2AYRA-100025Velop 7 Max

Velop 7 Demonstration QSG, 1-Pack Revision: 20250620a Accordian brochure Overall size: A4 [210 X 297 mm] Drawing Scale: 1:1 Instructions: Print page 2 only for QSG, single sided fold as 3 panel accordian per drawing Not for mass production. Do not print this page. 3-panel accordion-fold brochure QSG front cover this panel QSG Step 2 this panel QSG Step 1 this panel Ready Wait Ethernet Cable Linksys Router Modem or Gateway Internet Quick Start Guide Demonstration QSG. Not for production. ©2025 Linksys Holdings, Inc. rev2025.06.20 The Router light will blink white as it is being set up and turn solid white once setup is complete. Unable to visit www.myrouter.info? 1. Make sure your Router is connected to your modem and internet is available. 2. Confirm that you are connected to your new Router’s WiFi. Visit www.myrouter.info • Personalise your WiFi Name • Enable Guest WiFi Scan the QR code to set up your Router. Follow the on-screen instructions. Receive an error message? Don’t be concerned. Your connection is private, secure and encrypted. It’s safe to proceed to 192.168.1.1 This error only occurs when accessing a router using an HTTPS connection. For more information visit: https://support.linksys.com/kb/article/65-en/ Step 2 Scan the QR code to connect to your WiFi. Save this guide for future reference. Your default WiFi Name and Password are also printed on the bottom of your Router. Step 1 Connect your Router to the modem. Use the provided Ethernet cable to connect the modem to the Internet port on the Router. Plug your Router into a power outlet. Give it a minute to start up. The Router light will blink blue as it is starting up and turn solid blue once ready for setup. Restart your modem or gateway by unplugging it. Wait 3 minutes and plug it back in. Disconnect your old router from your modem or gateway. QR Code SSID and QR Code Velop 7 Router ® Linksys USA, Inc. Regulatory Information LNM620 LNM620WH LNM620MS LNM620EC SPNM62 Velop 7 Max Wireless Regulatory Information FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna  Increase the separation between the equipment and devices  Connect the equipment to an outlet other than the receiver’s  Consult a dealer or an experienced radio/TV technician for assistance FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device and its antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. FCC regulations restrict the operation of this device to indoor use only. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. 2.4 GHz operation of this product in the USA is firmware-limited to channels 1 through 11. Selection of other channels is not possible. The device for the band 5150-5250 MHz is only for indoor usage to reduce the potential for harmful interference to co-channel mobile satellite systems. The country code selection is for non-US model only and is not available to all US model. Per FCC regulation, all WiFi product marketed in US must fixed to US operation channels only. Devices shall not be used for control of or communications with unmanned aircraft systems. The operation of this device is prohibited on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet. Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or communications with unmanned aircraft systems. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 35 cm between the radiator and your body. This device and it’s antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. Innovation, Science and Economic Development Canada Statement CAN ICES (B)/NMB (B) This device complies with ISED’s license-exempt RSS standards. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. For product available in the USA/Canada market, only channel 1~11 can be operated for 2.4 GHz. Selection of other channels is not possible. The device could automatically discontinue transmission in case of absence of information to transmit, or operational failure. Note that this is not intended to prohibit tran…

Text truncated - open the document above for the full version.

