2BBQXTYRC-1Remote Control with BLE

U s eU  0a n u a l PRODUCT 产品 Remote Control 遥控器 Customer Part No. 客户料号 TYRC-1 Seneasy Model No. 供方部品型号 TYRC-1 1. General information一般信息 Title标题 Remote Control遥控器 Manufacturer制造商 Country of origin 原产国 China中国 2. Unit standard单位 No.序 号 Check Item检查项目 Description/Specification描述/规范 1 Standard Voltage 标准电压 DC 3.0V 2 Operation Voltage 工作电压 DC 2.2V~3.6V 3 Operation temperature工 作温度 -10°C-50°C(≤95%RH)，86-106Kpa 4 Storage temperature 储存温度 -20°C~60°C 5 Battery type 电池类型 UM-4,AAAbattery*2 6 Netweight(No battery, no packaging) 净重（不含电池、包 装） Subject to sample±3% 以样品为准±3% Telly, Inc. Specification规范 3. Visual specification No. Check Item 检查项目 Description/Specification描述/规范 1 Appearance外观 Refer to appearance drawing 请参阅外观图 2 Case material 塑胶材质 ABS 3 Rubber KEY PADmaterial 按键材料 Rubber橡胶 4 Nameplate material 铭牌材料 N/A 5 Assembly组装 No moving parts inside the RC 遥控器内部没有活动部件 6 Plastic visual 塑料外观 No visual of scratch, crack, contamination and deformation 外观无划伤、裂纹、污染和变形 7 Printing visual 丝印外观 Printings and Indications are same as drawing 印刷和说明与图纸相同 Remark: For all visual standard should refer to approved sample 备注:所有外观标准应以认可的样品为准 4. Mechanical specification机械测试规格 No. Check Item 检查项目 Description/Specification描述/规范 1 Key force 按键作用力 200±50gf 2 Key stroke 按键行程 0.2-1mm 3 Rubber key press 硅胶按键 Key should return fast after key released 按键释放后，按键应快速返回 4 Button operating feel 按键手感 When pressing buttons, there shall have a clear click feeling 按下按钮时，应有清晰的点击感 5 Alcohol abrasion resistance 酒精耐磨 Select a plane for the test, rub the test surface back and forth with 99.8% alcohol, the pressure is 5N, and the speed is 30 back and forth/minute. Plastic shell: 50 times, rubber button: 100 times, rubber paint: 50 times, silk screen without peeling and exposure 选择平面进行测试，用浸有浓度为 99.8%酒精来回磨擦测试表 面，压力 5N，速度为 30 来回/分钟。 塑胶壳：50 次，橡胶钮：100 次，橡胶漆：50次，丝印无脱落 和露底现象 6 Rubber friction 橡皮摩擦 Use a 7017R eraser and apply a 5N force to vertically wipe the silk screen. Line: 25.4mm; Speed: 30 round-trip/minute. Shell screen printing: 30 times. RUBBER button silk printing: 20 times. Use an air gun to blow away the residue of the rubber while wiping the silk screen. Screen printing without peeling or exposing the bottom 使用 7017R 橡皮擦,以 5N 力度垂直擦丝印。行:25.4mm； 速度:30 来回/分钟。 机壳丝印： 30 次。 RUBBER 钮丝印： 20 次。 擦丝印的同时用风枪将橡胶的残渣吹走。 丝印无脱落和露底现象 7 Screen printing, oil spray slicing adhesive paper testing 丝印、喷油切片胶 纸测试 Draw a grid on the surface of the test location at an angle of 20 ° to 30 ° using a specialized hundred grid knife; The depth of the frame is based on only passing through the coating without damaging the material; Then use a brush to clean the fragments in the test area; Stick 3M adhesive tape onto the test cell and use an eraser to press the surface of the tape to ensure smooth adhesion between the tape and the test surface. Let it stand for 90 seconds; Pull up one end of the tape at a 60 ° angle, quickly remove the tape, and check for coating detachment; 1. If there is paint cracking during the