SMART WATCH Quick Guide Please read this manual carefully and reserve it for use 01 ※ If the power-on fails after pressing the power button for 3 seconds, please try again after charging. Touch and key Key Sliding: control panel Slide up: SMS notification Right slide: custom card Left slide: shortcut function Short press: light the screen, return to the dial interface, and enter the menu interface Long press: enter the system menu 02 Connect to phone You need to download and install the CO-FIT PRO application on your phone. CO-FIT APP supports iOS 11.0 and Android 5.0. 1. Open the mobile phone Bluetooth, open the app registration login to enter the home page. 2. Pair the watch with the APP. When pairing, please ensure that the watch and the APP can communicate with each other (synchronize data); Open APP>Device>Add new device>Select HK89 3. In the search binding list, select the HK89 with the strongest signal and click Pair. At this time, the Bluetooth icon on the watch is blue, indicating that you have connected Bluetooth 5.0 4. Bluetooth 3.0 connection mode: IPhone users support Bluetooth 5.0+3.0 dual Bluetooth one-button link (follow the system prompt box when matching) 1. The Android user system will pop up Bluetooth pairing request, check the prompt permission, and click "pairing" to complete Bluetooth 5.0+3.0 pairing; 2. If the Android user system does not pop up a Bluetooth pairing request, you need to click "unbind" in the "call service pairing option" in the Bluetooth pairing prompt interface, and then follow the interface operation prompts to complete the Bluetooth. Subsequent links to the mobile phone will generate memory for the watch 3.0 Bluetooth, so as to realize the double Bluetooth one-button link (if Bluetooth 3.0 is not automatically connected, please manually search the Bluetooth watch model "HK89" on the mobile phone) (CO-FIT APP) 03 Function Introduction Sport Activity Dial Connect the mobile phone with Bluetooth to dial out, and you can make a call at the watch end. Enter the sports mode selection interface, and click again to start the corresponding sports mode data detection: sports time, distance, calories, heart rate and other data. Count the activity data of the day. The number of steps per day can be set in the APP to reach the standard value, and the watch also has a prompt of reaching the standard. 04 Heart rate Blood pressure Blood oxygen Put the watch close to the wrist, and the best place to wear it is on the wrist bone above the arm. The real-time heart rate value can be measured. The normal value of the average person is 60-100 times/minute. You can also view the heart rate record. Put the watch close to the wrist, and the best place to wear it is above the wrist bone and arm. Real-time blood pressure can be measured. Adult diastolic blood pressure: 60~80 (mmHg), adult systolic blood pressure: 100~120 (mmHg). Put the watch close to the wrist, and the best wearing position is above the wrist bone and the arm. The real-time blood oxygen value can be measured, and the normal range of the value is generally 95% to 100%. 05 It can push the content of real messages, such as SMS, QQ, WeChat, etc. (the system above IOS12 will block the SMS reminder by default). If the APP is not connected, enter the weather display prompt, and the current weather temperature will be displayed after connecting the APP. Turn on sleep detection to detect sleep quality during sleep, and view data such as sleep duration, deep sleep and light sleep. Message Sleep Weather 06 It can control the playback of music in the phone, switch the previous and next music, and adjust the volume. You can customize the alarm clock and delete it. When connecting the mobile phone Bluetooth, click to talk to realize remote control. Music Voice Assistant Alarm 07 You can set the time and rhythm of breathing training, and then click to start breathing training. Start and end the stopwatch. Numeric calculations are possible. Breathing training Stopwatch Calculator 08 View the calendar. calendar Settings Including dial switch, brightness adjustment, language setting, password lock and other functions. FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications to this unit not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. 09 Matters needing attention 1 2 3 4 5 6 7 Do not disassemble, repair, or modify the product without authorization. Do no…

Text truncated - open the document above for the full version.

