2AZMHMD31028Transmitter

Button function and batter y install specification B Open the back cover 1.5V dr y cell seven×2 Match code key CODE【】 Programme key SET【】 Open the back cover with force’s direction Install the back cover with force’s direction Contrar y CODE SET Front Display channel 9 or 99 (P represents group control) Channel Key Up Key Stop Key Down Key H12022 A/3 Transmitter Operating Manual Company reser ves the right to change product design and specifications without prior notice then photos are for reference only. CODE SET CODE SET Lock channel: ： CODE SET factor y default is the maximum channel Display the maximum channel and flicker 4、Display channel P； A A B ! CODE SET CODE SET CODE SET CODE SET CODE SET Adjust the third limit： Repeat the operation once to eliminate the third limit： Press [up/down] button to move blinds, and then stop blinds at the appointed position. Tool with 3 mm diameter or less. Motor response: rotate back and for th once. Third limit position Up limit position Down limit position 1、Select the channel that will be used to adjust limits； 3、Press & Hold Set button on transmitter about 10s 【】 2、Blinds moves to the third limit position； 4 press Down button about 5s； 、Within 10s af ter motor stops, 【】 Motor response: Rotate back and for th once. Now you can star t to adjust limits 5、 ； Within 10s af ter motor stops, press Stopbutton about 5s【】 Motor response: Rotate back and for th once. Successful to adjust the third limits ① Set the third limit between up and down limit, as the half position of blinds； ② Reset up and down limit, or repeat third limit setting steps will eliminate the third limit； ③ Press & Hold [stop] button about 3s； 4、Within 10s af ter motor stops, press【Down】button about 5s； 5、Within 10s press Up button to adjust up limit； 【】 2、Select the channel that will be used to adjust limits； Adjust up limit 8、Within 10s press Down button to adjust down limit ； 【】 10、Press & hold Stop + Down about 1s to save down limit； 【】 Adjust down limit 7、Press & hold Stop + Up about 1s to save up limit； 【】 Motor response: rotate back Confirm that blinds stops at the up limit position Press stop button when blinds is near the appointed position. Save up limit 6、Press Up/Down button to move blinds, and then stop blinds at the appointed position； 【】 9、Press Up/Down button to move blinds, and then stop blinds at the appointed position； 【】 Save down limit Confirm that blinds stops at the down limit position Press stop button when blinds is near the appointed position. 3、Press & Hold Set button on transmitter about 10s； 【】 Confirm direction [ ]Up button [Down] button 1、Press up button, blinds up. Press down button, blinds down； If direction is not logical, please reset direction according “Reset direction”steps. Adjusting Limits： When you pressUporDownbuttonthe blinds will move up or down and stop automatically at the appointed position【 】 【】，。 Now you can star t to adjust limits Tool with 3 mm diameter or less Motor response: rotate back and for th once. Motor response: rotate back and for th once. Motor response: rotate back Reset direction ： Reset motor direction up button，blinds run up。 。Such as: before reset，press transmitter up button，blinds run down。Af ter reset，press transmitter 2、Press & Hold Set button on transmitter about 10s； 【】 3、 press Stopbutton about 5s Within 10s af ter motor stops, 【】； Motor response: rotate back and for th once. 1、Select the channel that will be reset direction； Tool with 3 mm diameter or less Motor response: rotate back and for th once. Copy： Add a new channel to control motor (No need to touch motor)：。 1、Select the channel that will be copied； 2、 transmitter about 10s Press & Hold Code button on【】 3、Within 10s af ter motor stops, pair on the new channe； Tool with 3 mm diameter or less Motor response: rotate back and for th once. Tool with 3 mm diameter or less Motor response: rotate back and for th once. A transmitter A transmitterB transmitter Speed setting： Two speed can be adjusted， Default is first： Motor response: rotate back and for th three times. 1、【】 ； Press & Hold Set button on motor about 15s 1、Press & Hold Set button on motor about 10s 【】 ； 2、Press Set button on motor again；【】 Clear pairing ： Clear all pairing on the motor ： Motor response: rotate back and for th twice. Motor response: rotate back and for th once. 1、Select the channel that will be paired； 2、Press Set button on motor；【】 Motor response: rotate back and for th once. Tool with 3 mm diameter or less 3、Within 10s af ter motor stops, press 【Code】 button； Motor response: rotate back and for th once. Pairing transmitter and motor： Repeat the pairing operation once to eliminate the current pairing。A motor stores up to 10 transmitter channels，Adding a new transmitter channel will cover the earliest channel For example, current paired channels are 1~10 If you add channel 11 paired channels will be 2~11： 。 。，。 Instructions I ( *Take A3 button transmitter as an example，For other transmitters please refer to the corresponding transmitter manual。) ， Inching / Continuous moving interchange： Default is continuous moving. After switching to inching moving, press & hold Upor Down button about 2s, motor will continuously moves： 【】 【】 1、Select the channel that will be interchanged； 2、Press & Hold Set button on transmitter about 10s； 【】 3、Within 10s af ter motor stops, press【Up】button about 5s； Tool with 3 mm diameter or less Motor response: rotate back and for th once. Motor response: rotate back and for th once. 2、With in 6s, press Select-button to choose channel you want to lock； 3 to save the currently locked channel 、Press the【Stop key 】 1、 Set key about 10s Keep press transmitter 【】； Tool with 3 mm diameter or less FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesir…

Text truncated - open the document above for the full version.

