GemLightbox PRO User Manual Scan to watch Setup Video The Picup Media Team At Picup Media, we’ve helped over 10,000+ jewelers enter the digital world and we hope to share the same experience with you! We created GemLightbox PRO during the pandemic to seamlessly assist the industry into going digital when going digital is the ONLY way forward. As you take your first GemLoupe photo, we want to say thank you and congratulations! The digital future is now, but together, we will thrive! Onwards to business resiliency! 15 Thank You Thank you! GemLightbox Pro 2014: Release of GemLightbox; The World's First Smartphone Jewelry Lightbox 2016: Release of GemLightbox Turntable and GemLightbox App 2019: Release of GemLightbox Aerial; World's first dangling turntable 2022: GemLightbox PRO ALL-IN-ONE GemLightbox. GemLightbox Pro Built in Aerial turntable Built in base turntable Bigger, faster and Pro lighting Adjustable lighting Photography automation to capture 1 video and 4 photographs in one click! GemLightbox Pro Removable lid to reveal top shooting angle Power Removable reflector Power socket Plug in power cable here Switch between manual and GemLightbox app control Slow: turntable will be rotating endlessly at 30 seconds/ 360 rotation FAST: turntable will be rotating endlessly at 15 seconds/ 360 rotation APP: Turntable can be connected to the GemLightbox APP. Accessories GemLoupe User Manual | What’s Included GemLightbox PRO What’s Included? 2 Scan to download Or search for “GemLightbox” in your App Store Before you start Install the GemLightbox App GemLightbox App 4 10 GemLightbox Pro is a plug and play solution, with absolutely no setup required. Simply plug in the adapter and Power on How to Take Photos and Videos Power cable at the back of box Power on Power On Top shooting angle Front shooting angle Two shooting angles This angle will give you a bird's eye view of the jewelry. Remove the diamond piece from the lid and slide the turntable to the side to reveal the top shooting angle. Front shooting angle is the most common shooting angle GemLoupe User Manual | What’s Included Step 1: Setup Jewelry or gemstone 2 Hang necklaces using the necklace stand GemLoupe User Manual | What’s Included 2 Hang Necklaces GemLoupe User Manual | What’s Included 2 Hang Earrings by attaching them onto the T- bar stands and then attaching it onto the necklace stand. Hang Earrings GemLoupe User Manual | What’s Included 2 Hang watches by placing the watch onto the watch stand and then attaching it onto the necklace stand. Hang Watches GemLoupe User Manual | What’s Included 2 Place brooches, rings and other accessories on the base turntable. Place in jewelry on the base turntable GemLoupe User Manual | What’s Included 2 Place gemstones on the base turntable GemLoupe User Manual | What’s Included 2 Additional lighting “Sparkles” sits at 5500k and is used to bring out natural sparkles without damaging the nature of the stone. It is a direct light source designed to highlight natural fires and scintillation. The PRO comes with 2 additional add-on lights to help you bring out the true color and sparkle in all your jewelry items. “Yellow” is another add-on light that sits at 3500k, and mimics a natural sunlight environment. This feature works best for Rubies, Emeralds, Sapphires, Opals, and any other stones that require yellow light to bring out their true color. SparklesYellow GemLoupe User Manual | What’s Included 2 If you have not installed the GemLightbox app yet. Simple search for “GemLightbox” on the iOS App store or Google Play store or scan the QR code here Step 2: Connect the GemLightbox APP GemLoupe User Manual | What’s Included 2 Once you are in the Application, open up the Bluetooth section and connect to the GemLightbox Pro by clicking on it. Connect to bluetooth GemLoupe User Manual | What’s Included 2 You can place your smartphone vertically or horizontally. Place your smartphone horizontally to get a direct front on view of your jewelry Place your phone vertically to capture your jewelry from a 45 degree view Place smartphone onto stand 3 Smartphone stand To adjust, simply open up the smartphone stand and place the legs at the angle you wish. You can also adjust the height. Simply push the stand upwards or downwards. The smartphone stand is used to hold your smartphone steady when photographing your jewelry. Place your smartphone onto the smartphone stand and adjust to your desired angle. How to Install 5 Step 3 Click to capture One click away! How to Install 5 1 videos and 4 photos in 15 seconds! Simply click the capture button and the PRO will go into automation creating a perfect 360 video and 4 still photographs for you in just one click! This allows you to complete your entire photography for each product in just 15 seconds! Burst mode The PRO comes with a built in automation feature that automatically takes photos for you during the video process; saving you even more time! The Picup Media Team At Picup Media, we’ve helped over 10,000+ jewelers enter the digital world and we hope to share the same experience with you! We created GemLoupe during the pandemic to seamlessly assist the industry into going digital when going digital is the ONLY way forward. As you take your first GemLoupe photo, we want to say thank you and congratulations! The digital future is now, but together, we will thrive! Onwards to business resiliency! 15 Thank You Thank you! 4.9 333 Reviews 10X Magnification For loose diamonds and gemstones 0.1 carat to 50 carats GemLightbox Macro www.picupmedia.com/macro Looking for a solution to capture loose diamonds? Learn more at: Discuss, learn, and network with other jewelers worldwide Find us on social media Community Scan Here to join facebook group 14 Join Jewelers Network @gemlightbox Picup Media GemLightbox @picup_media This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)…

