2AYQ6-N21USB WIFI ADAPTER

Shenzhenshi Jiujiadianzishangwuyouxiangongsi
USB WIFI ADAPTER - FCC ID 2AYQ6-N21 - Shenzhenshi Jiujiadianzishangwuyouxiangongsi
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Jun 25, 2023
Application Purpose
Original Equipment
Date of Application
Jun 25, 2023
Equipment Note
USB WIFI ADAPTER
Frequency Range
2412.00000000 - 2462.00000000
Company
Shenzhenshi Jiujiadianzishangwuyouxiangongsi
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

Test Report

↗
↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

USB WIFI ADAPTER Warning:This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:--Reorient or relocate the receiving antenna.--Increase the separation between the equipment and receiver.--Connect the equipment into an outlet on a circuit different.from that to which the receiver is connected.--Consult the dealer or an experienced radio/TV technician for help.NOTE: This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitt er The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Attestation Statements

Shenzhenshi Jiujiadianzishangwuyouxiangongsi 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: Shenzhenshi Jiujiadianzishangwuyouxiangongsi Address: Longgangqu Bujijiedao Jihualu,393 Hao Haifadasha 220, shenzhen Guangdong, China Product Name: USB WIFI ADAPTER FCCID: 2AYQ6-N21 Model(s): N21, N36, N35, N34, N33, N32, N30, M32, M21, M33, M34, M35, M36, M37, M39, L21, L20, L23, L32, L33, L35 2.911(d)(5)(i) EquipmentType We, [Shenzhenshi Jiujiadianzishangwuyouxiangongsi] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: John kang Date: Jun. 20, 2023 Signature: Title and Company name: Manager/ Shenzhenshi Jiujiadianzishangwuyouxiangongsi NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Attestation Statements

Shenzhenshi Jiujiadianzishangwuyouxiangongsi 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhenshi Jiujiadianzishangwuyouxiangongsi Address: Longgangqu Bujijiedao Jihualu,393 Hao Haifadasha 220, shenzhen Guangdong, China Product Name: USB WIFI ADAPTER FCCID: 2AYQ6-N21 Model(s): N21, N36, N35, N34, N33, N32, N30, M32, M21, M33, M34, M35, M36, M37, M39, L21, L20, L23, L32, L33, L35 2.911(d)(5)(ii) Applicant filing We, [Shenzhenshi Jiujiadianzishangwuyouxiangongsi] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: John kang Date: Jun. 20, 2023 Signature: Title and Company name: Manager/ Shenzhenshi Jiujiadianzishangwuyouxiangongsi NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Cover Letter(s)

Shenzhenshi Jiujiadianzishangwuyouxiangongsi Agent Authorization Company name: Shenzhenshi Jiujiadianzishangwuyouxiangongsi Address: Longgangqu Bujijiedao Jihualu,393 Hao Haifadasha 220, shenzhen Guangdong, China Product Name: USB WIFI ADAPTER Model Number(s): N21, N36, N35, N34, N33, N32, N30, M32, M21, M33, M34, M35, M36, M37, M39, L21, L20, L23, L32, L33, L35 Product Description: USB WIFI ADAPTER We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jun. 20, 2023 Name: John kang Title: Manager Company: Shenzhenshi Jiujiadianzishangwuyouxiangongsi

Cover Letter(s)

Shenzhenshi Jiujiadianzishangwuyouxiangongsi Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jun. 20, 2023 Subject; Request for Confidentiality FCC ID: 2AYQ6-N21 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure software security Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: John kang Title: Manager

Cover Letter(s)

Shenzhenshi Jiujiadianzishangwuyouxiangongsi Model Difference Declaration To Whom It May Concern, We, Shenzhenshi Jiujiadianzishangwuyouxiangongsi (USB WIFI ADAPTER); Trade Mark: Nineplus, livingthing, mobelly, Model Number: N21, N36, N35, N34, N33, N32, N30, M32, M21, M33, M34, M35, M36, M37, M39, L21, L20, L23, L32, L33, L35; All model’s the function, software and electric circuit are the same, only with the shape of the shell, the color and model named different. Test sample model: N21 Please contact me if you have any question. Signature: Date: Jun. 20, 2023 Name: John kang Title: Manager