process of drawing a hundred squares, it is judged as NG; 2. If there is detachment phenomenon during the testing process in the undivided area, it is judged as NG; 3. There are small pieces of paint peeling off at the edges and intersections of the line, and the total peeling area is between 5% and 15%; 用专用百格刀呈角度 20°～30°角度在测试位置表面划网格；画 格深度以只划透涂层，不伤及素材为准；然后用毛刷将测试区域 的碎片刷干净；将 3M 胶带粘住被测试小格，并使用橡皮擦按 压胶带表面，使胶带与测试面尽量粘合平整，静置 90s 后；拉 起胶带的一端呈 60° ，迅速扯下胶带,检查涂层脱落状况； 1.在划百格过程中出现油漆崩裂判为 NG； 2.未划百格区域在测试过程中出现脱落现象，判定 NG； 3.在划线的边缘及交叉点处有小片的油漆脱落，且脱落总面积 在 5％～ 15％之间 ； 8 Edible oil resistance test 耐食用油测试 Apply edible oil to the test surface and place it in an oven with a temperature and humidity of 40 °C, 90-95% (RH), for 100 hours. Test samples: rubber, plastic, oil spray No changes on the test surface 将食用油涂在测试表面，放入温湿度为 40 °C 90-95%(RH)炉内 100H 。测试样品：橡胶、塑胶、喷油 测试表面无变化 9 Detergent testing 洗洁剂测试 Soak half of the remote control in kitchen detergent for 24 hours, then remove it There is no difference between the part immersed in the solution and the part outside 将遥控器的一半浸在厨房洗洁剂里放置24H，然后取出 浸在溶液里的部分和外面的部分没有差别 10 Hand sweat test 抗手汗测试 Spray artificial sweat on the test surface and place it in an environment of 40 °C, 90-95% humidity, for 100 hours. There is no significant change in the appearance of the product, and there are no abnormalities such as discoloration, blistering, cracking, or detachment. 在测试表面喷上人造汗液，在40°C，90-95%的湿度环境中放置 100H。 产品外观无明显变化，无变色、起泡、开裂、脱落等异常。 11 Key life 按键的负荷寿命 Key service life tester: select more than two common key centers to apply a force of 500g vertically, with an interval of 60 times per minute, and the test times of 300000 times (100000 times per minute, completed in 3 times). The mechanical appearance is normal, without fracture damage, and meets the specifications and standards. Key force: the original value ± 20%. The function is normal after the test 按键寿命测试仪：选择两个以上的常用键中心垂直施以压力 500g的力，间隔时间以每分钟60次，测试次数30万次（一次 100000次，分3次完成，机械外观正常，无破裂损坏，符合规 格标准，按键力：原值±20%测试完后功能正常 12 Battery cover life 电池盖插拔寿命 Pull out and insert the battery cover, 3 times per minute, 500 times. The battery cover switch is tightly closed, and the buckle is not broken or damaged拔出并插入电池盖，每分钟3次，500次，电 池盖开关扣合力度正常，扣位无破裂，破损 13 Compressive strength of fuselage 机身抗压强度 Press the fuselage with a force greater than 30N for 3Min, and the fuselage and interior are free of mechanical damage, and the function is normal 用大于30N的力压机身3Min，机身和内部无机械损伤,功能正 常 14 Knocking machine 敲机 Test purpose: Evaluate the remote control The buckle strength of each buckle position ensures that mechanical and functional defects will not occur when users accidentally hit one end on a hard wooden desktop during normal use of the remote control. Scope of application: Suitable for remote controls and other combinations, such as hard button combinations, red mirrors, edge strips, surface and bottom shells, and other combinations. Testing method: Install the battery on the remote control, close the battery door, hold one end of the remote co…