Shenzhen Hongbo Intelligent Electronics Co., Ltd. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen Hongbo Intelligent Electronics Co., Ltd. Address: 2 / F, No. 10-5, Minsheng 1st Road, Baoyuan Community, Shiyan Street, Baoan District, Shenzhen Product Name: SmartWatch FCC ID: 2BBPB-HK85 Model(s): HK85,HK87,HK89,HK26,HK30,HK29,HK39,HK40,HK95,HK983 2.911(d)(5)(i) Equipment Type We, [Shenzhen Hongbo Intelligent Electronics Co., Ltd.] certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Lizhong Fang Date: Jun.30, 2023 Title and Company name: General Manager / Shenzhen Hongbo Intelligent Electronics Co., Ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Hongbo Intelligent Electronics Co., Ltd. 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen Hongbo Intelligent Electronics Co., Ltd. Address: 2 / F, No. 10-5, Minsheng 1st Road, Baoyuan Community, Shiyan Street, Baoan District, Shenzhen Product Name: SmartWatch FCC ID: 2BBPB-HK85 Model(s): HK85,HK87,HK89,HK26,HK30,HK29,HK39,HK40,HK95,HK983 2.911(d)(5)(ii) Applicant filing We, [Shenzhen Hongbo Intelligent Electronics Co., Ltd.] certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Lizhong Fang Date: Jun.30, 2023 Title and Company name: chairman / Shenzhen Hongbo Intelligent Electronics Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Hongbo Intelligent Electronics Co., Ltd. 2.911 (d)(7)USA Agent v1.3 Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen Hongbo Intelligent Electronics Co., Ltd. Address: 2 / F, No. 10-5, Minsheng 1st Road, Baoyuan Community, Shiyan Street, Baoan District, Shenzhen Product Name: SmartWatch FCC ID: 2BBPB-HK85 Model(s): HK85,HK87,HK89,HK26,HK30,HK29,HK39,HK40,HK95,HK983 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen Hongbo Intelligent Electronics Co., Ltd.] (“the applicant”) designate [Electronic Mac, Inc.] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Electronic Mac, Inc. Address: 6525 Crown Blvd, # 20805, San Jose, CA 95120 FRN: 0033414541 Contact Name: Ray Sia Telephone No: 408-332-2399 Email: [email protected] Applicant Company name: Shenzhen Hongbo Intelligent Electronics Co., Ltd. Address: 2 / F, No. 10-5, Minsheng 1st Road, Baoyuan Community, Shiyan Street, Baoan District, Shenzhen FCC Grantee Code: 2BBPB Contact Name: Lizhong Fang Telephone No: 13760189420 Email: [email protected] Signature: Title: General Manager Signature: Title: General Manager Date: Jun.30, 2023 Date: Jun.30, 2023 Shenzhen Hongbo Intelligent Electronics Co., Ltd. 2.911 (d)(7)USA Agent v1.3 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Shenzhen Hongbo Intelligent Electronics Co., Ltd. Agent Authorization Company: Shenzhen Hongbo Intelligent Electronics Co., Ltd. Address: 2 / F, No. 10-5, Minsheng 1st Road, Baoyuan Community, Shiyan Street, Baoan District, Shenzhen Product Name: SmartWatch Model Number(s): HK85,HK87,HK89,HK26,HK30,HK29,HK39,HK40,HK95,HK983 Product Description: SmartWatch We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jun.30, 2023 Name: Lizhong Fang Title: General Manager Company: Shenzhen Hongbo Intelligent Electronics Co., Ltd.