External Photos

Annex A External Photos Model No.: N21 Page 1 of 3 Model No.: N21 Page 2 of 3 Model No.: N21 Page 3 of 3

ID Label/Location Info

FCC ID LABEL: Ca: 10mm x 30mm Label Location FCC ID: 2AYQ6-N21

Internal Photos

Annex B Internal Photos Model No.: N21 Page 1 of 3 Model No.: N21 Page 2 of 3 Antenna 2 Antenna 1 Model No.: N21 Page 3 of 3

Test Report

Report No.: HK2306062322-1E FCC TEST REPORT Test report On Behalf of Shenzhenshi Jiujiadianzishangwuyouxiangongsi For USB WIFI ADAPTER Model No.: N21, N36, N35, N34, N33, N32, N30, M32, M21, M33, M34, M35, M36, M37, M39, L21, L20, L23, L32, L33, L35 FCC ID: 2AYQ6-N21 Prepared for : Shenzhenshi Jiujiadianzishangwuyouxiangongsi Longgangqu Bujijiedao Jihualu,393 Hao Haifadasha 220, shenzhen Guangdong, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Jun. 06, 2023 ~ Jun. 14, 2023 Date of Report: Jun. 14, 2023 Report Number: HK2306062322-1E Page 2 of 111 Report No.: HK2306062322-1E TEST RESULT CERTIFICATION Applicant’s name .................. : Shenzhenshi Jiujiadianzishangwuyouxiangongsi Address .................................. : Longgangqu Bujijiedao Jihualu,393 Hao Haifadasha 220, shenzhen Guangdong, China Manufacture's Name ............. : Shenzhenshi Jiujiadianzishangwuyouxiangongsi Address .................................. : Longgangqu Bujijiedao Jihualu,393 Hao Haifadasha 220, shenzhen Guangdong, China Product description Trade Mark: Nineplus, livingthing, mobelly Product name ............................ : USB WIFI ADAPTER Model and/or type reference . : N21, N36, N35, N34, N33, N32, N30, M32, M21, M33, M34, M35, M36, M37, M39, L21, L20, L23, L32, L33, L35 Standards .............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.247 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Jun. 06, 2023 ~ Jun. 14, 2023 Date of Issue ........................................... : Jun. 14, 2023 Test Result ............................................... : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 111 Report No.: HK2306062322-1E TABLE OF CONTENTS 1. Test Result Summary ............................................................................... 5 1.1. TEST PROCEDURES AND RESULTS ............................................................................................... 5 1.2. INFORMATION OF THE TEST LABORATORY ................................................................................. 5 1.3. MEASUREMENT UNCERTAINTY ............................................................................................................... 6 2. EUT Description ........................................................................................ 7 2.1. GENERAL DESCRIPTION OF EUT ................................................................................................... 7 2.2. CARRIER FREQUENCY OF CHANNELS ..................................................................................................... 8 2.3. OPERATION OF EUT DURING TESTING .................................................................................................... 8 2.4. DESCRIPTION OF TEST SETUP ....................................................................................................... 9 3. Genera Information ................................................................................. 10 3.1. TEST ENVIRONMENT AND MODE ............................................................................................................ 10 3.2. DESCRIPTION OF SUPPORT UNITS ........................................................................................................ 11 4. Test Results and Measurement Data .................................................... 12 4.1. CONDUCTED EMISSION ........................................................................................................................ 12 4.2. MAXIMUM CONDUCTED OUTPUT POWER .............................................................................................. 16 4.3. EMISSION BANDWIDTH ......................................................................................................................... 19 4.4. POWER SPECTRAL DENSITY ................................................................................................................ 34 4.5. CONDUCTED BAND EDGE AND SPURIOUS EMISSION MEASUREMENT ..................................................... 50 4.6. RADIATED SPURIOUS EMISSION MEASUREMENT ................................................................................... 76 4.7. ANTENNA REQUIREMENT ........................................................................................................... 108 4.8. PHOTOS OF THE EUT ................................................................................................................... 111 Page 4 of 111 Report No.: HK2306062322-1E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release Jun. 14, 2023 Jason Zhou Page 5 of 111 Report No.: HK2306062322-1E 1. Test Result Summary 1.1. TEST PROCEDURES AND RESULTS Requirement CFR 47 Section Result Antenna requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(3) PASS 6dB Emission Bandwidth §15.247 (a)(2) PASS Power Spectral Density §15.247 (e) PASS Band Edge 1§5.247(d) PASS Spurious Emission §15.205/§15.209 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 1.2. INFORMATION OF …

