2BAWSRDG-XXDride4K

We thought about every little detial so you could only focus on your driving. Drive Safe. The dride team What's in the box USB cable Camera bracket & tape Single or Dual lens Trim tool Cable clips Fusebox adapter Installation 1 SIM Insert memory card up to 1 TB. Insert nano SIM card. *In selected models only Apply the tape on the camera bracket. Attach the camera to the camera bracket and gently push it away to lock it in place. 2 3 Place the Dride 4k behind the car mirror. 4 Connect the power cable to the power socket on your Dride 4k. 5 Plug the fusebox adapter and connect it to the fuse box in your car. It might be a good idea to consult with a professional. Battery Ignition Ground Use the trim tool to carefully remove any trim and tidy any remaining wiring with the cable clips. 5 Use the trim tool to carefully remove any trim and tidy any remaining wiring with the cable clips. 6 White LED Recording Yellow LED Powering on/off Red LED An error occurred, open the app for more info 7 To get started, Download the app and follow the instructions Search for “ ” on App store or Google play Scan QR code or Support Visit the Dride Help Center as your resource for tips, troubleshooting and guides on how to get the most out of Dride. .io/help Specification View angle: 140 degree Video Mode: Loop record / Motion Detection Video Format: MP4 Video Encoding: H.264 Or H.265 Video Resolution: Up to 4K 3840X2160@30fps + 1080p@30fps Chipset: Dual – Core ARM cortex [email protected] Camera: Front: IMX415 Internal: SC2322 Front cam Night vision: Sony Starvis In cabin Night vision: Active IR cut GPS: Included Wi-Fi: 2.4Ghz & 5Ghz 802.11a/b/g/n/ac Bluetooth: BLE 4.1 Impact detection (G-Sensor): Included Parking mode: Triggered by Doppler Radar Microphone: Included Speaker: Included Storage: SD Card eMMC Cloud storage: Free unlimited cloud storage for road videos SD Card: Up to 1TB eMMC: 128GB (Optional) Charging interface: USB C Power loss prevention: Supercapacitors Power consumption: Parking mode 50 MAH Wi-Fi version 400 MAH - 500 MAH LTE version 900 MAH - 1000 MAH Power supply: 5 V/ 2 A Storage temperature: -30 o c 100 o c Operating temperature: -20 o c 80 o c FCC Warning Statement 19 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provid ereasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be colocated for operating in conjunction with any other antenna or transmitter. Changes ormodifications notexpressly approved bythe partyresponsible for compliance could void the user’s authority to operate the equipment. This equipmenthasbeentested and foundtocomplywith thelimitsfora Class B digitaldevice, pursuant to Part 15 ofthe FCC Rules. These limits are designed to provid ereasonable protection against harmfulinterference in a residential installation. This equipment generates uses and can radiate radio frequency energyand, ifnot installed and used in accordance with the instructions,may cause harmfulinterference to radio communications. However, there is no guarantee thatinterference willnotoccur in a particularinstallation. Ifthis equipment does cause harmfulinterference to radio ortelevision reception, which can be determined byturning the equipment off and on,the userisencouraged to try to correct the interference byone or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement The ant ennas used for this transmitter must be installed to pro vide a separation dis tance of at leas t 20 cm fr om all persons and must not be colocated for operating in co njunction with any other antenna or transmitter. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

Dride Technology LTD Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Dride Technology LTD Address: Eliyahu Eitan 1, Rishon Letzion, Israel Product Name: Dride4K FCC ID: 2BAWSRDG-XX Model(s): DR4K1-RDG-XX 2.911(d)(5)(i) Equipment Type We, [Dride Technology LTD] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Yossi Neiman Date: Jun. 08, 2023 Title and Company name: CEO; Dride Technology LTD NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the 2.911 (d)(5)(i) Equipment Type Attestation v1.2

