2AZKE-BS19000ELECTRIC FIREPLACE

INSTALLATION AND OPERATION INSTRUCTIONS FOR ELECTRIC FIREPLACE SYM-34 BESPOKE SYM-42 BESPOKE SYM-50 BESPOKE SYM-60 BESPOKE SYM-74 BESPOKE SYM-88 BESPOKE SYM-100 BESPOKE INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE. CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE. WARNING: This product can expose you to chemicals including lead in the wiring, which is [are] known to the State of California to cause birth defects of other reproductive harm. For more information visit: www.p65warnings.ca.gov SAFETY INFORMATION Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other. if the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. WARNING 1 www.amantii.com BS1900034-1 BS1900042-1 BS1900050-1 BS1900060-1 BS1900074-1 BS1900088-1 BS1900100-1 TABLE OF CONTENTS Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. 2 IMPORTANT INSTRUCTIONS CAUTIONS FCC STATEMENT UNPACKING AND TESTING APPLIANCE GROUNDING APPLIANCE LOCATING THE FIREPLACE PRODUCT SPECIFICATION OUTDOOR INSTALLATIONS INSTALLATION-WALL MOUNT INSTALLATION- BUILT-IN HARD- WIRE INSTALLATION DECORATIVE MEDIA INSTALLATION MANUAL OPERATION REMOTE CONTROL OPERATION REPLACEMENT PARTS EXPLODED VIEW ENERGY SAVING FUNCTION 3 4 4 5 5 5 6 8 9 10 13 14 16 15 18 TROUBLE SHOOTING 19 19 21 1. Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front, sides and rear of the heater. 3. Always unplug heater when not in use. 4. Do not operate the fireplace if it has a damaged cord or plug, after it has malfunctioned, or if the unit has been dropped or damaged in any way. 5. Do not run the cord under carpeting. Do not cover the cord with throw rugs, runners or anything else. Arrange the cord away from traffic areas where it could not be tripped over. 6. To disconnect the heater, turn the controls to "OFF" before removing the plug from the outlet. 7. Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may cause an electric shock, fire or damage to the heater. 8. To prevent a possible fire, do not block air intakes in any manner. 9. A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint or flammable liquids are used or stored. 10. Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or injury. 11. Avoid the use of an extension cord, the extension cord will overheat and cause a fire. This heater is not to be used with an extension cord. 12. Always use properly grounded fused and polarized outlets. 13. Always use ground fault protection where it is required by electrical codes. 14. Always disconnect the power before performing any cleaning, maintenance or relocation of the heater. 15. To prevent a possible fire, do not burn wood or other materials in this heater. 16. To prevent electric shock or fire, always use a certified electrician, should new circuits or outlets be required. 17. When transporting or storing the heater, keep it in a dry place, free from excessive vibration. 18. This appliance should not be modified under any circumstances. 19. Packaging material should be kept away from children and be disposed of in a safe manner. Plastic bags are not toys and should be kept away from children and infants. 20. Do not use this heater in small rooms when they are occupied by persons not capable of leaving the room on their own, unless constant supervision is provided. 21. If the glass is damaged, do not use the heater in order to avoid a hazard. 22. Do not leave children unsupervised where heater is turned on. 23. CAUTION Some parts of this product can become very hot and cause burns. Particular atten- tion has to be given where children and vulnerable people are present. 3 SAVE THESE INSTRUCTIONS CAUTIONS Always install the heater in accordance with this guide. If in doubt obtain expert advice. Always make sure the electrical socket is accessible and located adjacent to, but not above the heater. Always disconnect the heater from the electrical supply before moving it, or carrying out cleaning, maintenance. Always make sure the heater is firmly secured to prevent it from being tipped over. Always use a fireguard when young children and infirm persons can come into contact with the heater. Never leave children unsupervised in a room where the heater is ON and unguarded. Never obstruct or cover the fan outlet or force items into heater openings. Never use aerosols or steam cleaners on or around the heater. Never route the main supply cable under carpet etc. Never install the heater close to curtains or combustible materials. Never use the heater to dry clothes etc. Never sit or stand on the heater. Do’s Don’ts 4 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular in…

Text truncated - open the document above for the full version.

Differences Declaration To whom concern, We company AMANTII IMPORTS CORP hereby declares: The product models BS1900034-1, BS1900042-1, BS1900050-1, BS1900060-1, BS1900074-1, BS1900088-1, BS1900100-1, BS1910034-1, BS1910042-1, BS1910050-1, BS1910060-1, BS1910074-1, BS1910088-1, BS19100100-1, BS2000026-1, BS2000030-1, BS2000033-1, BS2000038-1, BS2000044-1, BS2000048-1 are identical in the same PCB layout, interior structure and electrical circuits, The differences are appearance color and model name for commercial purpose. Authorized signature: Date: 2021-04-14

DATE : 2021-04-14 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AZKE-BS19000 Product Name: ELECTRIC FIREPLACE Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name: BRIAN RICHARDS Title: CEO Company: AMANTII IMPORTS CORP

DATE : 2021-04-14 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with AMANTII IMPORTS CORP And 502-1027 Davie Street, Vancouver, BC V6E4L2, Canada Signature: Name: BRIAN RICHARDS Title: CEO Company: AMANTII IMPORTS CORP

Name: ELECTRIC FIREPLACE Size: Material: Tagboard Glue: Adhesive sticker Font type: Arial Font color: Black Page color: White FCC ID:2AZKE-BS19000 ELECTRIC FIREPLACE Amantii Imports Corp. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation. 100*50mm

label location

.

