2AZWZ-D9DASH CAMERA

KAWA ELECTRONICS COMPANY LIMITED FLAT A 21/F CHEUNG LEE IND BLDG 9 CHEUNG LEE ST CHAI WAN HONG KONG, CHINA Nov. 17, 2025 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID: 2AZWZ-D9 Models: D9, D9 Lite, D9 Pro, D9X, D9X Pro, CJ5517 To Whom It May Concern: We, The KAWA ELECTRONICS COMPANY LIMITED hereby declare that the model :D9 Lite, D9 Pro, D9X, D9X Pro, CJ5517 is identical with the model : D9, except the model names, trademarks and the color of appearance. All the models are the same circuit and RF module. Sincerely, KAWA ELECTRONICS COMPANY LIMITED Signature: [Yuwei Zhang, General Manager]

KAWA ELECTRONICS COMPANY LIMITED FLAT A 21/F CHEUNG LEE IND BLDG 9 CHEUNG LEE ST CHAI WAN HONG KONG, CHINA Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Nov. 17, 2025 Subject; Request for Confidentiality FCC ID: 2AZWZ-D9 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Yuwei Zhang Title: General Manager

KAWA ELECTRONICS COMPANY LIMITED FLAT A 21/F CHEUNG LEE IND BLDG 9 CHEUNG LEE ST CHAI WAN HONG KONG, CHINA Nov. 17, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2AZWZ-D9 I, the undersigned, hereby authorize (Attestation of Global Compliance (Shenzhen) Co., Ltd) to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by (Attestation of Global Compliance (Shenzhen) Co., Ltd) shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with KAWA ELECTRONICS COMPANY LIMITED. We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, (Signature) Full name of contact person listed on FCC’s website: Yuwei Zhang Title: General Manager Tel: 13428982606 Email: [email protected]

FCC ID and ISED Label Location 36.00mm*19.30mm FCC ID:2AZWZ-D9 IC:27280-D9 HVIN:D9

