2AZSG-NV-09724SMART WATCH-ROUND-BLACK BELT

Smart Wristband User's Guide Charge the bracelet Use it for the first time to ensure that the battery is in normal condition. If the power is not turned on normally, please connect the charger to charge the device. Install the bracelet app on your phone System requirements: Android 5.0 and above; iOS9.0 and above; support for Bluetooth 4.0. Device connection ⚫ For the first use, you need to connect the APP for calibration. After the connection is successful, the bracelet will automatically synchronize the time. ⚫ Turn on the Bluetooth switch of the mobile phone system → enter the app device module settings → click “Bind device, experience more features” to enter, find and connect the bracelet device. ⚫ Android phones need to allow apps to run in the background. ⚫ Android phones use all notification permissions to read contact information and give the app background running in the phone settings. Wear it properly The bracelet is best worn after the ulnar styloid Adjust the size of the wrist according to the adjustment hole; buckle the wrist strap buckle. The sensor should be close to the skin to avoid moving. Health tricycle ⚫ Number of steps (the outermost ring): The total number of steps every day, reset overnight, and the number of steps can be set on the APP. ⚫ Exercise (middle ring): The data comes from any exercise under exercise, and it is cleared overnight. (As long as it is any exercise time in the exercise, it can be accumulated.) It can be set on the exercise target APP. ⚫ Standing (innermost ring): Data source (if the number of steps in an hour is more than 20 consecutive steps, a standing will be displayed), reset overnight, and can be set on the standing target APP. ⚫ The second page shows the goals and proportions of the three rings of health. Histogram: Figure 1 Steps: Distribution of steps per hour. Figure 2 Exercise: hourly exercise duration distribution. Figure 3 Standing: Hourly distribution of standing. Below the graph there is also a display showing total distance and total calories. Exercise : Heart rate is measured at the beginning of each exercise, and then it is automatically measured every 5 minutes during the exercise process. Each exercise can pause and continue its functions, and the music can be controlled during the exercise. When the exercise is finished, the current exercise summary will be displayed. This exercise data is not saved locally, and the exercise summary will not be displayed when the exercise is finished for less than 5 minutes. Heart rate /blood pressure/bloxygen/electrocardiogram After entering the measurement interface and waiting for a few seconds, the current test result will be displayed. This feature requires the bracelet to support a heart rate sensor. Dial Dial the dial to make calls (note: the phone needs to be connected with audio to use this function) Phone book Add common contacts in the APP, and the contacts can be displayed in the phone book of the phone ring synchronously. Click The contact person can make a call (note: the phone needs to be connected with audio to use this function) Music control The bracelet can control to switch the previous song, the next song, pause/start playback. (Note: The use of this feature phone requires an audio connection) Style switch can switch between different styles of the main menu in the options . Voice assistant ⚫ Pull down the standby page to enter the shortcut interface, click the voice assistant menu to start the language assistant. ( Note: The mobile phone needs to be connected to the Audio device at the same time , and the user's voice needs to be set in advance in the voice menu on the smartphone side ) Information mode connected to the APP, if the push notification reminder is enabled, when the bracelet pushes multiple reminder messages, you can enter this interface to view the latest message records . Stopwatch function Enter the stopwatch and click the start button to start timing, click the pause button to stop, and click the reset button to clear the timing. Weather Connect to the app and enter this interface to view the weather conditions of the day. Find phone APP is connected , click "Find Phone " on the bracelet and the phone will emit a prompt tone QR code Scan the QR code with your mobile phone to download the APP Sleep mode The latest 7-day records are displayed locally on the sleep details page, and the sleep data details can be viewed by connecting to the APP. Do not disturb mode Turn on the Do Not Disturb mode, the bracelet stops receiving notification messages to avoid reminding messages. Note: Only when the app is connected and the bracelet is worn to sleep will the sleep data be uploaded to the app and the detection will start at 10 pm. Photograph connected to the app , start the camera from the bracelet or enter the remote camera interface from the APP, shake/turn the wrist/touch the bracelet, and automatically take a photo after a countdown of 3 seconds. Please allow the APP to access the album to save the self-portrait photo. Reset Resetting this function will clear all data on the bracelet. (like step counting) * Siri: Tap the voice assistant menu to launch the language assistant. (Note: The mobile phone needs to be connected to the audio at the same time, and the user's voice needs to be set in advance in the voice menu on the smartphone side) More ⚫ About: You can view information about the machine. ⚫ Language: You can set any language in the options. ⚫ Set Date: You can set the date required by the user. ⚫ Set time: You can set the time required by the user. ⚫ Backlight time: There are multiple options on the backlight time setting page. When the corresponding time is selected, the screen will automatically turn off. ⚫ Return to the dial: There are multiple options for returning to the dial setting page. After the disk is extinguished, the timer starts. When the corresponding time is selected, it will return to the dial. APP function and settings Sleep mode W…

Text truncated - open the document above for the full version.

