Fabriqué en Chine Hecho en China Residential use only Usage résidentiel seulement Uso residencial solamente Indoor and outdoor use Usage intérieur et exterieur Uso interior y exterior LED Wall light - Pillar TM INSTRUCTION MANUAL IMPORTANT: READ CAREFULLY AND KEEP. luminaire mural à DEL - Pillar MC MANUEL D’INSTRUCTIONS IMPORTANT: À LIRE ATTENTIVEMENT ET À CONSERVER. luminaria LED de pared - Pillar MR MANUAL DE INSTRUCCIONES IMPORTANTE: LEER DETENIDAMENTE Y CONSERVAR. Rev. 05-05-2022 Model / Modèle / Modelo: OUT-PI-BL 2 ITEM PIÈCE PIEZA DESCRIPTION DESCRIPTION DESCRIPCIÓN QUANTITY QUANTITÉ CANTIDAD A Mounting bracket Support de montage Soporte de montaje × 1 B Mounting Screw Vis de support de montage Tornillo roscado x 2 C Wire connector Capuchon de connexion Conector de cable × 3 D Canopy screw Vis de la base Tornillo de dosel × 2 E Rubber washer Rondelle en caoutchouc Lavadora de caucho × 2 F Light fixture Luminaire Lámpara × 1 INCLUDED HARDWARE MATÉRIEL INCLUS HERRAMIENTAS INCLUIDO 3 STEP-BY-STEP INSTALLATION INSTALLATION DÉTAILLÉE INSTALACIÓN ETAPA POR ETAPA 1 Screwdriver Tournevis 2 Destornillador Sealant Scellant Sellante WHAT YOU WILL NEED VOUS AUREZ BESOIN LO QUE NECESITARÁ ACC DEF 4 WARNING: Risk of electrical shock. Turn off breaker at the panel. Switch off the main electrical supply from the fuse box/ circuit breaker before installing the unit or doing any maintenance. Can be installed outdoors / indoors. AVERTISSEMENT: Risque de décharge électrique. Éteindre le disjoncteur sur le panneau électrique. Il est important de couper l’alimentation électrique du disjoncteur avant de procéder à l’installation ou à l’entretien. Peut s’installer à l’extérieur / intérieur. ADVERTENCIA: Riesgo de descarga eléctrica. Desconectar la corriente eléctrica del panel (disyuntor). Desconecte la instalación eléctrica en la caja de circuitos/ disyuntor antes de instalar esta unidad o realizar tareas de mantenimiento en ella. Se puede instalar en exteriores / interiores. IMPORTANT The installer and/or user must read, understand and follow these instructions before installing the product. This product must be properly installed before it is used. If instructions are not followed, the manufacturer will not be held responsible for any problems or product malfunction. Failure to follow installation and/or operating instructions voids the warranty. We recommend that this product be installed by a certified electrician. In some states or provinces, it is a legal requirement for this type of product to be installed by a certified electrician, according to the electrical and building codes effective in the region where the unit is used. IMPORTANT Avant l’installation de ce produit, l’utilisateur et/ou l’installateur doit avoir lu et compris ces instructions. Cet appareil doit être installé convenablement avant usage. Si ces instructions ne sont pas respectées, le fabricant ne pourra être tenu responsable d’aucun problème ou de dysfonctionnement du produit. Le non-respect des instructions d’installation et/ou d’utilisation annulera la garantie en vigueur. Nous recommandons que ce produit soit installé par un électricien certifié. Dans certains États ou provinces, il est légalement requis que ce type de produit soit installé par un électricien certifié conformément aux codes de l’électricité et du bâtiment en vigueur. IMPORTANTE El instalador o usuario debe leer detenidamente las instrucciones antes de instalar el producto y seguirlas fielmente. El producto debe estar correctamente instalado antes de su utilización. Si no siguen las instrucciones, el fabricante no se hará responsable de problemas o de un funcionamiento incorrecto del producto. Si no sigue las instrucciones de instalación o de uso, se anulará la garantía. Le recomendamos que el producto sea instalado por un electricista certificado. En algunos estados o provincias, se requiere por ley que este tipo de producto sea conectado por un electricista certificado siguiendo los códigos eléctricos y arquitectónicos de la región. CAUTION ATTENTION ATENCIÓN 5 MINIMUM CLEARANCE ESPACE MINIMUM ESPACIO MÍNIMO 1 1.2 m (4 ft / pi / pies) Plan the desired height Planifier la hauteur désirée Alcanzar la altura deseada F ! 6 MOUNTING BRACKET INSTALLATION INSTALLATION DU SUPPORT DE MONTAGE INSTALACIÓN DEL SOPORTE DE MONTAJE 2 AC 7 WIRE CONNECTION CONNECTION DES FILS CONECTANDO LOS CABLES 3 A Ground wire (G) Fil de mise à la terre (G) Cable de tierra (G) White (N) Blanc (N) Blanco (N) Black (L) Noir (L) Negro (L) C F 8 MOUNTING BRACKET INSTALLATION INSTALLATION DU SUPPORT DE MONTAGE INSTALACIÓN DEL SOPORTE DE MONTAJE 4 ED F 9 TUNABLE WHITE TECHNOLOGY TECHNOLOGIE DE BLANC RÉGLABLE TECNOLOGÍA DE BLANCO AJUSTABLE 6 3000K 4000K 5000K PEEL OFF 3000K4000K5000K PEEL OFF F 10 F FOR OUTDOOR INSTALLATION (SEALANT) POUR INSTALLATION EXTÉRIEUR (SCELLANT) PARA INSTALACIÓN EN EXTERIORES (SELLAD) 5 13 Operation is subject to the following two conditions: 1. this device may not cause interference, and 2. this device must accept any inteference, including inteference that may cause undesired operation of the device. L’exploitation est autorisée aux deux conditions suivantes : 1. l’appareil ne doit pas produire de brouillage; et 2. l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. La operación está sujeta a las dos condiciones siguientes: 1. este dispositivo no puede causar interferencias perjudiciales, y 2. este dispositivo debe aceptar cualquier interferencia recibida, incluídas las interferencias que puedan provocar un funcionamiento no deseado. CANADA (IC) 14 WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, a…

Text truncated - open the document above for the full version.