Page 1 of 10 RF Exposure Report Report No.: AGC17208251002FH01 FCC ID : 2AZWZ-D9 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : DASH CAMERA BRAND NAME : KAWA, WESN MODEL NAME : D9, D9 Lite, D9 Pro, D9X, D9X Pro, CJ5517 APPLICANT : KAWA ELECTRONICS COMPANY LIMITED DATE OF ISSUE : Nov. 14, 2025 STANDARD(S) : FCC Part 2 Subpart J §2.1091 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC17208251002FH01 Page 2 of 10 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Nov. 14, 2025 Valid Initial Release Report No.: AGC17208251002FH01 Page 3 of 10 Table of Contents 1. General Information ........................................................................................................................................ 4 2. Product Information ........................................................................................................................................ 5 2.1 Product Technical Description ................................................................................................................... 5 3. Test Environment ............................................................................................................................................ 6 3.1 Address Of The Test Laboratory ............................................................................................................... 6 3.2 Test Facility ................................................................................................................................................ 6 3.3 Environmental Conditions ......................................................................................................................... 7 4. Mobile Device Evaluation Method and Limit ................................................................................................ 8 5. Measurement Results ..................................................................................................................................... 9 6. Measurement Evaluation ................................................................................................................................ 9 Report No.: AGC17208251002FH01 Page 4 of 10 1. General Information Applicant KAWA ELECTRONICS COMPANY LIMITED Address FLAT A 21/F CHEUNG LEE IND BLDG 9 CHEUNG LEE ST CHAI WAN HONG KONG, CHINA Manufacturer KAWA ELECTRONICS COMPANY LIMITED Address FLAT A 21/F CHEUNG LEE IND BLDG 9 CHEUNG LEE ST CHAI WAN HONG KONG, CHINA Factory Dongguan Apical Technology Co., Ltd Address No. 686, Xiecao Road, Xiegang Town, Dongguan City, Guangdong Province, China Product Designation DASH CAMERA Brand Name KAWA, WESN Test Model D9 Series Model(s) D9 Lite, D9 Pro, D9X, D9X Pro, CJ5517 Difference Description All the series models are the same as the test model except for the model names, trademarks and the color of appearance. Date of receipt of test item Oct. 11, 2025 Date of Test Oct. 11, 2025~Nov. 14, 2025 Deviation from Standard No any deviation from the test method Condition of Test Sample Normal Test Result Pass Test Report Form No AGCER-FCC-RF Exposure-V1 Note: The test results of this report relate only to the tested sample identified in this report. Prepared By Jasiel Xie (Project Engineer) Nov. 14, 2025 Reviewed By Bibo Zhang (Reviewer) Nov. 14, 2025 Approved By Angela Li (Authorized Officer) Nov. 14, 2025 Report No.: AGC17208251002FH01 Page 5 of 10 2. Product Information 2.1 Product Technical Description Frequency Band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5.825GHz Bluetooth: 2.402GHz ~ 2.480GHz Other: Hardware Version CJ5517-MAIN-01A Software Version V0.0.2 Modulation Type 2.4G WLAN: 802.11b:(DQPSK, DBPSK, CCK) DSSS 802.11g/n:(64-QAM,16-QAM, QPSK, BPSK) OFDM 802.11ax:(1024-QAM,256-QAM,64-QAM,16QAM,QPSK,BPSK)OFDMA Device Category Portable (<20cm separation) Mobile (>20cm separation) Others: Antenna Diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Antenna Designation FPC Antenna Antenna Gain 1.0dBi Minimum Assessment Distance 20cm Evaluation Applied MPE Evaluation SAR Evaluation Report No.: AGC17208251002FH01 Page 6 of 10 3. Test Environment 3.1 Address Of The Test Laboratory Laboratory: Attestation of Global Compliance (Shenzhen) Co., Ltd. Address: 1-2/F, Building 19, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 3.2 Test Facility The test facility is recognized, certified, or accredited by the following organizations: CNAS-Lab Code: L5488 Attestation of Global Compliance (Shenzhen) Co., Ltd. has been assessed and proved to follow CNAS-CL01 Accreditation Criteria for Testing and Calibration Laboratories (identical to ISO/IEC17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories.) A2LA-Lab Cert. No.: 5054.02 Attestation of Global Compliance (Shenzhen) Co., Ltd. EMC Laboratory has been accredited by A2LA for technical competence in the field of electrical testing, and proved to follow ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories and any additional program requirements in the identified field of testing. FCC-Registration No.: 975832 Attestation of Global Compliance (Shenzhen) Co., Ltd. EMC Laboratory has been registered and fully described in a report filed with the FCC (Federal Communications Commission). The acceptance letter from the FCC is maintained in our files with Registration 975832. IC-Registration No.: 24842(CAB identifier: CN0063) Attestation of Global Compliance (Shenzhen) Co., Ltd. EMC Laboratory has been registered and fully described in a report filed with the Certification and Engineering Bureau of Industry Canada. The acceptance letter from the IC is maintained in our files with Registration 24842. Report No.: AGC17208251002FH01 Page 7 of 10 3.3 Env…

Text truncated - open the document above for the full version.