Max Sales Group Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-07-24 FCC ID: 2AZSG-NV-09724 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Max Sales Group certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Max Sales Group certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: Max Sales Group Address: 15240 East Nelson Ave., City of Industry, California, United States, 91744 Contact Person: TARUN KHIANI Tel.: +852 23663150 Email: [email protected] Sincerely, Signature:

Address： Date: 2024-07-24 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(7) Filing SUBJECT: FCC Application for FCC ID: 2AZSG- NV-09724 FRN: 0030864680 Grantee code:2AZSG MAX SALES GROUP certifies that, as of the date of the filing of the application, Cleveland International Trade Agency . is our designated U.S. agent for service of process for the above referenced FCC ID: 2AZSG- NV-09724. MAX SALES GROUP accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Cleveland International Trade Agency accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Cleveland International Trade Agency Address: 4033 St Clair Ave, Cleveland, OH 44103, USA Contact Person: Becky Deng Tel.: 216.600.0606 Email: [email protected] FRN: 0033401837 S incerely, Signed on behalf of MAX SALES GROUP Signed on behalf of Cleveland International Trade Agency Signature Signature Name: TARUN KHIANI Name: Becky Deng Title: Manager Title: Manager Date: 2024.07.22 Date: 2024.07.22 Max Sales Group 15240 East Nelson Ave., City of Industry, California, United States, 91744

Product specification Quick Reference Date Frequenc Range 2400 ~ 2500MHz Ant. Port Input Pwr. (dBm) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm) -1.2 (Input pwr – loss pwr) Peak EIRP(dBm) 1.2 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) 6 0.2 % Gain (dBi) 2.0 (Avg Gain XZ-plane) Maximum Power (dBm) 1.7 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Input Impendence(ohm) 50 Polarization Type V ertical & Horizontal V . S .W . R < 1.4 All the technical data and information contained herein are subject to change without prior notice Antenna Layout & module on the system board Antenna Gain Gain Table Unit in dBi @2.44GHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module Board 1.2 -0.5 2.0 -3.6 1.1 -3.0 6 0.2 % Manufacturer: IDEA PLUS INTERNATIONAL(HK)LTD Address: RM-1318-19,HOLLYWOOD PLAZA MONG KOK,KOWLOON Antenna Type Wire Antenna Wire Lntenna Length:25 mm Retum Loss The Environment of Antenna Radiation Pattem 3D radiation pattern diagram XY-plane XZ-plane YZ-plane

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Max Sales Group Date：2024-07-24 Product Model Number: NV-09724 ; FCC ID：2AZSG-NV-09724 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: TARUN KHIANI Contact Listed on FCC Wesbite Title: Email: [email protected] On behalf of: Max Sales Group

Max Sales Group Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 25, 2024 Subject; Request for Confidentiality FCC ID: 2AZSG-NV-09724 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: TARUN KHIANI Title:

Page 1 of 5 Report No.: LGT24G081 Appendix - External Photographs of EUT Constructional Details Model: NV-09724 Photo 1 Photo 2 Page 2 of 5 Report No.: LGT24G081 Photo 3 Photo 4 Page 3 of 5 Report No.: LGT24G081 Photo 5 Photo 6 Page 4 of 5 Report No.: LGT24G081 Photo 7 Photo 8 Page 5 of 5 Report No.: LGT24G081 Photo 9 Photo 10

Label Size: 20*5mm FCC ID: 2AZSG-NV-09724

Page 1 of 3 Report No.: LGT24G081 Appendix - Internal Photographs of EUT Constructional Details Model: NV-09724 Photo 1 Photo 2 Page 2 of 3 Report No.: LGT24G081 Photo 3 Photo 4 BT ANT Page 3 of 3 Report No.: LGT24G081 Photo 5 Photo 6

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: SMART WATCH-ROUND-BLACK BELT Model Name: NV-09724 FCC ID: 2AZSG-NV-09724 Issued For : Max Sales Group 15240 East Nelson Ave., City of Industry, California, United States, 91744 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24G081HA01 Sample Received Date: Jul. 11, 2024 Date of Test: Jul. 11, 2024 – Jul. 24, 2024 Date of Issue: Jul. 24, 2024 Report No.: LGT24G081HA01 Page 2 of 9 TEST REPORT CERTIFICATION Applicant: Max Sales Group Address: 15240 East Nelson Ave., City of Industry, California, United States, 91744 Manufacture: IDEA PLUS INTERNATIONAL(HK)LTD Address: RM-1318-19,HOLLYWOOD PLAZA MONG KOK,KOWLOON Product Name: SMART WATCH-ROUND-BLACK BELT Trademark: N/A Model Name: NV-09724 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24G081HA01 Page 3 of 9 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.5 TEST RESULT 8 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS 9 Report No.: LGT24G081HA01 Page 4 of 9 Revision History Rev. Issue Date Revisions 00 Jul. 24, 2024 Initial Issue Report No.: LGT24G081HA01 Page 5 of 9 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: SMART WATCH-ROUND-BLACK BELT Trademark: N/A Model Name: NV-09724 Series Model: N/A Model Difference: N/A Frequency Bands: Bluetooth 2402-2480MHz Rating: Input: DC 5V 500mA Battery: Rated Voltage: 3.7V Hardware Version: N/A Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT24G081HA01 Page 6 of 9 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT24G081HA01 Page 7 of 9 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT24G081HA01 Page 8 of 9 2.5 TEST RESULT Turn up Result Mode Turn up Power BLE-GFSK 2.5±1dBm The MPE result of worst mode: RF Function Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result BT 2480 3.50 2.24 0.705 3 0.235 Pass Note: 1. The Maximum Power Density is less than the limit, complies with the exemption requirements. Report No.: LGT24G081HA01 Page 9 of 9 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Note: Please see the attached NV-09724_EUT Photos. ※※※※※END OF THE REPORT※※※※※

