2BAF2-R801Carplay Android Box

Android Box Model: R801 Get Strated Supported 2.4G BT&WIFI, 5G WIFI&LTE Communication Input: DC 5V1A ①SIM card slot：For individual network ②TF card slot：Up to 256G expansion card ③LED Light：system status indicator ④Type-C Port：connect and plug into original display system USB ⑤HDMI Port: connect HDMI expansion screen or TV (Optional) 1. Getting to Know Before Using The product is suitable for display system which built-in OEM wired Android Box, it can upgrade wired Android Box to Android system, and supports iPhone to wireless Android Box and Android Phone to wireless Android Auto. 2. INITIAL CONNECTION (1) Plug and play, insert the Sim card and TF card into the Sim card, and then use the Type-c cable to connect the Android Box AI Box and the display system (2) Observe the indicator light, if the red light turns blue and flashes, it is a normal connection (3)Wait for the boot animation to finish playing and enter the display system ai box system 3. Function Instructions (1) Product Settings It has a modern design concept, long press the function key, you can perform simple and convenient personalized settings, from screens, themes to widgets. (2) Application management This product can download the application online through the google play store or APK Pure, and can also insert the TF card to install the APK through APK Manger. When you want to uninstall the app, you can also do it in APK Manger. (3) Wireless Android Box connection . 3.1 Enter the "Android Box" application 3.2 Turn on iPhone's Wifi and Bluetooth 3.3 Pair the device, and then enter the wireless Android Box interface. (4) Wireless Android Auto connection 4.1. Enter the "Android Auto" application 4.2. Turn on android phone's Wifi and Bluetooth 4.3. Pair the device, and then enter the wireless Android Auto interface. 4.5. Cast your phone screen to your display system. Just connect the box to your phone's hotspot, or connect your phone and box to the same network. (5) Super CAST Cast your phone screen to your display system. Just connect the box to your phone's hotspot, or connect your phone and box to the same network. Application Screen casting Enter the "Cast" application, open the app on the mobile phone to play the video, select the screen casting icon, select the device name, and complete the screen casting. Screen Mirroring for iPhone Enter the "CAST" application, turn on the screen mirroring function on the iPhone, select the device name, and complete the mirroring (6) Support HDMI Use the Type-C cable to provide power to the box, and then use the HDMI cable to connect the box and the monitor. After entering the interface, use the wireless Bluetooth remote control to connect to WIFI to play audio and video. (7) TF card file management Enter the "Files" application, select "TF Card", choose to play music, video or view pictures (8) DIY Animation Enter the settings, select "Startup Animation", select "Replace", select the video to be replaced, and wait for the replacement boot animation to complete. (9) Upload Log Enter the settings, select "system settings", select "General settings", select "Log upload", and wait for the successful upload. (10) OTA upgrade Enter the settings, select "system settings"-"General settings"-"Version Information"-"Check for updates" (11) Wireless bluetooth remote control Use the bluetooth remote control to aim at the ai box, press the pairing button, and it can be used after the pairing is successful. (12) 4G network hotspot sharing Enter the settings, select " Hotspot", select "ON" to enable the hotspot network function 4. How to report an issue (1). Provide SN code information Enter settings, "system setting" select "About the unit" (2). Provide the version number Enter Settings, "system settings" select "Version Information" (3). After the box is connected to the network, upload the Log 5. This device is a client product FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. 2.Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequence energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an autlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. This equipment should be installed and operated with a minumum distance of 20 cm between the radiator and your body.