Text truncated - open the document above for the full version.

Test Report

Page 48 of 111 Report No.: HK2306062322-1E 802.11ax (HT40) Modulation Lowest channel Middle channel Highest channel Page 49 of 111 Report No.: HK2306062322-1E For MIMO antenna port 1+antenna port 2 TX 802.11b Mode Frequency Power Density (dBm) Limit (dBm) Result 2412 MHz / 8 / 2437 MHz / 8 / 2462 MHz / 8 / TX 802.11g Mode 2412 MHz / 8 / 2437 MHz / 8 / 2462 MHz / 8 / TX 802.11n/HT20 Mode 2412 MHz -2.15 8 PASS 2437 MHz -1.74 8 PASS 2462 MHz -1.68 8 PASS TX 802.11n/HT40 Mode 2422 MHz -2.95 8 PASS 2437 MHz -4.85 8 PASS 2452 MHz -4.67 8 PASS TX 802.11ax/HT20 Mode 2412 MHz -2.21 8 PASS 2437 MHz -2.58 8 PASS 2462 MHz -1.56 8 PASS TX 802.11ax/HT40 Mode 2422 MHz -4.74 8 PASS 2437 MHz -4.65 8 PASS 2452 MHz -4.69 8 PASS Note: 1 Result unit: W, The end result is converted to units of dBm. Note: This product supports antenna 1 and antenna 2 launches, but only support 802.11 n/ax for MIMO mode, not support 802.11 b and 802.11 g for MIMO mode. Page 50 of 111 Report No.: HK2306062322-1E 4.5. Conducted Band Edge and Spurious Emission Measurement 4.5.1. Test Specification Test Requirement: FCC Part15 C Section 15.247 (d) Test Method: KDB558074 Limit: In any 100 kHz bandwidth outside of the authorized frequency band, the emissions which fall in the non-restricted bands shall be attenuated at least 20 dB / 30dB relative to the maximum PSD level in 100 kHz by RF conducted measurement and radiated emissions which fall in the restricted bands, as defined in Section 15.205(a), must also comply with the radiated emission limits specified in Section 15.209(a). Test Setup: Test Mode: Transmitting mode with modulation Test Procedure: 1. The testing follows FCC KDB Publication No. 558074 D01 15.247 Meas Guidance v05r02. 2. The RF output of EUT was connected to the spectrum analyzer by RF cable and attenuator. The path loss was compensated to the results for each measurement. 3. Set to the maximum power setting and enable the EUT transmit continuously. 4. Set RBW = 100 kHz, VBW=300 kHz, Peak Detector. Unwanted Emissions measured in any 100 kHz bandwidth outside of the authorized frequency band shall be attenuated by at least 20 dB relative to the maximum in-band peak PSD level in 100 kHz when maximum peak conducted output power procedure is used. If the transmitter complies with the conducted power limits based on the use of RMS averaging over a time interval, the attenuation required under this paragraph shall be 30 dB instead of 20 dB per 15.247(d). 5. Measure and record the results in the test report. 6. The RF fundamental frequency should be excluded against the limit line in the operating frequency band. Test Result: PASS Page 51 of 111 Report No.: HK2306062322-1E 4.5.2. Test Instruments RF Test Room Equipment Manufacturer Model Serial Number Calibration Date Calibration Due Spectrum analyzer Agilent N9020A HKE-048 Feb. 17, 2023 Feb. 16, 2024 Signal generator Agilent N5183A HKE-071 Feb. 17, 2023 Feb. 16, 2024 RF Cable (9KHz-26.5GHz) Tonscend 170660 N/A Feb. 17, 2023 Feb. 16, 2024 RF automatic control unit Tonscend JS0806-2HKE-060 Feb. 17, 2023 Feb. 16, 2024 Note: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to international system unit (SI). Page 52 of 111 Report No.: HK2306062322-1E 4.5.3. Test Data Chain 1 802.11b Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2412MHz) Spurious emission(2462MHz) Page 53 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 54 of 111 Report No.: HK2306062322-1E 802.11g Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2412MHz) Spurious emission(2462MHz) Page 55 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 56 of 111 Report No.: HK2306062322-1E 802.11n (HT20) Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2412MHz) Spurious emission(2462MHz) Page 57 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 58 of 111 Report No.: HK2306062322-1E 802.11n (HT40) Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2422MHz) Spurious emission(2452MHz) Page 59 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 60 of 111 Report No.: HK2306062322-1E 802.11ax (HT20) Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2412MHz) Spurious emission(2462MHz) Page 61 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 62 of 111 Report No.: HK2306062322-1E 802.11ax (HT40) Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2422MHz) Spurious emission(2452MHz) Page 63 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 64 of 111 Report No.: HK2306062322-1E Chain 2 802.11b Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2412MHz) Spurious emission(2462MHz) Page 65 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz)

