0 PCWL-0500 PCWL-0510 Version 1.03 [USERS MANUAL ] PicoCELA Corporation 1 1 Introduction. ........................................................................................................................ 4 1.1 precautions .................................................................................................................... 4 1.2 Warning. ....................................................................................................................... 5 1.3 Prohibitions .................................................................................................................... 5 1.4 Precautions Regarding Radio Waves .................................................................................. 6 1.5 Security precautions........................................................................................................ 7 1.6 Definition of Terms ......................................................................................................... 7 2 Packaging and product appearance and name .......................................................................... 9 2.1 PCWL-0500 Package Contents .......................................................................................... 9 2.2 PCWL-0500 Product appearance and name ........................................................................ 9 2.3 PCWL-0510 Package Contents .........................................................................................15 2.4 PCWL-0510 Product appearance and name .......................................................................16 3 Mounting method ................................................................................................................21 3.1 PCWL-0500 installation method .......................................................................................21 3.2 Antenna mounting direction for PCWL-0500 ......................................................................24 3.3 How to remove PCWL-0500 ............................................................................................27 3.4 How to install PCWL-0510 ..............................................................................................28 Mounting on a pole ...............................................................................................................29 Wall Mounting Method ..........................................................................................................29 3.5 How to remove PCWL-0510 ............................................................................................29 4 Installation method ..............................................................................................................30 ステップ 1 : Prepare the necessary equipment..............................................................................30 ステップ 2 : Check the Internet connection. .................................................................................30 ステップ 3 : Temporarily install PCWL (parent unit/core) to connect to the Internet ..........................31 ステップ 4 : Temporarily install PCWL( child/branch) .....................................................................37 ステップ 5 : Check the link (connection) between parent and child ..................................................38 ステップ 6 : Connect to the Internet with a Wi-Fi device ................................................................39 ステップ 7 : Perform the main installation ....................................................................................40 ステップ 8 : If you want to extend the area ..................................................................................40 5 About setting changes ..........................................................................................................41 6 How to operate PCWL's management screen ..........................................................................43 6.1 Screen header and footer icon operation ..........................................................................43 6.2 Help Screen Operation....................................................................................................44 7 Detailed settings of the monitoring system .............................................................................45 7.1 Backhaul (relay line) settings ..........................................................................................45 Operation mode setting ........................................................................................................45 Wireless Setup .....................................................................................................................46 Backhaul route update setting: at core setting .........................................................................48 Restoration settings in case of backhaul route failure: when core is configured ............................48 Backhaul special settings .......................................................................................................49 7.2 Network configuration: in router mode (parent unit/core only) ............................................53 WAN-side network configuration: Eth-up port connection ..........................................................53 WAN-side network settings: PPPoE connection .........................................................................54 LAN-side network settings .....................................................................................................55 2 DHCP Server Settings ...........................................................................................................55 7.3 Network settings: in bridge mode, in branch mode ............................................................57 LAN-side IP address setting ...................................................................................................57 7.4 VLAN Settings ...........................…

Text truncated - open the document above for the full version.

PicoCELA Inc. 050523-17 rev 8 Certification Application Attestation Statements Date: July 11, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: FCC ID: 2BBYQPCWL-0510 Statement for 47 CFR section 2.911(d)(5)(i) ______PicoCELA Inc. ______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ______PicoCELA Inc. ______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☐ - is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: __________________________ _____ Ryoji Kuribayashi _____ (Signature 2 ) (Print name) Title: ____ Manager ______ Company: ____ PicoCELA Inc.____ Telephone: __+81 3 6661 2780__ 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters must be placed on appropriate letterhead.

