2AYQZ-V10AProjector

Dongguan Yi Pai Ji He Electronic Co., Ltd
Projector - FCC ID 2AYQZ-V10A - Dongguan Yi Pai Ji He Electronic Co., Ltd
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Jul 18, 2022
Application Purpose
Original Equipment
Date of Application
Jul 18, 2022
Equipment Note
Projector
Frequency Range
2402.00000000 - 2480.00000000
Company
Dongguan Yi Pai Ji He Electronic Co., Ltd
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗
↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the follow ing two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, inc luding interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentia l installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televis ion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technic ian for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be insta lled and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.

Attestation Statements

DongguanYiPaiJiHeElectronicCo.,Ltd ModelDifference Productdescription:Projector Modelname:V10A V1,V2,V3,V5,V6,V7,V8,V9,V10,V11,V12,V13,V15,V16,V17,V18, V19,V20,V21,V22,V23,V25,V26,V27,V28,V29,V30,V31,V32,V33, V35,V36,V37,V38,V39,V40,V41,V42,V43,V45,V46,V47,V48,V49, V50,V51,V52,V53,V55,V56,V57,V58,V59,V60,V61,V62,V63V65, V66,V67,V68,V69,V70,V71,V72,V73,V75,V76,V77,V78,V79,V80, V81,V82,V83,V85,V86,V87,V88,V89,V90,V91,V92,V93,V95,V96, V97,V98,V99,YP13,YP13B,YP13C,YP12,V10S,V10P,V10F,V10H TradeName:N/A FCCID:2AYQZ-V10A AllthemodelarethesamecircuitandRFmodule,onlyformodelname. Regards Sincerely Client’ssignature: Client’sname/title:YongqiuYU(N/A) Contactinformation/address: 6F,96JinghaiMiddleRoad,Chang'anTown,DongguanCity,GuangdongProvince

Cover Letter(s)

C5266091_X8_Ed.1 1/1 LetterofAuthorization <DongguanYiPaiJiHeElectronicCo.,Ltd> Company:DongguanYiPaiJiHeElectronicCo.,Ltd Address:6F,96JinghaiMiddleRoad,Chang'anTown,DongguanCity,GuangdongPro vince ProductName:Projector ModelNumber:V10A V1,V2,V3,V5,V6,V7,V8,V9,V10,V11,V12,V13,V15,V16,V17,V18, V19,V20,V21,V22,V23,V25,V26,V27,V28,V29,V30,V31,V32,V3 3, V35,V36,V37,V38,V39,V40,V41,V42,V43,V45,V46,V47,V48,V4 9, V50,V51,V52,V53,V55,V56,V57,V58,V59,V60,V61,V62,V63V65, V66,V67,V68,V69,V70,V71,V72,V73,V75,V76,V77,V78,V79,V8 0, V81,V82,V83,V85,V86,V87,V88,V89,V90,V91,V92,V93,V95,V9 6, V97,V98,V99,YP13,YP13B,YP13C,YP12,V10S,V10P,V10F,V10H FCCIdentifier:2AYQZ-V10A WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. C5266091_X8_Ed.1 1/1 Name:YongqiuYUDate:2022-07-13 Title:N/A Signatureofapplicant:

Cover Letter(s)

C5266091_X10_Ed.1 1/1 <DongguanYiPaiJiHeElectronicCo.,Ltd> OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:2022-07-13 Subject:RequestforConfidentiality FCCID:2AYQZ-V10A ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo BlockDiagram Schematics TestReportNoNo TestSetupPhotosNo User’sManual InternalPhotos PartsList/TuneUp RFExposureInfo OperationalDescription CoverLetter(s)NoNo SDRSoftware/SecurityInfoNo Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. Sincerely, Signature: Name:YongqiuYU Title:N/A

External Photos

EUT PHOTO(ExternalPhotos)

