2AZNP-L206FGNLaser Projector

说明书印刷说明： 1. 尺寸：120 x 190mm 2. 材质：105g哑粉 3. 印刷颜色： PT Blue 072U + PANTONE Cool Gray 11 C 4. 装订方式：折页正反印刷 5. 材料符合RoHS, REACH及POPS环保要求 说明书版本变更 A新版发行2021.08.17 内容修改2022.02.08B C D 版本说明时间 Formovie Theater Laser Projector User Manual The terms HDMI, HDMI High-Definition Multimedia In terface, and the HDMI Logo are trademarks or registered tr ademarks of HDMI Licensing Administr ator , Inc. For DTS patents, see hp://patents.dts.com. Manufactured under license from DTS, Inc. (for companies headquartered in the U.S./Japan/Taiwan) or under license from DTS Licensing Limited (for all other companies). DTS, DTS:X, and the DTS:X logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries. © 2022 DTS, Inc. ALL RIGHTS RESERVED. Dolby, Dolby Vision, Dolby Audio, Dolby Atmos, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation. Manufactured under license from Dolby Laboratories. Confidential unpublished works. Copyright © 1992–2022 Dolby Laboratories. All rights reserved.

Formovie (Chongqing) Innovative Technology Co., Ltd. Date: 2022-03-17 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2AZNP-L206FGN To Whom It May Concern: This letter is to ascertain that Formovie (Chongqing) Innovative Technology Co., Ltd. EUT：Laser Projector MODEL No.: L206FGN, L206******* (*=0-9, a-z, A-Z, - or blank, indicates for different market purposes) Has been the units used for conducting FCC compliance testing, the SDoC part will be tested by EMTEK (SHENZHEN) CO., LTD. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： Pover Xiao/Certification Manager Contact information / address: Formovie (Chongqing) Innovative Technology Co., Ltd. /4-401, #2 Longgang Road, Guojiatuo Area, Jiangbei District, Chongqing, China

Rev 11/20/07 Formovie (Chongqing) Innovative Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AZNP-L206FGN Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, Block Diagram, Schematics, Operational Description, The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Client’s name / title ： Pover Xiao/Certification Manager Contact information / address: Formovie (Chongqing) Innovative Technology Co., Ltd. /4-401, #2 Longgang Road, Guojiatuo Area, Jiangbei District, Chongqing, China

Declaration on model difference We the undersigned hereby confirm that any of our production units bearing the following model numbers are identical in circuitry and electrical, mechanical and physical construction; only indicates for different market purposes; FCC ID: 2AZNP-L206FGN Production name Trade name Model no. Laser Projector FORMOVIE, WEMAX L206FGN, L206******* (*=0-9, a-z, A-Z, - or blank, indicates for different market purposes) Confirmed by Formovie (Chongqing) Innovative Technology Co., Ltd. Client’s name / title ： Pover Xiao/Certification Manager Contact information / address: Formovie (Chongqing) Innovative Technology Co., Ltd. /4-401, #2 Longgang Road, Guojiatuo Area, Jiangbei District, Chongqing, China Date: 2022-03-17

Formovie (Chongqing) Innovative Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2022-03-17 SUBJECT: FCC Application for FCC ID: 2AZNP-L206FGN To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Pover Xiao/Certification Manager Formovie (Chongqing) Innovative Technology Co., Ltd.

100#哑光PET L206FGN铭牌 D66010000824 宋晓雷 向翔 A新版发行2021-11-24 向翔B内容修改2022-02-11 B PANTONE Black 6 U PANTONE Cool Gray 6 U 技术要求： 1. 尺寸：71.5x71.5mm, 公差：±0.2mm； 2. 材料：哑光100#PET不干胶,防刮花哑膜； 3. 字体： 方正悠黑，大小如图； 4. 将SN条码打印在在条码区； 5. 材料符合RoHS, REACH及POPS环保要求； 条码打印示意图（仅供参考，请以实际的条码为准）： 1. 将SKU和SN条码打印在图示位置； 2. 条码字体/大小/颜色如图所示； 3. 条码为树脂碳带打印； 4. 条码必须通过耐磨测试； 5. 环保要求：符合RoHS、REACH及POPS法规。 6. 打印清晰，能通过可靠性测试，酒精加白布反复擦拭不掉色 （要满足1千克力来回擦拭50次不掉色）。 7. 包装方式： 卷装，卷轴直径76mm。 卷向示意： 41mm 7.1mm 字体：Arial Regular 4PT 5mm SKUMLT21AA550BGL No.60139 SN: 21103/4000001X 71.5mm 71.5mm

