2AYTM-GLBMV1Gemlightbox Macro

SUPPORT.PICUPMEDIA.COM GemLightbox Macro User Manual Welcome to the GemLightbox Family Table of Contents SUPPORT.PICUPMEDIA.COM Welcome Overview What’s Included GemLightbox Macro GemLightbox Application Setting Up Correct Positioning Lighting Options FAQ Join Our Community Appendix 3 4 5 6 7 9 11 12 13 15 16 3 SUPPORT.PICUPMEDIA.COM At Picup Media, we’ve helped over 10,000+ jewelers enter the digital world and hope to share the same experience with you. This user manual will teach you how to set up and use the GemLightbox Macro, its add-ons, and provide useful tips and tricks to help you capture perfect loose stone videos. We recommend reading our full tutorial on the following pages to make the most of your GemLightbox Macro experience. We are thrilled to guide you on your first steps to effortless diamond and gemstone photography. support.picupmedia.com Welcome GEMLIGHTBOX MACRO USER MANUAL | WELCOME VISIT THE LINK TO WATCH THE SETUP VIDEO! 4 SUPPORT.PICUPMEDIA.COM Overview Different Lighting Options Sparkles, 5500k, 3500k, 6500k Depth Adjustment Smartphone Holder Power On Height Adjustment Reflector Cover with built- in macro lens 10x zoom GEMLIGHTBOX MACRO USER MANUAL | OVERVIEW 5 SUPPORT.PICUPMEDIA.COM GEMLIGHTBOX MACRO USER MANUAL | WHAT’S INCLUDED What’s Included GemLightbox Macro 1pc International power adapter 1pc Grey loose stone table tops 3pcs Black loose stone table tops 3pcs White loose stone table tops 3pcs VISIT THE LINK TO WATCH THE SETUP VIDEO! 6 SUPPORT.PICUPMEDIA.COM GEMLIGHTBOX MACRO USER MANUAL | GEMLIGHTBOX MACRO GemLightbox Macro 7 SUPPORT.PICUPMEDIA.COM GemLightbox Application GEMLIGHTBOX MACRO USER MANUAL | GEMLIGHTBOX APP The GemLightbox Application is your all-in- one diamond and loose stone photography companion, and is essential to capturing amazing diamond and loose stone images and videos. Simply follow the steps below to get started: iOS App Store Google Play Store The GemLightbox Application is available to download on both the iOS App Store and Google Play Store. To download, simply search for “GemLight- box” and follow the download instructions, or scan the QR code. 1 Download the Application Click “Sign Up”, then follow the steps to create your GemLightbox Application account. Please note that only one device may be logged into an account at any time. 2 Create an Account 8 SUPPORT.PICUPMEDIA.COM GEMLIGHTBOX MACRO USER MANUAL | GEMLIGHTBOX APP GemLightbox Application Watch Setup Video here: The GemLightbox Application optimizes your smartphone camera settings for jewelry and diamond photography, meaning that you’ll capture the best results every time. The GemLightbox Application connects with your GemLightbox Macro unit directly via Bluetooth. Please ensure that the Bluetooth setting on your smartphone is enabled in order to successfully connect with the GemLightbox Macro. To learn more about the GemLightbox Application functions and its newest updates, simply visit our online knowledge base at https://support.picupmedia.com for more information. Setting Up VISIT THE LINK TO WATCH THE SETUP VIDEO! 9 SUPPORT.PICUPMEDIA.COM GEMLIGHTBOX MACRO USER MANUAL | SETTING UP Scan here to see more detailed instructions for your phone model Setting Up Before you set up the smartphone stand, please ensure to remove the front Macro cov- er and your smartphone case, if any. 1 Lift the lock counterclockwise to loosen the smartphone holder. 2 Adjust the smartphone holder. Ensure that the smartphone camera lens is pointing right into the Macro lens. 3 Push the width adjuster towards your phone. Lock it by rotating clockwise. *See Appendix for complete smartphone holder set-up process. Once the procedure is complete, we suggest not to change the set-up again for ease of use in the future. 1 Set up the smartphone stand 1 2 3 Macro comes with three (3) loose stone discs to match the size of your loose stones. • Small for stones under 1ct • Medium for 1 -10ct • Large for 10ct and above The loose stone discs come in 3 colors - white, grey, and black. Simply place the loose stone disc on top of the metal stand inside of the GemLightbox Macro and firmly push down to secure it in place. 2 Choose the correct loose stone disc 3x Small (for under 1ct) 3x Medium (for under 10ct) 3x Large (for 10ct-50ct) 10 SUPPORT.PICUPMEDIA.COM GEMLIGHTBOX MACRO USER MANUAL | SETTING UP Setting Up 4 Using the Macro lens When using the Macro lens, ensure the following: • The Macro lens is on before starting photography. • Keep the lens away from water and other liquids. • Use a microfiber cloth to clean the lens from time to time to ensure the best results. Scan here to see more detailed instructions for your phone model 3 Using the adjuster, adjust the height and width The height adjuster and the depth adjuster on the left and right side of the box allow you to move the center point of the turntable so that you can capture the best angle of your loose stone. 11 SUPPORT.PICUPMEDIA.COM Correct Positioning GEMLIGHTBOX MACRO USER MANUAL | CORRECT POSITIONING Correct positioning of your loose stones is critical to the quality of the 360-video. Position the loose stone correctly to capture the details of the gems or diamonds in the best light possible. Follow the steps below for the optimal position. Use the height and depth adjustment on both sides of the box to adjust the posi- tion of the loose stone. En- sure that the stone is not too far backward or too far for- ward to get the best result. Always position the gem in the center of the disc; oth- erwise, the gem will be car- ried farther away from the center of the turntable when it rotates. The disc comes with a groove to mark the center point. Place the gem right on the groove and start shooting. Use the width and height adjustment to position the gemstones closer or farther away from the lens. Small stones should be moved closer to the lens and large ones farther away from the lens to achieve the optimal result. Small stoneLarge stone 12 SUPPORT.P…

