User’s Manual: Item MA123 Light the Way LIGHT UP LANTERN Wireless Speaker Important Safety Precautions When using your Lantern Speaker, basic safety precautions should always be followed, including: 1. READ ALL INSTRUCTIONS BEFORE USING YOUR SPEAKER. 2. Clean using a soft cloth or paper towel. Do not use abrasive chemicals to cleans this speaker. 3. This product is not a toy, do not allow children to play with it. Adult supervision is advised. 4. Do not expose your speaker to excessive heat or fire. 5. Do not use in extremely dry environments, as this can lead to static discharge during usage. 6. Do not expose your speaker to temperatures above 100°F. 8. Do not attempt to repair this product yourself. Contact a qualified service center if your speaker is in need of service. 9. Do not drop, puncture or expose the speaker to extreme physical force. 10. Your speaker is not intended for commercial use. 11. Do not place near objects that generate a strong magnetic field. 12. Unplug this device when not in use for long periods of time and during lightning storms. BATTERY WARNING: -The device is equipped with an integrated lithium ion battery. The battery cannot be replaced. Do not attempt to remove the battery from the device. -Do not dispose of in fire or expose to excessive heat. -Do not crush, puncture, incinerate, or short circuit external contacts. -Please recycle or dispose of the battery properly. Contact your local recycling facilities and/or the manufacturer for further information. CAUTION Important Safety Precautions When using your Lantern Speaker, basic safety precautions should always be followed, including: 1. READ ALL INSTRUCTIONS BEFORE USING YOUR SPEAKER. 2. Clean using a soft cloth or paper towel. Do not use abrasive chemicals to cleans this speaker. 3. This product is not a toy, do not allow children to play with it. Adult supervision is advised. 4. Do not expose your speaker to excessive heat or fire. 5. Do not use in extremely dry environments, as this can lead to static discharge during usage. 6. Do not expose your speaker to temperatures above 100°F. 8. Do not attempt to repair this product yourself. Contact a qualified service center if your speaker is in need of service. 9. Do not drop, puncture or expose the speaker to extreme physical force. 10. Your speaker is not intended for commercial use. 11. Do not place near objects that generate a strong magnetic field. 12. Unplug this device when not in use for long periods of time and during lightning storms. Introduction Thank you for purchasing the Light the Way Light Up Lantern Speaker, item MA123. You can connect your speaker with most smartphones and Bluetooth devices to stream music wirelessly while camping, gathering or partying outside. Using the built-in clip, you can attach this speaker for easy travel and set-up. Please read this manual carefully before using the speaker. Package Contents -Light the Way Lantern Speaker -USB Charging Cable -User’s Manual with Warranty Information Specifications Bluetooth Specification: V5.1 Bluetooth Range: Up to 33 feet (10 meters) Battery Type: 1200mAh Lithium Ion Battery Play Time (Music only): 20 Hours** Play Time (Music and Lights): 7 Hours** Play Time (Lights Only): 11 Hours **Applicable at 50% of maximum volume. Results will be lower when volume is higher. Charging Your Speaker Charging = (red) Charging Complete = (off) NOTES: --When battery power is running low, your speaker will emit a beeping sound. Recharge your speaker’s battery when you hear this sound. --Remove the charging cable once charging is complete. --Overcharging could reduce the life of the battery. --A charged battery will lose its capacity if it is not used on a regular basis. --Make sure the rubber battery compartment seal is securely closed once charging is complete and before use. Important: To avoid a complete discharge of the battery, charge your speaker at least once every six months. 1. The USB charging cable has a Micro USB plug and a standard USB plug. 2. Lift the rubber flap and insert the USB charging cable’s Micro USB plug into the speaker’s charging port. Micro USB Plug USB Plug 3. Insert the USB charging cable’s standard USB plug into the USB port of a computer or suitable 5V 1A USB charging adapter. 4. The LED Indicator Light behind the speaker’s charging port will turn red when the speaker is charging and will turn off when charging is complete. + ˗ DC5V Charging Your Speaker + ˗ DC5V The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Sakar International is under license. Other trademarks and trade names are those of their respective owners. Bluetooth Pairing 1. Press and hold the Power button for three to four seconds to turn the speaker On. 3. On your phone, go into the Bluetooth page in the Settings app. Make sure Bluetooth is turned on before connecting to the available device ‘MA123’. 2. The LED Indicator Light behind the charging port will flash blue indicating your speaker is in pairing mode. 2 to 3 SECONDS MA123 PRESS & HOLD 4. The LED Indicator Light behind the charging port will turn solid blue indicating your speaker and phone are paired. The LED Indicator Light will slowly flash blue when music is playing. Pairing Mode Blue Flashing LED Lights Pairing Mode Blue Flashing LED Lights + ˗ DC5V Bluetooth Pairing + ˗ DC5V + ˗ DC5V Using Your Speaker Music Control: Power Button: Press to pause and play music. Press to answer and end a phone call and press twice to decline an incoming call. + Button:Short press to increase the volume. Press and hold to the next track. Short press to decrease the volume. Press and hold to the previous track.-- Button: Light Control: Press the light button to toggle through the four light modes: Natural Flames, Dim White Light, Bright White Light, and SOS Lights. True Wireless Pairing: This feature is if you own two MA123 Margaritaville Light the Way Lantern Speakers. Before pairing …