Label Location

BT/WIFI Module

BT Antenna WIFI Antenna WIFI Antenna BT Antenna

FCC ID : 2AZNP-L206FGN RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500- 100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500- 100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 ,If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. RF Exposure Information: The radiated output power of this device meets the limits of FCC/IC radio frequency exposure limits.This device should be operated with a minimum separation distance of 20cm (8 inches) between the equipment and a person's body. 11.2 Measurement Result WIFI2.4G and Bluetooth can transmit at the same time BT Antenna 1 gain: 3.55 dBi Antenna 2 gain: 3.62 dBi Measured power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 8.03 7.0 to 9.0 9.0 2.3 0.004 1 BLE Antenna 1 gain: 3.55 dBi Antenna 2 gain: 3.62 dBi Measured power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 6.22 5.0 to 7.0 7.0 2.3 0.002 1 Wifi 2.4G Antenna 1 gain: 2.97 dBi Antenna 2 gain: 2.95 dBi Directional gain: 5.97 dBi Measured power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 18.00 17.0 to 19.0 19.0 4.0 0.062 1 Wifi 5G Antenna 1 gain: 4.69 dBi Antenna 2 gain: 4.82 dBi Directional gain: 7.77 dBi Frequency band Measure d power (dBm) Tune-up power (dBm) Max tune- up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 5150MHz- 5250MHz 15.01 15.0 to 17.0 17.0 6.0 0.060 1 5250MHz- 5350MHz 15.97 15.0 to 17.0 17.0 6.0 0.060 1 5470MHz- 5725MHz 16.40 15.0 to 17.0 17.0 6.0 0.060 1 5725MHz- 5850MHz 15.66 15.0 to 17.0 17.0 6.0 0.060 1 MAX RF EXPOSURE EVALUATION Wifi 2.4G BT Summation of Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 0.062 0.004 0.066 <1

