2AZOM-BT4500-BBlueIOT RTLS Tag

Operating temperature THM Tag is designed to work best in ambient temperatures between -10°C (14°F) and +60°C (140°F) and be stored in temperatures between -20°C (-4°F) and +70°C (158°F). THM Tag can be damaged and battery life could be shortened if stored or operated outside of these temperature ranges. Avoid exposing THM Tag to dramatic changes in temperature or humidity. 5. Trouble Shooting The THM Tag will flash the status light once every 5 seconds. If the status light does not flash for a long time, please double-click the button. If the status light of THM Tag is still off, the battery power of your THM Tag has been used up, or the THM Tag is out of order. Please contact your system administrator in time. Bluetooth wireless may penetrate some objects to establish connection, such as wooden box, shelf, hollow wall, etc. However, it may cause an increase in location error. If the THM Tag you are wearing is squeezed hard or entered with liquid, resulting in the short circuit of the vibration motor. Please contact the manager in time in this case. BlueIOT RTLS Tag Tamper-alarm Heart rate Monitoring Tag (Anti-dismantle type) BT4500-b USER MANUAL Status Indicator Alarm Button Numbering Area 1. Tag Introduction 1.1. General BT4500-b tamper-alarm heart rate monitoring tag (THM tag) is a multi-functional wristband type tag mainly used for personnel locating and identification. It can work with BlueIOT anchor to achieve precise positioning of personnel, heart rate detection, status indication and other functions. The anti-disassembly design can alarm when the wristband is cut and removed. The tag has a simple structure, with waterproof and dustproof, suitable for wearing in harsh environments. 1.2 Panel Contents 1. Tag Introduction 1.1. General 1.2. Panel 2. Tag Usage 2.1. Turn on 2.2. Recharge 2.3. Wearing and Removing 3. Basic function 3.1. Locating 3.2. SOS Alarm 3.3. Tag Configuration 3.4. Swipe Card 3.5 Data Privacy 4. Operation Conditions 5. Trouble Shooting 6. Safety Instructions 7. Disposal and Recycling Information 8. Limited Warranty 9. Statement on Intellectual Property Rights 10. Responsibility Statement 11. Product Parameters 1 1 1 2 2 2 4 5 5 5 5 6 6 6 8 9 15 16 18 19 22 2. Tag Usage 2.1. Turn on The tag will be powered on automatically by default if the battery has power. When turned on, the tag will remain active, the user can not turn it off. If any need to close the tag, please contact the system administrator, realizing through the BlueIOT anchor and related software. 2.2. Recharge When using the tag, note that the tag battery should have power. The LED indicator on the tag flashes every 5 seconds to indicate the current battery level. Charging Port Heart Rate Monitoring Window Tamper Proof Lock The indicator light flashes in blue and green, indicating that the charging is normal; The indicator turns to solid green, indicating that the battery is fully charged. The indicator turns red, indicating that the battery needs recharging as soon as possible. If the battery is completely exhausted before charging, it will take a while to get enough power to make the indicator light work. Follow the steps below to charge: Please use the original power adapter and charging cable, checking if they are in good condition, clean and dry Connect the magnetic charging cable with the charging port on the back panel of the tag Insert the USB port of the charging cable into the power adapter Power on WARNING: Using the wrong size or a poor-quality charger to charge the tag may cause the tag battery to swell, heat up or even catch fire. Use the original charger to charge the tag! Please avoid leaving the battery of the device uncharged for a long time. 2.3. Wearing and Removing The wristband should be put on and taken off with a special tool for the tamper-proof lock. Please wear the wristband to approximately 1 finger width from the wrist bone and tighten up to a comfortable level. Note: Wearing the wristband too loosely may affect the monitoring of heart rate data by the sensor. This tag has an anti-disassembly function. When disassembling or cutting, the indicator light will flash in white, and will trigger the backend server alarm state. 3. Basic function 3.1. Locating After the tag is turned on, it automatically enters the normal mode of locating. In the normal mode, the tag sends a locating signal to the BlueIOT anchor at a certain refresh interval. The refresh interval defaults to 200 milliseconds. This value can be set on the service configuration software. When the tag stays static for a long time, it will automatically switch to sleep mode. In sleep mode, the tag will enter a low power consumption status. The refresh interval for the tag to send positioning signals to the base station will be extended to 10 seconds; when the tag moves or vibrates, it will immediately get back to the normal mode from the sleep mode. The static time from normal mode to sleep mode is 15 seconds by default, and this value can be set on the server configuration software. 3.2. SOS Alarm Press the tag's alarm button and hold it for more than 3 seconds, the tag will upload the emergency alarm information. After the alarm takes effect, the LED indicator of the tag will flash orange, indicating that it is currently in the distress alarm state. 3.3. Tag Configuration The tag can be configured on the service configuration software, and the instructions of are issued to the tag through the BlueIOT anchor. For specific configuration functions, please refer to the "Service Configuration Software Manual" 3.4. Swipe Card The tag has a built-in RFID coil, which can be used for radio frequency identification through a card reader. 3.5. Data Privacy Tag data will only be uploaded to the server designated by the user. When using tags, please consider and abide by local regulations related to data privacy 4. Operation Conditions Exposure to liquid The THM Tag is water resistant. This product is suitable for normal rain a…