Text truncated - open the document above for the full version.

Telly, Inc. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Telly, Inc. Address: 14622 Ventura Blvd Ste 102 PMB 2037 Sherman Oaks, CA 91403-3662 United States Product Name: Remote Control FCC ID: 2BBQXTYRC-1 Model(s): TYRC-1 2.911(d)(5)(i) Equipment Type We, Telly, Inc. (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Ilya Pozin Date: 2024-08-16 Title: CEO Company name: Telly, Inc. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Telly, Inc. 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Telly, Inc. Address: 14622 Ventura Blvd Ste 102 PMB 2037 Sherman Oaks, CA 91403-3662 United States Product Name: Remote Control FCC ID: 2BBQXTYRC-1 Model(s): TYRC-1 2.911(d)(5)(ii) Applicant filing We, [Telly, Inc.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Ilya Pozin Date: 2024-08-16 Title: CEO Company name: Telly, Inc. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Telly, Inc. U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: August 16, 2024 Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID: 2BBQXTYRC-1 FRN: 0033811662 Telly, Inc.(“the applicant”) certifies that, as of the date of the filing of the application, Telly, Inc.(“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. Telly, Inc. ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name:Telly, Inc. FRN: 0033811662 GC: 2BBQX Address: 14622 Ventura Blvd Ste 102 PMB 2037 Sherman Oaks, CA 91403-3662 United States Signature: Contact Person: Ilya Pozin Tel: 4247773401 Email: [email protected] Applicant Company Name:Telly, Inc. FRN: 0033811662 GC: 2BBQX Address: 14622 Ventura Blvd Ste 102 PMB 2037 Sherman Oaks, CA 91403-3662 United States Signature: Contact Person: Ilya Pozin Tel: 4247773401 Email: [email protected]

Telly, Inc. Agent Authorization Company: Telly, Inc. Address: 14622 Ventura Blvd Ste 102 PMB 2037 Sherman Oaks, CA 91403-3662 United States Product Name: Remote Control Model Number(s): TYRC-1 Product Description: Remote Control with BLE We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2024-08-16 Name: Ilya Pozin Title: CEO Company: Telly, Inc.

Telly, Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-08-16 Subject; Request for Long Term Confidentiality FCC ID: 2BBQXTYRC-1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram BOM Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Ilya Pozin Title: CEO

ANT

RF EXPOSURE EVALUATION EUT Specification EUT Remote Control Model Number TYRC-1 FCC ID 2BBQXTYRC-1 Antenna gain(Max) 1.69dBi Operation Frequency 2402-2480MHz Input Rating DC 3V from battery（2*AAA battery） Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation GFSK Max.outputpower 2.26dBm (0.001683W) TestRequirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guide lines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters without put power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. BLE DTS: According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Stone Tang Date: 2024- 08-10 Transmit Frequency (MHz) Bit Rate of Transmitter Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402 1Mbps GFSK 1.62 2±1 3 0.618386 3 2440 1Mbps GFSK 1.54 1±1 2 0.495170 3 2480 1Mbps GFSK 2.26 2±1 3 0.628346 3

深圳市英佳创电子科技有限公司 Shenzhen Yingjiachuang Electronic Technology Co., LTD Product antenna commissioning report Proposed system: Huang Zhiwei Audit: Fang Wenfeng Approval: Xiao Han Date: March 14, 2023 Shenzhen company address: building A.C, guangming valley, hongyu guangming valley, no. 11, jiangyou magang, shiwei community, matantian office, guangming district, shenzhen Hangzhou company address: 212, Building B, Dahua Jianghong International Innovation Park, No. 369, Internet of Things Street, Binjiang District, Hangzhou Telephone: 0755-27810060 Fax : 0755-27810057 Company website: http://www.szsyjc.com E-mail: [email protected] 一. Project Overview CustomerNameProject Name Antenna implementation method 802 SRC-1811 Onboard antenna Working frequency band (MHz） 2.4G2400-2500 MHz 4. Original antenna location diagram 5. Standing wave diagram of the original antenna 6. Passive test data of the original antenna 7. 2D3D image of original antenna test 8. New antenna change chart 9. Standing wave diagram of the new antenna 10. New antenna passive test data 11. New antenna test 2D3D diagram Directory: New antenna change chart The original C8 position match is changed to 1PF capacitor The original L2 position match was changed to 0 ohm resistance Standing wave diagram of the new antenna Frequency Efficiency (%) Gain. (dBi) 2400MHz 43.211.39 2410MHz 42.071.28 2420MHz 42.951.17 2430MHz 40.211.08 2440MHz 43.081.25 2450MHz 46.951.69 2460MHz 45.731.48 2470MHz 41.721.09 2480MHz 42.111.14 2490MHz 44.091.47 2500MHz 42.481.36 New antenna passive test data Phi 0 2Dfigure Phi 90 2Dfigure Theta 90 2Dfigure 2400 24502500 New antenna test 2D3D diagram