ID Label/Location Info

Labelandlabellocation Projector FCCID:2AYQZ-V10A

Internal Photos

EUTPHOTO(InternalPhotos) WIFIANT BTANT

Internal Photos

※※※※※ENDOFREPORT※※※※※

RF Exposure Info

FCCID:2AYQZ-V10A RFExposureEvaluation Limits Thecriterialistedinthefollowingtableshallbeusedtoevaluatetheenvironmentimpactofhumanexposure toradiofrequency(RF)radiationasspecifiedin1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Frequencyrange (MHz) Electricfield strength (V/m) Magneticfieldstrength (A/m) Powerdensity (mW/cm 2 ) Averagingtime (minutes) (A)LimitsforOccupational/ControlledExposures 0.3–3.06141.63*(100)6 3.0–301842/f4.89/f*(900/f 2 )6 30–30061.40.1631.06 300–1500f/3006 1500–100,00056 (B)LimitsforGeneralPopulation/UncontrolledExposure 0.3–1.346141.63*(100)30 1.34–30824/f2.19/f*(180/f 2 )30 30–30027.50.0730.230 300–1500f/150030 1500–100,0001.030 f=frequencyinMHz Friistransmissionformula:Pd=(Pout*G)/(4*pi*r 2 ) Where Pd=powerdensityinmW/cm 2 ,Pout=outputpowertoantennainmW; G=gainofantennainlinearscale,Pi=3.1416; R=distancebetweenobservationpointandcenteroftheradiatorincm PdidthelimitofMPE,1mW/cm 2 .Ifweknowthemaximumgainoftheantennaandthetotalpowerinputto theantenna,throughthecalculation,wewillknowthedistancerwheretheMPElimitisreached. TestProcedure SoftwareprovidedbyclientenabledtheEUTtotransmitandreceivedataatlowest,middleandhighest channelindividually. TestResultofRFExposureEvaluation 2.4GWIFImode Mode Outputpower toantenna (dBm) Outputpowerto antenna(mW) PowerDensityat R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b12.84919.270.0038341.0PASS 802.11g13.28821.320.0042421.0PASS 802.11n2013.01620.030.0039841.0PASS 802.11gn4013.0220.040.0039881.0PASS BT Mode Outputpower toantenna (dBm) Outputpowerto antenna(mW) PowerDensityat R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK1.5891.440.0002871.0PASS π/4-DQPSK-1.3120.740.0001471.0PASS 8-DPSK-1.1710.760.0001521.0PASS Remark:antennagain=0dBi