Text truncated - open the document above for the full version.

HEIG LIMITED Model Difference Product Name: Gemlightbox Macro Model Number: GLBMV1, GLBM, GLBMV2, GLBMV3, GLBMV4, GLBMV5 FCC Identifier: 2AYTM-GLBMV1 All the models are the same circuit and RF module, except the model names and outlook color. Regards Sincerely Client’s signature Client’s name / title : Zeng Kevin / Manager Contact information / address: 7/F, Low Block, Grand Millennium Plaza 181 Queen’s Road, Central HongKong

HEIG LIMITED 1/1 Letter of Authorization Company: HEIG LIMITED Address: 7/F, Low Block, Grand Millennium Plaza 181 Queen’s Road, Central HongKong Product Name: Gemlightbox Macro Model Number: GLBMV1, GLBM, GLBMV2, GLBMV3, GLBMV4, GLBMV5 FCC Identifier: 2AYTM-GLBMV1 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Zeng Kevin Date: 2021-01-28 Title: Manager Signature of applicant:

HEIG LIMITED 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-01-28 Subject: Request for Confidentiality FCC ID: 2AYTM-GLBMV1 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Zeng Kevin Title: Manager

Model: GLBMV1

Size:18*15mm M/N: GLBMV1 FCC ID: 2AYTM-GLBMV1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

Model: GLBMV1 Antenna location

Global United Technology Services Co., Ltd. Report No.: GTSL202101000189F01 Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 30 + TEST REPORT Applicant: HEIG LIMITED Address of Applicant: 7/F, Low Block, Grand Millennium Plaza 181 Queen’s Road, Central HongKong Manufacturer: BKL Industries Limited Address of Manufacturer: Building A2,Fangxing Science & Technology Park,No.13 Baonan Rd., Nanlian,Longgang District, Shenzhen, Guangdong, China 518116 Equipment Under Test (EUT) Product Name: Gemlightbox Macro Model No.: GLBMV1, GLBM, GLBMV2, GLBMV3, GLBMV4, GLBMV5 Trade Mark: GemLightbox FCC ID: 2AYTM-GLBMV1 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 Date of sample receipt: Jan. 22, 2021 Date of Test: Jan. 22, 2021 - Jan. 27, 2021 Date of report issued: Jan. 27, 2021 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Report No.: GTSL202101000189F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 30 2 Version Version No. Date Description 00 Jan. 27, 2021 Original Prepared By: Date: Jan. 27, 2021 Project Engineer Check By: Date: Jan. 27, 2021 Reviewer Report No.: GTSL202101000189F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 30 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 7 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.4 DEVIATION FROM STANDARDS ............................................................................................................ 7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................. 7 5.6 TEST FACILITY ................................................................................................................................... 8 5.7 TEST LOCATION ................................................................................................................................. 8 5.8 ADDITIONAL INSTRUCTIONS ................................................................................................................ 8 6 TEST INSTRUMENTS LIST ..................................................................................................................... 9 7 TEST RESULTS AND MEASUREMENT DATA .................................................................................... 11 7.1 ANTENNA REQUIREMENT ................................................................................................................... 11 7.2 CONDUCTED EMISSIONS ................................................................................................................... 12 7.3 RADIATED EMISSION METHOD ........................................................................................................... 15 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 17 7.3.2 Spurious emissions .................................................................................................................... 18 7.3.3 Bandedge emissions .................................................................................................................. 23 7.4 20DB OCCUPY BANDWIDTH .............................................................................................................. 24 8 TEST SETUP PHOTO ............................................................................................................................ 26 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 28 Report No.: GTSL202101000189F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 30 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 Pass Field strength of the fundamen…

Text truncated - open the document above for the full version.

Measurement Photos Model: GLBMV1