RADIO TEST REPORT Report No. : FR542105-01AA TEL : 886-3-656-9065 Page Number : 2 of 36 FAX : 886-3-656-9085 Issued Date : Jan. 26, 2026 Report Template No.: CB-A10_10 Ver1.3 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ........................................................................................................................... 10 1.3 Testing Location Information ................................................................................................................ 10 1.4 Measurement Uncertainty .................................................................................................................... 11 2 Test Configuration of EUT ................................................................................................................. 12 2.1 Test Channel Mode .............................................................................................................................. 12 2.2 The Worst Case Measurement Configuration ...................................................................................... 13 2.3 EUT Operation during Test .................................................................................................................. 15 2.4 Accessories .......................................................................................................................................... 15 2.5 Support Equipment ............................................................................................................................... 16 2.6 Test Setup Diagram ............................................................................................................................. 17 3 Transmitter Test Result ..................................................................................................................... 21 3.1 AC Power-line Conducted Emissions .................................................................................................. 21 3.2 DTS Bandwidth..................................................................................................................................... 23 3.3 Maximum Conducted Output Power .................................................................................................... 24 3.4 Power Spectral Density ........................................................................................................................ 27 3.5 Emissions in Non-restricted Frequency Bands .................................................................................... 29 3.6 Emissions in Restricted Frequency Bands ........................................................................................... 30 4 Test Equipment and Calibration Data .............................................................................................. 34 Appendix A. Test Results of AC Power-line Conducted Emissions Appendix B. Test Results of DTS Bandwidth Appendix C. Test Results of Maximum Conducted Output Power Appendix D. Test Results of Power Spectral Density Appendix E. Test Results of Emissions in Non-restricted Frequency Bands Appendix F. Test Results of Emissions in Restricted Frequency Bands Appendix G. Test Results of Radiated Emission Co-location Appendix H. Test Photos Photographs of EUT v01 RADIO TEST REPORT Report No. : FR542105-01AA TEL : 886-3-656-9065 Page Number : 3 of 36 FAX : 886-3-656-9085 Issued Date : Jan. 26, 2026 Report Template No.: CB-A10_10 Ver1.3 Report Version : 01 History of this test report Report No. Version Description Issued Date FR542105-01AA 01 Initial issue of report Jan. 26, 2026 RADIO TEST REPORT Report No. : FR542105-01AA TEL : 886-3-656-9065 Page Number : 4 of 36 FAX : 886-3-656-9085 Issued Date : Jan. 26, 2026 Report Template No.: CB-A10_10 Ver1.3 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 1.1.2 15.203 Antenna Requirement PA SS - 3.1 15.207 AC Power-line Conducted Emissions PA SS - 3.2 15.247(a) DTS Bandwidth PA SS - 3.3 15.247(b) Maximum Conducted Output Power PA SS - 3.4 15.247(e) Power Spectral Density PA SS - 3.5 15.247(d) Emissions in Non-restricted Frequency Bands PA SS - 3.6 15.247(d) Emissions in Restricted Frequency Bands PA SS - Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Muse Chan RADIO TEST REPORT Report No. : FR542105-01AA TEL : 886-3-656-9065 Page Number : 5 of 36 FAX : 886-3-656-9085 Issued Date : Jan. 26, 2026 Report Template No.: CB-A10_10 Ver1.3 Report Version : 01 1 General Description 1.1 Information 1.1.1 RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Frequency (MHz) Channel Number 2400-2483.5 b, g, n (HT20), VHT20, ax (HEW20), be (EH…

Text truncated - open the document above for the full version.

Test Photos Appendix H Sporton International Inc. Hsinchu Laboratory Page No. : 1 of 3 1. Photographs of Conducted Emissions Test Configuration Test Mode: Mode 2 FRONT VIEW REAR VIEW Report No. : FR542105-01AD Test Photos Appendix H Sporton International Inc. Hsinchu Laboratory Page No. : 2 of 3 2. Photographs of Radiated Emissions Test Configuration Test Configuration: 30MHz~1GHz / Test Mode: Mode 1 FRONT VIEW REAR VIEW Report No. : FR542105-01AD Test Photos Appendix H Sporton International Inc. Hsinchu Laboratory Page No. : 3 of 3 Test Configuration: Above 1GHz FRONT VIEW REAR VIEW ─────THE END───── Report No. : FR542105-01AD

Test Photos Appendix H Sporton International Inc. Hsinchu Laboratory Page No. : 1 of 3 1. Photographs of Conducted Emissions Test Configuration Test Mode: Mode 2 FRONT VIEW REAR VIEW Report No. : FR542105-01AA Test Photos Appendix H Sporton International Inc. Hsinchu Laboratory Page No. : 2 of 3 2. Photographs of Radiated Emissions Test Configuration Test Configuration: 30MHz~1GHz / Test Mode: Mode 1 FRONT VIEW REAR VIEW Report No. : FR542105-01AA Test Photos Appendix H Sporton International Inc. Hsinchu Laboratory Page No. : 3 of 3 Test Configuration: Above 1GHz FRONT VIEW REAR VIEW ─────THE END───── Report No. : FR542105-01AA

