1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: TRANS-PAC CHINA LLC FRN: 0033505975 Contact Name: Lisa Lee Address: 3715 S 182nd Street, C120 Seatac, WA 98188-9993 US Telephone No: +1 (818) 818-0538 Email: [email protected] Applicant: Company name: Imagine Marketing Ltd. Product Description: Airdopes 141 Grantee code: 2BARQ FCC ID: 2BARQ-AD141 Contact Name: abhinav pandey Address: E Wing, 2nd Floor, Corporate Avenue AG Road, Opp. Satellite Gazebo Andheri East, Mumbai, 400093, India Telephone No: 0769-85421455 Email: [email protected] [Imagine Marketing Ltd.] certifies that, as of the date of this filing of the application with the TCB, [TRANS-PAC CHINA LLC] is our designated US agent for service of process for the above referenced FCC ID. [Imagine Marketing Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [TRANS-PAC CHINA LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911.

C5266091_X24_Ed.1 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Imagine Marketing Ltd. Grantee code: 2BARQ FCC ID: 2BARQ-AD141 Contact Name: abhinav pandey Address: E Wing, 2nd Floor, Corporate Avenue AG Road, Opp. Satellite Gazebo Andheri East, Mumbai, 400093, India Telephone No: 0769-85421455 Fax No: Email: [email protected] i. [Imagine Marketing Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Imagine Marketing Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Date: 4.10.2023 Applicant’s Name: abhinav pandey Title: CEO Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Imagine Marketing Ltd. Product Similarity Declaration Product name: Airdopes 141 Model name: Airdopes 141, Airdopes 141R, Airdopes 141RTL, Airdopes 141F, Airdopes 143, Airdopes 148, Airdopes 141v2 FCC ID: 2BARQ-AD141 We (Imagine Marketing Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name. Demonstrate the detail(descriptions and pictures) as to the difference list above. Signature: Name: abhinav pandey Title: CEO Date: 4.10.2023

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Imagine Marketing Ltd. Address: E Wing, 2nd Floor, Corporate Avenue AG Road, Opp. Satellite Gazebo Andheri East, Mumbai, 400093, India Product Name: Airdopes 141 Model Number: Airdopes 141, Airdopes 141R, Airdopes 141RTL, Airdopes 141F, Airdopes 143, Airdopes 148, Airdopes 141v2 FCC Identifier: 2BARQ-AD141 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: abhinav pandey Date: 4/10/2023 Title: CEO Signature of applicant:

C5266091_X10_Ed.1 1/1 Imagine Marketing Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 4/10/2023 Subject: Request for Confidentiality FCC ID: 2BARQ-AD141 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: abhinav pandey Date: 4/10/2023 Title: CEO

Page 1 of 4 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: Airdopes 141 Page 2 of 4 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 4 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 4 of 4 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report----

Label Location

Imagine Marketing Ltd. version02 4/10/2023 Dear Sirs: We hereby declare that because the earphone size is too small, the FCC ID number is printed on the User Manual, hereby declare. FCC ID: 2BARQ-AD141 Sincerely, Signature: Name: abhinav pandey Title: CEO Company: Imagine Marketing Ltd.

Page 1 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: Airdopes 141 Page 2 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ANT Page 3 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report----

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] RF EXPOSURE Test Report Report No.: MTi230224016-05E2 Date of issue: 2023-03-20 Applicant: Imagine Marketing Ltd. Product: Airdopes 141 Model(s): Airdopes 141, Airdopes 141R, Airdopes 141RTL, Airdopes 141F, Airdopes 143, Airdopes 148, Airdopes 141v2 FCC ID: 2BARQ-AD141 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 6- Report No.: MTi230224016-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 6- Report No.: MTi230224016-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Applicant: Imagine Marketing Ltd. Address: E Wing, 2nd Floor, Corporate Avenue AG Road, Opp. Satellite Gazebo Andheri East, Mumbai, 400093, India Manufacturer: KVANCE TECHNOLOGY CO., LTD Address: 4 floor, Building A, No. 103, Baonan Road, Longgang District, Shenzhen, Guangdong, China, 518116 Product description Product name: Airdopes 141 Trademark: boAt Model name: Airdopes 141 Serial Model: Airdopes 141R, Airdopes 141RTL, Airdopes 141F, Airdopes 143, Airdopes 148, Airdopes 141v2 Standards: N/A Test method: KDB 447498 D01 v06 Date of Test Date of test: 2023-03-14 ~ 2023-03-20 Test result: Pass Test Engineer : (Letter Lan) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) - Page 4 of 6- Report No.: MTi230224016-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of Contents 1. STANDALONE SAR TEST EXCLUSION CONSIDERATIONS ............................................................................................ 5 2. SAR TEST EXCLUCSION THRESHOLDS ........................................................................................................................ 6 - Page 5 of 6- Report No.: MTi230224016-05E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] 1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f (GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. b) For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following (also illustrated in Appendix B): 1) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·(f(MHz)/1…

Text truncated - open the document above for the full version.

Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230224016-05E1 Date of issue: 2023-03-20 Applicant: Imagine Marketing Ltd. Product: Airdopes 141 Model(s): Airdopes 141, Airdopes 141R, Airdopes 141RTL, Airdopes 141F, Airdopes 143, Airdopes 148, Airdopes 141v2 FCC ID: 2BARQ-AD141 Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 61 Report No.: MTi230224016-05E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 61 Report No.: MTi230224016-05E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 5 1.3 Test conditions .................................................................................................................................................... 7 1.4 Description of support units ................................................................................................................................ 7 2 Measurement uncertainty ............................................................................................................... 8 3 Summary of Test Result .................................................................................................................. 9 4 Test Laboratory ............................................................................................................................. 10 5 Equipment List .............................................................................................................................. 11 6 Test Result ..................................................................................................................................... 12 6.1 Antenna requirement ........................................................................................................................................ 12 6.2 AC power line conducted emissions................................................................................................................. 13 6.3 Radiated spurious emission ............................................................................................................................. 14 6.4 20dB emission bandwidth ................................................................................................................................ 28 6.5 Maximum conducted output power .................................................................................................................. 29 6.6 Carrier frequency separation ............................................................................................................................ 30 6.7 Time of occupancy............................................................................................................................................ 31 6.8 Number of hopping channels ........................................................................................................................... 32 6.9 Band edge (Conducted) ................................................................................................................................... 33 6.10 Conducted spurious emissions ...................................................................................................................... 34 Appendix A: 20dB Emission Bandwidth ............................................................................................. 35 Appendix B: Maximum conducted output power ............................................................................... 38 Appendix C: Carrier frequency separation ......................................................................................... 42 Appendix D: Time of occupancy ......................................................................................................... 44 Appendix E: Number of hopping channels......................................................................................... 47 Appendix F: Band edge measurements .............................................................................................. 49 Appendix G: Conducted Spurious Emission ...................................................................................... 53 Photographs of the Test Setup ............................................................................................................ 60 Photographs of the EUT....................................................................................................................... 61 Page 4 of 61 Report No.: MTi23022401…

Text truncated - open the document above for the full version.

5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 1 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com Product Name: WiFi/Bluetooth Chip Antenna – CW201 Part Number: H2U34C1H1B0100 Features: zSupporting WiFi/Bluetooth, covering 2400 to 2484 MHz zSurface Mount zDimensions: 2.0 x 1.2 x 0.6 mm zHigh performance, small size. zRoHS & REACH Compliant Applications: zISM 2.4 GHz applications zZigBee/BLE applications zBluetooth earphone systems zHand-held devices when WiFi / Bluetooth functions are needed, e.g., Smart phones zIEEE802.11 b/g/n zWireless PCMCIA cards or USB dongles e ded, e.g., 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 2 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com WiFi/Bluetooth Chip Antenna MODEL: CW201 Version: A I. Specifications: Mechanical Specifications Dimensions (mm) 2.0(L) x 1.2 (W) x 0.6 (H) Material Ceramic Termination Ag (environmental Pb free) Environmental Conditions Operation Temperature ( o C)-40 ~ +85 Storage Temperature ( o C)-5 ~ +40 Relative Humidity 10 ~ 70 % Items Specifications Frequencies (MHz) 2400~2484 Efficiency (%) 59.2 Average Gain (dB) -2.3 Peak Gain (dBi) 1.9 Test Condition 40 x 20 mm² (Evaluation board) Impedance (ƻ)50 Polarization Linear Polarization 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 3 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com II. Layout Guide: Solder Land Pattern: The solder land pattern (gold marking areas) is shown below. Recommendation on matching circuit will be provided according to customer’s installation conditions. Grounding Pin Signal Input Transmission Line with 50ƻ Impedance Characteristic To p V ie w Bottom View 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 4 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com III. Mechanical Dimensions: a)Antenna Dimensions b) PIN Definition PIN 12 Soldering PadSignal Input Tuning/Signal Output TOP View Bottom View Side View Unit: mm Unit: mm 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 5 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com c) Test Board with Antenna Unit: mm 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 6 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com IV. Properties: a) Return loss (dB) b) Efficiency (%) 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 7 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com c) Average Gain (dB) d) Peak Gain (dBi) 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 8 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com V. Antenna Radiation Pattern Measurement: The antenna radiation patterns are measured in Unictron’s 3D Anechoic Chamber. The measurement setup is as show below. Z Y X 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 9 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com 3D Radiation Gain Pattern 2450 MHz (unit: dBi) X Y Z 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 10 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com VI. Frequency tuning: System Matching Circuit Component Location Description Vendor Tolerance 1N/C-- 25.0 pF (0402)MURATA ±0.05 pF 30.8 pF (0402)MURATA ±0.05 pF 42.7 pF (0201)MURATA ±0.05 pF DC Block 22 pF (0402) MURATA ±5% 13 2 DC Block 4 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 11 © Unictron Technologies Corp. All specifications subject to change without notice. www.sanav.com www.unictron.com VII. Soldering conditions: Typical Soldering Profile for Lead-free Process VIII.Reminders for use of Unictron’s ceramic chip antennas: a)This chip antenna is made of ceramic materials which is relatively more rigid and brittle compared to circuit board materials. Furthermore, the length of this antenna is quite long. Bending of circuit board at the locations where chip antenna is mounted may cause the cracking of solder joints or antenna itself. b)Punching/cutting of the break-off tab of PCB panel may cause severe bending of the circuit board which may result in cracking of solder joints or chip antenna itself. Therefore break-off tab shall be located away from the installation site of chip antenna. c)Be cautious when ultrasonic welding process needs to be used near the locations where chip antennas are installed. Strong ultrasonic vibration may cause the cracking of chip antenna solder joints. ntennantenna iif titi e locations e locations th he t ip alll tiitf 5F., No. 83, Kewang Rd., Longtan Dist., Taoyuan City 32556, Taiwan (R.O.C.) Tel: 886-3-4072728焋Fax: 886-3-4072738 焋[email protected] 12 © Unictron Technologies Corp. …

Text truncated - open the document above for the full version.

Page 1 of 1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - Test Setup Photos Model: Airdopes 141 Radiated emissions –Below 1 GHz Radiated emissions –Above 1 GHz ----End of Report----