Dride Technology LTD Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Dride Technology LTD Address: Eliyahu Eitan 1, Rishon Letzion, Israel Product Name: Dride4K FCC ID: 2BAWSRDG-XX Model(s): DR4K1-RDG-XX 2.911(d)(5)(ii) Applicant filing We, [Dride Technology LTD] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Yossi Neiman Date: Jun. 08, 2023 Title and Company name: CEO; Dride Technology LTD NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the 2.911 (d)(5)(ii) Applicant Attestation v1.2

Dride Technology LTD Section 2.911(d)(7) USA Agent for Service of Process Company name: Dride Technology LTD Address: Eliyahu Eitan 1, Rishon Letzion, Israel Product Name: Dride4K FCC ID : 2BAWSRDG-XX Model(s): DR4K1-RDG-XX 2.911(d)(7) USA Designated Agent for Service of Process We, [Dride Technology LTD] (“the applicant”) designate [Dride Inc .] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. 2.911 (d)(7)USA Agent v1.3 Dride Technology LTD USA Agent Company name: Dride Inc. Address: 2035 Sunset Lake Road, Suite B-2, Newark, Delaware, 19702 FRN: 0033884883 Contact Name: Yossi Neiman Telephone No: +1 (917) 675-5195 Email: [email protected] Applicant Company name: Dride Technology LTD Address: Eliyahu Eitan 1, Rishon Letzion, Israel FCC Grantee Code: 2BAW S Contact Name: Yossi Neiman Telephone No: +972524624657 Email: [email protected] Signature: Title: CEO Signature: Title: CEO Date: 2023/6/8 Date: 2023/6/8 NO TE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/ 02/06/2022-28263/ prot ecting-agai nst-nation al-security-threats-to-the-communications-supply-chai n-through-the 2.911 (d)(7)USA Agent v1.3

< Dride Technolo gy LTD > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date: Jun. 08, 2023 Subject; Request for Long Term Confidentiality FCC ID: 2BAWSRDG-XX To Whom It May Concern, P ursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description SDR Software / Security Info It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Yossi Neiman Title : CEO

Dride Technology LTD Letter of Authorization Company: Dride Technology LTD Address: Eliyahu Eitan 1, Rishon Letzion, Israel Product name: Dride4K Trade name: N/A Model name: DR4K1-RDG-XX FCC Identifier: 2BAWSRDG-XX We authorize MiCOM LabsInc, 575 Boulder Court, Pleasanton, California94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM LabsInc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Yossi Neiman Date: Jun. 08, 2023 Title: CEO Signature of applicant:

Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX

FCC ID LABEL: Label Location: FCC ID: 2BAWSRDG-XX Product Name: Dride4K Model Name: DR4K1-RDG-XX

Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX Model: DR4K1-RDG-XX BLE Antenna Model: DR4K1-RDG-XX 5G WiFi Antenna 24G Radio Antenna Model: DR4K1-RDG-XX 2.4G WIFI Antenna