Antenna Testing Report Customer： apical Technology Project Name：CJ5517 Report Number:SZ25443IB77/SZ25443IA54 Manufacturer: Sunnyway Technology(CHINA) Address: Floor 6, Building 5, Nam Tai Inno Park, Guangming District, Shenzhen Report version：2025.12.17 Wireless connections create unlimited possibilities 履历 Version TimeUpdate Notes A02025.12.17Latest test data A1 A2 A3 A4 A5 A6 A7 A8 A9 2 Table of Contents 3 1.Resume...................................................................... 2. Project Overview............................................................ 3.Company and Test Environment Introduction.................................... 4. Matching circuit............................................................. 5.WiFi antenna-related data..................................................... 6.LORA antenna-related data..................................................... 7. Complete machine environmental handling....................................... 8. Summary...................................................................... Prototype status Active machine Project Prototype Diagram： Product Type Temperature and humidity sensor Number of antennas WIFI Antenna,GNSSAntenna Antenna frequency band GNSS（1561/1575.42MHz） WIFI 802.11 /b/g/n Structural form FPC/Ceramics Environmenta l management No changes made Matching circuit No changes made Project Overview 4 Equipment List 5 The industry's top 64 sensors OTA chamber Frequency range: 400MHz-11GHz Device Llimitation: 2M Load-bearing limitation:100KG Matching Circuit 6 Antenna matching has not been changed Antenna installation position 7 Project pictures and Passive fixturs 8 WI FI antenna/Antenna size WI FI Antenna type: FPC WI FI Antenna model: SZ25443IB77 GPS antenna/Antenna size GPS Antenna type: Ceramics GPS Antenna model: SZ25443IA54 9 WiFi Antenna S11 WiFi Antenna efficiency 10 Frequency/MhzMaxGain/dBiEfficiency / % 2400-0.448.53 2410-0.1950.6 2420-0.9444.16 2430-1.0943.35 2440-0.5847.21 24500.0451.33 24600.2650.58 24700.4148.17 2480149.2 24900.8948.76 25001.5247.7 WiFi Active testing 11 MeasurementBandChannelTotal TRPWIFI_B (1M)113.3 TRPWIFI_B (1M)713.47 TRPWIFI_B (1M)1313.69 TIS(EIRP)WIFI_B (11M)13-80.28 TRPWIFI_G (6M)113.56 TRPWIFI_G (6M)714.06 TRPWIFI_G (6M)1314.68 TIS(EIRP)WIFI_G (54M)13-65.06 TRPWIFI_N_ISM (6.5M)112.47 TRPWIFI_N_ISM (6.5M)712.34 TRPWIFI_N_ISM (6.5M)1313.38 TIS(EIRP)WIFI_N_ISM (65M)13-62.72 WiFiAntenna Radiation Pattern 12 13 GPS Antenna S11 GPS Antenna efficiency 14 Frequency/MhzMaxGain/dBiEfficiency / % 1555-3.126.61 1556-2.829.44 1557-2.5832.66 1558-2.2836.06 1559-1.9139.17 1560-1.7141.21 1561-1.5741.11 1562-1.4339.45 1563-1.636.56 1564-233.42 1565-2.4634.76 1566-2.8532.97 1567-3.1132.18 1568-3.2832.31 1569-3.3933.11 1570-3.334.27 1571-2.8235.41 1572-2.4136.51 1573-2.0437.57 1574-1.6938.75 1575-1.3240.22 1576-1.0341.93 1577-0.7239.63 1578-0.4140.64 1579-0.2440.55 1580-0.339.17 GPS Antenna Radiation Pattern 15 Antenna Environment Processing 16 Antenna environment processing not added Summary 17 1. Antenna matching has not changed; 2.Environmental handling has not changed; 3.The trial production machine's antenna verification data is OK, with little difference from before.. 18 11/11