Report No. ENS2201110045W00602R Page 1 of 89 Ver.1.0 TEST REPORT Product Name ： Laser Projector Model Number ： L206FGN, L206******* (*=0-9, a-z, A-Z, - or blank, indicates for different market purposes) FCC ID ： 2AZNP-L206FGN Prepared for : Formovie (Chongqing) Innovative Technology Co., Ltd. Address : 4-401, #2 Longgang Road, Guojiatuo Area, Jiangbei District, Chongqing, China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2201110045W00602R Date(s) of Tests : January 11, 2022 to March 9, 2022 Date of issue : March 10, 2022 $二维码$ Report No. ENS2201110045W00602R Page 2 of 89 Ver.1.0 Table of Contents 1 TEST RESULT CERTIFICATION ....................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ..................................................................................................... 5 3 SUMMARY OF TEST RESULT .......................................................................................................... 6 4 TEST METHODOLOGY ..................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................ 7 4.2 MEASUREMENT EQUIPMENT USED ....................................................................................... 7 4.3 DESCRIPTION OF TEST MODES ............................................................................................. 9 5 FACILITIES AND ACCREDITATIONS ............................................................................................. 10 5.1 FACILITIES ............................................................................................................................... 10 5.2 EQUIPMENT ............................................................................................................................. 10 5.3 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................ 10 6 TEST SYSTEM UNCERTAINTY ...................................................................................................... 11 7 SETUP OF EQUIPMENT UNDER TEST ......................................................................................... 12 7.1 RADIO FREQUENCY TEST SETUP 1 ..................................................................................... 12 7.2 RADIO FREQUENCY TEST SETUP 2 ..................................................................................... 12 7.3 CONDUCTED EMISSION TEST SETUP ................................................................................. 15 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ..................................................... 16 7.5 SUPPORT EQUIPMENT .......................................................................................................... 16 8 TEST REQUIREMENTS ................................................................................................................... 17 8.1 DTS 6DB BANDWIDTH ............................................................................................................ 17 8.2 DTS 99% BANDWIDTH ............................................................................................................ 25 8.3 MAXIMUM PEAK CONDUCTED OUTPUT POWER ............................................................... 32 8.4 MAXIMUM POWER SPECTRAL DENSITY ............................................................................. 40 8.5 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ............................. 47 8.6 RADIATED SPURIOUS EMISSION ......................................................................................... 73 8.7 CONDUCTED EMISSIONS TEST ............................................................................................ 85 8.8 ANTENNA APPLICATION ......................................................................................................... 88 Report No. ENS2201110045W00602R Page 3 of 89 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Formovie (Chongqing) Innovative Technology Co., Ltd. Address : 4-401, #2 Longgang Road, Guojiatuo Area, Jiangbei District, Chongqing, China Manufacturer : Formovie (Chongqing) Innovative Technology Co., Ltd. Address : 4-401, #2 Longgang Road, Guojiatuo Area, Jiangbei District, Chongqing, China EUT : Laser Projector Model Name : L206FGN, L206******* (*=0-9, a-z, A-Z, - or blank, indicates for different market purposes) Trademark : FORMOVIE, WEMAX Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2 , Subpart J FCC 47 CFR Part 15, Subpart C PASS IC RSS-GEN, Issue 5(04-2018)+A1(03-2019)+A2(02-2021) IC RSS-247 Issue 2(02-2017) PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2, Part 15.247, IC RSS-247 Issue 2 and IC RSS-GEN, Issue 5. The test results of this report relate only to the tested sample identified in this report. Date of Test : January 11, 2022 to March 9, 2022 Prepared by : Una Yu /Editor Reviewer : Joe Xia/Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No. ENS2201110045W00602R Page 4 of 89 Ver.1.0 Modified History Version Report No. Revision Date Summary V1.0 ENS2201110045W00602R / Original Report Report No. ENS2201110045W00602R Page 5 of 89 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Characteristics Description Product: Laser Projector Model Number: L206FGN, L206******* (*=0-9, a-z, A-Z, - or blank, indicates for different market purposes) Sample number: 2# Device Type： Bl…

Text truncated - open the document above for the full version.