MPE ESTIMATION FCC ID: 2BAWSRDG-XX 1. Limit for General Population/Uncontrolled Exposures Frequency Power Density(mW/cm2) Averaging Time(minutes) 300MHz-1.5GHz F/1500 30 1.5GHz-100GHz 1.0 30 Note: F= Frequency in MHz 2. Estimation Result 2.4G WiFi: Worst case Mode Max PK Output Power(dBm) Tune Up Power(dBm ) Max Tune Up Power(mW) Antenna Gain(dBi) Antenna Gain (linear) MPE (mW/cm²) Power Density(m W/cm2) Limit Result 11b 2412MHz 14.63 15±1(16) 39.811 0.5 1.122 0.008886 1.0 PASS Note: Note: The estimation distance is 20cm. Note: PK Output power=conducted power. Conducted power see the test report 23032009ER-63. 5G WiFi: Worst case Mode Max PK Output Power(dBm) Tune Up Power(dBm ) Max Tune Up Power(mW) Antenna Gain(dBi) Antenna Gain (linear) MPE (mW/cm²) Power Density(m W/cm2) Limit Result Band 1 13.36 13±1(14) 25.119 -10.49 0.0893 0.000446 1.0 PASS Band 2 12.65 13±1(14) 25.119 -11.51 0.0706 0.000353 1.0 PASS Band 3 13.19 13±1(14) 25.119 -4.35 0.3673 0.001835 1.0 PASS Band 4 13.35 13±1(14) 25.119 -1.01 0.7925 0.003960 1.0 PASS Note: Note: The estimation distance is 20cm. Note: PK Output power=conducted power. Conducted power see the test report 23032009ER-64. BLE: Worst case Mode Reading result (dBμV) EIRP(dBm) Tune Up Power(dBm) Max Tune Up Power (mW) MPE (mW/cm²) Power Density (mW/cm2) Limit Result GFSK 2402MHz 95.85 0.65 1±1(2) 1.585 0.000315 1.0 PASS Note: Note: The estimation distance is 20cm. Note: Reading result see the test report 23032009ER-62. EIRP= Reading result - 95.2 24G: Worst case Mode Reading result (dBμV) EIRP(dBm) Tune Up Power(dBm) Max Tune Up Power (mW) MPE (mW/cm²) Power Density (mW/cm2) Limit Result Radar 108.92 13.72 14±1(15) 31.623 0.006291 1.0 PASS Note: Note: The estimation distance is 20cm. Note: Reading result see the test report 23032009ER-64. EIRP= Reading result - 95.2 The BT, BLE and 2.4GHz WIFI cannot transmit simultaneously. So the worst simultaneous transmitting consideration: The ratio=MPE 2.4G WIFI /Limit +MPE 5G WIFI /Limit+ MPE 24G Radar/ Limit =0.008886/1.00+0.003960/1.00+0.006291/1.00=0.019137＜1.00 ------The End------

