2AYOTHSA-M001SHP MPP 1.51 Pen

User manual Model:HSA-M001S The net content: 11g Voltage : DC 5Vcc Working Current : 0.08mA Battery: AAAA battery * Please use with cautious,avoiding falling, colliding, soaking, etc. Replace the refill * Do not remove the refill frequently and repalce the new one when it is worn or broken. Pull the refill with the clip and pull it out. 1 Put into the new refill and press lightly. 2 * The manual is for reference only and does not constitute a commitment of any kind. The manufacturer reserves the right to modify this manual, to the extent permitted by law. Button Refill Sever life The sever life of the product is: 10 years HSA-M001S HP MPP 1.51 PEN Made in China NR:XXXX-XX-X-XXXX X-XXXXX Security Information Warranty Service 1. The product comes with a warranty against defect in materials and workmanship under normal use for a term of 12 months beginning from the date of delivery of the produact. 2. This warranty dose not apply and the authorized service center will charge the repair reasonably if the customer or accessory is: i. damaged by Man-made; ii. no warranty card and valid invoice, or the warranty period has been exceeded; iii. the warranty card does not match the product model designation, or has been altered; iv. damaged by failure to use, maintained product as instructions; v. disassembly and repair of products without authorize , or immersion in water or damage to products; vi.other force majeure such as earthquakes, floods, etc. Warranty Card Product model: Date of purchase: username: contact number: Dealer number: Stamp of dealer: Please use the battery approved by the device manufacturer and supplied with this model. The equipment should be stored in -10~50 and 10%~90% RH, should be used in 5~35 and 20%~80% RH. The equipment should be stored in clean, cool and dry room, should avoid direct sunlight, avoid contact with corrosive substances. If the battery leakage, do not let the skin or eye contact to the leakage of liquid. If inadvertent contact, please rinse with clean water immediately, and go to the hospital for medical treatment. If a battery is in use, charging or preservation process have discoloration, deformation, abnormal heating and other anomalies, please stop using and replace the new battery. The provisions of this equipment, please handle the battery and other accessories according to local, cannot use them as garbage disposal. If the battery is not handled properly, it may cause the battery to explode. Do not use the equipment in the gray, damp, dirty place, in order to avoid circuit faults caused by internal equipment. Do not let children or pets biting equipment or accessories, lest cause damage or lead to equipment failure. The equipment and accessories contain small parts, please send the equipment and accessories in the reach of infants. Infants may unintentionally swallow small parts and cause asphyxiation or other dangers. Please keep the drying equipment and accessories. Do not use a microwave oven or a blower and other external heating equipment to dry it. Please do not make the equipment and accessories are falling, extrusion or a strong impact, so as not to damage the equipment and accessories, lead to equipment failure. Do not use harsh chemicals, cleaning agent or detergent cleaning equipment or accessories. Please use a clean, dry soft cloth to wipe the equipment or its accessories. Do not disassemble or refit equipment and accessories, otherwise the equipment and accessories will not be in the scope of free warranty, equipment failure please contact an authorized service center. To ensure the best performance of the equipment and avoid dangerous or illegal conditions, please read and follow the following safety information. "This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help." This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment complies with FCC and Industry Canada radiation exposure limits set forth for an uncontrolled environment. Cet équipement est conforme à l'exposition aux rayonnements FCC & Industry Canada limites établies pour un environnement non contrôlé. FCC Statement IC statement

Confidentiality Letter Date: 26 May 2021 Subject: Confidentiality Request for FCC ID: 2AYOTHSA-M001S and IC ID: 26903-HSAM001S Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality RequestedExhibit Short Term PermanentBlock Diagrams Short TermExternal Photos Short Term PermanentInternal Photos Short Term PermanentOperation Description/Theory of Operation Short Term PermanentPart List/Tune-Up Procedure Short Term PermanentSchematics Short TermTest Setup Photos Short Term PermanentUser’s Manual Shenzhen qianfenyi intelligent technology co., LTD. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04- 1705. Sincerely, By:Zusha Wei / Certification Engineer (Signature)(Print name/Title)

Photo Documentation Page 1 of 3 Report No.: CN21GDDB 001 Product: HP MPP 1.51 Pen Type Designation: HSA-M001S Rev. 0 Fig.1 External view-01 Fig.2 External view-02