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: SMART WATCH-ROUND-BLACK BELT Model Name: NV-09724 FCC ID: 2AZSG-NV-09724 Issued For : Max Sales Group 15240 East Nelson Ave., City of Industry, California, United States, 91744 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24G081RF01 Sample Received Date: Jul. 11, 2024 Date of Test: Jul. 11, 2024 – Jul. 24, 2024 Date of Issue: Jul. 24, 2024 Report No.: LGT24G081RF01 Page 2 of 48 TEST REPORT CERTIFICATION Applicant: Max Sales Group Address: 15240 East Nelson Ave., City of Industry, California, United States, 91744 Manufacturer: IDEA PLUS INTERNATIONAL(HK)LTD Address: RM-1318-19,HOLLYWOOD PLAZA MONG KOK,KOWLOON Product Name: SMART WATCH-ROUND-BLACK BELT Trademark: N/A Model Name: NV-09724 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24G081RF01 Page 3 of 48 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 EUT OPERATING CONDITIONS 13 3.5 TEST RESULTS 14 4. RADIATED EMISSION MEASUREMENT 16 4.1 RADIATED EMISSION LIMITS 16 4.2 TEST PROCEDURE 18 4.3 TEST SETUP 18 4.4 EUT OPERATING CONDITIONS 19 4.5 FIELD STRENGTH CALCULATION 19 4.6 TEST RESULTS (BAND EDGE REQUIREMENTS) 25 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 27 5.1 LIMIT 27 5.2 TEST PROCEDURE 27 5.3 TEST SETUP 27 5.4 EUT OPERATION CONDITIONS 27 5.5 TEST RESULTS 27 6. POWER SPECTRAL DENSITY TEST 28 6.1 LIMIT 28 6.2 TEST PROCEDURE 28 6.3 TEST SETUP 28 6.4 EUT OPERATION CONDITIONS 28 Report No.: LGT24G081RF01 Page 4 of 48 6.5 TEST RESULTS 28 7. BANDWIDTH TEST 29 7.1 LIMIT 29 7.2 TEST PROCEDURE 29 7.3 TEST SETUP 29 7.4 EUT OPERATION CONDITIONS 29 7.5 TEST RESULTS 29 8. PEAK OUTPUT POWER TEST 30 8.1 LIMIT 30 8.2 TEST PROCEDURE 30 8.3 TEST SETUP 30 8.4 EUT OPERATION CONDITIONS 30 8.5 TEST RESULTS 30 9. ANTENNA REQUIREMENT 31 9.1 STANDARD REQUIREMENT 31 9.2 EUT ANTENNA 31 APPENDIX I - TEST RESULTS 32 DUTY CYCLE 32 MAXIMUM PEAK CONDUCTED OUTPUT POWER 34 -6DB BANDWIDTH 35 OCCUPIED CHANNEL BANDWIDTH 37 MAXIMUM POWER SPECTRAL DENSITY LEVEL 39 BAND EDGE 41 CONDUCTED RF SPURIOUS EMISSION 44 APPENDIX II - MEASUREMENT PHOTOS 47 APPENDIX III - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS 48 Report No.: LGT24G081RF01 Page 5 of 48 Revision History Rev. Issue Date Revisions 00 Jul. 24, 2024 Initial Issue Report No.: LGT24G081RF01 Page 6 of 48 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 Part 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT24G081RF01 Page 7 of 48 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 9K-30MHz ±2.84dB 4 All emissions, radiated 30M-1GHz ±4.39dB 5 All emissions, radiated 1G-6GHz ±5.10dB 6 All emissions, radiated>6G ±5.48dB 7 Conducted Emission (9KHz-150KHz) ±2.79dB 8 Conducted Emission (150KHz-30MHz) ±2.80dB 9 Emission Bandwidth ±3.2 % Note: The measurement uncertainty is not included in the test result. Report No.: LGT24G081RF01 Page 8 of 48 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: SMART WATCH-ROUND-BLACK BELT Trademark: N/A Model Name: NV-09724 Series Model: N/A Model Difference: N/A Product Description: Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE (1M PHY) Number Of Channel: 40 Antenna Designation: Wire antenna Antenna Gain (dBi) 2dBi Channel List: Please refer to the Note 3. Rating: Input: DC 5V 500mA Battery: Rated Voltage: 3.7V Hardware Version: N/A Software Version: N/A Connecting I/O Port(s): Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User Manual. 2. The antenna information refers to the manufacturer provide re…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.: LGT24G081 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT24G081 Set-up for Conducted Emission
