2AYU8-2044DOG TRAINING COLLAR

FCC Instructions： This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This product generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the product does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the product and receiver. -- Connect the product into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference.(2)this device must accept any interference received, including interference that may cause Undesired operation. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 5mm between the radiator & your body. 3

ExternalPhotographs YX-2044 TXDevice RXDevice

、 ＼ f 飞 67.8X18.6MM DOG TRAINING COLLAR Mode: YX-2044 Input: DC 3.7V by Battery FCC ID: 2AYU8-2044 Made in china ＼、 〈《FCR。HS2三

InternalPhotographs YX-2044 RFANT

DongguanYanxitechnologyco.,Ltd. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:YX-2044 FCCID:2AYU8-2044 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: ModelNo.ofantenna:N/A Typeofantenna:WireAntenna Gainoftheantenna:0dBi Frequencyrange:433.93MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Sincerely, Signature [LiYonghua] [GeneralManager] [DongguanYanxitechnologyco.,Ltd.] version01

KSIGN (Guangdong) Testing Co., Ltd. West Side of 1/F., Building C, Zone A, Fuyuan New Factory, Jiujiu Industrial Park, Minzhu,Shatou, Shajing, Bao'an District, Shenzhen, Guangdong, People’s Republic of China Tel.: + (86)755-29852678 Fax: + (86)755-29852397 E-mail: [email protected] Website: www.gdksign.com RF EXPOSURE EVALUATION PRODUCT INFORMATION Product Description DOG TRAINING COLLAR Model Name YX-2044 FCC ID 2AYU8-2044 Max. output power 83.76dBuV/m (-11.498dBm)(0.070mW) Portable Device According to §15.247(i) and §1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance V6, section 4.3.1. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 16 where ·f(GHz) is the RF channel transmit frequency in GHz ·Power and distance are rounded to the nearest mW and mm before calculation17 ·The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. KSIGN (Guangdong) Testing Co., Ltd. West Side of 1/F., Building C, Zone A, Fuyuan New Factory, Jiujiu Industrial Park, Minzhu,Shatou, Shajing, Bao'an District, Shenzhen, Guangdong, People’s Republic of China Tel.: + (86)755-29852678 Fax: + (86)755-29852397 E-mail: [email protected] Website: www.gdksign.com Measurement Result Channel Frequency (MHz) Max Output power (dBm) Max tune-up tolerance Output power (dBm) Max Output power (mW) Calculation Value (Note 1) Threshold Value 433.93 -11.498 -11.498±1 0.089 0.012 3.0 EIRP=E-104.8+20logD= 83.76-104.8+20log3=-11.498dbm Note 1: Calculation Value =[(max. power of channel,mW /min.test separation distance,mm) *√f(GHz)]. Fox example: 0.089/5*√0.43393=0.012≤3.0 KSIGN (Guangdong) Testing Co., Ltd. West Side of 1/F., Building C, Zone A, Fuyuan New Factory, Jiujiu Industrial Park, Minzhu,Shatou, Shajing, Bao'an District, Shenzhen, Guangdong, People’s Republic of China Tel.: + (86)755-29852678 Fax: + (86)755-29852397 E-mail: [email protected] Website: www.gdksign.com According to KDB447498 D01 V6, threshold at which no SAR required is ≤3.0 for 1-g SAR, separation distance is 5mm, and no simultaneous SAR measurement is required. Standard Applicable According to 2.1093 this is a portable device. According to KDB 447498 D01 V6, Appendix A SAR test exclusion thresholds for below table, the power level 22mW at 5mm. Measurement Result: This is a portable device and the Max. peak output power is -10.498dBm(0.089mW) lower than low threshold 22mW at 5mm in general population category; The SAR measurement is not necessary.