Test Report

ProjectNo.:ZKT-220630096E Page 1 of 80 FCCTESTREPORT FCCID:2AYQZ-V10A ReportNumber. .................................... :ZKT-220630096E DateofTest ...................................................... : Jun.26,2022toJul.15,2022 Dateofissue ......................................... : Jul.15,2022 Totalnumberofpages ......................... 80 TestResult .......................................... : PASS TestingLaboratory...........................: ShenzhenZKTTechnologyCo.,Ltd. Address ............................................... : 1/F,No.101,BuildingB,No.6,TangweiCommunityIndustrial Avenue,FuhaiStreet,Bao'anDistrict,Shenzhen,China Applicant'sname.............................:DongguanYiPaiJiHeElectronicCo.Ltd Address ............................................... : 6thfloor,No.96JinghaiMiddleRoad,Chang'anTownDongguan, GuangdongChina Manufacturer'sname......................: DongguanYiPaiJiHeElectronicCo.Ltd Address...............................................: 6thfloor,No.96JinghaiMiddleRoad,Chang'anTownDongguan, GuangdongChina Testspecification: Standard ................................................ : FCCCFRTitle47Part15SubpartCSection15.247 ANSIC63.10:2013 Testprocedure.....................................: / Non-standardtestmethod ................ :N/A TestReportFormNo........................: TRF-EL-112_V0 TestReportForm(s)Originator.....: ZKTTesting MasterTRF ........................................ : Dated:2021-04-22 ThisdevicedescribedabovehasbeentestedbyZKT,andthetestresultsshowthattheequipmentunder test(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofZKT,thisdocumentmay bealteredorrevisedbyZKT,personalonly,andshallbenotedintherevisionofthedocument. Productname ..................................... :Projector Trademark ........................................... :N/A Model/Typereference.........................:V10A V1,V2,V3,V5,V6,V7,V8,V9,V10,V11,V12,V13,V15,V16,V17,V18, V19,V20,V21,V22,V23,V25,V26,V27,V28,V29,V30,V31,V32,V33, V35,V36,V37,V38,V39,V40,V41,V42,V43,V45,V46,V47,V48,V49, V50,V51,V52,V53,V55,V56,V57,V58,V59,V60,V61,V62,V63V65, V66,V67,V68,V69,V70,V71,V72,V73,V75,V76,V77,V78,V79,V80, V81,V82,V83,V85,V86,V87,V88,V89,V90,V91,V92,V93,V95,V96, V97,V98,V99,YP13,YP13B,YP13C,YP12,V10S,V10P,V10F,V10H Ratings..................................................:Input:AC110-240V50/60Hz ProjectNo.:ZKT-220630096E Page 2 of 80 Testingprocedureandtestinglocation: TestingLaboratory .......................................... :ShenzhenZKTTechnologyCo.,Ltd. Address............................................................:1/F,No.101,BuildingB,No.6,TangweiCommunity IndustrialAvenue,FuhaiStreet,Bao'anDistrict, Shenzhen,China TomZou Testedby(name+signature) ....................... : JacksonFang Reviewer(name+signature) ....................... : LakeXie Approved(name+signature).......................: ProjectNo.:ZKT-220630096E Page 3 of 80 TableofContents Page 1.VERSION.......................................................................................................................................5 2.TESTSUMMARY........................................................................................................................6 2.1TESTFACILITY..............................................................................................................................7 2.2MEASUREMENTUNCERTAINTY...........................................................................................7 3.GENERALINFORMATION.......................................................................................................8 3.1GENERALDESCRIPTIONOFEUT........................................................................................8 3.2TestSetupConfiguration.............................................................................................................9 3.3SupportEquipment......................................................................................................................10 3.4TestMode.......................................................................................................................................11 3.5EQUIPMENTSLISTFORALLTESTITEMS......................................................................12 4.EMCEMISSIONTEST.............................................................................................................14 4.1Conductedemissions.................................................................................................................14 4.1.1POWERLINECONDUCTEDEMISSIONLimits............................................................14 4.1.2TESTPROCEDURE...............................................................................................................14 4.1.3DEVIATIONFROMTESTSTANDARD............................................................................14 4.1.4TESTSETUP.............................................................................................................................14 4.1.5EUTOPERATINGCONDITIONS.......................................................................................15 4.1.6TestResult.................................................................................................................................16 4.2Radiatedemissions.....................................................................................................................18 4.2.1RadiatedEmissionLimits.......................................................................................................18 4.2.2TESTPROCEDURE...............................................................................................................18 4.2.3DEVIATIONFROMTESTSTANDARD............................................................................19 4.2.4TESTSETUP.......................................................................................................…

Text truncated - open the document above for the full version.

