2BAW4-AG5PF3TPMS Sensor

Sensata Technologies Inc. Strictly Confidential. © Copyright Sensata Technologies Inc. 2015. All rights reserved. Hard copy is uncontrolled. The World Depends on Sensors and Controls Destination: External Issue: 01 Date: 20/04/2023 Author: Zhao, Tokin AG5PF3 TPMS sensor user manual AG5PF3 TPMS sensor user manual Issue: Date: 01 20/04/2023 Sensata Technologies Inc. Strictly Confidential. © Copyright Sensata Technologies Inc. 2015. All rights reserved. Hard copy is uncontrolled. The World Depends on Sensors and Controls Page 2 of 6 Table of Contents 目录 1. PRODUCTION INTRODUCTION .................................................................................................. 3 1.1 PRODUCT FEATURE ............................................................................................................ 3 1.2 CAUTION ............................................................................................................................ 3 1.3 INSTALLATION TIPS ............................................................................................................ 3 1.4 MONITORING FEATURE ..................................................................................................... 4 2. FCC REGULATORY COMPLIANCE STATEMENTS ......................................................................... 5 3. ISED REGULATORY COMPLIANCE STATEMENTS ........................................................................ 6 Sensata Technologies Inc. Strictly Confidential. © Copyright Sensata Technologies Inc. 2015. All rights reserved. Hard copy is uncontrolled. The World Depends on Sensors and Controls Page 3 of 6 1. Production Introduction 1.1 Product Feature TPMS sensor is used to monitor tyre pressure and temperature data of each tyre. Sensor will transmit RF frames to receiver. Sensor could be activated by LF command or Delta P or motion. 1.2 Caution 1. The tyre’s temperature and pressure will increase while driving. The vehicle should be stopped for colling is there’s a high temp warning and avoid braking problem or tire blowout 2. Driver should stop the vehicle and get off to check the tyre if there’s continue low pressure warning 3. Be aware of tyre blowout when there is low pressure warning 4. The TPM system can effectively monitor tyre pressure and temperature but cannot avoid traffic accident after tyre blowout. Using quality tyre product and correct tyre pressure monitoring is still necessary 5. Be aware of driving safety while checking tyre data on the way of driving 1.3 Installation Tips Sensata Technologies Inc. Strictly Confidential. © Copyright Sensata Technologies Inc. 2015. All rights reserved. Hard copy is uncontrolled. The World Depends on Sensors and Controls Page 4 of 6 1. The sensor will be in sleep mode to save battery life. After mounter onto rim, and inflate the tyre to recommend pressure data(RCP from Car manufacturer), sensor will exit sleep mode and enter into stationary mode. 2. If sensor detects motion, wheel rotates to the threshold which could active sensor( e.g. 25km/h), then sensor will transmit RF frames cyclically. 3. Due to the air expansion and contraction, the tyre pressure and temperature will normally changing all the time while driving 4. There is normal air leakage in every tyre rim, TPM sensor should have no responsibility to keep the tyre pressure unchanged after long time storage or driving 1.4 Monitoring Feature NO Component 1 Enclosure 2 Valve Assembly 3 Screw 4 Battery 5 PCB and antenna 6 Pressure port seal 7 Lid Sensata Technologies Inc. Strictly Confidential. © Copyright Sensata Technologies Inc. 2015. All rights reserved. Hard copy is uncontrolled. The World Depends on Sensors and Controls Page 5 of 6 2. FCC Regulatory Compliance Statements Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. Caution： Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement This equipment complies with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. Sensata Technologies Inc. Strictly Confidential. © Copyright Sensata Technologies Inc. 2015. All rights reserved. Hard copy is uncontrolled. The World Depends on Sensors and Controls Page 6 of 6 3. ISED Regulatory Compliance Statements This device contains licence-exempt transmitter(s)/receiver(s) that comply with …

Text truncated - open the document above for the full version.

Sensata Technologies (Changzhou) Co., Ltd. Sensata Technologies (Changzhou) Co., Ltd. No. 18, Chuangxin Road, Xinbei District, Changzhou City, Jiangsu, China, 213031 Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Apr.17.2023 Attestation Statement according to 2.911(d)(5)(i) and 2.911(d)(5)(ii) FCC ID: 2BAW4-AG5PF3 TO WHOM IT MAY CONCERN: Hereby we certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Further we certify that, as of the date of the filing of the application, Sensata Technologies (Changzhou) Co., Ltd. is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, _______________ (signature & company stamp) Company: Sensata Technologies (Changzhou) Co., Ltd.> FRN: 0033678038 Address: No. 18, Chuangxin Road, Xinbei District, Changzhou City, Jiangsu, China, 213031 Name: Peter Lu Phone: +86-18861139066 Email: [email protected]