Page 1 of 91 FCC Test Report Report No.: AGC17208251002FR01 FCC ID : 2AZWZ-D9 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : DASH CAMERA BRAND NAME : KAWA, WESN MODEL NAME : D9, D9 Lite, D9 Pro, D9X, D9X Pro, CJ5517 APPLICANT : KAWA ELECTRONICS COMPANY LIMITED DATE OF ISSUE : Nov. 14, 2025 STANDARD(S) : FCC Part 15 Subpart C §15.247 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC17208251002FR01 Page 2 of 91 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Nov. 14, 2025 Valid Initial Release Report No.: AGC17208251002FR01 Page 3 of 91 Table of Contents 1. General Information ........................................................................................................................................ 5 2. Product Information ........................................................................................................................................ 6 2.1 Product Technical Description ................................................................................................................... 6 2.2 Table of Carrier Frequency ........................................................................................................................ 7 2.3 IEEE 802.11n Modulation Scheme ........................................................................................................... 8 2.4 Related Submittal(S) / Grant (S) ............................................................................................................... 9 2.5 Test Methodology ...................................................................................................................................... 9 2.6 Special Accessories .................................................................................................................................. 9 2.7 Equipment Modifications ........................................................................................................................... 9 2.8 Antenna Requirement................................................................................................................................ 9 2.9 Description of Test Software ................................................................................................................... 10 3. Test Environment .......................................................................................................................................... 11 3.1 Address of The Test Laboratory .............................................................................................................. 11 3.2 Test Facility .............................................................................................................................................. 11 3.3 Environmental Conditions ....................................................................................................................... 12 3.4 Measurement Uncertainty ....................................................................................................................... 12 3.5 List of Equipment Used ........................................................................................................................... 13 4.System Test Configuration ............................................................................................................................ 14 4.1 EUT Configuration ................................................................................................................................... 14 4.2 EUT Exercise ........................................................................................................................................... 14 4.3 Configuration of Tested System .............................................................................................................. 14 4.4 Equipment Used in Tested System ......................................................................................................... 15 4.5 Summary of Test Results ........................................................................................................................ 16 5. Description of Test Modes ........................................................................................................................... 17 6. Duty Cycle Measurement ............................................................................................................................. 18 7. RF Output Power Measurement .................................................................................................................. 20 7.1 Provisions Applicable .............................................................................................................................. 20 7.2 Measurement Procedure ......................................................................................................................... 20 7.3 Measurement Setup (Block Diagram of Configuration) .......................................................................... 20 7.4 Measurement Result ............................................................................................................................... 21 8. 6dB Bandwidth Measurement ...................................................................................................................... 22 8.1 Provisions Applicable .............................................................................................................................. 22 8.2 Measurement Procedure ......................................................................................................................... 22 8.3 Measurement Setup (Block Diagram of Configuration) .......................................................................... 22 8.4 Measurement Result .............................................................................................................................…

Text truncated - open the document above for the full version.