Page 1 of 31 Report No.: 23032009ER-61 FCC RADIO TEST REPORT FCC ID: 2BAWSRDG-XX Sample： Dride4K Trade Name： N/A Main Model： DR4K1-RDG-XX Additional Model： N/A Report No.： 23032009ER-61 Prepared for Dride Technology LTD Eliyahu Eitan 1, Rishon Letzion, Israel Prepared by Global United Technology Services Co. Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Page 2 of 31 Report No.: 23032009ER-61 TEST RESULT CERTIFICATION Applicant................................ : Dride Technology LTD Address ................................... : Eliyahu Eitan 1, Rishon Letzion, Israel Manufacturer ......................... : Dride Technology LTD Address ................................... : Eliyahu Eitan 1, Rishon Letzion, Israel Product description Product.................................... : Dride4K Trade Name ............................ : N/A Model Name............................ : DR4K1-RDG-XX Test Methods ......................... : FCC Rules and Regulations Part 15 Subpart C Section 15.249, ANSI C63.10: 2013 This device described above has been tested by Global United Technology Services Co. Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval, this document may be altered or revised by Global United Technology Services Co. Ltd., personnel only, and shall be noted in the revision of the document. Date of Test .......................................... : Date (s) of performance of tests ............ : Mar. 20, 2023 ~ May. 09, 2023 Date of Issue .......................................... : Jul. 13, 2023 Test Result ............................................. : Pass Prepared By: Date: 2023-7-13 Project Engineer Check By: Date: 2023-7-13 Reviewer Page 3 of 31 Report No.: 23032009ER-61 Table of Contents Pages 1 TEST SUMMARY 5 1.1 TEST PROCEDURES AND RESULTS 5 1.2 TEST FACILITY 6 1.3 MEASUREMENT UNCERTAINTY 7 1.4 ENVIRONMENTAL CONDITIONS 7 2 GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 CARRIER FREQUENCY OF CHANNELS 9 2.3 DESCRIPTION OF TEST MODES 9 2.4 TEST SETUP 9 2.5 EQUIPMENT USED IN TESTED SYSTEM 10 2.6 MEASUREMENT INSTRUMENTS LIST 11 3 CONDUCTED EMISSION 12 3.1 TEST LIMIT 12 3.2 TEST SETUP 12 3.3 TEST PROCEDURE 13 3.4 TEST RESULT 13 4 RAD IATED EMISSION 14 4.1 TEST LIMIT 14 4.2 TEST SETUP 15 4.3 TEST PROCEDURE 16 4.4 TEST RESULT 16 5 BAND EDGE 23 5.1 TEST LIMIT 23 5.2 TEST SETUP 23 5.3 MEASUREMENT EQUIPMENT USED 23 5.4 TEST PROCEDURE 23 5.5 TEST RESULT 23 6 20dB BANDWID TH 26 6.1 TEST SETUP (BLOCK DIAGRAM OF CONFIGURATION) 26 6.2 MEASUREMENT EQUIPMENT USED 26 6.3 TEST PROCEDURE 26 6.4 TEST RESULT 26 7 ANTENNA REQUIREMENT 29 Page 4 of 31 Report No.: 23032009ER-61 Table of Contents Pages 8 PHOTO OF TEST 30 Page 5 of 31 Report No.: 23032009ER-61 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS Note: “N/A” denotes test is not applicable in this Test Report. Item FCC Rules Description Of Test Result 1 FCC Part 15.207 Conducted Emission N/A 2 FCC Part 15.209/15.249 Radiated Emission Pass 3 FCC Part 15.249/15.205 Band Edge Pass 4 FCC Part 15.215 20dB Bandwidth Pass 5 FCC Part 15.203 Antenna Requirement Pass Page 6 of 31 Report No.: 23032009ER-61 1.2 TEST FACILITY Test Firm : Global United Technology Services Co. Ltd. Address : No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 The test facility is recognized, certified, or accredited by the following organizations: ● FCC—Registration No.: 381383 Designation Number: CN5029 Global United Technology Services Co., Ltd. Shenzhen EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in files. ● IC —Registration No.: 9079A CAB identifier: CN0091 The 3m Semi-anechoic chamber of Global United Technology Services Co. Ltd. has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing. ● NVLAP (LAB CODE: 600179-0) Global United Technology Services Co. Ltd. is accredited by the National Voluntary Laboratory Accreditation Program (NVLAP). Page 7 of 31 Report No.: 23032009ER-61 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 150kHz 2.96 150kHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 Above 1000MHz 4.13 C. RF Conducted Method: Item Measurement Uncertainty Uncertainty of total RF power, conducted U c = ±0.8 dB Uncertainty of RF power density, conducted U c = ±2.6 dB Uncertainty of spurious emissions, conducted U c = ±2 % Uncertainty of Occupied Channel Bandwidth U c = ±2 % 1.4 ENVIRONMENTAL CONDITIONS During the measurement the environmental conditions were within the listed ranges: NORMAL CONDITIONS EXTREME CONDITIONS Temperature range (°C) 15 - 35 -20 - 50 Relative humidty range 20 % - 75 % 20 % - 75 % Pressure range (kPa) 86 - 106 86 - 106 Note: The Extreme Temperature and Extreme Voltages declared by the manufacturer. Page 8 of 31 Report No.: 23032009ER-61 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product: Dride4K Trade Name: N/A Main Model: DR4K1-RDG-XX Additional Model: N/A Model Difference: N/A FCC ID: 2BAWSRDG-XX Operation Frequency: 2402MHz~2480MHz Number of Channels: 40CH Field Strength of Fundam ental: 95.85dBuV/m Modulation Type: GFSK Antenna Type: Chip Antenna Antenna Gain: 0.5dBi Battery: N/A…

Text truncated - open the document above for the full version.