Galtronics Electronics (Wuxi) Co.,LTD 2365-82000006R GALTRONICS CONFIDENTIAL AND PROPRIETARY INFORMATION MAY NOT BE COPIED OR DISCLOSED. Product CONTENTS 1. Product performance ..................................................................................................................... 3 1.1 Describe ......................................................................................................................................................... 3 1.2 Features ......................................................................................................................................................... 3 1.3 Specifications and Interface ........................................................................................................... 3 1.4 VSWR ( Return Loss ) ............................................................................................................................ 4 1.5 Peak Gain & Efficiency ......................................................................................................................... 4 1.6 Frequency Band & RF pattern ............................................................................................................. 5 2. Production Specification ...................................................................................................... 9 2.1 Drawing ........................................................................................................................................................... 9 3.Material .......................................................................................................................................................... 11 3.1 PCB material certification ............................................................................................................ 11 3.2 Cable material certification ....................................................................................................... 13 3.3 UL Card ............................................................................................................................................................ 23 4.Dimension report .......................................................................................................................................... 4.1 FA （To be updated） ................................................................................................................................. 4.2 CPK report （ Not Applicable ） 5.Final picture & Net weight（To be updated） ......................................................... 6.Cable tension test （To be updated） ..................................................................................... 7.Packing specification & Drop test report （To be updated） ....... 24

Galtronics Electronics (Wuxi) Co.,LTD 2365-82000003R GALTRONICS CONFIDENTIAL AND PROPRIETARY INFORMATION MAY NOT BE COPIED OR DISCLOSED. Product CONTENTS 1. Product performance ..................................................................................................................... 3 1.1 Describe ......................................................................................................................................................... 3 1.2 Features ......................................................................................................................................................... 3 1.3 Specifications and Interface ........................................................................................................... 3 1.4 VSWR ( Return Loss ) ............................................................................................................................ 4 1.5 Peak Gain & Efficiency ......................................................................................................................... 4 1.6 Frequency Band & RF pattern ............................................................................................................. 5 2. Production Specification ...................................................................................................... 9 2.1 Drawing ........................................................................................................................................................... 9 3.Material .......................................................................................................................................................... 11 3.1 PCB material certification ............................................................................................................ 11 3.2 Cable material certification ....................................................................................................... 13 3.3 UL Card ............................................................................................................................................................ 23 4.Dimension report .......................................................................................................................................... 4.1 FA （To be updated） ................................................................................................................................. 4.2 CPK report （ Not Applicable ） 5.Final picture & Net weight（To be updated） ......................................................... 6.Cable tension test （To be updated） ..................................................................................... 7.Packing specification & Drop test report （To be updated） ....... 24