FCC US Agent, LLC U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: FCC US Agent, LLC Contact Name: Tim Payne Street Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA City/Province/Zip: Saint Charles/IL/ 60174 Telephone No: 708-571-3148 Email: [email protected] FRN #: 0033402884 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Signed by (Printed Name/Title): Tim Payne, Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: PicoCELA Inc. Grantee Code: 2BBYQ FCC ID:2BBYQPCWL-0510 Contact Name: Ryoji Kuribayashi Street Address: 2-34-5 Nihonbashi Ningyo-cho Chuo-ku City/Province/Zip: Tokyo/ 103-0013 Telephone No: +81 3 6661 2780 Email: [email protected] Applicant Signature 1 : Date:11.July.2023 Signed by (Printed Name/Title): Ryoji Kuribayashi / Product Development Manager 1 - Letters must be placed on appropriate letterhead. The signee for the applicant must be one of the following: Applicant (grantee) contact of record in the FCC’s authorization system, or authorized officers or employee of the applicant (grantee). 7/23/2023

PicoCELA Inc Declaration of Authorization We Name: PicoCELA Inc Address: 2-34-5 Nihonbashi Ningyo-cho Chuo-ku Tokyo 103-0013 JAPAN Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: WiFi 6 (802.11ax) 4×4 MU-MIMO Tri Band Access point FCC ID: 2BBYQPCWL-0510 Model No.: PCWL-0510 Sincerely, _ ________________ Name: Ryoji Kuribayashi Title: Manager Email: [email protected] Date:2023-06-12

PicoCELA Inc Date: June 12, 2023 Federal Communications Commission Authorization and Evaluation Division FCC ID: 2BBYQPCWL-0510 To Whom It May Concerm: This letter is to ascertain that the following information of applicant, product with model(s) have been the units used for conducting FCC compliance testing, the sDoC part will be tested by FCC recognized test lab. Product: WiFi 6 (802.11ax) 4×4 MU-MIMO Tri Band Access point Model: PCWL-0510 If you have any question or concerns, pls. contact us. Signature: Name: Ryoji Kuribayashi Position: Manager

PicoCELA Inc. 050222-17 Request for Confidentiality Date: August 22, 2023 Subject: Confidentiality Request for: ______2BBYQPCWL-0510 _____ Pursuant to FCC 47 CFR 0.457(d) and 0.459 and/or IC RSP-100, Section 12.4, the applicant requests that a part of the subject application(s) be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term --------------------------- External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term Operation Description/Theory of Operation ☐ Short Term Parts List & Placement/BOM ☐ Short Term Tune-Up Procedure ☐ Short Term Schematics ☐ Short Term --------------------------- Test Setup Photos ☐ Short Term ☐ Permanent * 1 User’s Manual ______PicoCELA Inc. ______ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of __ (specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: (specify ISED expiration date / date of marketing) . Sincerely, By: __________________________ ____ Ryoji Kuribayashi ___ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. Manager ☒Permanent ☐ Permanent ☐Permanent ☒Permanent

PicoCELA Inc Non-SDR (Software Defined Radio) Cover Letter Page 1 of 1 Non-SDR (Software Defined Radio) Cover Letter Refer to KDB 442812 D01 SDR apps Guide v02r03. The following six questions can be used for determining if a radio can elect to be, or must be an SDR. 1. Can the RF parameters of the device be altered through software? Yes - go to 2. No, not an SDR Reply：Yes 2. Can third parties not permitted by the Commission through specific filings modify, configure, or load different software, or make configuration settings to operate the device or host hardware radio frequency parameters (frequency range, modulation type, maximum output power or other radio parameters) in any other way than granted (or expected to be granted)? Yes, must be an SDR. No - go to 3. Reply：No 3. Is the device capable of operating in any other in any other way than granted, or will be, granted? Yes, - go to 4. No - go to 5. Reply：No 4. Is this a Part 15 client Device as defined in Section 15.202 (as opposed to a master device)? Yes, qualifies as a part 15 client devices - go to 5. No, must be an SDR. YES 5. Does the manufacturer elect SDR? Yes, elects to be an SDR. No, Not an SDR Reply：No Final conclusion: According to the above questions reply, we can confirm this device (Product Description: WiFi 6 (802.11ax) 4×4 MU-MIMO Tri Band Access point) must be a Non-SDR. _________________ Name: Ryoji Kuribayashi Title: Manager Email: [email protected] Date: 2023-06-12