Text truncated - open the document above for the full version.

Blueiot(Beijing)TechnologyCo.,Ltd. 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:Blueiot(Beijing)TechnologyCo.,Ltd. Address:10/F,TowerA,TusParkInnovationPlaza,HaidianDistrict, Beijing,China ProductName:BlueIOTRTLSTag FCCID:2AZOM-BT4500-B Model(s):BT4500-b 2.911(d)(5)(i)EquipmentType We,[Blueiot(Beijing)TechnologyCo.,Ltd.](“theapplicant”)certifythattheequipmentforwhich authorizationissoughtthroughcertificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:LiujidaDate:2023-05-12 TitleandCompanyname:Manager/Blueiot(Beijing)TechnologyCo.,Ltd. NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Blueiot(Beijing)TechnologyCo.,Ltd. 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:Blueiot(Beijing)TechnologyCo.,Ltd. Address:10/F,TowerA,TusParkInnovationPlaza,HaidianDistrict, Beijing,China ProductName:BlueIOTRTLSTag FCCID:2AZOM-BT4500-B Model(s):BT4500-b 2.911(d)(5)(ii)Applicantfiling We,[Blueiot(Beijing)TechnologyCo.,Ltd.](“theapplicant”)certifythat,asofthedateofthefilingof theapplication,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 ,establishedpursuant to§1.50002ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely, Name:LiujidaDate:2023-05-12 TitleandCompanyname:Manager/Blueiot(Beijing)TechnologyCo.,Ltd. NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911(d)(7)USAAgentv1.4 Blueiot (Beijing) Technology Co., Ltd. Section 2.9 11(d)(7) USA Agent for Service of Process Company name: Blueiot (Beijing) Technology Co., Ltd. Address: 10/ F, Tower A, TusPark Innovation Plaza, Haidian District, Beijing, China Product Name: BlueIOT RTLS Tag FCCID: 2AZOM-BT4500-B Model(s): BT4500-b 2.911(d)(7) USA Designated Agent for Service of Process We, [Blueiot (Beijing) Technology Co., Ltd.] (“the applicant”) designate [Homewerks Worldwide, LLC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent:We acknowledgeour consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledgeour acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation:We acknowledgeourobligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email addressfor no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USAAgent Companyname:HomewerksWorldwide, LLC USA Address:55 AlbrechtDrive.,Lake Bluff ,Illinois,60044UnitedStates FRN Number: 0022641336 ContactName:MichaelMalaker TelephoneNo: 224-543-1529 Email:[email protected] Applicant Companyname:Blueiot(Beijing) TechnologyCo., Ltd. Address:10/F, TowerA, TusPark InnovationPlaza,HaidianDistrict, Beijing,China FCC GranteeCode:2AZOM FRN: 0030825889 ContactName:Liu jida TelephoneNo: 15101154880 Email:[email protected] Blueiot (Beijing) Technology Co., Ltd. 2.911(d)(7)USAAgentv1.4 Signature: Title: SourcingDirector Signature: Title: Manager Date: 2023-05-12Date: 2023-05-12 NOTE1: An applicantlocatedin the UnitedStatesmay designateitself as the agent for service of process. Reference;FederalRegisterdocument2022-28263publishedon 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Blueiot(Beijing)TechnologyCo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2023-05-12 Subject;RequestforLongTermConfidentiality FCCID:2AZOM-BT4500-B ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:Liujida Title:Manager