NOVO (GUANGDONG) HIGH-TECH CO., LTD. Agent Authorization Company: NOVO (GUANGDONG) HIGH-TECH CO., LTD. Address: No.7-1, Jiye Road, Leping Town, Sanshui District, Foshan City, China Product Name: Transmitter Trademark: N/A Model Number(s): MD31028 FCC ID: 2AZMHMD31028 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021/04/15 Name: LIU SHUN Title: Manager Company: NOVO (GUANGDONG) HIGH-TECH CO., LTD.

NOVO (GUANGDONG) HIGH-TECH CO., LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021/04/15 Subject; Request for Confidentiality FCC ID: 2AZMHMD31028 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: LIU SHUN Title: Manager

External Photos

Size:20*10mm Model : MD31028 FCC ID: 2AZMHMD31028 Label Location

Internal Photos Antenna

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2007001211E FCC Part 15C Test Report FCC ID: 2AZMHMD31028 Product Name: Transmitter Trademark: N/A Model Name : MD31028 Prepared For : NOVO (GUANGDONG) HIGH-TECH CO., LTD. Address : No.7-1, Jiye Road, Leping Town, Sanshui District, Foshan City, China Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Jul. 23, 2020 to Aug. 25, 2020 Date of Report : Aug. 26, 2020 Report No.: BCTC2007001211E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2007001211E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 30 VERIFICATION OF COMPLIANCE Applicant’s name ................. : NOVO (GUANGDONG) HIGH-TECH CO., LTD. Address ................................. : No.7-1, Jiye Road, Leping Town, Sanshui District, Foshan City, China Manufacture's Name ............ : NOVO (GUANGDONG) HIGH-TECH CO., LTD. Address ................................. : No.7-1, Jiye Road, Leping Town, Sanshui District, Foshan City, China Product description Product name............................ : Transmitter Trademark: N/A Model Name: MD31028 Test Standards: FCC Part15.231 ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result.............................................. : Pass Prepared by(Engineer): Cai Fang Zhong Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2007001211E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 3 of 30 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 11 3.1.2 TEST PROCEDURE 12 3.1.3 DEVIATION FROM TEST STANDARD 12 3.1.4 TEST SETUP 12 3.1.5 EUT OPERATING CONDITIONS 12 3.1.6 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 TEST SETUP 15 3.2.4 EUT OPERATING CONDITIONS 16 3.2.5 TEST RESULTS 17 4 . BANDWIDTH TEST 22 4.1 APPLIED PROCEDURES / LIMIT 22 4.1.1 TEST PROCEDURE 22 4.1.2 DEVIATION FROM STANDARD 22 4.1.3 TEST SETUP 22 4.1.4 EUT OPERATION CONDITIONS 22 4.1.5 TEST RESULTS 23 5 . CALCULATION OF AVERAGE FACTOR 24 6 . DWELL TIME 26 6.1 DEVIATION FROM STANDARD 26 6.2 TEST SETUP 26 6.3 EUT OPERATION CONDITIONS 26 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2007001211E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 4 of 30 Table of Contents Page 6.4 TEST RESULTS 27 7 . ANTENNA REQUIREMENT 28 7.1 STANDARD REQUIREMENT 28 7.2 EUT ANTENNA 28 8 . EUT TEST PHOTO 29 9 . EUT PHOTO 30 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2007001211E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 5 of 30 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.231) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.209,15.231b Fundamental &Radiated Spurious Emission Measurement PASS 15.231c Occupy Bandwidth PASS 15.231a Dwell time PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2007001211E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 6 of 30 1.1 TEST FACILITY Shenzhen BCTC Testing Co., Ltd. Add.: BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China FCC Test Firm Registration Number: 712850 IC Registered No.: 23583 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 3m camber Radiated spurious emission(30MHz-1GHz) U=4.3dB 2 3m chamber Radiated spurious emission(1GHz-18GHz) U=4.5dB 3 3m chamber Radiated spurious emission(18GHz-40GHz) U=3.34dB 4 Conducted Adjacent channel power U=1.38dB 5 Conducted output power uncertainty Above 1G U=1.576dB 6 Conducted output power uncertainty below 1G U=1.28dB 7 humidity uncertainty U=5.3% 8 Temperature uncertainty U=0.59°C Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2007001211E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 7 of 30 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Transmitter Trade Name N/A Model Name MD31028 Serial Model N/A Model Difference N/A Product Description Operation Frequency: 433.92MHz Modulation Type: FSK Antenna Type: PCB antenna Antenna Gain: 0dBi Ratings DC 3V Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2007001211E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 8 of 30 2.2 DESCRIPTION OF TEST MODES For All Emi…

Text truncated - open the document above for the full version.

Radiated Measurement Photos
