2AZ4R-T269278-T1 Curtain Gem Lights, Enbrighten WIFI, RGB 3ft by 7ft, 69281-T2 Enbrighten WIFI String Fairy Lights RGB 20ft

INSTALLATION Suppliers Declaration of Conformity | Model # 69278 | Jasco Products Co., 10 E. Memorial Rd., Oklahoma City, OK 73114, www.byjasco.com. This device complies with Part 15 of the FCC and Industry Canada license exempt RSS standards. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAN ICES-3(B)/NMB-3(B) LED Wi-Fi Curtain Lights Model – 69278 Your Enbrighten Smart LED Wi-Fi Curtain Lights transform your space with dynamic colors and customization — all using the free Enbrighten Wi-Fi app. Read all instructions before installing. Please read all the warning statements included in these instructions. Scan the QR code or search Enbrighten on the Apple App Store or on Google Play Download the app Add devices, control the smart curtain lights from anywhere and create schedules Setup and installation 3. Hang and plug in the smart curtain lights Setup and installation Create an account in the Enbrighten app 1. 2. Voice control works with Amazon Alexa or Google Assistant Select "Support" in the Enbrighten app or follow the steps in the Amazon Alexa or Google Home app to connect your Enbrighten account Voice control 12 43 Remotely operate your smart curtain lights with the easy-to-use Enbrighten app. Follow the available instructions and resources to set up your smart device. NOTE: For best results, pair your lights near your router prior to installation. Requires 2.4GHz Wi-Fi connection. Thank you for your purchase! Instructions made easy Register your product Discover innovative lighting solutions at enbrightenme.com. Like our product? Leave a review on your favorite retailer website or amazon.com. Having problems? Let us know how we can help. Call 1-800-654-8483 between 7AM-8PM, M-F, Central Time. Read instructions or watch easy-to-follow video. Scan code or visit byjasco.com/69278i. Receive exclusive deals and register your product. Scan code or visit byjasco.com/deals. 69278 v1 9/22 MADE IN CAMBODIA Distributed by Jasco Products Company LLC, 10 E. Memorial Rd., Oklahoma City, OK 73114. This Jasco product comes with a 1-year limited warranty. Visit www.byjasco.com for warranty details. Questions? Contact our U.S.-based Consumer Care at 1-800-654-8483 between 7AM-8PM, M-F, Central Time. STEP 1: HANG CURTAIN LIGHTS Use the built-in hooks to hang the curtain lights in your preferred indoor or covered outdoor location. Ensure the 13ft. USB power cord is within reach of a power source. STEP 2: UNTIE LED STRINGS AND POWER CORD Carefully untie and straighten out each LED string and the USB power cord. 13ft.1ft. 7ft. STEP 3: PLUG INTO USB-A PORT Plug the USB power cord into a 5V, 1A minimum USB-A port or adapter (not included). RISK OF ELECTRIC SHOCK • RECEPTACLE OUTLETS USED FOR POWERING CURTAIN LIGHTS SHALL COMPLY WITH ALL NATIONAL AND LOCAL ELECTRICAL CODES. CONSULT LOCAL ELECTRICIAN IF UNSURE OF COMPLIANCE REQUIREMENTS. • DO NOT SUBMERSE. • DO NOT USE AROUND AQUARIUMS. • DO NOT USE IN WET LOCATIONS. • DO NOT INSTALL IN LOCATIONS WHERE CURTAIN LIGHTS CAN BE STEPPED ON. • ENSURE CURTAIN LIGHTS ARE UNPLUGGED FROM POWER DURING INSTALLATION. • CURTAIN LIGHTS SHOULD BE INSTALLED OUT OF CHILDREN’S REACH. DO NOT ALLOW CHILDREN TO PLAY WITH THEM. RISK OF FIRE • NOT INTENDED FOR USE NEAR OPEN FLAMES OR ABOVE STOVES, COOK TOPS, SINKS OR OTHER HEAT PRODUCING APPLIANCES, SUCH AS COFFEE MAKERS, TOASTERS OR TOASTER OVENS. • USE INDOORS OR IN PROTECTED OUTDOOR LOCATIONS ONLY. WARNING USB power Laptop Power bank MANUAL OPERATION Press the button on the USB plug to cycle through 12 lighting effects. 1. Float 2. Rainbow 3. Snake 4. Rainbow chase 5. Flying 6. Red/Yellow Flash 7. Crash 8. Bounce 9. Twinkle 10. Flash 11. Pulse 12. Strobe All brand names shown are trademarks of their respective owners. App Store is a service mark of Apple Inc. Google, Google Play and Google Home are trademarks of Google LLC. Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. INSTALACIÓN Declaración de conformidad de proveedores | Modelo n.º: 69278 | Jasco Products Co., 10 E. Memorial Rd., Oklahoma City, OK 73114, www.byjasco.com. Este dispositivo cumple con las normas RSS de exención de licencia de la Parte 15 de la FCC y de Industry Canada. Su funcionamiento está sujeto a las siguientes dos condiciones: (1) este dispositivo no podrá causar interferencias perjudiciales, y (2) este dispositivo debe aceptar cualquier interferencia recibida, incluidas las interferencias que puedan causar un funcionamiento no deseado. NOTA DE LA FCC: El fabricante no se responsabiliza…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 1 of 4 Appendix External Photos for GZCR2210001284LM Test Model No.: 69281-T2 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 4 of 4

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 1 of 4 Appendix Internal Photos for GZCR2210001284LM Test Model No.: 69281-T2 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 4 of 4 RF ANT