Blueiot(Beijing)TechnologyCo.,Ltd. 10/F,TowerA,TusParkInnovationPlaza,HaidianDistrict, Beijing,China AgentAuthorization Company:Blueiot(Beijing)TechnologyCo.,Ltd. Address:10/F,TowerA,TusParkInnovationPlaza,HaidianDistrict, Beijing,China ProductName:BlueIOTRTLSTag ModelNumber(s):BT4500-b ProductDescription:BlueIOTRTLSTag WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2023-05-12 Name:Liujida Title:Manager Company:Blueiot(Beijing)TechnologyCo.,Ltd.

Page 1 of 3 Appendix C: Photographs of EUT Product: BlueIOT RTLS Tag Model: BT4500-b External Photos Page 2 of 3 Page 3 of 3

LabelArtworkandLocation Model:BT4500-b Label: Size:L*W=26*14mm

Page 1 of 4 Appendix C: Photographs of EUT Product: BlueIOT RTLS Tag Model: BT4500-b Internal Photos Page 2 of 4 Antenna Page 3 of 4 Page 4 of 4

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2AZOM-BT4500-B Test Report No. ............... : TCT230407E004 Date of issue ................... : Apr. 13, 2023 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Blueiot (Beijing) Technology Co., Ltd. Address ........................... : 10/F, Tower A, TusPark Innovation Plaza, Haidian District, Beijing, China Manufacturer's name ... : Blueiot (Beijing) Technology Co., Ltd. Address ........................... : 10/F, Tower A, TusPark Innovation Plaza, Haidian District, Beijing, China Standard(s) ..................... : KDB 447498 D01 General RF Exposure Guidance v06 Test item description ..... : BlueIOT RTLS Tag Trade Mark ...................... : Model/Type reference..... : BT4500-b Rating(s).......................... : Rechargeable Li-ion Battery DC 3.8V Date of receipt of test item ......................................... : Apr. 07, 2023 Date (s) of performance of test ................................... : Apr. 07, 2023 ~ Apr. 13, 2023 Tested by (+signature) ... : Yannie ZHONG Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT230407E004 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 Report No.: TCT230407E004 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Test item description ........... : BlueIOT RTLS Tag Model/Type reference........... : BT4500-b Sample Number....................: TCT230407E003-0101 Operation Frequency ........... : 2402MHz~2480MHz Modulation Type ................... : GFSK Antenna Type ........................ : Metal Antenna Antenna Gain ........................ : 0.5dBi Rating(s)................................ : Rechargeable Li-ion Battery DC 3.8V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. Report No.: TCT230407E004 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 3.8V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT230407E004 Page 5 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the following organizations: ● FCC - Registration No.: 645098 SHENZHEN TONGCE TESTING LAB Designation Number: CN1205 The testing lab has been registered and fully described in a report with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. ● IC - Registration No.: 10668A-1 SHENZHEN TONGCE TESTING LAB CAB identifier: CN0031 The testing lab has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing. 3.2. Location SHENZHEN TONGCE TESTING LAB Address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an Dis…

Text truncated - open the document above for the full version.