Professional Installation Attestation Date: 2023-08-31 FCC ID: 2BBYQPCWL-0510 TCB: PicoCELA Inc, declare that the above reference product is professionally installed. The PCWL-0510 are intended for enterprise level installations. PCWL-0510 supports direct sales to large customers and sales via value-added resellers/distributors. There are no retail or mail order sales channels. In all cases, installation is performed by a trained installer. There is a specific ordering guide that provides a list of acceptable antennas for a particular access point. This is referenced in the Installation Guide. Sign by: Print Name: Ryoji Kuribayashi Title: Manager Company: PicoCELA Inc

Report No.: 2305RSU028-UE 1 of 7 EUT Photograph (1) EUT Photo (2) EUT Photo Report No.: 2305RSU028-UE 2 of 7 (3) EUT Photo (4) EUT Photo Report No.: 2305RSU028-UE 3 of 7 (5) EUT Photo (6) EUT Photo Report No.: 2305RSU028-UE 4 of 7 (7) EUT Photo (8) EUT Photo Wi-Fi Antenna 2# (Model No.: SAA04-222060) Report No.: 2305RSU028-UE 5 of 7 (9) EUT Photo Wi-Fi Antenna 2# (Model No.: SAA04-222060) (10) EUT Photo Wi-Fi Antenna 2# (Model No.: SAA04-222060) Report No.: 2305RSU028-UE 6 of 7 (11) EUT Photo (12) EUT Photo Wi-Fi Antenna 1# (Model No.: PIC04-220080(AP)) Report No.: 2305RSU028-UE 7 of 7 (13) EUT Photo Wi-Fi Antenna 1# (Model No.: PIC04-220080(AP))

Report No.: 2305RSU028-UE 1 of 4 EUT Photograph (1) EUT Photo (2) EUT Photo Report No.: 2305RSU028-UE 2 of 4 (3) EUT Photo (4) EUT Photo Report No.: 2305RSU028-UE 3 of 4 (5) EUT Photo (6) EUT Photo Report No.: 2305RSU028-UE 4 of 4 (7) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2305RSU028-U4 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2023-07-25 1 of 10 RF Exposure Evaluation Declaration FCC ID: 2BBYQPCWL-0510 Applicant: PicoCELA Inc Product: WiFi 6 (802.11ax) 4×4 MU-MIMO Tri Band Access point Model No.: PCWL-0510 Brand Name: PicoCELA FCC Classification: Digital Transmission System (DTS) Unlicensed National Information Infrastructure (NII) FCC Rule Part(s): FCC Part 2.1091 Test Procedure(s): KDB 447498 D04v01 Reviewed By: Jame Yuan Approved By: Robin Wu The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2305RSU028-U4 2 of 10 Revision History Report No. Version Description Issue Date Note 2305RSU028-U4 V01 Initial Report 2023-07-25 Valid Report No.: 2305RSU028-U4 3 of 10 CONTENTS Description Page 1. General Information ................................................................................................................................ 4 1.1. Applicant ........................................................................................................................................ 4 1.2. Manufacturer ................................................................................................................................. 4 1.3. Testing Facility ............................................................................................................................... 4 1.4. Product Information ....................................................................................................................... 