Shenzhen Hongbo Intelligent Electronics Co., Ltd. Family models declaration letter. Date: July 3, 2023 We Shenzhen Hongbo Intelligent Electronics Co., Ltd. Of 2 / F, No. 10-5, Minsheng 1st Road, Baoyuan Community, Shiyan Street, Baoan District, Shenzhen Product: SmartWatch Model Name: HK85 Serial Model: HK87,HK89,HK26,HK30,HK29,HK39,HK40,HK95,HK983 Difference description of series models: All the model are the same circuit and RF module, except the model names and colors Thanks Sincerely Signature Name: Lizhong Fang Date: Jul.03, 2023 Title: General Manager

Shenzhen Hongbo Intelligent Electronics Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 3, 2023 Subject; Request for Confidentiality FCC ID: 2BBPB-HK85 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Lizhong Fang Title: General Manager

- Page 1 of 4 - ET-23060598 Product Name: SmartWatch Test Model No.: HK85 Ext Photos - Page 2 of 4 - ET-23060598 - Page 3 of 4 - ET-23060598 - Page 4 of 4 - ET-23060598 -----END-----

FCC ID：2BBPB-HK85 label size: 5mm*2mm Label location

- Page 1 of 4 - ET-23060598 Product Name: SmartWatch Test Model No.: HK85 Internal photos - Page 2 of 4 - ET-23060598 ANT - Page 3 of 4 - ET-23060598 - Page 4 of 4 - ET-23060598 ------END-----

FCC ID: 2BBPB-HK85 RF Exposure Evaluation TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). FCC ID: 2BBPB-HK85 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). This exemption may not be used in conjunction with other exemption criteria other than those is paragraph (b)(3)(i)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(i)(A). (B) in the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. Where: a = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(B) of Part 1.1307 for Pth, including existing exempt transmitters and those being added. b = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(C) of Part 1.1307 for Threshold ERP, including existing exempt transmitters and those being added. c = number of existing fixed, mobile, or portable RF sources with known evaluation for the specified minimum distance including existing evaluated transmitters. Pi = the available maximum time-averaged power or the ERP, whichever is greater, for fixed, mobile, or portable RF source i at a distance between 0.5 cm and 40 cm (inclusive). Pth,i = the exemption threshold power (Pth) according to paragraph (b)(3)(i)(B) of this section for fixed, mobile, or portable RF source i. FCC ID: 2BBPB-HK85 ERPj = the ERP of fixed, mobile, or portable RF source j. ERPth,j = exemption threshold ERP for fixed, mobile, or portable RF source j, at a distance of at least λ/2π according to the applicable formula of paragraph (b)(3)(i)(C) of Part 1.1307. Evaluatedk = the maximum reported SAR or MPE of fixed, mobile, or portable RF source k either in the device or at the transmitter site from an existing evaluation at the location of exposure. Exposure Limitk = either the general population/uncontrolled maximum permissible exposure (MPE) or specific absorption rate (SAR) limit for each fixed, mobile, or portable RF source k, as applicable from § 1.1310. Test Result of RF Exposure Evaluation Protocol Fre. (GHz) Output power (dBm) Tune-up power (dBm) Max tune-up power (dBm) ANT Gain ( dBi) Max EIRP (dBm) Max EIRP (mW) Separation distance (cm) Limit (mW) Result BT 2.441 0.97 1±1 2 1.5 3.5 2.24 0.5 2.75 PASS BLE 2.440 0.99 1±1 2 1.5 3.5 2.24 0.5 2.75 PASS Note: 1.This device is portable device. 2.The source of the evaluation data results is based on the test report ET-23060598E01/02 3.The Maxinum power is less than the limit, complies with the exemption requirements.