Shenzhen Fusion Aurora Technology Co., Ltd 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen Fusion Aurora Technology Co., Ltd Address: L25, 4th Floor, Lianhui Building, Longhua Street, Longhua District, Shenzhen Product Name: Carplay Android Box FCC ID: 2BAF2-R801 Model(s): R801, R802, R803, R805, R806, R811, R812, R813, R815, R816 2.911(d)(5)(i) Equipment Type We, Shenzhen Fusion Aurora Technology Co., Ltd (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Rex Song Date: 2023-06-12 Title: / Company name: Shenzhen Fusion Aurora Technology Co., Ltd NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Fusion Aurora Technology Co., Ltd 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen Fusion Aurora Technology Co., Ltd Address: L25, 4th Floor, Lianhui Building, Longhua Street, Longhua District, Shenzhen Product Name: Carplay Android Box FCC ID: 2BAF2-R801 Model(s): R801, R802, R803, R805, R806, R811, R812, R813, R815, R816 2.911(d)(5)(ii) Applicant filing We, [Shenzhen Fusion Aurora Technology Co., Ltd] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Rex Song Date: 2023-06-12 Title and Company name: / Shenzhen Fusion Aurora Technology Co., Ltd NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Fusion Aurora Technology Co., Ltd U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: Jun-11-2023 Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID: 2BAF2-R801 Shenzhen Fusion Aurora Technology Co., Ltd (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC(“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. THREE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: Shenzhen Fusion Aurora Technology Co., Ltd Address: L25, 4th Floor, Lianhui Building, Longhua Street, Longhua District, Shenzhen Signature: Contact Person: Rex Song Tel: +86-15999576346 Email: [email protected]

Shenzhen Fusion Aurora Technology Co., Ltd Agent Authorization Company: Shenzhen Fusion Aurora Technology Co., Ltd Address: L25, 4th Floor, Lianhui Building, Longhua Street, Longhua District, Shenzhen Product Name: Carplay Android Box Model Number(s): R801, R802, R803, R805, R806, R811, R812, R813, R815, R816 Product Description: Carplay Android Box We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023-06-14 Name: Rex Song Title: / Company: Shenzhen Fusion Aurora Technology Co., LtdI

Difference Description We Shenzhen Fusion Aurora Technology Co., Ltd state: Product name: Carplay Android Box Model: R801, R802, R803, R805, R806, R811, R812, R813, R815, R816 All model’s the function, software and electric circuit are the same. the model name is different. Signature: Signature: Date: 2023-06-14 Name: Rex Song Title: / Company: Shenzhen Fusion Aurora Technology Co., Ltd

Shenzhen Fusion Aurora Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-06-14 Subject; Request for Long Term Confidentiality FCC ID: 2BAF2-R801 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram BOM Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Rex Song Title: /

Appendix II external photos ------End------

Product: Carplay Android Box Model: R801, Input: DC 5V FCC ID: 2BAF2-R801 Made In China

AppendixIIIinternalphotos Wifi&BT ANT 4GMainANT 4G Diversity antenna ------End------

