2BACV-C-WIRELESSWireless Speaker

VDLRSPKDISP-ASST VDLRSPK-DGRY VDLRSPK-SMBL 1. Press and hold the Power button for 2-3 seconds to turn on the speaker. Wireless Speaker 2-3 SEC PRESS & HOLD SPECIFICATIONS CHARGING BLUETOOTH PAIRING Bluetooth Range: Up to 33 feet (10 meters) Battery Type: Polymer Lithium Ion Battery Charging Input: Play Time: Approximately 3-5 hours** Charging Time: Approximately 1-2 hours **Applicable at 50% of maximum volume. Results will be lower when volume is higher. 1. The included USB charging cable has a Micro USB plug and a standard USB plug. 2. Insert the cable’s standard USB plug into the USB port of a computer or suitable USB charging adapter. Then insert the cable’s Micro USB end Micro USB Plug USB Plug The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Sakar International is under license. Other trademarks and trade names are those of their respective owners. A QUICK LOOK 2. Go to the Bluetooth settings menu on your phone. Make sure that Bluetooth is turned on. Connect to the device listed as "Wireless Speaker ." connected Wireless Speaker DC 5V 500 mA Charging portPower User Manual Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Consult the dealer or an experienced radio/TV technician for help. 1. READ ALL INSTRUCTIONS BEFORE USING YOUR SPEAKER. 2. Do not allow children to use the speaker without proper adult supervision. 3. Do not expose your speaker to excessive heat or fire. 4. Always press the buttons carefully. 5. Do not use in extremely dry environments as this can lead to static discharge during usage. 6. Do not expose your speaker to temperatures above 140 ° / 40 C. Keep out of direct sunlight. 7. Do not attempt to repair this product yourself. Contact a qualified service center if your speaker are in need of service. 8. Do not drop, puncture or expose the speaker to extreme physical force. 9. Your speaker are not intended for commercial use. 10. Do not place the speaker near objects that generate a strong magnetic field. 11. Use only the included charging cable. 12.Unplug this device when not in use for long periods of time and during lightning storms. 13. Do not pull or yank on the power cable. Always remove the cable gently from wall outlets and the speaker’s charging port. 14. Use a soft cloth to clean your speaker . Never use rubbing alcohol or other harsh chemicals. 15. Please recycle or dispose of your speaker properly based on the laws and rules of your 16. municipality. Contact local recycling facilities and/or the manufacturer of your speaker for futher information. IMPORTANT SAFETY PRECAUTIONS VIVITAR ONE YEAR WARRANTY FCC STATEMENT ©2023 Sakar International 195 Carter Drive Edison, NJ 08817 Support: 800 592 9541 www.vivitar.com OTHER FUNCTIONS This warranty covers the original consumer purchaser only and is not transferable. This warranty covers products that fail to function properly UNDER NORMAL USAGE, due to defects in material or workmanship. Your product will be repaired or replaced at no charge for parts or labor for a period of one year. What Is Not Covered by Warranty Damages or malfunctions not resulting from defects in material or workmanship and damages or malfunctions from other than normal use, including but limited to, repair by unauthorized parties, tampering, modification or accident. To Obtain Warranty Service and Troubleshooting Information: Call 1-800-592-9541 or visit our website at www.vivitar.com. To receive Warranty service along with the name and address of an authorized product service center, the original consumer purchaser must contact us for problem determination and service procedures. Proof of purchase in the form of a bill of sale or receipted invoice, evidencing that the product is within the applicable Warranty period(s), MUST be presented in order to obtain the requested service. It is your responsibility to properly package and send any defective products along with a dated copy of proof of purchase, a written explanation of the problem, and a valid return address to the authorized service center at your expense. Do not include any other items or accessories with the defective product. Any products received by the authorized service center that are not covered by warranty will be returned unrepaired. 1. Turn on two speakers (Do not do BT pairing pls). 2. Short press twice one of the power button into tws pairing. 3. Wait for ting voice means tws pairing successfully. 4. Do BT pairing, then go for music playing. 5. End TWS pairing: close BT pairing firstly, short press twice power button to end tws pairing. TWS ° F

Dongguan Unity Win Electronic Tech Co., Limited Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 6, 2023 FCC ID: 2BACV-C-WIRELESS Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Dongguan Unity Win Electronic Tech Co., Limited certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Dongguan Unity Win Electronic Tech Co., Limited certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: Dongguan Unity Win Electronic Tech Co., Limited Address: F501, Building 2, No.30 XinHua Rd, WanJiang Street, Dongguan, Guangdong, China Contact Person: Mary Chen Tel.: +86-0769-22224037 Email: [email protected] Sincerely, Signature:

DongguanUnityWinElectronicTechCo.,Limited U.S.AgentLetterofAttestation To:FederalCommunicationsCommission 7435OaklandMillsRoad,Columbia,MD21046,USA Date:08-17-2023 Ref: AttestationStatement–Part 2.911(d)(7)filing FCCID:2BACV-C-WIRELESS DongguanUnityWinElectronicTechCo.,Limited(“theapplicant”)certifiesthat,asofthedateofthe filingoftheapplication,SakarInternationalInc(“theagent”)isourdesignatedU.S.agentforservice ofprocessfortheabovereferenceFCCID.Theapplicantacceptstomaintainanagentforservice ofprocessintheUnitedStatesfornolessthanoneyearaftereitherthegranteehaspermanently terminatedallmarketingandimportationoftheapplicableequipmentwithintheU.S.,orthe conclusionofanyCommission-relatedadministrativeorjudicialproceedinginvolvingtheequipment, whicheverislater.TheapplicantfurtheracknowledgesitisourresponsibilitytoinformtheFCC whenevertheagentinformationchanges. SakarInternationalInc("theagent)understanditistheagent'sobligationtoacceptserviceof processintheUnitedStatesformattersrelatedtotheapplicableequipment,andatthephysicalU.S. addressandemailaddress. DesignatedU.S.Agent CompanyName: SakarInternationalInc FRN:0028102671 Address: 195CarterDrive,Edison,NewJersey,08817United States Signature: ContactPerson:DAWNLEITAO Tel:8006371090Email:[email protected] Applicant CompanyName:DongguanUnityWinElectronicTechCo.,Limited Address: F501,Building2,No.30XinHuaRd,WanJiangStreet, Dongguan,Guangdong,China Signature: ContactPerson:MaryChen Tel:+86-0769-22224037Email:[email protected]

Report No: SSP23080083A Antenna Test Report Page 1 of 4 Antenna Test Report Test Standard: IEEE 149-1979 Manufacturer: Dongguan Unity Win Electronic Tech Co., Limited Product Name: 2.4GHz Antenna Model: VDLRSPKDISP-ASST Report No.: SSP23080083A Tested Date: 2023-08-10 Issued Date: 2023-08-11 Tested By: William Liu (Engineer) Approved By: Lahm Peng (Manager) Prepared By: Shenzhen ZRLK Testing Technology Co., Ltd. 1F, No. 35 Building, Changxing Technology Industrial Park, Yutang Street, Guangming New District, Shenzhen City, Guangdong Province, China Tel.: +86-755-33019599 Fax.: +86-755-33019599 Website: www.zrlklab.com Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen ZRLK Testing Technology Co., Ltd. Report No: SSP23080083A Antenna Test Report Page 2 of 4 1. General Information 1.1 Product Information Manufacturer Manufacturer: Dongguan Unity Win Electronic Tech Co., Limited Address of Manufacturer: F501, Building 2, No.30 XinHua Rd, WanJiang Street, Dongguan, Guangdong, China General Description of Antenna Product Name: 2.4GHz Antenna Model No.: VDLRSPKDISP-ASST Frequency Range: 2400MHz-2483.5MHz Type of Antenna: PCB Antenna Antenna Gain: 0dBi (Max.) Impedance: 50 ohm Antenna View (15mm*5mm) 1.2 Test Methodology All measurements contained in this report were conducted with standards IEEE 149-1979 for IEEE Standard Test Procedures for Antennas. 1.3 Test Facilities Testing Lab: Shenzhen ZRLK Testing Technology Co., Ltd. All measurement facilities used to collect the measurement data are located at 1F, No. 35 Building, Changxing Technology Industrial Park, Yutang Street, Guangming New District, Shenzhen City, Guangdong Province, China Report No: SSP23080083A Antenna Test Report Page 3 of 4 2. OTA Test 2.1 Gain Frequency Peak Gain (dBi) Polarity 2402MHz 0 Horizontal 2402MHz -0.73 Vertical 2442MHz -1.66 Horizontal 2442MHz -2.41 Vertical 2480MHz -2.62 Horizontal 2480MHz -2.94 Vertical 2.2 Radiation Pattern View Report No: SSP23080083A Antenna Test Report Page 4 of 4

Dongguan Unity Win Electronic Tech Co., Limited Date: September 6, 2023 Product Model Number: VDLRSPKDISP-ASST, VDLRSPK-DGRY, VDLRSPK-SMBL, FBBTBALN1-PNK, FBBTBALN1-BLU, FBBTBALN1- GLD, ST34-RS-TA, C1, C2, C3, C4, C5, C6, L-SP006, MS34-NS-TA, NS- MS34-BT, NS-MS34-DM FCC ID: 2BACV-C-WIRELESS To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. By: Mary Chen Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: +86-0769-22224037 On behalf of: Dongguan Unity Win Electronic Tech Co., Limited

Dongguan Unity Win Electronic Tech Co., Limited Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 6, 2023 Subject; Request for Confidentiality FCC ID: 2BACV-C-WIRELESS To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Mary Chen Title: Manager

Dongguan Unity Win Electronic Tech Co., Limited Model Difference Statement Dear Sir/Madam, Added models VDLRSPK-DGRY, VDLRSPK-SMBL, FBBTBALN1-PNK, FBBTBALN1-BLU, FBBTBALN1-GLD, ST34-RS-TA, C1, C2, C3, C4, C5, C6, L-SP006, MS34-NS-TA, NS-MS34-BT, NS-MS34-DM basis of the original product VDLRSPKDISP-ASST. The color of appearance and model name of series models listed are different from the main model, but the circuit and the electronic construction are the same, declared by the manufacturer. Sincerely, Name: Mary Chen Title: Manager Company name: Dongguan Unity Win Electronic Tech Co., Limited Address: F501, Building 2, No.30 XinHua Rd, WanJiang Street, Dongguan, Guangdong, China

FCC ID: 2BACV-C-WIRELESS External

Page 1 of 1 Label and Information FCC Label Sample FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location a

FCC ID: 2BACV-C-WIRELESS Internal BT ANT