Report No. ENS2201110045W00602R Page 43 of 88 Ver.1.0 BLE_2M_Ant2_2402 BLE_2M_Ant1_2440 Report No. ENS2201110045W00602R Page 44 of 88 Ver.1.0 BLE_2M_Ant2_2440 BLE_2M_Ant1_2480 Report No. ENS2201110045W00602R Page 45 of 88 Ver.1.0 BLE_2M_Ant2_2480 Report No. ENS2201110045W00602R Page 46 of 88 Ver.1.0 8.5 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 8.5.1 Applicable Standard According to FCC Part 15.247(d) and KDB 558074 D01 15.247 Meas Guidance v05r02 According to RSS-247 5.5 8.5.2 Conformance Limit In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of RMS averaging over a time interval, as permitted under paragraph (b)(3) of this section, the attenuation required under this paragraph shall be 30 dB instead of 20 dB. 8.5.3 Test Configuration Test according to clause 7.1 radio frequency test setup 1 8.5.4 Test Procedure The transmitter output (antenna port) was connected to the spectrum analyzer  Reference level measurement Establish a reference level by using the following procedure: Set instrument center frequency to DTS channel center frequency. Set the span to = 1.5 times the DTS bandwidth. Set the RBW = 100 kHz. Set the VBW ≥ 3 x RBW. Set Detector = peak. Set Sweep time = auto couple. Set Trace mode = max hold. Allow trace to fully stabilize. Use the peak marker function to determine the maximum PSD level. Note that the channel found to contain the maximum PSD level can be used to establish the reference level.  Band-edge measurement Use the following spectrum analyzer settings: Span = wide enough to capture the peak level of the emission operating on the channel closest to the band-edge, as well as any modulation products which fall outside of the authorized band of operation Set RBW ≥ 1% of the span=100kHz Set VBW ≥ 3 x RBW Set Sweep = auto Set Detector function = peak Set Trace = max hold Allow the trace to stabilize. Set the marker on the emission at the bandedge, or on the highest modulation product outside of the band, if this level is greater than that at the bandedge. Enable the marker-delta function, then use the marker-to-peak function to move the marker to the peak of the in-band emission. The marker-delta value now displayed must comply with the limit specified in this Section.  Emission level measurement Set the center frequency and span to encompass frequency range to be measured. Set the RBW = 100 kHz. Set the VBW =300 kHz. Set Detector = peak Sweep time = auto couple. Trace mode = max hold. Allow trace to fully stabilize. Report No. ENS2201110045W00602R Page 47 of 88 Ver.1.0 Use the peak marker function to determine the maximum amplitude level. Ensure that the amplitude of all unwanted emissions outside of the authorized frequency band (excluding restricted frequency bands) are attenuated by at least the minimum requirements . Report the three highest emissions relative to the limit. 