RF EXPOSURE EVALUATION EUT Specification EUT Android Box Model Number R801, R802, R803, R805, R806, R811, R812, R813, R815, R816 FCC ID 2BAF2-R801 Antenna gain (Max) 2.4GWIFI ：1.37 dBi BT/BLE ：1.51 dBi 5GWIFI ：1.45dBi LTE Band 2: Maximum Gain is 0.69dBi. LTE Band 4: Maximum Gain is 0.62dBi. LTE Band 5: Maximum Gain is 0.58dBi. LTE Band 7: Maximum Gain is 1.1dBi. LTE Band 12: Maximum Gain is 0.7dBi. LTE Band 17: Maximum Gain is 0.7dBi. LTE Band 38: Maximum Gain is 1.1dBi. LTE Band 41: Maximum Gain is 1.1dBi. Operation Frequency BT/BLE:2402-2480MHz 2.4GWIFI:2412-2462MHz 5GWIFI: 5180~5240MHz; 5260-5320MHz; 5500-5700MHz; 5745~5825MHz: 5190~5230MHz; 5260-5320MHz; 5510-5670MHz; 5755~5795MHz,5210MHz, 5290MHz, 5530MHz, 5775MHz LTE Band 2: 1850 ~ 1910 MHz LTE Band 4: 1710 ~ 1755 MHz LTE Band 5: 824 ~ 849 MHz LTE Band 7: 2500 ~ 2570 MHz LTE Band 12: 699MHz ~ 716MHz LTE Band 17: 704 MHz ~ 716 MHz LTE Band 38: 2570 MHz ~ 2620 MHz LTE Band 41: 2555MHz ~ 2655MHz Input Rating DC 5V from adapter Max. output power LTE B2: 24.97dBm, LTE B4: 24.95 dBm LTE B5: 24.87dBm, LTE B7: 24.89dBm LTE B12: 24.88dBm, LTE B17: 24.80dBm LTE B38: 24.21dBm, LTE B41: 24.38dBm EDR: 3.53 dBm, BLE: 3.5 dBm 5GHz WiFi: Band 1: 16.78dBm, Band 2: 16.86dBm Band 3: 16.79dBm, Band 4: 16.80dBm 2.4GHz WiFi: b:13.83dBm, g:13.40dBm, n20:13.65dBm, n40:13.58dBm Test Requirement: According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm=20cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 Measurement Result Mode Frequency range(MHz) Max measu red power (dBm) Tune- up power (dBm) Max tune-up power (dBm) Antenna Gain (Nume ric) Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) EDR 2402-2480 3.53 3±1 4 1.416 0.000708 1 BLE 2402-2480 3.5 3±1 4 1.416 0.000708 1 2.4GWIFI 2412-2462 13.83 14±1 15 1.371 0.008629 1 2412-2462 13.40 13±1 14 1.371 0.006854 1 2412-2462 13.65 14±1 15 1.371 0.008629 1 2422-2452 13.58 13±1 14 1.371 0.006854 1 5G WIFI B1(5150-5250) 16.78 17±1 18 1.396 0.017537 1 B2(5250-5350) 16.86 17±1 18 1.396 0.017537 1 1 B3(5470-5725) 6.79 17±1 18 1.396 0.017537 1 1 B4(5725-5850) 6.80 17±1 18 1.396 0.017537 1 LTE B2 (1850-1910) 24.97 25±1 26 1.172 0.092886 1 B4 (1710-1755) 24.95 25±1 26 1.153 0.091401 1 B5(824-849) 24.87 25±1 26 1.143 0.090563 0.5493 B7(2500-2570) 24.89 25±1 26 1.288 0.102082 1 B12 (699-716) 24.88 25±1 26 1.175 0.093100 0.4660 B17 (704-716) 24.80 25±1 26 1.175 0.093100 0.4733 B38 (2570-2620) 24.21 24±1 25 1.288 0.081087 1 B41 (2555-2655) 24.38 24±1 25 1.288 0.081087 1 Maximum Simultaneous transmission MPE Ratios for 2.4GWIFI+LTE: Max MPE ratio WIFI Max MPE Ratio LTE ∑ MPE ratios Limit Result 0.008629 0.102082 0.110711 1 Pass MPE= Limit of Power Density (S) (mW/cm2)/ Limit of Power Density (S) (mW/cm2) ratios Maximum Simultaneous transmission MPE Ratios for 5GWIFI+LTE: Max MPE ratio WIFI Max MPE Ratio LTE ∑ MPE ratios Limit Result 0.017537 0.102082 0.119619 1 Pass MPE= Limit of Power Density (S) (mW/cm2)/ Limit of Power Density (S) (mW/cm2) ratios Maximum Simultaneous transmission MPE Ratios for BT+LTE: Max MPE ratio WIFI Max MPE Ratio LTE ∑ MPE ratios Limit Result 0.000708 0.102082 0.10279 1 Pass MPE= Limit of Power Density (S) (mW/cm2)/ Limit of Power Density (S) (mW/cm2) ratios Signature: Stone Tang Date: 2023-06- 12

Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 1 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China RF Test Report For Applicant Name: Shenzhen Fusion Aurora Technology Co., Ltd Address: L25, 4th Floor, Lianhui Building, Longhua Street, Longhua District, Shenzhen EUT Name: Carplay Android Box Brand Name: N/A Model Number: R801, R802, R803, R805, R806, R811, R812, R813, R815, R816 Series Model Number: Refer to section 2 Issued By Company Name: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Report Number: BTF230612R00302 Test Standards: 47 CFR Part 15.247 Test Conclusion: Pass FCC ID: 2BAF2-R801 Test Date: 2023-05-20 to 2023-05-30 Date of Issue: 2023-06-12 Prepared By: elma.yang / Project Engineer Date: 2023-06-12 Approved By: Ryan.CJ / EMC Manager Date: 2023-06-12 Note: All the test results in this report only related to the testing samples. Which can be duplicated completely for the legal use with approval of applicant; it shall not be reproduced except in full without the written approval of BTF Testing Lab (Shenzhen) Co., Ltd., All the objections should be raised within thirty days from the date of issue. To validate the report, you can contact us. Test Report Number: BTF230612R00302 Page 2 / 79 TIRT-TRF/FCC01-2(E):2021A0 Revision History Version Issue Date Revisions Content R_V0 2023-06-12 Original Note: Once the revision has been made, then previous versions reports are invalid. Test Report Number: BTF230612R00302 Page 3 / 79 TIRT-TRF/FCC01-2(E):2021A0 TABLE OF CONTENTS Description Page 1. SUMMARY OF STANDARDS AND RESULTS -------------------------------------------------------------------- 5 1.1. Description of Standards and Results -------------------------------------------------------------------- 5 2. GENERAL INFORMATION ---------------------------------------------------------------------------------------------- 6 2.1. Description of Device (EUT) ----------------------------------------------------------------------------------- 6 2.2. Accessories of Device (EUT) --------------------------------------------------------------------------------- 7 2.3. Tested Supporting System Details ------------------------------------------------------------------------- 7 2.4. Block Diagram of connection between EUT and simulators ------------------------------------- 7 2.5. Test Mode Description ------------------------------------------------------------------------------------------ 7 2.6. Test Conditions ---------------------------------------------------------------------------------------------------- 8 2.7. Test Facility ---------------------------------------------------------------------------------------------------------- 8 2.8. Measurement Uncertainty-------------------------------------------------------------------------------------- 8 2.9. Test Equipment List ---------------------------------------------------------------------------------------------- 8 3. MAXIMUM PEAK OUTPUT POWER ------------------------------------------------------------------------------- 14 3.1. Limit ------------------------------------------------------------------------------------------------------------------ 14 3.2. Test Procedure --------------------------------------------------------------------------------------------------- 14 3.3. Test Setup ---------------------------------------------------------------------------------------------------------- 14 3.4. Test Result --------------------------------------------------------------------------------------------------------- 14 4. BANDWIDTH --------------------------------------------------------------------------------------------------------------- 15 4.1. Limit ------------------------------------------------------------------------------------------------------------------ 15 4.2. Test Procedure --------------------------------------------------------------------------------------------------- 15 4.3. Test Result --------------------------------------------------------------------------------------------------------- 15 5. CARRIER FREQUENCY SEPARATION--------------------------------------------------------------------------- 25 5.1. Limit ------------------------------------------------------------------------------------------------------------------ 25 5.2. Test Procedure --------------------------------------------------------------------------------------------------- 25 5.3. Test Result --------------------------------------------------------------------------------------------------------- 25 6. NUMBER OF HOPPING CHANNEL -------------------------------------------------------------------------------- 28 6.1. Limit ------------------------------------------------------------------------------------------------------------------ 28 6.2. Test Procedure --------------------------------------------------------------------------------------------------- 28 6.3. Test Result --------------------------------------------------------------------------------------------------------- 28 7. DWELL TIME --------------------------------------------------------------------------------------------------------------- 30 7.1. Test limit ------------------------------------------------------------------------------------------------------------ 30 7.2. Test Procedure --------------------------------------------------------------------------------------------------- 30 7.3. Test Result --------------------------------------------------------------------------------------------------------- 30 8. RADIATED EMISSIONS ------------------------------------------------------------------------------------------------ 47 8.1. Limit ------------------------------…

Text truncated - open the document above for the full version.

Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 41 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report Dwell NVNT 2-DH5 2441MHz Ant1 One Burst Dwell NVNT 2-DH5 2441MHz Ant1 Accumulated Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 42 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report Dwell NVNT 3-DH1 2402MHz Ant1 One Burst Dwell NVNT 3-DH1 2402MHz Ant1 Accumulated Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 43 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report Dwell NVNT 3-DH1 2441MHz Ant1 One Burst Dwell NVNT 3-DH1 2441MHz Ant1 Accumulated Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 44 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report Dwell NVNT 3-DH1 2480MHz Ant1 One Burst Dwell NVNT 3-DH1 2480MHz Ant1 Accumulated Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 45 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report Dwell NVNT 3-DH3 2441MHz Ant1 One Burst Dwell NVNT 3-DH3 2441MHz Ant1 Accumulated Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 46 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report Dwell NVNT 3-DH5 2441MHz Ant1 One Burst Dwell NVNT 3-DH5 2441MHz Ant1 Accumulated Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 47 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report 8. RADIATED EMISSIONS 8.1. Limit All the emissions appearing within 15.205 restricted frequency bands shall not exceed the limits shown in 15.209, all the other emissions shall be at least 20dB below the fundamental emissions, or comply with 15.209 limits. 15.205 Restricted frequency band 15.209 Limit FREQUENCY MHz DISTANCE Meters FIELD STRENGTHS LIMIT V/m dB(V)/m 0.009-0.490 300 2400/F(KHz) / Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 48 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report 0.490-1.705 30 24000/F(KHz) / 1.705-30 30 30 29.5 30 ~ 88 3 100 40.0 88 ~ 216 3 150 43.5 216 ~ 960 3 200 46.0 960 ~ 1000 3 500 54.0 Above 1000 3 74.0 dB(V)/m (Peak) 54.0 dB(V)/m (Average) 8.2. Block Diagram of Test setup 8.2.1 In 3m Anechoic Chamber Test Setup Diagram for below 30MHz 8.2.1 In 3m Anechoic Chamber Test Setup Diagram for below 1GHz Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 49 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report 8.2.2 In 3m Anechoic Chamber Test Setup Diagram for frequency above 1GHz Note: For harmonic emissions test a appropriate high pass filter was inserted in the input port of AMP. 8.3. Test Procedure (1) EUT was placed on a non-metallic table, 80 cm above the ground plane inside a semi-anechoic chamber. (2) Setup EUT and simulator as shown in section 1.4 and 6.1 (3) Test antenna was located 3m from the EUT on an adjustable mast. Below pre-scan procedure was first performed in order to find prominent radiated emissions. (a) Change work frequency or channel of device if practicable. (b) Change modulation type of device if practicable. (c) Rotated EUT though three orthogonal axes to determine the attitude of EUT arrangement produces highest emissions (4) Spectrum frequency from 9KHz to 25GHz (tenth harmonic of fundamental frequency) was investigated (5) For final emissions measurements at each frequency of interest, the EUT were rotated and the antenna height was varied between 1m and 4m in order to maximize the emission. Measurements in both horizontal and vertical polarities were made and the data was recorded. In order to find the maximum emission, the relative positions of equipments and all of the interface cables were changed according to ANSI Test Report Number: BTF230612R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 50 of 79 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China EMC Test Report C63.10:2013on Radiated Emission test. (6) For emissions above 1GHz, both Peak and Average level were measured with Spectrum Analyzer, and the RBW…

Text truncated - open the document above for the full version.

Technical Specification Band Mode Name Frequency Antenna Type Antenna Max Gain LTE Band Band-02 1900 FDD PCS 1850-1990 Internal ANT 0.69 dBi Band-04 1700/2100 FDD AWS 1710-2155 0.62 Band-05 850 FDD CLR 824-894 0.58 Band-07 2600 FDD IMT-E 2500-2690 1.1 Band-12 700 FDD LSMH 699-746 0.7 Band-17 700 FDD LSMH 704-746 0.7 Band-38 2600 TDD IMT-E 2570-2620 1.1 Band-41 2500 TDD BRS 2555-2655 1.1 WiFi 802.11b/g/n 2.4GHz Wi-Fi 4 2401-2495 Internal ANT 1.37 dBi 802.11a/n/ac 5GHz Wi-Fi 5/6 4910-5895 1.45 BT Bluetooth 2400-2500 Internal ANT 1.51 dBi Technical Specification ANT SIZE 5GWIFI LTE 2.4GWIFI&BT GPS Technical Specification MAIN 3-D Patten Plots Main: 600Mhz Main: 700Mhz Main: 800Mhz Main: 900Mhz Main: 1700Mhz Main: 1900Mhz Main: 2100Mhz Main: 2400Mhz Main: 2600Mhz Main: 2700Mhz Technical Specification GWB 3-D Patten Plots GPS: 1570Mhz BT: 2420Mhz BT: 2450Mhz BT: 2480Mhz Technical Specification WIFI6 3-D Patten Plots WIFI: 2420Mhz WIFI: 2450Mhz WIFI: 2480Mhz WIFI: 5500Mhz

Conducted Emission at AC power line Emissi…

Text truncated - open the document above for the full version.