Text truncated - open the document above for the full version.

HEIG LIMITED 1/1 Letter of Authorization Company: HEIG LIMITED Address: 7/F, Low Block, Grand Millennium Plaza 181 Queen’s Road, Central HongKong Product Name: GemLightbox PRO Model Number: GLBPRO FCC Identifier: 2AYTM-GLBPRO We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Zeng Kevin Date: 2022-08-02 Title: Manager Signature of applicant:

HEIG LIMITED 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022-08-02 Subject: Request for Confidentiality FCC ID: 2AYTM-GLBPRO To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Zeng Kevin Title: Manager

Size:16*14mm M/N: GLBPRO FCC ID: 2AYTM-GLBPRO Label location

ANT

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220728025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 38 FCC Part 15C Test Report FCC ID: 2AYTM-GLBPRO Applicant: HEIG LIMITED Address: 7/F, Low Block, Grand Millennium Plaza 181 Queen’s Road, Central HongKong Manufacturer: Shenzhen BKL Technology Co., Ltd. Address: Building A2,Fangxing Science & Technology Park, No.13 Baonan Rd., Nanlian,Longgang District, Shenzhen, Guangdong, China. Zip:518116 EUT: GemLightbox PRO Trade Mark: Model Number: GLBPRO Date of Receipt: Jul. 18, 2022 Test Date: Jul. 18, 2022 - Jul. 28, 2022 Date of Report: Jul. 28, 2022 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.249 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20220728025E Prepared (Test Engineer): Pxing Huang Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220728025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 38 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 20 3.3.1 TEST REQUIREMENT: 20 3.3.2 TEST PROCEDURE 20 3.3.3 DEVIATION FROM TEST STANDARD 20 3.3.4 TEST SETUP 21 3.3.5 EUT OPERATING CONDITIONS 21 4 . BANDWIDTH TEST 23 4.1 APPLIED PROCEDURES / LIMIT 23 4.1.1 TEST PROCEDURE 23 4.1.2 DEVIATION FROM STANDARD 23 4.1.3 TEST SETUP 23 4.1.4 EUT OPERATION CONDITIONS 23 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220728025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 38 Table of Contents Page 4.1.5 TEST RESULTS 24 5 . ANTENNA REQUIREMENT 25 5.1 STANDARD REQUIREMENT 25 5.2 EUT ANTENNA 25 6 . TEST SEUUP PHOTO 26 7 . EUT PHOTO 28 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220728025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 38 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.205(a), 15.209(a) 15.249(a), 15.249(c) Fundamental &Radiated Spurious Emission Measurement PASS 15.249(d) Band Edge Emission PASS 15.215(c) 20dB Bandwidth PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220728025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 38 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: GemLightbox PRO Trademark Model No.: GLBPRO Model Difference N/A Operation Frequency: 2402~2480MHz Channel numbers: 40 Channels Channel separation: 2M Modulation technology: GFSK Antenna Type: Internal Antenna Antenna gain: -0.68dBi Power supply: DC 12V from adapter Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2.The EUT’s all information provided by client. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220728025E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 38 3. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 14 2430 27 2456 01 2404 15 2432 28 2458 02 2406 16 2434 29 2460 03 2408 17 2436 30 2462 04 2410 18 2438 31 2464 05 2412 19 2440 32 2466 06 2414 20 2442 33 2468 07 2416 21 2444 34 2470 08 2418 22 2446 35 2472 09 2420 23 2448 36 2474 10 2422 24 2450 37 2476 11 2424 25 2452 38 2478 12 2426 26 2454 39 2480 13 2428 / / / / 2.2 DESCRIPTION OF TEST MODES Note: (1) The measurements are performed at the highest, middle, lowest available channels. (2) A new fully charged battery was used for testing during the test. To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 CH00 GFSK Mode 2 CH19 Mode 3 CH39 Mode 4 Link Mode For Con…