C B A 12 C 345678 B E D E D A 9 料号： 123456789 完成日期 审 核 设 计 机 型 颜 色 底 色 材 质 pantone 877C 透明 72025000xx MPP1.51 25#透明PET哑油+可移胶 黄丽 2021- 04- 28 49*16mm 25#亮面PET+哑油 pantone 877 红色为背胶区 手撕位处无胶 格拉辛底纸 出标方向 ABC ABC ABC 文字转曲 CAN ICES-003(B) / NMB-003(B) HP MPP 1.51 Pen Model No./型号/型號: HSA-M001S Manufacturer制造商/製造商: Shenzhen qianfenyi intelligent technology Co., LTD. FCC ID: 2AYOTHSA-M001S IC: 26903-HSAM001S XXXXXXXXXXX KCC ID:R-R-hpk-HSA-M001S ANATEL ID:XXXXXXXXX HP, HQ-TRE, 71025 Boeblingen, Germany HP Inc UK Ltd, Regulatory Enquiries, Earley West, 300 Thames Valley Park Drive, Reading, RG6 1PT

Photo Documentation Page 2 of 3 Report No.: CN21GDDB 001 Product: HP MPP 1.51 Pen Type Designation: HSA-M001S Rev. 0 Fig.3 Internal view-01 Fig.4 Internal view-02 Photo Documentation Page 3 of 3 Report No.: CN21GDDB 001 Product: HP MPP 1.51 Pen Type Designation: HSA-M001S Rev. 0 Fig.5 PCB view-01 Fig.6 PCB view-02

Report No.: BTL-FCCP-1-2104C006A Page 1 of 25 FCC Radio Test Report FCC ID: 2AYOTHSA-M001S Project No. : 2104C006A Equipment : HP MPP 1.51 Pen Brand Name : HP Test Model : HSA-M001S Series Model : N/A Applicant : Shenzhen qianfenyi intelligent technology co., LTD. Address : 302, Floor 3 Chuangxingda Commercial Center Building, Bao'an District, Shenzhen, Guangdong, P.R. China Date of Receipt : Apr. 09, 2021 May 13, 2021 Date of Test : Apr. 13, 2021 ~ Apr. 21, 2021 Issued Date : May 25, 2021 Report Version : R00 Test Sample : Engineering Sample No.: DG2021040155 Standard(s) : FCC Part15, Subpart C (15.209) ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Sheldon Ou Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-1-2104C006A Page 2 of 25 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2104C006A Page 3 of 25 Table of Contents Page REPORT ISSUED HISTORY 4 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 1.3 TEST ENVIRONMENT CONDITIONS 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS 8 3 . RADIATED EMISSION TEST 9 3.1 LIMIT 9 3.2 TEST PROCEDURE 9 3.3 DEVIATION FROM TEST STANDARD 9 3.4 TEST SETUP 10 3.5 EUT OPERATING CONDITIONS 11 3.6 TEST RESULT - 9 KHZ TO 30 MHZ 11 3.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 11 4 . MEASUREMENT INSTRUMENTS LIST 12 5 . EUT TEST PHOTO 13 APPENDIX A - RADIATED EMISSION - 9 KHZ TO 30 MHZ 16 APPENDIX B - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 23 Report No.: BTL-FCCP-1-2104C006A Page 4 of 25 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Compared with original report(BTL-FCCP-1-2104C006), changed the Operation Frequency in chapter 2.1. It does not affect the test results, the rest are kept the same. May 25, 2021 Report No.: BTL-FCCP-1-2104C006A Page 5 of 25 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.209) Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions N/A N/A ------ 15.209(a) Radiated Emissions APPENDIX A APPENDIX B PA SS ------ ------ Bandwidth N/A N/A ------ NOTE: (1) “N/A” denotes test is not applicable to this device. Report No.: BTL-FCCP-1-2104C006A Page 6 of 25 1.1 TEST FACILITY The test facilities used to collect the test data in this report is at the location of No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. BTL's Test Firm Registration Number for FCC: 357015 BTL's Designation Number for FCC: CN1240 1.2 MEASUREMENT UNCERTAINTY ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)) The BTL measurement uncertainty as below table: A. Radiated emissions Measurement: Test Site Method Measurement Frequency Range Ant. H / V U, (dB) DG-CB03 CISPR 9kHz ~ 30MHz - 3.02 30MHz ~ 200MHz V 4.26 30MHz ~ 200MHz H 3.38 200MHz ~ 1,000MHz V 3.98 200MHz ~ 1,000MHz H 3.94 Note: Unless specifically mentioned, the uncertainty of measurement has not been taken into account to declare the compliance or non-compliance to the specification. 1.3 TEST ENVIRONMENT CONDITIONS Test Item Temperature Humidity Test Voltage Tested By Radiated Emissions-9K-30MHz 25°C 60% DC 1.5V Kwork Guo Radiated Emissions-30 MHz to 1000MHz 24°C 54% DC 1.5V Ryker Chen Report No.: BTL-FCCP-1-2104C006A Page 7 of 25 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment HP MPP 1.51 Pen Brand Name HP Te s t Model HSA-M001S Series Model N/A Model Difference(s) N/A Power Source Battery supplied. Power Rating DC 1.5V Operation Frequency 18-44KHz, 160-210KHz Note: 1. For a more detailed features de…