Report No.: AGC17208251002FR01 Page 70 of 91 Test_Graph_802.11ax40_ANT1_2437_MCS0_Lower Band Emissions Test_Graph_802.11ax40_ANT1_2437_MCS0_Higher Band Emissions Report No.: AGC17208251002FR01 Page 71 of 91 Test_Graph_802.11ax40_ANT1_2452_MCS0_Lower Band Emissions Test_Graph_802.11ax40_ANT1_2452_MCS0_Higher Band Emissions Report No.: AGC17208251002FR01 Page 72 of 91 Test Graphs of Band Edge Emissions in Non-Restricted Frequency Bands Test_Graph_802.11b_ANT1_2412_1Mbps_Lower Band Edge Emissions Test_Graph_802.11g_ANT1_2412_6Mbps_Lower Band Edge Emissions Report No.: AGC17208251002FR01 Page 73 of 91 Test_Graph_802.11n20_ANT1_2412_MCS0_Lower Band Edge Emissions Test_Graph_802.11n40_ANT1_2422_MCS0_Lower Band Edge Emissions Report No.: AGC17208251002FR01 Page 74 of 91 Test_Graph_802.11ax20_ANT1_2412_MCS0_Lower Band Edge Emissions Test_Graph_802.11ax40_ANT1_2422_MCS0_Lower Band Edge Emissions Report No.: AGC17208251002FR01 Page 75 of 91 Note: Emissions from 2483.5-2500MHz which fall in the restricted bands had been considered with the radiate d emission limits specified. Report No.: AGC17208251002FR01 Page 76 of 91 11. Radiated Spurious Emission 11.1 Measurement Limits  15.209(a) Limit in the below table has to be followed Frequencies (MHz) Field Strength (microvolts/meter) Measurement Distance (meters) 0.009~0.490 2400/F(kHz) 300 0.490~1.705 24000/F(kHz) 30 1.705~30.0 30 30 30~88 100 3 88~216 150 3 216~960 200 3 Above 960 500 3 Note: All modes were tested for restricted band radiated emission, the test records reported below are the worst result compared to other modes. 11.2 Measurement Procedure 1. The EUT was placed on the top of the turntable 0.8 or 1.5 meter above ground. The phase center of the receiving antenna mounted on the top of a height-variable antenna tower was placed 3 meters far away from the turntable. 2. Power on the EUT and all the supporting units. The turntable was rotated by 360 degrees to determine the position of the highest radiation. 3. The height of the broadband receiving antenna was varied between one meter and four meters above ground to find the maximum emissions field strength of both horizontal and vertical polarization. 4. For each suspected emission, the antenna tower was scan (from 1 M to 4 M) and then the turntable was rotated (from 0 degree to 360 degrees) to find the maximum reading. 5. Set the test-receiver system to Peak or CISPR quasi-peak Detect Function with specified bandwidth under Maximum Hold Mode. 6. For emissions above 1GHz, use 1MHz RBW and 3MHz VBW for peak reading. Place the measurement antenna away from each area of the EUT determined to be a source of emissions at the specified measurement distance, while keeping the measurement antenna aimed at the source of emissions at each frequency of significant emissions, with polarization oriented for maximum response. The measurement antenna may have to be higher or lower than the EUT, depending on the radiation pattern of the emission and staying aimed at the emission source for receiving the maximum signal. The final measurement antenna elevation shall be that which maximizes the emissions. The measurement antenna elevation for maximum emissions shall be restricted to a range of heights of from 1 m to 4 m above the ground or reference ground plane. 7. When the radiated emissions limits are expressed in terms of the average value of the emissions, and pulsed operation is employed, the measurement field strength shall be determined by averaging over one complete pulse train, including blanking intervals, as long as the pulse train does not exceed 0.1 seconds. As an alternative (provided the transmitter operates for longer than 0.1 seconds) or in cases where the Report No.: AGC17208251002FR01 Page 77 of 91 pulse train exceeds 0.1 seconds, the measured field strength shall be determined from the average absolute voltage during a 0.1 second interval during which the field strength is at its maximum values. 8. If the emissions level of the EUT in peak mode was 3 dB lower than the average limit specified, then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions which do not have 3 dB margin will be repeated one by one using the quasi-peak method for below 1GHz. 9. For testing above 1GHz, the emissions level of the EUT in peak mode was lower than average limit (that means the emissions level in peak mode also complies with the limit in average mode), then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions will be measured in average mode again and reported. 10. In case the emission is lower than 30MHz, loop antenna has to be used for measurement and the recorded data should be QP measured by receiver. High - Low scan is not required in this case.  The following table is the setting of spectrum analyzer and receiver. Spectrum Parameter Setting Start ~Stop Frequency 9kHz~150KHz/RB 200Hz for QP Start ~Stop Frequency 150kHz~30MHz/RB 9kHz for QP Start ~Stop Frequency 30MHz~1000MHz/RB 120kHz for QP Start ~Stop Frequency 1GHz~26.5GHz 1MHz/3MHz for Peak, 1MHz/3MHz for Average Receiver Parameter Setting Start ~Stop Frequency 9kHz~150KHz/RB 200Hz for QP Start ~Stop Frequency 150kHz~30MHz/RB 9kHz for QP Start ~Stop Frequency 30MHz~1000MHz/RB 120kHz for QP Report No.: AGC17208251002FR01 Page 78 of 91  Quasi-Peak Measurements below 1GHz 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. Span was set greater than 1MHz 3. RBW = as shown in the table above 4. Detector = CISPR quasi-peak 5. Sweep time = auto couple 6. Trace was allowed to stabilize  Peak Measurements above 1GHz 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = 1MHz 3. VBW = 3MHz 4. Detector = peak 5. Sweep time = auto couple 6. Trace mode = max hold 7. Trace was allowed to stabilize  Average Measurements above 1GHz 1. Analyzer center frequency was set to the frequ…