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000128403 Page: 1 of 9 FCC ID: 2AZ4R-T2 Kobe Jian EMC Laboratory Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2210001284LM Applicant:Lamues Light Enterprise Co., Ltd Address of Applicant:NO.3, STREET 86K, PHUM TRAPEANG CHREY, SANGKAT KAKAB, KHAN POR SEN CHEY, PHNOM PENH CITY, CAMBODIA. Manufacturer:Lamues Light Enterprise Co., Ltd Address of Manufacturer:NO.3, STREET 86K, PHUM TRAPEANG CHREY, SANGKAT KAKAB, KHAN POR SEN CHEY, PHNOM PENH CITY, CAMBODIA. Factory:Lamues Light Enterprise Co., Ltd Address of Factory:NO.3, STREET 86K, PHUM TRAPEANG CHREY, SANGKAT KAKAB, KHAN POR SEN CHEY, PHNOM PENH CITY, CAMBODIA. Equipment Under Test (EUT): EUT Name:69278-T1: Curtain Gem Lights, Enbrighten WIFI, RGB 3ft by 7ft 69281-T2: Enbrighten WIFI String Fairy Lights RGB 20ft Model No.: 69281-T2, 69278-T1   Please refer to section 2 of this report which indicates which item was actually evaluated and which were electrically identical. Standard(s) : 47 CFR Part 1.1310 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2022-10-10 Date of Evaluation: 2022-10-20 Date of Issue: 2022-11-09 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000128403 Page: 2 of 9 Revision Record VersionReport No.DateRemark 01GZCR2210001284032022-11-09Original Authorized for issue by: Pank Feng/Project Engineer Ricky Liu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000128403 Page: 3 of 9 2Evaluation Summary ItemStandardMethodRequirementResult RF Exposure KDB447498D01 General RF Exposure Guidance v06 KDB447498D01 General RF Exposure Guidance v06 47 CFR Part 1.1310Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section.  Declaration of EUT Family Grouping: Model No.: 69281-T2, 69278-T1 According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only difference on model name. Therefore, only one model 69281-T2 was tested in this report. Model 69281-T2Model 69278-T1 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000128403 Page: 4 of 9 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................4 4General Information.................................................................................................................................5 4.1Details of E.U.T.................................................................................................................................5 4.2Evaluating Location...........................................................................................................................5 4.3Facility...............................................................................................................................................6 4.4Deviation from Standards..................................................................................................................6 4.5Abnormalities from Standard Conditions...........................................................................................6 5Technical Requirements Specification..................................................................................................7 5.1General Description of Applied Standards........................................................................................7 5.2RF Exposure Evaluation....................................................................................................................7 5.2.1Limit & Test Method......................................................................................................................7 5.2.2Conclusion....................................................................................................................................8 6EUT Constructional Details (EUT Photos).............................................................................................9 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000128403 Page: 5 of 9 4General Information 4.1Details of E.U.T. Power supply:DC 5V Cable(s):DC cable: about 3.6m unshielded For Bluetooth: Version:V5.1 LE Operation Frequency:2402MHz to 2480MHz Modulation Type:GFSK Number of Channels:40 Channel Spacing:2MHz For WiFi: Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz; 802.11n(HT40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK); 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels:802.11b/g/n(HT20): 11 802.11n(HT40): 7 Channel Spacing:802.11b/g/n(HT20)/(HT40):5MHz Antenna Type:Integral Antenna Antenna Gain:1.96dBi 4.2Evaluating Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou Branch EMC Laboratory, 198 Kezhu Road, Scientech Park, Guangzhou Economic & Technology Development District, Guangzhou, China 510663 Tel: +86 20 82155555Fax: +86 20 82075059 No tests were sub-contracted. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000128403 Page: 6 of 9 4.3Facility The facility is recognized, certified, or accredited by th…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 1 of 144 FCC ID: 2AZ4R-T2 Kobe Jian EMC Laboratory Manager TEST REPORT Application No.: GZCR2210001284LM Applicant: Lamues Light Enterprise Co., Ltd Address of Applicant: NO.3, STREET 86K, PHUM TRAPEANG CHREY, SANGKAT KAKAB, KHAN POR SEN CHEY, PHNOM PENH CITY, CAMBODIA. Manufacturer: Lamues Light Enterprise Co., Ltd Address of Manufacturer: NO.3, STREET 86K, PHUM TRAPEANG CHREY, SANGKAT KAKAB, KHAN POR SEN CHEY, PHNOM PENH CITY, CAMBODIA. Factory: Lamues Light Enterprise Co., Ltd Address of Factory: NO.3, STREET 86K, PHUM TRAPEANG CHREY, SANGKAT KAKAB, KHAN POR SEN CHEY, PHNOM PENH CITY, CAMBODIA. Equipment Under Test (EUT): EUT Name: 69278-T1: Curtain Gem Lights, Enbrighten WIFI, RGB 3ft by 7ft 69281-T2: Enbrighten WIFI String Fairy Lights RGB 20ft Model No.: 69281-T2, 69278-T1   Please refer to section 2 of this report which indicates which item was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2022-10-10 Date of Test: 2022-10-12 to 2022-10-20 Date of Issue: 2022-11-09 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 2 of 144 Revision Record Version Report No. Date Remark 01 GZCR221000128402 2022-11-09 Original Authorized for issue by: Pank Feng/Project Engineer Ricky Liu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 3 of 144 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 4 of 144  Declaration of EUT Family Grouping: Model No.: 69281-T2, 69278-T1 According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only difference on model name. Therefore, only one model 69281-T2 was tested in this report. Model 69281-T2 Model 69278-T1 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 5 of 144 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 5 4 General Information .................................................................................................................................. 