8.5.5 Test Results Temperature: 25 ̊C Relative Humidity: 45% ATM Pressure: 1011 mbar Note: N/A TestMode Antenna Freq(MHz) Max.Point[MHz] Result[dBm] BLE_1M Ant1 2402 2401.99 4.81 Ant2 2402 2402.25 5.16 Ant1 2440 2439.99 4.69 Ant2 2440 2439.99 4.84 Ant1 2480 2479.99 4.25 Ant2 2480 2479.98 4.30 BLE_2M Ant1 2402 2401.99 4.77 Ant2 2402 2401.99 4.86 Ant1 2440 2439.98 4.31 Ant2 2440 2439.98 4.43 Ant1 2480 2479.99 4.11 Ant2 2480 2479.98 4.23 Report No. ENS2201110045W00602R Page 48 of 88 Ver.1.0 BLE_1M_Ant1_2402 BLE_1M_Ant2_2402 BLE_1M_Ant1_2440 Report No. ENS2201110045W00602R Page 49 of 88 Ver.1.0 BLE_1M_Ant2_2440 BLE_1M_Ant1_2480 Report No. ENS2201110045W00602R Page 50 of 88 Ver.1.0 BLE_1M_Ant2_2480 BLE_2M_Ant1_2402 Report No. ENS2201110045W00602R Page 51 of 88 Ver.1.0 BLE_2M_Ant2_2402 BLE_2M_Ant1_2440 Report No. ENS2201110045W00602R Page 52 of 88 Ver.1.0 BLE_2M_Ant2_2440 BLE_2M_Ant1_2480 Report No. ENS2201110045W00602R Page 53 of 88 Ver.1.0 BLE_2M_Ant2_2480 Report No. ENS2201110045W00602R Page 54 of 88 Ver.1.0 TestMod e Antenn a ChNam e Frequency[MHz ] RefLevel[dBm ] Result[dBm ] Limit[dBm ] Verdic t BLE_1M Ant1 Low 2402 4.81 -37.07 ≤-15.19 PASS Ant2 Low 2402 5.16 -37.24 ≤-14.84 PASS Ant1 High 2480 4.25 -37.55 ≤-15.75 PASS Ant2 High 2480 4.30 -37.39 ≤-15.7 PASS BLE_2M Ant1 Low 2402 1.60 -26.18 ≤-18.4 PASS Ant2 Low 2402 4.86 -27.01 ≤-15.14 PASS Ant1 High 2480 4.11 -37.66 ≤-15.89 PASS Ant2 High 2480 4.23 -37.46 ≤-15.77 PASS Report No. ENS2201110045W00602R Page 55 of 88 Ver.1.0 BLE_1M_Ant1_Low_2402 BLE_1M_Ant2_Low_2402 BLE_1M_Ant1_High_2480 Report No. ENS2201110045W00602R Page 56 of 88 Ver.1.0 BLE_1M_Ant2_High_2480 BLE_2M_Ant1_Low_2402 Report No. ENS2201110045W00602R Page 57 of 88 Ver.1.0 BLE_2M_Ant2_Low_2402 BLE_2M_Ant1_High_2480 Report No. ENS2201110045W00602R Page 58 of 88 Ver.1.0 BLE_2M_Ant2_High_2480 Report No. ENS2201110045W00602R Page 59 of 88 Ver.1.0 TestMode Antenna Frequency[MHz] FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 30~1000 4.81 -50.67 ≤-15.19 PASS 1000~26500 4.81 -39.52 ≤-15.19 PASS Ant2 2402 30~1000 5.16 -50.25 ≤-14.84 PASS 1000~26500 5.16 -39.88 ≤-14.84 PASS Ant1 2440 30~1000 4.11 -51.09 ≤-15.89 PASS 1000~26500 4.11 -39.81 ≤-15.89 PASS Ant2 2440 30~1000 4.84 -50.58 ≤-15.16 PASS 1000~26500 4.84 -39.62 ≤-15.16 PASS Ant1 2480 30~1000 2.17 -51.13 ≤-17.83 PASS 1000~26500 2.17 -39.89 ≤-17.83 PASS Ant2 2480 30~1000 4.30 -51.16 ≤-15.7 PASS 1000~26500 4.30 -39.12 ≤-15.7 PASS BLE_2M Ant1 2402 30~1000 1.60 -50.59 ≤-18.4 PASS 1000~26500 1.60 -39.7 ≤-18.4 PASS Ant2 2402 30~1000 4.86 -50.26 ≤-15.14 PASS 1000~26500 4.86 -39.3 ≤-15.14 PASS Ant1 2…

