ComXim intelligent turntable instruction MT320RL40 Electric turntable operating manual ComXim Used for product rotation display 360 degree shooting 3D scanning ① Plug in power supply and turn on the turntable. ②Use the remote control to control the rotation modes, rotation speeds and rotation angles.) ③This Series of electric turntables support 3 rotation modes: continuous, intermittent and left-and-right swing. Product parameters Item No. Voltage Speed（S/Lap）Max Load（Kg） MT200RL20x MT320RL40x MT350RL40x MT400RL40x MT500RL200x NT600RL200x MT800RL300x NT400RL40x 100V – 240vAC 100V – 240vAC 1 00V – 240vAC 1 00V – 240vAC 1 00V – 240vAC 1 00V – 240vAC 1 00V – 240vAC 1 00V – 240vAC 20-68(S/Lap) 25-72(S/Lap) 28-74(S/Lap) 27-76(S/Lap) 34-90(S/Lap) 34-90 (S/Lap) 55-140(S/Lap) 25-72(S/Lap) 20 Kg 40 Kg 40 Kg 40 Kg 200 Kg 200 Kg 300 Kg 40 Kg Copyright reserved by Shenzhen ComXim Technologies Co.,Ltd.2023 www.comxim.com MT Series turntable model maming rules, identification and main characteristics 320 RL L40 MT 200 RL L20 X Series Turntable Sub code Max Load name Model R: Remote control (Kg) code Diameter (cm) 2 International or color Small remote controller instructions Note:ACR2025 buon baery is used to provide power for the remote controller. Copyright reserved by Shenzhen ComXim Technologies Co.,Ltd.2023 www.comxim.com save start / plause speed down speed up clockwise rotation counterclockwise rotation 3 Medium remote controller instructions Copyright reserved by Shenzhen ComXim Technologies Co.,Ltd.2023 www.comxim.com 1.Save:Stor the current settings to the tuentable flash. 3.SIngle rotation:By pressing thebutton in this group ,the turntable rotaes only ince.If you press the 0.1 or 0.5,just rotate 0.1 degrees or 0.5 degrees,it will stop.If you press the 1/64,1/48,1/32..., the turntabale rotates only ince ,such as 1/64,that is run 360*1/64 degrees. These buttons are respectively rotation angle:5.625 degrees,7.5 degrees, 11.25 degrees... 9.Multi angle shooting shortcut keys:Function:Press this key to control the turntable to suspend”n” times within a circle.(n=2,n=4,n=8...) For example:press the ket in this group(e.g.8 keys),theturntable rotates every time 1/8circle,45 degrees (=360*1/8),suspended one times,suspended time 4 seconds(MTxxxBSLx/MTxxxWSLx series is automatically sent out the shutter signal to take a photo),repeat 8 times that a circle automatically back to the starting position. 10.Focus:Control the turntable to output the focus signal. Notice:These three functions (Item14/Item15/Item16)are supported only by MTxxxBSLx and MTxxxWSLx.Product model name contains”WSL”or”BSL”. 2.Lock: In addition to this button,the other key is invalid. 4.Set origin location:Set the current position to the starting position of the turntable. 5. Speed up:The rotary speed is accelerated. 6.Clokwise rotation:Control the turntable to rotate clockwise. 7.Start/Stop:Control the turntable to rotate or stop. 8.Continuous totation:Control the turntable to rotate continuously. 11. Return to the origin:Contrl the turntable to return to the orignal position. 12.Counter clockwise rotation:Control the turntable to rotate counter clockwis. 13.Slow down:Control the turntable speed decrease. 14.Intermittent rotation:Control the turntable to rotate intermittently. 15.Auto:Control the turntable to output the focus signal and the shutter signal. 16.Shutter:Control the turntable to output the shutter signal. 4 Note:AAA baery is used to provide power for the remote controller. Copyright reserved by Shenzhen ComXim Technologies Co.,Ltd.2023 www.comxim.com 1.Lock: Except for this key, other keys are invalid. 7.Acceleration key: Press this key to increase the speed by one gear. 8.Rotate left:Turntable rotates clockwise. 9.Stop/Start 12.Continouse mode: Press this key to swich to continouse mode. 15.Hot keys of equally circular rotation:Forexample, press 8, the turntable will stop 8 times with 45° rotating angle and for 3 senconds each time. Duringeach stop,the turntable automatically sends a shutter signal for the camera to take pictures(Some premium versions support this features). Turntable will stop aftera lap. 16.Focus: Output camera focus signal. 19:Multimedia key(Adjust lights and volume.) 4. Original position: Turntable rotates back to the original position. 6. Reserved key: This key doesn't have function yet. 10.Rotate right: Turtable rotates counterclockwise. 11.Deceleration key:Press this keyto decrease the speed by one gear. 13.Interminnent mode: Press this key to switch to interminnent mode. 14.Left-and-right mode: For example, press 90°, the turntable willturn 45°to the left and 45° to the right,centeredon the current position. 17.Focuse and shutter: Output focus and shutter signal. (Pro version supports this feature.) 2. Save: Save current settings. 3. Hot keys: Press any key in this group and turtable rotates the corresponding angle once. 18.Shutter: Output camera shutter signal. (Pro version supports this feature.) 5.Original position setting: Set current position as original position. Large remote controller instructions 5 Note:AAA baery is used to provide power for the remote controller. Pl recautions ①Attention: Electric turntables are of electric products. They are Not waterproof and not heat resistant. ②In cases when turntable doesn’t work, please check whether the turntable is powered on, whether the power cord is plugged in tightly, and whether the switch is turned on. If the turntable still cannot work normally, please contact us. ③The load-bearing capacity of the turntable refers to the maximum load that the turntable can bear when the item is smaller than the diameter of the turntable. If the item exceeds the diameter of the turntable, the load-bearing capacity will be greatly reduced, and even it will not turn. ④In order to prolong the service life of the turntable, it is recommended to stop for 2 hours after working continuously for 8 hours. ⑤In order to protect the safety of users, unauthorized m…
