USER MANUAL TheCC 2530 RADIO MODULE is a high- performance, FCC & IC certified and ETSI compliant radio module that incorporates the Texas Instruments CC2530. The CC2530 is a true system-on-chip (SoC) solution for IEEE 802.15.4, Zigbee and RF4CE applications. It enables robust network nodes to be built with very low total bill-of-material costs. The CC2530 combines the excellent performance of a leading RF transceiver with an industry- standard enhanced 8051 MCU, in-system programmable flash memory, 8-KB RAM, and many other powerful features. The CC2530 comes in four different flash versions: CC2530F32/64/128/256, with 32/64/128/256 KB of flash memory, respectively. The CC2530 has various operating modes, making it highly suited for systems where ultralow power consumption is required. FCC ID: 2AZ89C2530 CC2530 RADIO MODULEE Features & Applications General: Minimal RF engineering experience necessary Minimal ZigBee® experience necessary Easy to program and implement, short design cycle No additional “Intentional Radiator” certification required (FCC CFR 47 Part 15, IC RSS-210) Minimal real estate required Easily implemented on a two layer PCB No additional harmonic filtering required 100% RF-tested in production Common footprint for similar products in family No additional DC decoupling required Includes IEEE 802.15.4 MAC Timer CSMA/CA hardware support Accurate Digital RSSI/LQI support Battery monitor and temperature sensor AES Security co processor Applicatons Consumer electronics Mobile phone accessories Sports & Fitness equipment HID applications Home and Building Automation, Lighting Control, Alarm and Security Electronic Shelf Labeling, Proximity Tags And many more... Electrical Characteristics ITEM TEST REQUIREMENT REMARKS Excellent receiver sensitivity and robustness to interference (-95dBm average) Wide input voltage range (2.2V – 3.6V) 100% RF tested in production Module weight approximately 0.7 grams Current Consumption: (TC = 25°C, VDD = 3.0V) Active mode RX (CPU Idle): 28 mA Active mode TX (CPU Idle): 68 mA @1dBm, 78mA @8dBm 130mA @ 15dBm 3 Low power/sleep modes from 1uA to 200 uA RECOMMENDED OPERATING CONDITIONS Operating temperature –40 to +85 ̊C CAUTION: ESD sensitive device. Precautions should be used when handing the device in order to prevent permanent damage. 55.00 20.00 55.00 1.50 2.50 Pin assignemet PIN NAME PIN PIN TYPE VDD 14,15 GND 1, 2, 3, 4, 5, 12, 13, 16, ,17, 18, 24, 25, 35, 36, 37, 38, 39 P0_0 34 Digital I/O P0_1 33 Digital I/O P0_2 32 Digital I/O P0_3 31 Digital I/O P0_4 30 Digital I/O P0_5 29 Digital I/O P0_6 28 Digital I/O P0_7 27 Digital I/O P1_0 26 Digital I/O P1_1 23 Digital I/O P1_2 22 Digital I/O P1_3 21 Digital I/O P1_4 20 Digital I/O P1_5 19 Digital I/O P1_6 11 Digital I/O P1_7 10 Digital I/O P2_0 9 Digital I/O P2_1 8 Digital I/O P2_2 7 Digital I/O RESET_N 6 Digital input Pin countig starts top left. 1 14 39 26 1525 FCC regulatory compliance statement §15.19 Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the follow- ing two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. §15.21 Information to user Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. List of applicable FCC rules: 47 CFR Part 15, Subpart C 15.203 47 CFR Part 15, Subpart C 15.205 47 CFR Part 15, Subpart C 15.207 47 CFR Part 15, Subpart C 15.209 47 CFR Part 15, Subpart C 15.247 47 CFR Part 2 2.1091 Summarize the specific operational use conditions This module can be used in IOT devices, the input voltage to the module is nominal- ly 5V. Only the embedded integral antenna is allowed. Any other external antenna is prohibited. Limited module procedures This module is not a limited module. Trace antenna designs The antenna is not a trace antenna. RF exposure considerations This Module complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Antennas If you desire to increase antenna gain and either change antenna type or use same antenna type certified, a Class II permissive change application is required to be filed by us, or you (host manufacturer) can take responsibility through the change in FCC ID (new application) procedure followed by a Class II permissive change application. FCC regulatory compliance statement Label and compliance information Please notice that if the FCC identification number is not visible when the module is in- stalled inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC ID: 2AZ89C2530_” any similar wording that expresses the same meaning may be used. § 15.19 Labelling requirements shall be complied on end user device. Labelling rules for special device, please refer to §2.925, § 15.19 (a)(5) and relevant KDB publications. For E-label, please refer to §2.935. Information on test modes and additional testing requirements The OEM integrator is responsible for ensuring that the end-user has no manual in- struction to remove or install module. The module is limited to installation in mobile application, a separate approval is required for all other operating configurations, including portable configurations with respect to §2.1093 and difference antenna configurations. Additional testing, Part 15 Subpart B disclaimer This modular transmitter is only FCC authorized for the specific rule parts listed on our grant, host product manufacturer is responsible for compliance to any other FCC…