Product Name: Remote Control Report No:ITEZA2-202400283RF Product Model: TYRC-1 Security Classification: Open Version: V1.0 Total Page:55 TIRT Testing Report Prepared By: Checked By: Approved By: Aaron Long Stone Tang Joky Wang Report No.:ITEZA2-202400283RF Page 2 of 55 FCC Radio Test Report FCC ID: 2BBQXTYRC-1 According to 47 CFR FCC Part 15, Subpart C(Section 15.247) ANSI C63.10:2013 Applicant: Telly, Inc. Address: 14622 Ventura Blvd Ste 102 PMB 2037 Sherman Oaks, CA 91403-3662 United States Manufacturer: Telly, Inc. Address: 14622 Ventura Blvd Ste 102 PMB 2037 Sherman Oaks, CA 91403-3662 United States Sample No: 1000041925 Product Name: Remote Control Brand Name: N/A Model No.: TYRC-1 Test No.: TYRC-1 Date of Receipt: 2024/07/25 Date of Test: 2024/07/25~2024/08/05 Issued Date: 2024/08/16 Testing Lab: TIRT Note: This report shall not be reproduced except in full, without the written approval of Beijing TIRT Technology Service Co.,Ltd Shenzhen.Laboratory. This document may be altered or revised by Beijing TIRT Technology Service Co.,Ltd Shenzhen. Laboratory.Personnel only, and shall be noted in the revision section of the document. The test results of this report relate only to the tested sample identified in this report. Report No.:ITEZA2-202400283RF Page 3 of 55 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 DESCRIPTION OF TEST MODES 11 2.3 PARAMETERS OF TEST SOFTWARE 12 2.4. ACCESSORIES OF DEVICE (EUT) 12 2.5 BLOCKDIAGRAMSHOWINGTHECONFIGURATIONOFSYSTEMTESTED 12 2.6 SUPPORT UNITS 12 3 .AC POWER LINE CONDUCTED EMISSIONS 13 3.1 LIMIT 13 3.2 TEST PROCEDURE 13 3.3 DEVIATIONFROMTESTSTANDARD 13 3.4 TESTSETUP 14 3.5 EUT OPERATING CONDITIONS 14 3.6 TEST RESULTS 14 4 . RADIATED EMISSIONS 15 4.1 LIMIT 15 4.2 TEST PROCEDURE 16 4.3 DEVIATIONFROMTESTSTANDARD 17 4.4 TESTSETUP 17 4.5 EUT OPERATING CONDITIONS 19 4.6 TEST RESULT- 9KHZ TO 30MHZ 19 4.7 TEST RESULT- 30MHZ TO 1000MHZ 19 4.8 TEST RESULT- ABOVE 1000MHZ 19 5 .BANDWIDTH 20 5.1 LIMIT 20 5.2 TEST PROCEDURE 20 5.3 DEVIATION FROM STANDARD 20 5.4 TEST SETUP 20 Report No.:ITEZA2-202400283RF Page 4 of 55 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 20 5.6 TESTRESULTS 20 6 .MAXIMUM OUTPUT POWER 21 6.1 LIMIT 21 6.2 TEST PROCEDURE 21 6.3 DEVIATION FROM STANDARD 21 6.4 TEST SETUP 21 6.5 EUT OPERATION CONDITIONS 21 6.6 TESTRESULTS 21 7 .CONDUCTED SPURIOUS EMISSION 22 7.1 LIMIT 22 7.2 TEST PROCEDURE 22 7.3 DEVIATION FROM STANDARD 22 7.4 TEST SETUP 22 7.5 EUT OPERATION CONDITIONS 22 7.6 TEST RESULTS 22 8 .POWER SPECTRAL DENSITY 23 8.1 LIMIT 23 8.2 TEST PROCEDURE 23 8.3 DEVIATION FROM STANDARD 23 8.4 TEST SETUP 23 8.5 EUT OPERATION CONDITIONS 23 8.6 TEST RESULTS 23 9. ANTENNA REQUIREMENT 24 9.1STANDARD REQUIREMENT 24 9.2ANTENNA CONNECTED CONSTRUCTION 24 9.3RESULTS 24 10. MEASUREMENT INSTRUMENTS