5 1.5. Antenna Details ............................................................................................................................. 5 2. RF Exposure Evaluation ......................................................................................................................... 6 2.1. Test Limits ..................................................................................................................................... 6 2.2. Test Exemptions ............................................................................................................................ 7 2.3. Test Result ................................................................................................................................... 10 Report No.: 2305RSU028-U4 4 of 10 1. General Information 1.1. Applicant PicoCELA Inc 2-34-5 Nihonbashi Ningyo-cho Chuo-ku Tokyo 103-0013 JAPAN 1.2. Manufacturer PicoCELA Inc 2-34-5 Nihonbashi Ningyo-cho Chuo-ku Tokyo 103-0013 JAPAN 1.3. Testing Facility Test Site – MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 VCCI: R-20025 G-20034 C-20020 T-20020 R-20141 G-20134 C-20103 T-20104 Test Site – MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 CNAS: L10551 FCC: CN1284 ISED: CN0105 Test Site – MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: L3261-190725 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2305RSU028-U4 5 of 10 1.4. Product Information Product Name WiFi 6 (802.11ax) 4×4 MU-MIMO Tri Band Access point Model No. PCWL-0510 Wi-Fi Specification 802.11a/b/g/n/ac/ax Antenna Information Refer to Section 1.5 Power Supply AC/DC Adapter or PoE Adapter Accessories AC/DC Adapter Model: PSAC60W-120 Input: 100-240V, 1.6A Output: 12V, 5A Note 1: The information of EUT was provided by the manufacturer, and the accuracy of the information shall be the responsibility of the manufacturer. Note 2: AC/DC Adapter was not sold with the product. 1.5. Antenna Details Antenna Type Frequency Band (MHz) T X Paths Max Antenna Gain (dBi) Directional Gain (dBi) Beamforming Directional Gain (dBi) For Power For PSD Wi-Fi Antenna 1# (Model No.: PIC04-220080(AP)) Omni-Directional 2400 ~ 2500 4 4.50 4.50 10.52 10.52 Omni-Directional 5150 ~ 5875 4 7.00 7.00 13.02 13.02 Wi-Fi Antenna 2# (Model No.: SAA04-222060) Directional Panel 2400 ~ 2500 4 13.50 13.50 19.52 19.52 Directional Panel 5150 ~ 5875 4 15.50 15.50 21.52 21.52 Report No.: 2305RSU028-U4 6 of 10 2. RF Exposure Evaluation 2.1. Test Limits According to §1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in §1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 0.3-3.0 614 1.63 *(100) ≤6 3.0-30 1842/f 4.89/f *(900/f 2 ) <6 30-300 61.4 0.163 1.0 <6 300-1,500 -- -- f/300 <6 1,500-100,000 -- -- 5 <6 (B) Limits for General Population/ Uncontrolled Exposures 0.3-1.34 614 1.63 *(100) <30 1.34-30 824/f 2.19/f *(180/f 2 ) <30 30-300 27.5 0.073 0.2 <30 300-1,500 -- -- f/1500 <30 1,500-100,000 -- -- 1.0 <30 f= frequency in MHz. * = Plane-wave equivalent power density. Report No.: 2305RSU028-U4 7 of 10 2.2. Test Exemptions For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph §1.1307(b)(2) of this section): A single RF source is exempt if: (Option A) The available maximum time-averaged power is no more …

