AXON PC STICK OPERATING SYSTEM RAM STORAGE WIFI BLUETOOTH MINI DISPLAY PORT HD OUTPUT USB PORTS TYPE-C MICRO SD CARD DEVICE DIMENSIONS WINDOWS 10 PRO 4 GB / 8 GB EMMC 64 GB / 128 GB AC3165/7265 ,SUPPORT DUAL BAND 2.4G&5G AC BLUETOOTH 4.0 DP 1.2 4K@60FPS (X1) 1.4 4K@30 FPS (APL) / (X1) 2.0 4K@60 FPS (GML) (X1) 3.1 (X2) 3.0 X1 512 GB 5.1 IN X 1.5 IN 2.PLUG-IN DEVICE TO TV OR MONITOR HD INPUT. 3.POWER ON YOUR DEVICE. 4. MAKE SURE YOUR MONITOR OR TV IS IN THE CORRECT INPUT MODE. 5-ENJOY YOUR FULL COMPUTER HOW TO SET UP 1.CONNECT THE POWER ADAPTER. AXON TECHNOLOGIES.COM FCC Statement ： This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1)this device may not cause harmful interference, and 2) this device must accept any interference received,including interference that may cause undesired operation.This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: - Reorient the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

DATE : 2021-01-13 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with QUANTUM GLOBAL CONSULTING LLC. and 2336 ne 172nd St. North Miami Beach, FL 33160 Signature: Name: Julia Motchalova Title: General manager Company: QUANTUM GLOBAL CONSULTING LLC.

Differences Declaration To whom concern, We company QUANTUM GLOBAL CONSULTING LLC. hereby declares: The product models CA2221, CA1221, CA1222, CA1223, CA1224, CA2222, CA2223, CA2224 are identical in the same PCB layout, interior structure and electrical circuits, The difference between different models is EMMC capacity, OS and model name for commercial purpose. Differences are listed as bellow. Model EMMC capacity OS CA2221 64GHz Windows 10 Pro CA2222 64GHz Windows 10 IOT CA2223 64GHz Linux CA2224 64GHz Chrome CA1221 32GHz Windows 10 Pro CA1222 32GHz Windows IOT CA1223 32GHz Linux CA1224 32GHz Chrome Authorized signature: Date: 2021-01-13

DATE : 2021-01-13 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AYI3-CA2221 Product Name: Value Stick Request for Confidentiality To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description FCC Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature: Name: Julia Motchalova Title: General manager Company: QUANTUM GLOBAL CONSULTING LLC.

Test Model No.: CA2221

CA2221 Model No: 2AYI3-CA2221

Size:45*10mm Lable location

Test Model No.: CA2221 WiFi Antenna 2 WiFi/BT Antenna 1

FCC ID: 2AYI3-CA2221 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation Wireless function Output power to antenna (dBm) Antenna Gain(dBi) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result BT EDR 9.122 2.00 8.170 0.00258 1.000 PASS BT BLE 4.704 2.00 2.954 0.00093 1.000 PASS 2.4G WiFi 19.04 5.00(MIMO) 80.168 0.05043 1.000 PASS 5.1G WiFi 15.62 5.00(MIMO) 36.475 0.02295 1.000 PASS 5.8G SRD 16.30 5.00(MIMO) 42.658 0.02684 1.000 PASS Directional gain of MIMO = G ANT + 10 log(N ANT ) dBi=5.00dBi

Global United Technology Services Co., Ltd. Report No.: GTSL202101000065F04 Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 53 TEST REPORT Applicant: QUANTUM GLOBAL CONSULTING LLC. Address of Applicant: 2336 ne 172nd St. North Miami Beach, FL 33160 Manufacturer/Factory: QUTHC Limited Address of Manufacturer/Factory: 7th Floor, Building C, Longsheng Industrial Park, Huiyang District, Huizhou City, Guangdong province (516211) P.R.China Equipment Under Test (EUT) Product Name: Value Stick Model No.: CA2221,CA1221,CA1222,CA1223,CA1224,CA2222,CA2223, CA2224 Trade Mark: AXON FCC ID: 2AYI3-CA2221 Applicable standards: FCC CFR Title 47 Part 15 Subpart E Section 15.407 Date of sample receipt: Oct. 20, 2020 Date of Test: Oct. 20 - Nov. 19, 2020 Date of report issue: Nov. 19, 2020 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSL202101000065F04 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 53 2 Version Version No. Date Description 00 Nov. 19, 2020 Original Prepared By: Date: Nov. 19, 2020 Project Engineer Check By: Date: Nov. 19, 2020 Reviewer Report No.: GTS202011000007F04 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 53 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................. 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 7 5.3 TEST FACILITY .................................................................................................................................... 7 5.4 TEST LOCATION .................................................................................................................................. 7 5.5 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.6 DEVIATION FROM STANDARDS ............................................................................................................. 7 5.7 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA .................................................................................... 10 7.1 ANTENNA REQUIREMENT: .................................................................................................................. 10 7.2 CONDUCTED EMISSIONS ................................................................................................................... 11 7.3 EMISSION BANDWIDTH AND 99% OCCUPIED BANDWIDTH .................................................................... 14 7.4 PEAK TRANSMIT POWER ................................................................................................................... 24 7.5 POWER SPECTRAL DENSITY .............................................................................................................. 28 7.6 BAND EDGE ...................................................................................................................................... 36 7.7 RADIATED EMISSION ......................................................................................................................... 41 7.8 FREQUENCY STABILITY ...................................................................................................................... 51 8 TEST SETUP PHOTO ............................................................................................................................ 53 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 53 Report No.: GTS202011000007F04 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 53 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 PASS AC Power Line Conducted Emission 15.207 PASS Peak Transmit Power 15.407(a)(1) PAS…