Page 1 of 25 Report No.: 23032009ER-64 FCC RADIO TEST REPORT FCC ID: 2BAWSRDG-XX Sample： Dride4K Trade Name： N/A Main Model： DR4K1-RDG-XX Additional Model： N/A Report No.： 23032009ER-64 Prepared for Dride Technology LTD Eliyahu Eitan 1, Rishon Letzion, Israel Prepared by Global United Technology Services Co. Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Page 2 of 25 Report No.: 23032009ER-64 TEST RESULT CERTIFICATION Applicant................................ : Dride Technology LTD Address ................................... : Eliyahu Eitan 1, Rishon Letzion, Israel Manufacturer ......................... : Dride Technology LTD Address ................................... : Eliyahu Eitan 1, Rishon Letzion, Israel Product description Product.................................... : Dride4K Trade Name ............................ : N/A Model Name............................ : DR4K1-RDG-XX Test Methods ......................... : FCC Rules and Regulations Part 15 Subpart C Section 15.249, ANSI C63.10: 2013 This device described above has been tested by Shenzhen Accurate Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval, this document may be altered or revised by Global United Technology Services Co. Ltd., personnel only, and shall be noted in the revision of the document. Date of Test .......................................... : Date (s) of performance of tests ............ : Mar. 20, 2023 ~ May. 12, 2023 Date of Issue .......................................... : Jul. 13, 2023 Test Result ............................................. : Pass Prepared By: Date: 2023-7-13 Project Engineer Check By: Date: 2023-7-13 Reviewer Page 3 of 25 Report No.: 23032009ER-64 Table of Contents Page 1 TEST SUMMARY 4 1.1 TEST PROCEDURES AND RESULTS 4 1.2 TEST FACILITY 4 1.3 MEASUREMENT UNCERTAINTY 5 2 GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 CARRIER FREQUENCY OF CHANNELS 7 2.3 TEST MODE 7 2.4 TEST SETUP 7 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 7 2.6 MEASUREMENT INSTRUMENTS LIST 8 3 CONDUCTED EMISSION 10 3.1 TEST LIMIT 10 3.2 TEST SETUP 10 3.3 TEST PROCEDURE 11 3.4 TEST RESULT 11 4 RAD IATED EMISSION 12 4.1 TEST LIMIT 12 4.2 TEST SETUP 13 4.3 TEST PROCEDURE 14 4.4 TEST RESULT 15 5 BAND EDGE 18 5.1 TEST LIMIT 18 5.2 TEST SETUP 18 5.3 TEST PROCEDURE 18 5.4 TEST RESULT 18 6 99%OCCUPIED BANDWID TH&20dB BANDWIDTH 21 6.1 TEST SETUP 21 6.2 TEST PROCEDURE 21 6.4 TEST RESULT 21 7 ANTENNA REQUIREMENT 22 8 PHOTO OF TEST 23 Page 4 of 25 Report No.: 23032009ER-64 1TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS ITEM STANGARD RESULT CONDUCTED EMISSION FCC Part 15.207 Not Applicable RADIATED EMISSION FCC Part 15.209/15.249 COMPLIANT BAND EDGE FCC Part 15.249/15.205 COMPLIANT 20dB BANDWIDTH FCC Part 15.215 COMPLIANT ANTENNA REQUIREMENT FCC Part 15.203 COMPLIANT 1.2 TEST FACILITY Test Firm : Shenzhen Accurate Technology Co., Ltd. Address : 1/F., Building A, Changyuan New Material Port, Science & Industry Park, Nanshan District, Shenzhen, Guangdong, P.R. China. The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: Designation Number: CN1189 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 708358 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 5077A The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 5 of 25 Report No.: 23032009ER-64 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 150kHz 2.96 150kHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 Above 1000MHz 4.13 Page 6 of 25 Report No.: 23032009ER-64 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product: Dride4K Trade Name: N/A Main Model: DR4K1-RDG-XX Additional Model: N/A Model Difference: N/A Frequency Range: 24.05GHz~ 24.25GHz(Radar) Number of Channels: 1CH Modulation Type: FMCW(Radar) Field Strength of Fundamental: 108.92dBuV/m(Peak)@3m Antenna Type: PCB Array antenna Antenna Gain: 3.0dBi Battery: N/A Adapter: N/A Power Source: DC 12-24V from car charger Page 7 of 25 Report No.: 23032009ER-64 2.2 CARRIER FREQUENCY OF CHANNELS Channel List Channel Frequency(GHz) 01 24.09 2.3 TEST MODE The EUT was programmed to be in continuously transmitting mode. Channel List Test Channel Test Frequency (GHz) CH01 24.09 2.4 TEST SETUP Operation of EUT during Radiation testing: Operation of EUT during RF Conducted testing: 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Item Equipment Model No. Cable Length(cm) Remark 1 Dride4K DR4K1-RDG-XX 3m EUT 2 DC power supply -- -- AE Note: 1. The support equipment was authorized by Declaration of Confirmation. 2. All the above equipment/cables were pla…