Airgain Embedded Antenna Engineering Data Sheet Profile Series N08CBAUB 3611 Valley Centre Drive, Suite 150 San Diego, CA 92130 USA Tel: +1 760 579 0200 Fax: +1 760 579 0892 Information: [email protected] Sales: [email protected] Support: [email protected] Page 2 Airgain Proprietary Doc. # 5012C-02-00-001-1 Rev. 1.1 Airgain N08CBAUB Engineering Data Sheet Revision History (Required) Revision Date Note 5012C-02-00-001-1 Rev1.0 March 12, 2024 Preliminary Datasheet 1.0 5012C-02-00-001-1 Rev1.1 June 27, 2024 Released datasheet Disclaimers The information in this document is provided in connection with Airgain Antenna products. It is Airgain proprietary and is protected by international intellectual property laws. Airgain may make changes at any time, without notice. Please verify with Airgain before finalizing a product design. Page 3 Airgain Proprietary Doc. # 5012C-02-00-001-1 Rev. 1.1 Airgain N08CBAUB Engineering Data Sheet Contents 1. Airgain N08CBAUB Embedded Antenna ....................................................................................................... 4 2. Features ............................................................................................................................................................ 4 3. Specifications and Interface ............................................................................................................................. 5 4. Radiation Patterns ............................................................................................................................................ 5 5. Dimensions ...................................................................................................................................................... 8 6. ROHS& REACH/SVHC247 ........................................................................................................................... 8 7. Feature and Options Information ..................................................................................................................... 8 7.1 Part Number Conventions ............................................................................................................................... 8 7.2 Part Number Example ..................................................................................................................................... 9 8. Cable Data Sheet ........................................................................................................................................... 10 Figures Figure 1 Model N08CBAUB Embedded Antenna ............................................................................................................... 4 Figure 2 Model N08CBAUB Measurement axes ................................................................................................................ 5 Figure 3 N08CBAUB Azimuth pattern at 2.44 GHz ........................................................................................................... 6 Figure 4 N08CBAUB Elevation pattern at 6.5 GHz ........................................................................................................... 7 Figure 5 N08CBAUB Antenna dimensions ........................................................................................................................... 8 Figure 6 N08CBAUB with connector or stripped cable .................................................................................................... 9 Page 4 Airgain Proprietary Doc. # 5012C-02-00-001-1 Rev. 1.1 Airgain N08CBAUB Engineering Data Sheet 1. Airgain N08CBAUB Embedded Antenna The Model N08CBAUB Embedded Antenna provides a high efficiency, band embedded antenna solution for Wi-Fi and ISM band applications, such as WLAN products. As embedded antenna solutions become the focus of next generation wireless product design, the Model N08CBAUB provides the flexibility of an embedded antenna with top performance. The Model N08CBAUB Embedded Antenna is a shorter, center fed version of its predecessor, the N08CBAUB, allowing it to fit in shorter spaces where center feeding is better suited.. It is designed to accommodate most WLAN access point applications, such as routers and gateways can be easily integrated into an ID package design. 2. Features The Model N08CBAUB Embedded Antenna is defined by the following features: • IEEE 802.11 a/b/g/n/ac standards • Case mount • High efficiency • Quick integration Figure 1 Model N08CBAUB Embedded Antenna Page 5 Airgain Proprietary Doc. # 5012C-02-00-001-1 Rev. 1.1 Airgain N08CBAUB Engineering Data Sheet 3. Specifications and Interface Standard IEEE 802.11 a/b/g/n/ac Frequency range 2400-2490 MHz, 5925-7125MHz Peak gain 2.7 dBi@2440 MHz, 2.8 dBi@5925 MHz; 2.5 dBi@6300 MHz; 2.2 dBi@6500 MHz; 2.6 dBi@6800 MHz; 4.0 dBi@7125 MHz; VSWR < 2:1 Feed impedance 50 ohms Power handling 30 dBm Interface 50 ohms, 1.13 mm diameter, micro coax cable (available with optional U.FL-compatible cable connector and/or cable-mounted EMI ferrites) Antenna dimensions 33.55 x 15.55 x 0.5 mm Weight 0.89 g Temperature range Operating: -40° C to +75° C (-40° F to +167° F) Storage: -40° C to +85° C (-40° F to +185° F) Humidity range 0% to 95% non-condensing 4. Radiation Patterns Figure 2 Model N08CBAUB Measurement axes X Y Z Page 6 Airgain Proprietary Doc. # 5012C-02-00-001-1 Rev. 1.1 Airgain N08CBAUB Engineering Data Sheet Figure 3 N08CBAUB Azimuth pattern at 2.44 GHz Page 7 Airgain Proprietary Doc. # 5012C-02-00-001-1 Rev. 1.1 Airgain N08CBAUB Engineering Data Sheet Figure 4 N08CBAUB Elevation pattern at 6.5 GHz Page 8 Airgain Proprietary Doc. # 5012C-02-00-001-1 Rev. 1.1 Airgain N08CBAUB Engineering Data Sheet 5. Dimensions Figure 5 N08CBAUB Antenna dimensions 6. ROHS& REACH/SVHC247 Airgain N06CBAUA embedded antennas are ROHS& REACH/SVHC247 compliant. 7. Feature and Options Information Airgain N08CBAUB antennas are equipped with an RF cable I/O interface. Optional cable termination such as U.FL-compati…

Text truncated - open the document above for the full version.