Test Report

ProjectNo.:ZKT-220630096E Page 56 of 80 8-DPSKMiddleChannel 8-DPSKHighChannel ProjectNo.:ZKT-220630096E Page 57 of 80 8.MaximumPeakOutputPower TestRequirement:FCCPart15CSection15.247(b)(1) TestMethod:ANSIC63.10:2013 Limit:GFSK:30dBm π/4-DQPSK&8-DPSK:20.97dBm 8.1BlockDiagramOfTestSetup 8.2Limit Forfrequencyhoppingsystemsoperatinginthe2400-2483.5MHzbandemployingatleast75 non-overlappinghoppingchannels,andallfrequencyhoppingsystemsinthe5725-5850MHzband:1watt. Forallotherfrequencyhoppingsystemsinthe2400-2483.5MHzband:0.125watts. ForFHSsoperatingintheband2400-2483.5MHz,themaximumpeakconductedoutputpowershallnot exceed1.0Wifthehopsetuses75ormorehoppingchannels;themaximumpeakconductedoutputpower shallnotexceed0.125Wifthehopsetuseslessthan75hoppingchannels.Thee.i.r.p.shallnotexceed4W. 8.3Testprocedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaporttothespectrum. 2.Setthespectrumanalyzer:RBW=2MHz.VBW=6MHz.Sweep=auto;DetectorFunction=Peak. 3.KeeptheEUTintransmittingatlowest,mediumandhighestchannelindividually.Recordthemaxvalue. 8.4DEVIATIONFROMSTANDARD Nodeviation. 8.5TestResult ModeTestchannel PeakOutputPower (dBm) FCCLimit (dBm) Result GFSK Lowest1.589 30.00PassMiddle1.41 Highest1.087 π/4-DQPSK Lowest-1.312 21.00PassMiddle-1.428 Highest-1.531 8-DPSK Lowest-1.171 21.00PassMiddle-2.309 Highest-2.549 ProjectNo.:ZKT-220630096E Page 58 of 80 Testplots GFSKLowChannel GFSKMiddleChannel ProjectNo.:ZKT-220630096E Page 59 of 80 GFSKHighChannel π/4-DQPSKLowChannel ProjectNo.:ZKT-220630096E Page 60 of 80 π/4-DQPSKMiddleChannel π/4-DQPSKHighChannel ProjectNo.:ZKT-220630096E Page 61 of 80 8-DPSKLowChannel 8-DPSKMiddleChannel ProjectNo.:ZKT-220630096E Page 62 of 80 8-DPSKHighChannel ProjectNo.:ZKT-220630096E Page 63 of 80 9.HOPPINGCHANNELSEPARATION TestRequirement:FCCPart15CSection15.247(a)(1) TestMethod:ANSIC63.10:2013 Receiversetup: RBW=30KHz,VBW=100KHz,detector=Peak Limit: GFSK:20dBbandwidth π/4-DQPSK&8DSK:0.025MHzor2/3ofthe20dBbandwidth(whichever isgreater) 9.1TestSetup 9.2Testprocedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaport tothespectrum. 2.Setthespectrumanalyzer:RBW=30kHz.VBW=100kHz,Span=2.0MHz.Sweep=auto;Detector Function=Peak.Trace=Maxhold. 3.Allowthetracetostabilize.Usethemarker-deltafunctiontodeterminetheseparationbetweenthepeaksof theadjacentchannels.ThelimitisspecifiedinoneofthesubparagraphsofthisSectionSubmitthisplot. 9.3DEVIATIONFROMSTANDARD Nodeviation. ProjectNo.:ZKT-220630096E Page 64 of 80 9.4TestResult ModulationTestChannelSeparation(MHz)Limit(MHz)Result GFSKLow 0.9990.856 PASS GFSK Middle 1.1460.865 PASS GFSK High 1.1070.857 PASS π/4-DQPSK Low 0.99 0.952PASS π/4-DQPSK Middle 1.152 0.941PASS π/4-DQPSK High 1.167 0.951PASS 8-DPSK Low 1.005 0.941PASS 8-DPSK Middle 1.146 0.953PASS 8-DPSKHigh 0.999 0.957PASS Testplots GFSKLowChannel ProjectNo.:ZKT-220630096E Page 65 of 80 GFSKMiddleChannel GFSKHighChannel ProjectNo.:ZKT-220630096E Page 66 of 80 π/4-DQPSKLowChannel π/4-DQPSKMiddleChannel ProjectNo.:ZKT-220630096E Page 67 of 80 π/4-DQPSKHighChannel 8-DPSKLowChannel ProjectNo.:ZKT-220630096E Page 68 of 80 8-DPSKMiddleChannel 8-DPSKHighChannel ProjectNo.:ZKT-220630096E Page 69 of 80 10.NUMBEROFHOPPINGFREQUENCY TestRequirement:FCCPart15CSection15.247(a)(1)(iii) TestMethod:ANSIC63.10:2013 Receiversetup: RBW=100kHz,VBW=300kHz,Frequencyrange=2400MHz-2483.5MHz, Detector=Peak Limit: 15channels 10.1TestSetup 10.2Testprocedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaporttothespectrum. 