Text truncated - open the document above for the full version.

2.4GHz Mini Antenna, SMTP/N 2450AT18A100 Detail Specification: Page 1 of 5 *Efficiency based on Johanson's standard evaluation board ±± ±± ±± www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 3.0 2018 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" Part Number 7/9/2018 Avg. Rad Efficiency* Let us help you with the antenna design, optimization, and tuning! 2450AT18A100 2400 - 2500 76% General Specifications Frequency (MHz) 18 months max. -40 to +125°C -40 to +125°C 3000 Return Loss (dB) Impedance Input Power Storage Period Storage Temperature Operating Temperature Reel Quantity 50 Ω 2 Watts max. (CW) Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. e.g. 2450AT18A100(E or S)100% Tin Packing Style Evaluation Board 2450AT18A100-EBSMA (see page 2&3 for details) Bulk (loose) T & R Suffix = E or S Suffix = E P/N Suffix Mechanical Dimensions In L 0.1260.0083.200.2 W 0.0630.0081.600.2 T 0.0511.30+.004/-.008 +0.1/-0.2 a 0.0200.0120.500.3 Terminal Configuration Function FEED NC No. 1 2 mm e.g. 2450AT18A100E e.g. 2450AT18A100SSuffix = S Part Number Explanation Peak Gain (dBi typ.) Average Gain (dBi typ.) 0.5 -0.5 9.5 min. ① ② L W a T Want the layout file? Request it at: www.johansontechnology.com/ask-a-question 2.4GHz Mini Antenna, SMTP/N 2450AT18A100 Detail Specification: Page 2 of 5 JTI P/N for Matching Circuit: Cap (1.0pF): 500R07S1R0BV4T Inductor (2.7nH): L-07C2N7SV6T Inductor (3.9nH): L-07C3N9SV6T www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 3.0 2018 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" 7/9/2018 Mounting Considerations 1: Evaluation Board Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. GND NO GND Units in mm ) ) 13.5mm 6.5mm 39.5mm 6.5mm 50Ω Feed Line Antenna 4mm ) Matching Component JTI P/Ns: L-14C2N7JV4 L-14C2N2JV4 * 2.6 4.2 1.6 1.9 0.4 2.7nH 1.0pF 3.9nH To order a pre-tuned 50Ω EVB with a female SMA connector click here: www.johansontechnology.com/request-a-sample Reference p/n: 2450AT18A100-EBSMA 2.4GHz Mini Antenna, SMTP/N 2450AT18A100 Detail Specification: Page 3 of 5 Return Loss with matching circuit @ +25CVSWR with matching circuit @ +25C and +125C www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 3.0 2018 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" 7/9/2018 Mounting Considerations 1: Typical Electrical Performance (T=25°C) Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. 2.4GHz Mini Antenna, SMT P/N 2450AT18A100 Detail Specification: Page 4 of 5 www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.…