Text truncated - open the document above for the full version.

Report No. ENS2201110045W00602R Page 68 of 88 Ver.1.0 BLE_2M_Ant1_2440_1000~26500 BLE_2M_Ant2_2440_30~1000 Report No. ENS2201110045W00602R Page 69 of 88 Ver.1.0 BLE_2M_Ant2_2440_1000~26500 BLE_2M_Ant1_2480_30~1000 Report No. ENS2201110045W00602R Page 70 of 88 Ver.1.0 BLE_2M_Ant1_2480_1000~26500 BLE_2M_Ant2_2480_30~1000 Report No. ENS2201110045W00602R Page 71 of 88 Ver.1.0 BLE_2M_Ant2_2480_1000~26500 Report No. ENS2201110045W00602R Page 72 of 88 Ver.1.0 8.6 RADIATED SPURIOUS EMISSION 8.6.1 Applicable Standard According to FCC Part 15.247(d), 15.205, 15.209 and KDB 558074 D01 15.247 Meas Guidance v05r02 According to IC RSS-Gen and RSS-247 8.6.2 Conformance Limit According to FCC Part 15.247(d): radiated emissions which fall in the restricted bands, as defined in §15.205(a), must also comply with the radiated emission limits specified in §15.209(a) (see §15.205(c)). According to FCC Part15.205, Restricted bands MHz MHz MHz GHz 0.090-0.110 16.42-16.423 399.9-410 4.5-5.15 10.495-0.505 16.69475-16.69525 608-614 5.35-5.46 2.1735-2.1905 16.80425-16.80475 960-1240 7.25-7.75 4.125-4.128 25.5-25.67 1300-1427 8.025-8.5 4.17725-4.17775 37.5-38.25 1435-1626.5 9.0-9.2 4.20725-4.20775 73-74.6 1645.5-1646.5 9.3-9.5 6.215-6.218 74.8-75.2 1660-1710 10.6-12.7 6.26775-6.26825 123-138 2200-2300 14.47-14.5 8.291-8.294 149.9-150.05 2310-2390 15.35-16.2 8.362-8.366 156.52475-156.52525 2483.5-2500 17.7-21.4 8.37625-8.38675 156.7-156.9 2690-2900 22.01-23.12 8.41425-8.41475 162.0125-167.17 3260-3267 23.6-24.0 12.29-12.293 167.72-173.2 3332-3339 31.2-31.8 12.51975-12.52025 240-285 3345.8-3358 36.43-36.5 12.57675-12.57725 322-335.4 3600-4400 (2) 13.36-13.41 According to FCC Part15.205, the level of any transmitter spurious emission in Restricted bands shall not exceed the level of the emission specified in the following table Restricted Frequency(MHz) Field Strength ( μV/m) Field Strength (dB μV/m) Measurement Distance 0.009-0.490 2400/F(KHz) 20 log (uV/m) 300 0.490-1.705 24000/F(KHz) 20 log (uV/m) 30 1.705-30 30 29.5 30 30-88 100 40 3 88-216 150 43.5 3 216-960 200 46 3 Above 960 500 54 3 8.6.3 Test Configuration Test according to clause 7.2 radio frequency test setup 2 8.6.4 Test Procedure This test is required for any spurious emission that falls in a Restricted Band, as defined in Section 15.205. It must be performed with the highest gain of each type of antenna proposed for use with the EUT. Use the following spectrum analyzer settings: The EUT was placed on a turn table which is 0.8m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 1 MHz for f ≥ 1 GHz(1GHz to 25GHz), 100 kHz for f < 1 GHz(30MHz to 1GHz) Report No. ENS2201110045W00602R Page 73 of 88 Ver.1.0 VBW ≥ RBW Sweep = auto Detector function = peak Trace = max hold Follow the guidelines in ANSI C63.10-2013 with respect to maximizing the emission by rotating the EUT, measuring the emission while the EUT is situated in three orthogonal planes (if appropriate), adjusting the measurement antenna height and polarization, etc. A pre-amp and a high pass filter are required for this test, in order to provide the measuring system with sufficient sensitivity. Allow the trace to stabilize. The peak reading of the emission, after being corrected by the antenna factor, cable loss, pre-amp gain, etc., is the peak field strength, which must comply with the limit specified in Section 15.35(b). Submit this data. Now set the VBW to 10 Hz, while maintaining all of the other instrument settings. This peak level, once corrected, must comply with the limit specified in Section 15.209. If the dwell time per channel of the hopping signal is less than 100 ms, then the reading obtained with the 10 Hz VBW may be further adjusted by a “duty cycle correction factor”, derived from 20log(dwell time/100 ms), in an effort to demonstrate compliance with the 15.209 limit. Submit this data. Repeat above procedures until all frequency measured was complete. 8.6.5 Test Results Temperature: 22 ̊ C Relative Humidity: 43% ATM Pressure: 1011 mbar  Spurious Emission below 30MHz (9KHz to 30MHz) Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Over(dB) H/V PK AV PK AV PK AV -- -- -- -- -- -- -- -- Note: the amplitude of spurious emission that is attenuated by more than 20dB below the permissible limit has no need to be reported. Distance extrapolation factor =40log(Specific distance/ test distance)( dB); Limit line=Specific limits(dBuV) + distance extrapolation factor Report No. ENS2201110045W00602R Page 74 of 88 Ver.1.0  Spurious Emission Above 1GHz (1GHz to 25GHz) All the antenna(Antenna 1&2) and modes(BLE_1M, BLE_2M) mode have been tested, and the worst(Antenna 1&2, BLE_1M) result recorded was report as below: Test mode: BLE_1M Frequency: Channel 0: 2402MHz Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Over(dB) H/V PK AV PK AV PK AV 11366.36 V 54.10 36.30 74.00 54.00 -19.90 -17.70 14914.78 V 55.50 36.80 74.00 54.00 -18.50 -17.20 17818.82 V 62.94 46.80 74.00 54.00 -11.06 -7.20 11871.71 H 54.20 36.30 74.00 54.00 -19.80 -17.70 14886.79 H 55.50 36.80 74.00 54.00 -18.50 -17.20 17961.02 H 63.82 47.30 74.00 54.00 -10.18 -6.70 Test mode: BLE_1M Frequency: Channel 19: 2440MHz Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Over(dB) H/V PK AV PK AV PK AV 11600.35 V 54.18 36.50 74.00 54.00 -19.82 -17.50 14713.54 V 55.96 37.30 74.00 54.00 -18.04 -16.70 17942.86 V 63.76 46.50 74.00 54.00 -10.24 -7.50 11419.04 H 54.56 35.60 74.00 54.00 -19.44 -18.40 14888.94 H 56.18 36.80 74.00 54.00 -17.82 -17.20 17953.23 H 64.08 46.70 74.00 54.00 -9.92 -7.30 Test mode: BLE_1M Frequency: Channel 39: 2480MHz Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Over(dB) H/V PK AV PK AV PK AV 11995.88 V 54.52 36.80 74.00 54.00 -19.48 -17.20 15147.21 V 55.89 37.20 74.00 54.00 -18.11 -16.80 17979.20 V 64.45 46.80 74.00 54.00 -9.55 -7.20 11603.70 H 54.52 36.40 74…