LIST 25 11. PHOTOS OF TEST SETUP 26 12. PHOTOS OF EUT 28 APPENDIX A - RADIATED EMISSION -9 KHZ TO 30 MHZ 34 APPENDIX B - RADIATED EMISSION-30 MHZ TO 1000 MHZ 35 Report No.:ITEZA2-202400283RF Page 5 of 55 Table of Contents Page APPENDIX C - RADIATED EMISSION - ABOVE 1000 MHZ 37 APPENDIX D - BANDWIDTH 39 APPENDIX E - MAXIMUM OUTPUT POWER 43 APPENDIX F - CONDUCTED SPURIOUS EMISSION 45 APPENDIX G POWER SPECTRAL DENSITY 52 APPENDIX H DUTY CYCLE 54 Report No.:ITEZA2-202400283RF Page 6 of 55 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note ITEZA2-202400283RF V1.0 Original Report. 2024.08.16 Valid Report No.:ITEZA2-202400283RF Page 7 of 55 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subpart C Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A N/A Note(1) 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Output Power APPENDIX F PASS ------ 15.247(d) Conducted Spurious Emission APPENDIX G PASS ------ 15.247(e) Power Spectral Density APPENDIX H PASS ------ 15.203 Antenna Requirement ------ N/A Note(2) Note: (1) “N/A” denotes test is not applicable to this device. (2) The device what use a permanently attached antenna were considered sufficient to comply with the provisions of 15.203. Report No.:ITEZA2-202400283RF Page 8 of 55 1.1 TEST FACILITY Company: Beijing TIRT Technology Service Co.,Ltd Shenzhen Address: 104 Building C, Xinmingsheng Industrial Park No.132, Zhangge Old Village East Zone, Zhangge Community, Fucheng Street, Longhua District, Shenzhen, Guangdong, P. R. China CNAS Registration Number: CNAS L14158 A2LA Registration Number: 6049.01 FCC Accredited Lab.Designation Number: CN1366 FCC Test Firm Registration Number: 820690 Telephone: +86-0755-27087573 1.2 MEASUREMENT UNCERTAINTY ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)) The measurement uncertainty as below table: Uncertainty Parameter Uncertainty Occupied Channel Bandwidth ±142.12 KHz RF power conducted ±0.74 dB RF power radiated ±3.25dB Spurious emissions, conducted ±1.78dB Spurious emissions, radiated (30MHz～1GHz) ±4.6dB Spurious emissions, radiated (1GHz ~ 18GHz) ±4.9dB Conduction Emissions(150kHz~30MHz) ±3.1 dB Humidity ±4.6% Temprature ±0.7°C Time ±1.25% Note: Unless specifically mentioned, the uncertainty of measurement has not been taken into account to declare the compliance or non-compliance to the specification. Report No.:ITEZA2-202400283RF Page 9 of 55 1.3 TEST ENVIRONMENT CONDITIONS Test Item Temperature Humidity Test Voltage Tested By AC Power Line Conducted Emissions N/A N/A N/A N/A Radiated Emissions-9 kHz to 30 MHz 24.5°C 50% DC 3V from battery Stone Tang R…

Text truncated - open the document above for the full version.

Radiated Emissions Test Photos 30 MHz to 1 GHz Radiated Emissions Test Photos Above 1 GHz Conducted Test Photos