Sensata Technologies (Changzhou) Co., Ltd. Sensata Technologies (Changzhou) Co., Ltd. No. 18, Chuangxin Road, Xinbei District, Changzhou City, Jiangsu, China, 213031 Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Apr.17.2023 Attestation Statement according to 2.911(d)(7) FCC ID: 2BAW4-AG5PF3 TO WHOM IT MAY CONCERN: We, Sensata Technologies (Changzhou) Co., Ltd. designate FCC US Agent, LLC, to act as U.S. agent for service of process. FCC US Agent, LLC hereby acknowledges the obligation of the U.S. agent for service of process. Further Sensata Technologies (Changzhou) Co., Ltd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Sincerely (signature & company stamp) (signature & company stamp) FRN: 0033678038 FRN: 0033402884 Company: Sensata Technologies (Changzhou) Co., Ltd. Company: FCC US Agent, LLC Address: No. 18, Chuangxin Road, Xinbei District, Changzhou City, Jiangsu, China, 213031 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Name: Peter Lu Name: Tim Payne Email: [email protected] Email: [email protected] Phone: +86-18861139066 Phone: 708-571-3148

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 <2023.04.17> TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BAW4-AG5PF3 AG5PF3 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos 180 days Internal Photos 180 days Block Diagram Schematics Test Setup Photos 180 days User’s Manual 180 days Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Peter Lu Company: Sensata Technologies (Changzhou) Co., Ltd. Address: No. 18, Chuangxin Road, Xinbei District, Changzhou City, Jiangsu, China, 213031 Phone: 18861139066 Fax: E-Mail: [email protected]

Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23040302-2E01 Page 38 of 46 Appendix C: EUT photograph Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23040302-2E01 Page 39 of 46 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23040302-2E01 Page 40 of 46

1 SPECIFICATION APPLICATION FOR APPROVAL PART NAME : 315 PCB ANTENNA DATE : 2023/4/4 Release : Full release Customer Approval Program Manager R & D director Peter Lu Peter Lu Supplier Approval Program Manager R & D director 郝井强(Jingqiang Hao) 孙高鹤(Gaohe Sun) Company:Tianjin Yingshun Communication Technology Co., Ltd Address: Room 805, Building 2, Fubao Industrial Park, Zhangjiawo Town, Xiqing District, Tianjin Confidential This message contains information that may be confidential and privileged. Unless you are the addressee (or authorized to receive messages for the addressee), you can not use, copy or disclose to any third party or any information contained in the message. If you have received the message in error, please advise the sender by reply e-mail and delete the message. Nothing in this message should be interpreted as a digital or electronic signature that can be used to authenticate a contract or other legal document. Thank you very much. 2 REVISION REV.NO. DATE DESCRIPTION 0 2023/4/4 APPROVAL 3 1. ELECTRICAL SPECIFICATIONS 1-1 FREQUENCY BAND Freq. Band Freq.(MHz) 315 310-320MHz 1-2 IMPEDANCE Nominal Impedance(including matching circuit) : 50 ohms 1-3 MATCHING REQUIREMENTS The matching circuit on the PCB of the handset is according to Figure 1-3. Optimum matching circuit is highly dependent on the handset and thus. Final matching circuit layout and values will be defined when handset is available Figure 1-3 4 3.ENVIRONMENTAL CHARACTERISTICS NO. ITEM TEST CONDITION 1 Normal condition 1.Temperature: 25.1±1°C 2. Humidity: 34%±2% 3. Pressure: 100.9KPa 4. Test equipment Equipment Model No Manufactory Series No ENA vector analyzer E5071C Keysight MY46900684 OTA chamber FT-0024 FEITU FS20200302 5. PACKAGING Antenna is PCB type , packaging with PCB board. 6. APPENDIX All of the specifications are shown as the attached files. Customer No: Sensata Technologies (Changzhou) Co., Ltd. File: 2023/04/04 Test Condition: FREE SPACE Note: VSWR/ReturnLoss/Smith Chart Confirmation: Jing Qiang Hao Engineer: GaoHe Sun 5 Figure 2-1 0.5mm 10.44mm 22.00mm 6 Antenna Test Date 一：Antenna Efficiency&PeakGain Frequency ID 1 Frequency (MHz) 314.9Mhz Efficiency (dBi) -31.51 Gain (dBi) -24.04 Efficiency (%) 0.07 Directivity (dB) 7.48 Peak Gain Position (Theta) 165.00 Peak Gain Position (Phi) 90.00 Efficiency ThetaPol (%) 0.05 Efficiency PhiPol (%) 0.02 Upper Hem. Efficiency (%) 0.03 Lower Hem. Efficiency (%) 0.04 二：Antenna 2D-XZ/YZ/XY 三：Antenna 3D（314.9MHz）

Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23040302-2E01 Page 35 of 46 APPENDIX Appendix A: Test setup photograph Conduction Appendix B: Test setup photograph Radiation Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23040302-2E01 Page 36 of 46 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23040302-2E01 Page 37 of 46
