Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 230425035GZU FCC ID: 2BBPU128223012 Version: 08 July 2020 Page 1 of 2 FCC RF Exposure-Mobile (MPE) RF Exposure Compliance Requirement Model no.: 128223012 1. Standard requirement Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ׀, H׀ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ׀, H׀ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- F/1500 30 1500-100000 -- -- 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 230425035GZU FCC ID: 2BBPU128223012 Version: 08 July 2020 Page 2 of 2 FCC RF Exposure-Mobile (MPE) 2. MPE Calculation Method E (V/m)=(30*P*G) 0.5 /d Power Density: Pd(W/m 2 )=E 2 /377 E=Electric Field (V/m) P=Peak RF output Power (W) G=EUT Antenna numeric gain (numeric) d= Separation distance between radiator and human body (m) The formula can be changed to Pd= (30*P*G)/(377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. 3. Calculated Result and Limit Antenna Gain and peak output power were declared by applicant. Frequency (MHz) Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2402-2480 1.55 9.05 8.04 0.00248 1 Complies Test Location: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch All tests were performed at: Room102/104, No 203, KeZhu Road, Science City, GETDD Guangzhou, China

Winners Industry Co., Ltd. TEST REPORT SCOPE OF WORK EMC TESTING–128223012 REPORT NUMBER 230425035GZU-001 ISSUE DATE [REVISED DATE] 13-June-2023 [---------------------] PAGES 64 DOCUMENT CONTROL NUMBER FCC BT 3.0-f © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 14 December 2022 Page 2 of 64 FCC BT 3.0-f Applicant Name & Address : Winners Industry Co., Ltd. StorageMart 4000 S Providence Rd, Columbia, MO 65203 Manufacturing Site : Asia Grobal Industries Co., Limited Jinsong Road,Liuwuxiang Village,Liaobu Town,Dongguan City, Guangdong Province,China Intertek Report No: FCC ID: 230425035GZU-001 2BBPU128223012 Test standards 47 CFR PART 15 Subpart C: 2021 section 15.247 Sample Description Product : DC 7.5’ MUSIC DUAL LED Model No. : 128223012 Electrical Rating : Input:120V~60Hz,0.45A; Output: 29V,0.9A Serial No. : Not Labeled Date Received : 25 April 2023 Date Test Conducted : 19 May 2023-13 June 2023 Prepared and Checked By Richard Liu Engineer Approved By: Dean Liu Project Engineer TEST REPORT Intertek Report No.: 230425035GZU-001 Version: 14 December 2022 Page 3 of 64 FCC BT 3.0-f CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION .............................................................................................. 5 2.1 PRODUCT DESCRIPTION ........................................................................................................ 5 2.2 RELATED SUBMITTAL(S) GRANTS ............................................................................................ 6 2.3 TEST METHODOLOGY ........................................................................................................... 7 2.4 TEST FACILITY ...................................................................................................................... 7 3.0 SYSTEM TEST CONFIGURATION .................................................................................. 7 3.1 JUSTIFICATION ..................................................................................................................... 7 3.2 EUT EXERCISING SOFTWARE.................................................................................................. 8 3.3 SPECIAL ACCESSORIES ........................................................................................................... 8 3.4 MEASUREMENT UNCERTAINTY ............................................................................................... 8 3.5 EQUIPMENT MODIFICATION .................................................................................................. 9 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 9 4.0 MEASUREMENT RESULTS ......................................................................................... 11 4.1 ANTENNA REQUIREMENT .................................................................................................... 11 4.2 20 DB BANDWIDTH ........................................................................................................... 12 4.3 CARRIER FREQUENCIES SEPARATED ....................................................................................... 18 4.4 HOPPING CHANNEL NUMBER .............................................................................................. 21 4.5 DWELL TIME ..................................................................................................................... 23 4.6 PSEUDO RANDOM FREQUENCY HOPPING SEQUENCE ............................................................... 34 4.6.1 Standard requirement ........................................................................................... 34 4.6.2 EUT Pseudo random Frequency Hopping Sequence .............................................. 34 4.7 MAXIMUM PEAK CONDUCTED OUTPUT POWER ..................................................................... 34 4.8 OUT OF BAND CONDUCTED EMISSIONS ................................................................................. 41 4.9 OUT OF BAND RADIATED EMISSIONS .................................................................................... 43 4.10 RADIATED EMISSIONS IN RESTRICTED BANDS ...................................................................... 43 4.11 BAND EDGES REQUIREMENT ....................................................…

Text truncated - open the document above for the full version.

Model of Antenna: BT-2.4G antenna Manufacturing Site: Asia Grobal Industries Co., Linited Jinsong Road,Liuwuxiang Village,Liaobu Town,Dongguan City, Guangdong Province,China

Note:EUT is positioned at the center of the turntable to keep 3 m between the measurement antenna and EUT for the radiated emissions measurements Radiated Emission (30MHz-1000MHz) Radiated Emission (Above 1000MHz) Conducted disturbance voltage at mains ports（150KHz-30MHz）
