2AYVT-S9246LAV3 Smart Band

V3 Smart Band User Guide Product Summary Prompts: To make heart rate measurement more accurate, please wear the bracelet on the wrist away from the carpal bone; Please wear it close to the skin but not too tight. The bracelet and watchband are made of healthy materials, and which can be worn safely. If you feel dis-comfortable during wearing it for personal differences, such as skin discomfort, please stop wearing and consult your doctor. Contact point of the recharging thimble Heart rate Blood oxygen sensor Short watch band Long watch band Full-screen touch area (Support to slide up, down, left and right, and support long press selection) Side button (turn the watch off by pressing it for 3 seconds) Enter the mode to be paired Whenusingthewatchforthefirsttime, long press the power button (side button) for 6 seconds, the watch will vibrate and the logo will appear. Then the watch will start up and enter the mode to be paired. 1 Download "Band V3" App Search for "Band V3" in the app market to download and install. Setting and Pairing Click the plus icon in Watch V3 to add the device. Select the V3 band from a nearby device. Add device Scanning nearby device... Main screen operation Slide downward for rapid setting Slide upward for the list of functional menu Slideleftward,checkthefirstsmall part Press and hold for 3s for editing the watch face Slide rightward, check the information Press Turn on, off Press Wake the watch up Go back to the previous screen Lighten the screen, turn the screen off 2 Recharging: If you need to charge the bracelet, place the bracelet on the charging stand and make sure that the charging contact of the bracelet is aligned with the metal contact of the recharging base. Prompts: If
the
bracelet
hasn’t
been
used
for
a
long
time,

the
electricity
quantity
is
used
up,
the
watch
needs
a
long
time
to
start
automatically; Before
recharging,
please
clean
up
the
bracelet’s
contract
point,
to
avoid
residual
sweat
or
water. Replacement of the watch band Toggle the switch and press it, you can remove or install the watch band. Magnetic recharger Recharging contact point Packing List Noumenon of the bracelet/recharging base/user’s guide 3 To view the relevant regulatory information, please go to set the regulatory information about the bracelet. Medical Disclaimer Warning: This product is not a medical device. This Product and its related applications are not intended to diagnose, treat or prevent any disease or medical condition. Always consult a medical professional before you adjust your exercise, sleep, or nutrition schedule. Product Parameters Type: S9246LA Bluetooth: Support BLE Bluetooth frequency: 2402-2480 MHz Bluetooth’stransmittingpower:≤3.99dBm(Max) Equipment requirements: ios 11 and above or Android 5.0 and above Waterproof grade: IP68 Input: 5V 0.09A Working temperature: 0°C~45°C Storage temperature: -10~50°C Regulation Information Safety and Cautions Before using and operating the device, please read and observe the following precautions to ensure the best performance of the device and avoid dangerous or illegal situations. Routine use • When the bracelet is actively used to measure the heart rate or blood oxygen, please keep the wrist rest. • Waterproof grade of this product is IP68, you can wash your hands during wearing it, or wear it under the conditions of sweating, rain, dust, but it can’t be worn in situations of swimming, showering, sauna, and diving. • The bracelet’s touch screen does not support underwater operation, after being touched with water, it’s surface shall be dried with a soft cloth before operation. • Please avoid wearing tightly in daily use; Keep dry and clean 4 at the contact area between the bracelet and skin, the bracelet shall be cleaned with water regularly. If there is redness and swelling at the contact position, please discontinue use it immediately and consult your doctor. Electronic equipment Intheplaceswherebtheuseofwirelessdeviceshavebeen expressly forbidden, do not use this device, otherwise it will interfere with other electronic equipment or cause other dangerous. Safety of the battery • Keep the recharging base and device being in a dry environment when recharging; Do not touch the recharging base with your hands. Do not immerse the recharging base with water or other liquids. • Do not disassemble or modify the battery, insert foreign matter, or immerse the battery in water or other liquids to avoidbatteryleakage,overheating,fire,orexplosion. • Do not drop, squeeze, or puncture the battery. Do not expose the battery to excessive external pressure, which may cause internal short circuit and overheating. • The device is equipped with a non-removable built-in battery. Do not replace the battery by yourself to avoid damage to the battery or the device. The battery can only be replaced by authorized service centers. • Please dispose of the battery according to local instructions. Do not dispose of the battery as household garbage. Repair and maintenance • Before cleaning and maintaining the device, stop using of the device, close all applications, and disconnect all connections or cables from other devices. Use a clean, dry, soft cloth to wipe the device and its accessories. Do not use strong chemicals, cleaning agents or strong detergents to clean the equipment and its accessories. • Do not touch magnetic stripe cards (such as bank cards and phone cards) with the device for a long time. Otherwise, the magneticstripecardsmaybedamagedbymagneticfields. Operating environment • Please use the equipment in the temperature range of 0 °C~45°C, and store the equipment and its accessories in the temperature range of -10°C~50°C. When the ambient temperature is too high or too low, the device may be faulty. When temperatures are below 5°C, battery performance may be limited. Transportation safety •Wirelessdevicesmayinterferewiththeflightsystemofthe aircraft: Please comply with the re…