Text truncated - open the document above for the full version.

Report No. ENS2201110045W00603R Page 1 of 159 Ver.1.0 TEST REPORT Product Name ： Laser Projector Model Number ： L206FGN, L206******* (*=0-9, a-z, A-Z, - or blank, indicates for different market purposes) FCC ID ： 2AZNP-L206FGN Prepared for : Formovie (Chongqing) Innovative Technology Co., Ltd. Address : 4-401, #2 Longgang Road, Guojiatuo Area, Jiangbei District, Chongqing, China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2201110045W00603R Date(s) of Tests : January 11, 2022 to March 9, 2022 Date of issue : March 11, 2022 $二维码$ Report No. ENS2201110045W00603R Page 2 of 159 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ........................................................................................................ 3 2 EUT TECHNICAL DESCRIPTION ...................................................................................................... 5 3 SUMMARY OF TEST RESULT ........................................................................................................... 6 4 TEST METHODOLOGY ...................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................................. 7 4.2 MEASUREMENT EQUIPMENT USED ........................................................................................ 7 4.3 DESCRIPTION OF TEST MODES ............................................................................................... 8 5 FACILITIES AND ACCREDITATIONS ................................................................................................ 9 5.1 FACILITIES .................................................................................................................................. 9 5.2 EQUIPMENT ................................................................................................................................ 9 5.3 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................... 9 6 TEST SYSTEM UNCERTAINTY ....................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ........................................................................................... 11 7.1 RADIO FREQUENCY TEST SETUP 1 ........................................................................................ 11 7.2 RADIO FREQUENCY TEST SETUP 2 ........................................................................................ 11 7.3 CONDUCTED EMISSION TEST SETUP ................................................................................... 14 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ....................................................... 15 7.5 SUPPORT EQUIPMENT ............................................................................................................ 15 8 TEST REQUIREMENTS .................................................................................................................... 16 8.1 DTS 6DB BANDWIDTH .............................................................................................................. 16 8.2 DTS 99% BANDWIDTH ............................................................................................................. 33 8.3 MAXIMUM PEAK CONDUCTED OUTPUT POWER ................................................................. 50 8.4 MAXIMUM POWER SPECTRAL DENSITY ............................................................................... 67 8.5 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ............................... 84 8.6 RADIATED SPURIOUS EMISSION ......................................................................................... 143 8.7 CONDUCTED EMISSION TEST .............................................................................................. 155 8.8 ANTENNA APPLICATION ......................................................................…

Text truncated - open the document above for the full version.