Test Report

Page 66 of 111 Report No.: HK2306062322-1E 802.11g Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2412MHz) Spurious emission(2462MHz) Page 67 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 68 of 111 Report No.: HK2306062322-1E 802.11n (HT20) Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2412MHz) Spurious emission(2462MHz) Page 69 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 70 of 111 Report No.: HK2306062322-1E 802.11n (HT40) Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2422MHz) Spurious emission(2452MHz) Page 71 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 72 of 111 Report No.: HK2306062322-1E 802.11ax (HT20) Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2412MHz) Spurious emission(2462MHz) Page 73 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 74 of 111 Report No.: HK2306062322-1E 802.11ax (HT40) Modulation Lowest Channel Highest Channel Band Edge Band Edge Spurious emission(2422MHz) Spurious emission(2452MHz) Page 75 of 111 Report No.: HK2306062322-1E Spurious emission(2437MHz) Page 76 of 111 Report No.: HK2306062322-1E 4.6. Radiated Spurious Emission Measurement 4.6.1. Test Specification Test Requirement: FCC Part15 C Section 15.209 Test Method: ANSI C63.10: 2013 Frequency Range: 9 kHz to 25 GHz Measurement Distance: 3 m Antenna Polarization: Horizontal & Vertical Operation mode: Transmitting mode with modulation Receiver Setup: Frequency Detector RBW VBW Remark 9kHz- 150kHzQuasi-peak200Hz 1kHz Quasi-peak Value 150kHz- 30MHz Quasi-peak9kHz 30kHz Quasi-peak Value 30MHz-1GHzQuasi-peak120KHz300KHz Quasi-peak Value Above 1GHz Peak 1MHz 3MHz Peak Value Peak 1MHz 10Hz Average Value Limit: Frequency Field Strength (microvolts/meter) Measurement Distance (meters) 0.009-0.490 2400/F(KHz) 300 0.490-1.705 24000/F(KHz) 30 1.705-30 30 30 30-88 100 3 88-216 150 3 216-960 200 3 Above 960 500 3 Frequency Field Strength (microvolts/meter) Measurement Distance (meters) Detector Above 1GHz 500 3 Average 5000 3 Peak Test setup: For radiated emissions below 30MHz 30MHz to 1GHz 0.8m Page 77 of 111 Report No.: HK2306062322-1E Above 1GHz Test Procedure: 1. For the radiated emission test below 1GHz: The EUT was placed on a turntable with 0.8 meter above ground. The EUT was set 3 meters from the interference receiving antenna, which was mounted on the top of a variable height antenna tower. The EUT was arranged to its worst case and then tune the antenna tower (from 1 m to 4 m) and turntable (from 0 degree to 360 degrees) to find the maximum reading. A pre-amp and a high PASS filter are used for the test in order to get better signal level. For the radiated emission test above 1GHz: Place the measurement antenna on a turntable with 1.5 meter above ground, which is away from each area of the EUT determined to be a source of emissions at the specified measurement distance, while keeping the measurement antenna aimed at the source of