Global United Technology Services Co., Ltd. Report No.: GTSL202104000069F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 28 + TEST REPORT Applicant: AMANTII IMPORTS CORP Address of Applicant: 502-1027 Davie Street, Vancouver, BC V6E4L2, Canada Manufacturer: DONGGUAN CAMBRIDGE ELECTRICAL MANUFACTURING CO.LTD Address of Manufacturer: 102,No.36 Quling 1st Road,LiaobuTown, DongguanCity, Guangdong Province, China Equipment Under Test (EUT) Product Name: ELECTRIC FIREPLACE Model No.: BS1900034-1, BS1900042-1, BS1900050-1, BS1900060-1, BS1900074-1, BS1900088-1, BS1900100-1, BS1910034-1, BS1910042-1, BS1910050-1, BS1910060-1, BS1910074-1, BS1910088-1, BS19100100-1, BS2000026-1, BS2000030-1, BS2000033-1, BS2000038-1, BS2000044-1, BS2000048-1 Trade Mark: Amantii FCC ID: 2AZKE-BS19000 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 Date of sample receipt: April 08, 2021 Date of Test: April 08-14, 2021 Date of report issued: April 14, 2021 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSL202104000069F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 28 2 Version Version No. Date Description 00 April 14, 2021 Original Prepared By: Date: April 14, 2021 Project Engineer Check By: Date: April 14, 2021 Reviewer Report No.: GTSL202104000069F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 28 3 Contents Page 1 COVER PAGE .............................................................................................................................................1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................7 5.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 5.4 DEVIATION FROM STANDARDS ..............................................................................................................7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 5.6 TEST FACILITY ....................................................................................................................................8 5.7 TEST LOCATION ..................................................................................................................................8 5.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................8 6 TEST INSTRUMENTS LIST ......................................................................................................................9 7 TEST RESULTS AND MEASUREMENT DATA .....................................................................................11 7.1 ANTENNA REQUIREMENT ....................................................................................................................11 7.2 CONDUCTED EMISSIONS ....................................................................................................................12 7.3 RADIATED EMISSION METHOD ............................................................................................................15 7.3.1 Field Strength of The Fundamental Signal ..................................................................................17 7.3.2 Spurious emissions .....................................................................................................................18 7.3.3 Bandedge emissions ...................................................................................................................23 7.4 20DB OCCUPY BANDWIDTH ...............................................................................................................25 8 TEST SETUP PHOTO .............................................................................................................................28 9 EUT CONSTRUCTIONAL DETAILS .......................................................................................................28 Report No.: GTSL202104000069F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 75…

Text truncated - open the document above for the full version.

Global United Technology Services Co., Ltd. Report No.: GTSL202104000069F04 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 26 TEST REPORT Applicant: AMANTII IMPORTS CORP Address of Applicant: 502-1027 Davie Street, Vancouver, BC V6E4L2, Canada Manufacturer: DONGGUAN CAMBRIDGE ELECTRICAL MANUFACTURING CO.LTD Address of Manufacturer: 102,No.36 Quling 1st Road,LiaobuTown, DongguanCity, Guangdong Province, China Equipment Under Test (EUT) Product Name: ELECTRIC FIREPLACE Model No.: BS1900034-1, BS1900042-1, BS1900050-1, BS1900060-1, BS1900074-1, BS1900088-1, BS1900100-1, BS1910034-1, BS1910042-1, BS1910050-1, BS1910060-1, BS1910074-1, BS1910088-1, BS19100100-1, BS2000026-1, BS2000030-1, BS2000033-1, BS2000038-1, BS2000044-1, BS2000048-1 Trade Mark: Amantii FCC ID: 2AZKE-BS19000 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 Date of sample receipt: April 08, 2021 Date of Test: April 08-14, 2021 Date of report issued: April 14, 2021 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSL202104000069F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 26 2 Version Version No. Date Description 00 April 14, 2021 Original Prepared By: Date: April 14, 2021 Project Engineer Check By: Date: April 14, 2021 Reviewer Report No.: GTSL202104000069F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 26 3 Contents Page 1 COVER PAGE .............................................................................................................................................1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................7 5.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 5.4 TEST FACILITY ....................................................................................................................................7 5.5 TEST LOCATION ..................................................................................................................................7 5.6 ADDITIONAL INSTRUCTIONS ..................................................................................................................7 6 TEST INSTRUMENTS LIST ......................................................................................................................8 7 TEST RESULTS AND MEASUREMENT DATA .....................................................................................10 7.1 ANTENNA REQUIREMENT ....................................................................................................................10 7.2 CONDUCTED EMISSIONS ....................................................................................................................11 7.3 RADIATED EMISSION METHOD ............................................................................................................14 7.3.1 Field Strength of The Fundamental Signal ..................................................................................16 7.3.2 Spurious emissions .....................................................................................................................17 7.3.3 Bandedge emissions ...................................................................................................................22 7.4 20DB OCCUPY BANDWIDTH ...............................................................................................................24 8 TEST SETUP PHOTO .............................................................................................................................26 9 EUT CONSTRUCTIONAL DETAILS .......................................................................................................26 Report No.: GTSL202104000069F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 26 4 Test Summary Test Item Section Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 Pass Field strength of the fundamental signal 15.249 (a) Pass Spurious emissions 15.249 (a) (d)/15.209 Pass Band edge 15.249 (d)/15.205 Pa…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