Text truncated - open the document above for the full version.

Report No.: 2305RSU028-U2 56 of 647 802.11ax-HE40 26dB & 99% Bandwidth Channel 134 (5670MHz) Channel 142(5710MHz) Channel 151 (5755MHz) Channel 159 (5795MHz) Report No.: 2305RSU028-U2 57 of 647 802.11ax-HE80 26dB & 99% Bandwidth Channel 42 (5210MHz) Channel 58 (5290MHz) Channel 106 (5530MHz) Channel 122 (5610MHz) Channel 138 (5690MHz) Channel 155 (5775MHz) Report No.: 2305RSU028-U2 58 of 647 802.11ax-HE80+80 26dB & 99% Bandwidth Channel 42+58 (5210+5290MHz) Channel 106+122 (5530+5610MHz) Report No.: 2305RSU028-U2 59 of 647 A.3 6dB Bandwidth Test Result Test Site WZ-TR3 Test Engineer Lynn Yang Test Date 2023-06-01 Test Mode Data Rate/ MCS Channel No. Frequency (MHz) 6dB Bandwidth (MHz) Limit (MHz) 11a 6Mbps 149 5745 16.32 ≥0.5 11a 6Mbps 157 5785 16.07 ≥0.5 11a 6Mbps 165 5825 16.32 ≥0.5 11ac-VHT20 MCS0 149 5745 17.55 ≥0.5 11ac-VHT20 MCS0 157 5785 17.07 ≥0.5 11ac-VHT20 MCS0 165 5825 17.19 ≥0.5 11ac-VHT40 MCS0 151 5755 36.30 ≥0.5 11ac-VHT40 MCS0 159 5795 35.73 ≥0.5 11ac-VHT80 MCS0 155 5775 74.74 ≥0.5 11ax-HE20 MCS0 149 5745 18.92 ≥0.5 11ax-HE20 MCS0 157 5785 18.93 ≥0.5 11ax-HE20 MCS0 165 5825 22.34 ≥0.5 11ax-HE40 MCS0 151 5755 38.01 ≥0.5 11ax-HE40 MCS0 159 5795 37.57 ≥0.5 11ax-HE80 MCS0 155 5775 76.78 ≥0.5 Report No.: 2305RSU028-U2 60 of 647 802.11a 6dB Bandwidth Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz) Report No.: 2305RSU028-U2 61 of 647 802.11ac-VHT20 6dB Bandwidth Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz) 802.11ac-VHT40 6dB Bandwidth Channel 151 (5755MHz) Channel 159 (5795MHz) Report No.: 2305RSU028-U2 62 of 647 802.11ac-VHT80 6dB Bandwidth Channel 155 (5775MHz) Report No.: 2305RSU028-U2 63 of 647 802.11ax-HE20 6dB Bandwidth Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz) 802.11ac-VHT40 6dB Bandwidth Channel 151 (5755MHz) Channel 159 (5795MHz) Report No.: 2305RSU028-U2 64 of 647 802.11ax-HE80 6dB Bandwidth Channel 155 (5775MHz) Report No.: 2305RSU028-U2 65 of 647 A.4 Output Power Test Result Test Site WZ-TR3 Test Engineer Lynn Yang Test Date 2023-05-27~2023-06-20 Test Mode AP Mode Antenna No. 1# Test Mode Data Rate MCS Channel No. Freq. (MHz) Average Power (dBm) Total Average Power (dBm) Average Power Limit (dBm) Ant 0 Ant 1 Ant 2 Ant 3 11a 6Mbps 36 5180 7.31 7.99 7.23 6.68 13.35 29.00 11a 6Mbps 44 5220 7.22 7.79 7.03 6.69 13.22 29.00 11a 6Mbps 48 5240 6.71 7.78 7.30 7.46 13.35 29.00 11a 6Mbps 52 5260 8.56 9.21 8.66 8.32 14.72 22.71 11a 6Mbps 60 5300 8.62 8.91 8.90 8.51 14.76 22.71 11a 6Mbps 64 5320 9.03 9.02 8.73 8.77 14.91 22.71 11a 6Mbps 100 5500 8.76 9.40 8.81 8.66 14.94 22.71 11a 6Mbps 116 5580 8.78 9.18 9.00 9.23 15.07 22.71 11a 6Mbps 140 5700 8.60 9.03 8.41 8.30 14.61 22.71 11a 6Mbps 144 5720 8.96 9.26 8.68 8.81 14.95 21.60 11a 6Mbps 149 5745 20.77 21.88 21.35 21.60 27.44 29.00 11a 6Mbps 157 5785 20.40 21.53 20.55 21.30 26.99 29.00 11a 6Mbps 165 5825 20.80 21.43 21.13 21.72 27.30 29.00 11ac-VHT20 MCS0 36 5180 7.07 8.08 7.18 6.73 13.32 29.00 11ac-VHT20 MCS0 44 