emissions at each frequency of significant emissions, with polarization oriented for maximum response. The measurement antenna may have to be higher or lower than the EUT, depending on the radiation pattern of the emission and staying aimed at the emission source for receiving the maximum signal. The final measurement antenna elevation shall be that which maximizes the emissions. The measurement antenna elevation for maximum emissions shall be restricted to a range of heights of from 1 m to 4 m Page 78 of 111 Report No.: HK2306062322-1E above the ground or reference ground plane. 3. Corrected Reading: Antenna Factor + Cable Loss + Read Level - Preamp Factor = Level 4. For measurement below 1GHz, If the emission level of the EUT measured by the peak detector is 3 dB lower than the applicable limit, the peak emission level will be reported. Otherwise, the emission measurement will be repeated using the quasi-peak detector and reported. 5. Use the following spectrum analyzer settings: (1) Span shall wide enough to fully capture the emission being measured; (2) Set RBW=100 kHz for f < 1 GHz; VBW ≥RBW; Sweep = auto; Detector function = peak; Trace = max hold; (3) Set RBW = 1 MHz, VBW= 3MHz for f 1 GHz for peak measurement. For average measurement: VBW = 10 Hz, when duty cycle is no less than 98 percent. VBW ≥ 1/T, when duty cycle is less than 98 percent where T is the minimum transmission duration over which the transmitter is on and is transmitting at its maximum power control level for the tested mode of operation. Test results: PASS Page 79 of 111 Report No.: HK2306062322-1E 4.6.2. Test Instruments Radiated Emission Test Site (966) Name of Equipment Manufacturer Model Serial Number Calibration Date Calibration Due Receiver R&S ESR-7 HKE-010 Feb. 17, 2023 Feb. 16, 2024 Spectrum analyzer Agilent N9020A HKE-048 Feb. 17, 2023 Feb. 16, 2024 Preamplifier EMCI EMC051845 SE HKE-015 Feb. 17, 2023 Feb. 16, 2024 Preamplifier Agilent 83051A HKE-016 Feb. 17, 2023 Feb. 16, 2024 Loop antenna Schwarzbeck FMZB 1519 B HKE-014 Feb. 17, 2023 Feb. 16, 2024 Broadband antenna Schwarzbeck VULB 9163HKE-012 Feb. 17, 2023 Feb. 16, 2024 Horn antenna Schwarzbeck 9120D HKE-013 Feb. 17, 2023 Feb. 16, 2024 Antenna Mast Keleto CC-A-4M N/A N/A N/A Position controller Taiwan MF MF7802 HKE-011 Feb. 17, 2023 Feb. 16, 2024 Radiated test software Tonscend TS+ Rev 2.5.0.0 HKE-082 N/A N/A RF cable (9KHz-1GHz) Times 381806-001N/A N/A N/A RF cable Times 1-40G HKE-034 Feb. 17, 2023 Feb. 16, 2024 Horn Antenna Schewarzbeck BBHA 9170 HKE-017 Feb. 17, 2023 Feb. 16, 2024 Note: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to international system unit (SI). Page 80 of 111 Report No.: HK2306062322-1E 4.6.3. Test Data Please refer to following diagram for individual Below 1GHz All the test modes completed for test. only the worst result of 802.11b at 2412MHz was re…

Text truncated - open the document above for the full version.