Airgain Embedded Antenna Engineering Data Sheet Profile Series N06CBAUA 3611 Valley Centre Drive, Suite 150 San Diego, CA 92130 USA Tel: +1 760 579 0200 Fax: +1 760 579 0892 Information: [email protected] Sales: [email protected] Support: [email protected] Page 2 Airgain Proprietary Doc. # 5011C-02-00-001-1 Rev1.1 Airgain N06CBAUA Engineering Data Sheet Revision History Revision Date Note 5011C-02-00-001-1 Rev1.0 April 30, 2025 Preliminary Datasheet 1.0 5011C-02-00-001-1 Rev1.1 June 27, 2025 Released datasheet Disclaimers The information in this document is provided in connection with Airgain Antenna products. It is Airgain proprietary and is protected by international intellectual property laws. Airgain may make changes at any time, without notice. Please verify with Airgain before finalizing a product design. Page 3 Airgain Proprietary Doc. # 5011C-02-00-001-1 Rev1.1 Airgain N06CBAUA Engineering Data Sheet Contents 1. Airgain N06CBAUA Embedded Antenna ...................................................................................................... 4 2. Features ............................................................................................................................................................ 4 3. Specifications and Interface ............................................................................................................................. 5 4. Radiation Patterns ............................................................................................................................................ 5 5. Dimensions ...................................................................................................................................................... 7 6. ROHS& REACH/SVHC247 ........................................................................................................................... 7 7. Feature and Options Information ..................................................................................................................... 7 7.1 Part Number Conventions ............................................................................................................................... 8 7.2 Part Number Example ..................................................................................................................................... 8 8. Cable Data Sheet ............................................................................................................................................. 9 Figures Figure 1:Model N06CBAUA Embedded Antenna ........................................................................................................... 4 Figure 2:Model N06CBAUA Measurement axes ............................................................................................................. 5 Figure 3:Airgain N06CBAUA radiation patterns at 5925 MHz to 7125 MHz ...................................................... 6 Figure 4:N06CBAUA Antenna dimensions......................................................................................................................... 7 Figure 5:N06CBAUA with connector or stripped cable ................................................................................................ 8 Page 4 Airgain Proprietary Doc. # 5011C-02-00-001-1 Rev1.1 Airgain N06CBAUA Engineering Data Sheet 1. Airgain N06CBAUA Embedded Antenna The Model N06CBAUA Embedded Antenna provides a high efficiency, 5900-7125MHz band embedded antenna solution for Wi-Fi and ISM band applications, such as WLAN products; very low VSWR makes it suitable for 802.11ax applications. 2. Features The Model N06CBAUA Embedded Antenna is defined by the following features: • IEEE 802.11ax standard • Case mount • Truly balanced operation • Quick integration Figure 1:Model N06CBAUA Embedded Antenna Page 5 Airgain Proprietary Doc. # 5011C-02-00-001-1 Rev1.1 Airgain N06CBAUA Engineering Data Sheet 3. Specifications and Interface Frequency range 5925-7125MHz Peak gain 4.0 dBi@5925 MHz; 4.0 dBi@6300 MHz; 4.2 dBi@6500 MHz; 4.2 dBi@6800 MHz; 4.0 dBi@7125 MHz; VSWR < 2:1 Feed impedance 50 ohms Power handling 30 dBm Interface 50 ohms, 1.13 mm diameter, micro coax cable (available with optional U.FL-compatible cable connector and/or cable-mounted EMI ferrites) Antenna dimensions 54.8 x 10 x 0.5 (mm) Weight 1.17g Temperature range Operating: -40° C to +85° C (-40° F to +185° F) Storage: -40° C to +85° C (-40° F to +185° F) Humidity range 0% to 95% non-condensing 4. Radiation Patterns Figure 2:Model N06CBAUA Measurement axes Z X Y Page 6 Airgain Proprietary Doc. # 5011C-02-00-001-1 Rev1.1 Airgain N06CBAUA Engineering Data Sheet Figure 3:Airgain N06CBAUA radiation patterns at 5925 MHz to 7125 MHz Page 7 Airgain Proprietary Doc. # 5011C-02-00-001-1 Rev1.1 Airgain N06CBAUA Engineering Data Sheet 5. Dimensions Figure 4:N06CBAUA Antenna dimensions 6. ROHS& REACH/SVHC247 Airgain N06CBAUA embedded antennas are ROHS& REACH/SVHC247 compliant. 7. Feature and Options Information Airgain N06CBAUA antennas are equipped with an RF cable I/O interface. Optional cable termination such as U.FL-compatibl…

Text truncated - open the document above for the full version.