2.Setthespectrumanalyzer:RBW=100kHz.VBW=300kHz.Sweep=auto;DetectorFunction=Peak. Trace=Maxhold. 3.Allowthetracetostabilize.Itmayprovenecessarytobreakthespanuptosections.inordertoclearly showallofthehoppingfrequencies.ThelimitisspecifiedinoneofthesubparagraphsofthisSection. 4.Setthespectrumanalyzer:StartFrequency=2.4GHz,StopFrequency=2.4835GHz.Sweep=auto; 10.3DEVIATIONFROMSTANDARD Nodeviation. ProjectNo.:ZKT-220630096E Page 70 of 80 10.4TestResult TestPlots: 79Channelsintotal GFSK ProjectNo.:ZKT-220630096E Page 71 of 80 π/4-DQPSK 8-DPSK ProjectNo.:ZKT-220630096E Page 72 of 80 11.DWELLTIME TestRequirement:FCCPart15CSection15.247(a)(1)(iii) TestMethod:ANSIC63.10:2013 Receiversetup: RBW=1MHz,VBW=3MHz,Span=0Hz,Detector=Peak Limit: 0.4Second 11.1TestSetup 11.2Testprocedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaporttothespectrum. 2.Setspectrumanalyzerspan=0Hz; 3.SetRBW=1MHzandVBW=3MHz.Sweep=asnecessarytocapturetheentiredwelltimeperhopping channel.SettheEUTforDH5,DH3andDH1packettransmitting. 4.Usethemarker-deltafunctiontodeterminethedwelltime.Ifthisvaluevarieswithdifferentmodesof operation(e.g..datarate.modulationformat.etc.).repeatthistestforeachvariation.Thelimitisspecifiedin oneofthesubparagraphsofthisSection.Submitthisplot(s). 11.3DEVIATIONFROMSTANDARD Nodeviation. ProjectNo.:ZKT-220630096E Page 73 of 80 11.4TestResult GFSKmode: FrequencyPacketDwelltime(ms)Limit(ms)Result 2441MHzDH1 121.600 400Pass 2441MHzDH3 261.760 400Pass 2441MHzDH5 307.52 400Pass Remarks: Thetestperiod:T=0.4Second/Channelx79Channel=31.6s Testchannel:asblow CH:2441MHztimeslot=0.380(ms)*(1600/(2*79))*31.6=121.600ms CH:2441MHztimeslot=1.636(ms)*(1600/(4*79))*31.6=261.760ms CH:2441MHztimeslot=2.884(ms)*(1600/(6*79))*31.6=307.627ms π/4-DQPSKmode: FrequencyPacketDwelltime(ms)Limit(ms)Result 2441MHz2DH1 124.480 400Pass 2441MHz2DH3 262.560 400Pass 2441MHz2DH5 308.160 400Pass Remarks: Thetestperiod:T=0.4Second/Channelx79Channel=31.6s Testchannel:asblow CH:2441MHztimeslot=0.389(ms)*(1600/(2*79))*31.6=124.480ms CH:2441MHztimeslot=1.641(ms)*(1600/(4*79))*31.6=262.560ms CH:2441MHztimeslot=2.889(ms)*(1600/(6*79))*31.6=308.160ms 8-DPSKmode: FrequencyPacketDwelltime(ms)Limit(ms)Result 2441MHz3DH1 124.480 400Pass 2441MHz3DH3 262.400 400Pass 2441MHz3DH5 308.373 400Pass Remarks: Thetestperiod:T=0.4Second/Channelx79Channel=31.6s Testchannel:asblow CH:2441MHztimeslot=0.389(ms)*(1600/(2*79))*31.6=124.480ms CH:2441MHztimeslot=1.640(ms)*(1600/(4*79))*31.6=262.400ms CH:2441…

Text truncated - open the document above for the full version.

Test Setup Photos

EUTTESTPHOTO

Contact Information

Applicant

Yongqiu Yu(Engineer)
[email protected]+86-13823126718Fax: +86-0769-81888843

Technical Contact

Shenzhen ZKT Technology Co., Ltd.Lake xie
[email protected]0086-400 000 9970

Shenzhen · China

Non-Technical Contact

Shenzhen ZKT Technology Co., Ltd.Lake xie
[email protected]0086-400 000 9970

Test Firm

Shenzhen ZKT Technology Co., Ltd.Lake Xie
[email protected]0086-13620010775

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz1.44 mW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted.The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End-users must be provided with operating procedures for satisfying RF exposure compliance.