PRODUCTSPECIFICATION 1、PRODUCTTECHNICALSPECIFICATION Model Ant_BT4500b_BT_metal_L15W11H4.7_V1 SIZE 15.5x11.4x4.7mm Working Frequency 2.4GHz-2.485GHz Bandwidth85MHz Antennatype Metalantenna VSWR <2 Impendence 50Ω Polarization Type line Gain 0.5dBi WorkingTemp -30°C~65°C StorageTemp -30°C~65°C

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2AZOM-BT4500-B Test Report No. ............... : TCT230407E003 Date of issue ................... : Apr. 13, 2023 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Blueiot (Beijing) Technology Co., Ltd. Address ........................... : 10/F, Tower A, TusPark Innovation Plaza, Haidian District, Beijing, China Manufacturer's name ... : Blueiot (Beijing) Technology Co., Ltd. Address ........................... : 10/F, Tower A, TusPark Innovation Plaza, Haidian District, Beijing, China Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 Product Name ................. : BlueIOT RTLS Tag Trade Mark ...................... : Model/Type reference..... : BT4500-b Rating(s).......................... : Rechargeable Li-ion Battery DC 3.8V Date of receipt of test item ......................................... : Apr. 07, 2023 Date (s) of performance of test ................................... : Apr. 07, 2023 ~ Apr. 13, 2023 Tested by (+signature) ... : Yannie ZHONG Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT230407E003 Page 2 of 52 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 1.3. Operation Frequency ............................................................................................ 3 2. Test Result Summary .............................................................................. 4 3. General Information ................................................................................. 5 3.1. Test environment and mode ................................................................................. 5 3.2. Description of Support Units ................................................................................ 5 4. Facilities and Accreditations .................................................................. 6 4.1. Facilities ................................................................................................................. 6 4.2. Location ................................................................................................................. 6 4.3. Measurement Uncertainty ..................................................................................... 6 5. Test Results and Measurement Data ..................................................... 7 5.1. Antenna requirement ............................................................................................ 7 5.2. Conducted Emission ............................................................................................. 8 5.3. Conducted Output Power ................................................................................... 12 5.4. Emission Bandwidth ........................................................................................... 13 5.5. Power Spectral Density ....................................................................................... 14 5.6. Conducted Band Edge and Spurious Emission Measurement ....................... 15 5.7. Radiated Spurious Emission Measurement ...................................................... 17 Appendix A: Test Result of Conducted Test Appendix B: Photographs of Test Setup Appendix C: Photographs of EUT Report No.: TCT230407E003 Page 3 of 52 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : BlueIOT RTLS Tag Model/Type reference........... : BT4500-b Sample Number....................: TCT230407E003-0101 Bluetooth Version ................ : V5.0 Operation Frequency ........... : 2402MHz~2480MHz Channel Separation ............. : 2MHz Data Rate............................... : LE 1M PHY Number of Channel .............. : 40 Modulation Type ................... : GFSK Antenna Type ........................ : Metal Antenna Antenna Gain ........................ : 0.5dBi Rating(s)................................ : Rechargeable Li-ion Battery DC 3.8V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. 1.3. Operation Frequency Channel Frequency Channel Frequency Channel Frequency Channel Frequency 0 2402MHz 10 2422MHz 20 2442MHz 30 2462MHz 1 2404MHz 11 2424MHz 21 2444MHz 31 2464MHz ... ... ... ... ... ... ... ... 8 2418MHz 18 2438MHz 28 2458MHz 38 2478MHz 9 2420MHz 19 2440MHz 29 2460MHz 39 2480MHz Remark: Channel 0, 19 & 39 have been tested. Report No.: TCT230407E003 Page 4 of 52 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(3) PASS 6dB Emission Bandwidth §15.2…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix B: Photographs of Test Setup Product: BlueIOT RTLS Tag Model: BT4500-b Radiated Emission Page 2 of 2 Conducted Emission