7 4.1 Details of E.U.T. ................................................................................................................................. 7 4.2 Description of Support Units .............................................................................................................. 7 4.3 Measurement Uncertainty .................................................................................................................. 8 4.4 Test Location ...................................................................................................................................... 8 4.5 Test Facility ........................................................................................................................................ 9 4.6 Deviation from Standards ................................................................................................................... 9 4.7 Abnormalities from Standard Conditions ........................................................................................... 9 5 Equipment List ........................................................................................................................................ 10 6 Radio Spectrum Technical Requirement ............................................................................................. 13 6.1 Antenna Requirement ...................................................................................................................... 13 6.1.1 Test Requirement: ................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 87 of 144 1.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 88 of 144 1M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 89 of 144 2. Bandwidth 2.1 6dB BW 2.1.1 Test Result Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 0.675 >=0.5 Pass 2440 1 0.678 >=0.5 Pass 2480 1 0.676 >=0.5 Pass SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 90 of 144 2.2.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 91 of 144 1M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 92 of 144 3. Maximum Conducted Output Power 3.1 Power 3.1.1 Test Result Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 1M SISO 2402 -3.08 <=30 Pass 2440 -2.58 <=30 Pass 2480 -3.81 <=30 Pass Note1: Antenna Gain: Ant1: 1.96dBi; SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 93 of 144 3.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 94 of 144 1M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 95 of 144 4. Maximum Power Spectral Density 4.1 PSD 4.1.1 Test Result Mode TX Type Frequency (MHz) Maximum PSD (dBm/3kHz) Verdict ANT1 Limit 1M SISO 2402 -15.45 <=8 Pass 2440 -15.40 <=8 Pass 2480 -16.42 <=8 Pass Note1: Antenna Gain: Ant1: 1.96dBi; SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 96 of 144 4.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 97 of 144 1M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 98 of 144 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Ref 5.1.1 Test Result Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 1M SISO 2402 1 -4.14 2440 1 -3.63 2480 1 -4.93 Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2013, the channel contains the maximum PSD level was used to establish the reference level. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 99 of 144 5.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 100 of 144 1M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 101 of 144 5.2 CSE 5.2.1 Test Result Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 1M SISO 2402 1 -3.63 -23.63 Pass 2440 1 -3.63 -23.63 Pass 2480 1 -3.63 -23.63 Pass Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2013, the channel contains the maximum PSD level was used to establish the reference level. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 102 of 144 5.2.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 103 of 144 1M_MCH_2440MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 104 of 144 1M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 105 of 144 For Wi-Fi 1. Duty Cycle 1.1 Ant1 1.1.1 Test Result Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 802.11b SISO 2412 8.386 43.340 19.35 7.13 0.01 2437 8.386 43.340 19.35 7.13 0.00 2462 8.387 43.343 19.35 7.13 0.00 802.11g SISO 2412 1.394 13.977 9.97 10.01 0.02 2437 1.394 13.977 9.97 10.01 0.02 2462 1.394 1.409 98.94 0.05 0.03 802.11n (HT20) SISO 2412 1.302 1.317 98.86 0.05 0.03 2437 1.302 1.317 98.86 0.05 0.04 2462 1.303 1.317 98.94 0.05 0.03 802.11n (HT40) SISO 2422 0.650 0.658 98.78 0.05 0.04 2437 0.650 0.658 98.78 0.05 0.04 2452 0.650 0.658 98.78 0.05 0.07 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 106 of 144 1.1.2 Test Graph 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 107 of 144 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 108 of 144 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 109 of 144 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: …

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 140 of 144 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 141 of 144 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 142 of 144 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 143 of 144 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000128402 Page: 144 of 144 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV - End of the Report -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 1 of 3 Appendix Test Setup Photo for GZCR221000128402 Test Model No.: 69281-T2 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 3 of 3 Radiated Spurious Emissions & Radiated Emissions which fall in the restricted bands