Test Report

TEL:+860755-23073599FAX:+860755-23097189E-mail:[email protected] 地址: 深圳市宝安区航空路锦驰中心3015号 深圳市云顶通讯电子有限公司 SHENZHEN 客户 : 品名规格 DESCRIPTION: 料号 PARTNO.: 客户料号 CUSPARTNO. : 日期 DATE: 云顶呈样签章 工程 ENGINEERINGDEPARTMENT 品保 QCDEPARTMENT 业务 SALESDEPARTMENT 吴淑仪刘丽王洪涛 客户承认签章 工程 ENGINEERINGDEPARTMENT 品保 QCDEPARTMENT 采购 PURCHASINGDEPARTMENT 联系电话:07552307359915017941162 ж承认书一式三份,惠蒙贵司承认签章 жApprovalinduplicate,pleasesignedbyyourcompany. 承認書 APPROVAL M79D-WIFI 五金弹片天线 2023.6.19 讯曼 TEL:+860755-23073599FAX:+860755-23097189E-mail:[email protected] 地址: 深圳市宝安区航空路锦驰中心3015号 深圳市云顶通讯电子有限公司 SHENZHEN 1. 测试项目与设备 测试项目设备 1.S11参数 (S-parameter) 1.回波损耗(ReturnLoss) 2.电压驻波比(VSWR) 网络分析仪:AgilentE5071B HP8753D 2.有源测试 (Active) 1.发射功率(TRP) 2.接收灵敏度(TIS) 1.暗室:ETS7x4x3m(3D)Chamber ETS5x3x3m(3D)Chamber 2.综合测试仪:Agilent8960E5515B×2 StarPointSP6011 3.无源测试 (Passive) 1.天线增益(Gain)2.天线效 率(Efficiency) 1.暗室:ETS7x4x3m(3D)Chamber ETS5x3x3m(3D)Chamber 2.网络分析仪:AgilentE5071B HP8753D TEL:+860755-23073599FAX:+860755-23097189E-mail:[email protected] 地址: 深圳市宝安区航空路锦驰中心3015号 深圳市云顶通讯电子有限公司 SHENZHEN 2. 天线性能 WIFI-SWR TEL:+860755-23073599FAX:+860755-23097189E-mail:[email protected] 地址: 深圳市宝安区航空路锦驰中心3015号 深圳市云顶通讯电子有限公司 SHENZHEN 3. 天线效率与增益 TEL:+860755-23073599FAX:+860755-23097189E-mail:[email protected] 地址: 深圳市宝安区航空路锦驰中心3015号 深圳市云顶通讯电子有限公司 SHENZHEN 4. 天线结构图:

Test Setup Photos

N21 Radiated Emissions Conducted Emission

Contact Information

Applicant

John kang
[email protected]+86 0755-23008503Fax: +86 0755-23008503

Technical Contact

Shenzhenshi Jiujiadianzishangwuyouxiangongsi
[email protected]

China

Test Firm

Shenzhen HUAK Testing Technology Co., Ltd.Jason Zhou
[email protected]86-755-23029901

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz6.38 mW
Confidentiality
Long Term
Grant Notes
Output power listed is maximum combined conducted power. This device contains 20 and 40 MHz signal bandwidth. Device is a 2x2 MIMO as is described in the filing. The antennas used with this transmitter must be installed to provide a minimum separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-users must be provided with operating procedures for satisfying RF exposure compliance.