5220 7.03 8.24 7.50 7.42 13.59 29.00 11ac-VHT20 MCS0 48 5240 6.66 7.62 7.11 7.43 13.24 29.00 11ac-VHT20 MCS0 52 5260 8.99 9.26 9.15 8.68 15.05 22.98 11ac-VHT20 MCS0 60 5300 9.01 9.49 9.26 8.99 15.21 22.98 11ac-VHT20 MCS0 64 5320 8.65 8.98 8.78 8.56 14.77 22.98 11ac-VHT20 MCS0 100 5500 8.87 9.69 9.16 8.96 15.20 22.98 11ac-VHT20 MCS0 116 5580 8.68 9.10 8.62 9.15 14.91 22.98 11ac-VHT20 MCS0 140 5700 8.87 9.19 8.88 8.68 14.93 22.98 11ac-VHT20 MCS0 144 5720 8.62 9.09 8.79 8.70 14.82 21.78 11ac-VHT20 MCS0 149 5745 20.72 22.13 21.47 21.84 27.59 29.00 11ac-VHT20 MCS0 157 5785 20.05 21.24 20.75 21.21 26.86 29.00 11ac-VHT20 MCS0 165 5825 20.70 21.41 21.07 21.74 27.27 29.00 Report No.: 2305RSU028-U2 66 of 647 Test Mode Data Rate MCS Channel No. Freq. (MHz) Average Power (dBm) Total Average Power (dBm) Average Power Limit (dBm) Ant 0 Ant 1 Ant 2 Ant 3 11ac-VHT40 MCS0 38 5190 6.65 8.42 7.60 7.66 13.65 29.00 11ac-VHT40 MCS0 46 5230 6.88 8.39 7.67 8.23 13.85 29.00 11ac-VHT40 MCS0 54 5270 11.53 12.21 11.73 11.35 17.74 22.98 11ac-VHT40 MCS0 62 5310 12.29 12.68 12.21 12.30 18.39 22.98 11ac-VHT40 MCS0 102 5510 12.30 12.80 12.22 11.99 18.36 22.98 11ac-VHT40 MCS0 110 5550 12.35 12.99 12.32 12.33 18.53 22.98 11ac-VHT40 MCS0 134 5670 12.16 12.81 12.56 12.39 18.51 22.98 11ac-VHT40 MCS0 142 5710 12.09 12.60 12.26 12.10 18.29 22.98 11ac-VHT40 MCS0 151 5755 21.07 21.92 21.30 22.02 27.62 29.00 11ac-VHT40 MCS0 159 5795 20.70 21.50 20.71 21.49 27.14 29.00 11ac-VHT80 MCS0 42 5210 7.39 8.24 7.52 7.58 13.72 29.00 11ac-VHT80 MCS0 58 5290 13.93 14.30 14.05 13.88 20.06 22.98 11ac-VHT80 MCS0 106 5530 14.83 15.52 15.01 14.93 21.10 22.98 11ac-VHT80 MCS0 122 5610 14.42 15.36 15.28 15.46 21.17 22.98 11ac-VHT80 MCS0 138 5690 14.67 15.49 15.20 15.11 21.15 22.98 11ac-VHT80 MCS0 155 5775 18.90 19.99 19.53 19.92 25.63 29.00 11ac-VHT80+80 MCS0 42 5210 9.89 10.39 -- -- 13.16 29.00 58 5290 -- -- 10.12 10.08 13.11 22.98 11ac-VHT80+80 MCS0 106 5530 12.30 13.56 -- -- 19.03 22.98 122 5610 -- -- 12.67 13.38 11ax-HE20 MCS0 36 5180 7.31 8.12 7.25 7.10 13.48 29.00 11ax-HE20 MCS0 44 5220 7.32 7.82 7.27 6.99 13.38 29.00 11ax-HE20 MCS0 48 5240 7.27 8.00 7.42 7.65 13.61 29.00 11ax-HE20 MCS0 52 5260 9.10 9.39 9.43 8.99 15.25 22.98 11ax-HE20 MCS0 60 5300 8.79 9.11 9.08 8.62 14.93 22.98 11ax-HE20 MCS0 64 5320 8.87 9.33 8.96 8.75 15.00 22.98 11ax-HE20 MCS0 100 5500 8.92 9.43 8.77 8.79 15.01 22.98 11ax-HE20 MCS0 116 5580 8.77 9.51 8.99 9.38 15.19 22.98 11ax-HE20 MCS0 140 5700 9.00 9.56 9.07 8.95 15.17 22.98 11ax-HE20 MCS0 144 5720 8.88 9.53 8.66 8.96 15.04 21.90 11ax-HE20 MCS0 149 5745 21.25 22.20 21.56 21.90 27.76 29.00 11ax-HE20 MCS0 157 5785 20.60 21.43 20.89 21.49 27.14 29.00 11ax-HE20 MCS0 165 5825 21.01 21.70 21.52 21.71 27.51 29.00 Report No.: 2305RSU028-U2 67 of 647 Test Mode Data Rate MCS Channel No. Freq. (MHz) Average Power (dBm) Total Average Power (dBm) Average Power Limit (dBm) Ant 0 Ant 1 Ant 2 Ant 3 11ax-HE40 MCS0 38 5190 7.25 7.80 7.11 6.82 13.28 29.00 11ax-HE40 MCS0 46 5230 7.22 7.75 7.23 6.92 13.31 29.00 11…