Report No.: ET-23060598E02 This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen ETR Standard Technology Co., Ltd. TEST REPORT Applicant: Shenzhen Hongbo Intelligent Electronics Co., Ltd. Address of Applicant: 2 / F, No. 10-5, Minsheng 1st Road, Baoyuan Community, Shiyan Street, Baoan District, Shenzhen Manufacturer/Factory: Shenzhen Hongbo Intelligent Electronics Co., Ltd. Address of Manufacturer 2 / F, No. 10-5, Minsheng 1st Road, Baoyuan Community, Shiyan Street, Baoan District, Shenzhen Product Name: SmartWatch Model No.: HK85,HK87,HK89,HK26,HK30,HK29,HK39,HK40,HK95,HK98 Trade Mark: N/A FCC ID: 2BBPB-HK85 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of Test: Jun.10, 2023- Jun.17, 2023 Date of report issued: Jul.03, 2023 Test Result : PASS * Remark: * In the configuration tested, the EUT complied with the standards specified above. The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver Prepared By Shenzhen ETR Standard Technology Co., Ltd. Address: No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Compiled by: Reviewed by: Approved by: Project Engineer Project Manager Authorized Signature - Page 2 of 31 - Report No.: ET-23060598E02 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Report Revision History Report No. Description Issue Date ET-23060598E02 Original Jul.03, 2023 - Page 3 of 31 - Report No.: ET-23060598E02 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Contents Page 1. TEST SUMMARY ......................................................................................................................................4 2. GENERAL INFORMATION .......................................................................................................................5 2.1 GENERAL DESCRIPTION OF EUT .................................................................................................................5 2.2 TEST MODE ................................................................................................................................................7 2.3 DESCRIPTION OF SUPPORT UNITS ...............................................................................................................7 2.4 DEVIATION FROM STANDARDS .....................................................................................................................7 2.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 2.6 TEST FACILITY ............................................................................................................................................7 2.7 TEST LOCATION ..........................................................................................................................................7 2.8 ADDITIONAL INSTRUCTIONS .........................................................................................................................7 3. TEST INSTRUMENTS LIST ......................................................................................................................8 4. TEST RESULTS AND MEASUREMENT DATA .......................................................................................9 4.1 ANTENNA REQUIREMENT .............................................................................................................................9 4.2 CONDUCTED EMISSIONS ...........................................................................................................................10 4.3 CONDUCTED PEAK OUTPUT POWER ..........................................................................................................13 4.4 6DB BANDWIDTH ......................................................................................................................................14 4.5 POWER SPECTRAL DENSITY ......................................................................................................................16 4.6 BAND EDGES ............................................................................................................................................18 Conducted Emission Method ...................................................................................................................18 Radiated Emission Method ......................................................................................................................19 4.7 SPURIOUS EMISSION .................................................................................................................................21 Conducted Emission Method ...................................................................................................................21 Radiated Emission Method ......................................................................................................................23 5. TEST SETUP PHOTO .............................................................................................................................31 6. EUT CONSTRUCTIONAL DETAILS .......................................................................................................31 - Page 4 of 31 - Report No.: ET-23060598E02 Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzh…

Text truncated - open the document above for the full version.

SHENZHEN QXTD Technology Co., Ltd onfidential documents Antenna report Customer Name Shenzhen Haikang Sheng intelligent Electronics Co., LTD project Bluetooth antenna Material name wireway Material color black black Requested date five Reference drawing： Figure 2 0.8*20mmBT Product name ANTENNA Type name LT13 frequency band 2402MHz~2480MHz input impedance 50Ω Allowable power 5W Operating temperature range -25 ~ +65 °C Storage temperature range -40 ~ +85 °C Antenna gain 1.5 dBi SHENZHEN QXTD Technology Co., Ltd Page 1 Confidential documents 3. Field pattern diagram SHENZHEN QXTD Technology Co., Ltd Page 2 Confidential documents 4. Gain and Efficiency Frequency(MHz) Gain( dBi) Efficiency(%) 2400 1.01 45.8 2410 1.36 51.6 2420 1.27 42.9 2430 1.19 48.0 2440 1.30 49.6 2450 1.14 51.4 2460 1.25 44.9 2470 1.47 48.4 2480 1.50 43.8 2490 1.38 49.1 2500 1.29 51.6

ET-23060598 Page 1 of 2 Product Name: SmartWatch Test Model No.: HK85 Test Setup Photo Radiated emissions 30MHz to1GHz Above 1GHz ET-23060598 Page 2 of 2 Conducted Emission ------End------
