Duo Talk Wireless Microphone Instruction Manual Item: 7143-69, Model: SC001 Functions: 1/ Windproof net 2/ Microphone Indicator 3/ Microphone charging port 4/ Microphone clip 5/ Power on/off 6/ Receiver LED indicator 7/ Receiver port to Mobile 8/ Receiver charge port 9/ Lighting Receiver What’s included: 1x Microphone 2x Receivers 1x Charging case 1x Mesh case Instruction： 1/ Put the receiver to the phone. Note: OPPO/VIVO/IQ00/Realme mobile phone needs to go for setting to search for “OTO” to turn on OTO power supply. 2/ Press the button to power on the microphone, the indicator light will turn green. 3/ Plug the receiver of Type C on the mobile phone, the receiver indicator red light on, the microphone now is connected to mobile. Open the phone camera, live App or aother Apps to use the microphone to receive sound. Note: The Type C receiver not include battery inside, Once the mobile is at low power with receiver plug in, you can charge the mobile phone through the charge port from the receiver. Microphone Status Operation Light status Power on Press button 5 for 3S Red and green flash Power off Press button 5 for 3S No light Pairing / Red and green flash Connected / Green light on Mute Press button 5 one time Green light flash Cancel mute Press button 5 one time Green light on Mix sound Press button 5 twice Red light flash Monitor Plug into the Type C receiver No light No connection / No light Lower power Working status Red light flashes each 10s Charging Type C Red light on, light off after fully charge Type C Receiver Status Operation Light status Power on Plug on device Red Light on Power off Pull out the device Light off Pairing / Red light flash slowly Connected / Red light on FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. IC Statement This device contains licence-exempt transmitter (s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L' appareil ne doit pas produire de brouillage; (2) L' appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d' en compromettre le fonctionnement. Radio Frequency Exposure Statement for IC: This equipment complies with IC exposure limits set forth for an uncontrolled environment. This equipment can be used in portable exposure conditions. Déclaration d'exposition aux radiofréquences pour IC: Cet équipement est conforme aux limites d'exposition IC établies pour un environnement non contrôlé. Cet équipement peut être utilisé dans des conditions d'exposition portables. CAN ICES-3 (B) / NMB-3 (B) This Class B digital apparatus complies with Canadian ICES-003. (Cet appareil numérique de la Classe B conforme à la norme NMB-003 du Canada). Name of the Distributor: Leedsworld Inc Address of the Distributor: 400 Hunt Valley Road, New Kensington, PA 15068 USA. FCC ID: IC: Made in China
