2BBZE-WH05Wireless Car Charger Mount

DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD Agent Authorization Company: DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD Address: 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, China Pr oduct Name: Wireless Car Charger Mount Model Num ber(s): WH05, FlexDrive-Qi2 Product D escription: Wireless Car Charger Mount We au thorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Sept. 05, 2024 Name: Pengcheng Du Title: General Manager Company: DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD

FCC ID LABEL: Ca. 10mm x 20mm Label Location FCC ID: 2BBZE‐WH05

Page 1 of 11 Report No.: HK2408224862-2E FCC Test Report Test Report On Behalf of DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD For Wireless Car Charger Mount Model No.: WH05, FlexDrive-Qi2 FCC ID: 2BBZE-WH05 Prepared For: DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, China Prepared By: Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Aug. 22, 2024 ~ Sept. 03, 2024 Date of Report: Sept. 03, 2024 Report Number: HK2408224862-2E Page 2 of 11 Report No.: HK2408224862-2E Test Result Certification Applicant’s Name ................. : DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD Address.................................. : 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, China Manufacturer's Name .......... : DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD Address.................................. : 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, China Product Description Trade Mark ................................ : A2C Product Name ........................... : Wireless Car Charger Mount Model and/or Type Reference: WH05, FlexDrive-Qi2 Standards ............................. : FCC CFR 47 PART 18, KDB 680106 D01 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of Performance of Tests ............ : Aug. 22, 2024 ~ Sept. 03, 2024 Date of Issue ........................................... : Sept. 03, 2024 Test Result ............................................... : Pass Testing Engineer Len Liao Technical Manager Sliver Wan Authorized Signatory Jason Zhou Page 3 of 11 Report No.: HK2408224862-2E Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Frequency Band: 112-205KHz Channel List Channel Frequency (KHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Middle CH 128 The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. 2. Summary of Test Results 2.1 Test procedures according to the technical standards: FCC KDB 680106 D01 Wireless Power Transfer v04 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB 680106 D01v04 Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS 2.2 Measurement Uncertainty The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 All Emissions, Radiated(<30M)(9KHz-30MHz) ±3.90dB 2 Temperature ±0.5°C 3 Humidity ±2% Page 4 of 11 Report No.: HK2408224862-2E 2.3 Test Instruments Description Brand Model No. S/N Calibrated Date Calibrated Until Electric and Magnetic Field Analyzer narda EHP-200AC180ZX11028 Feb. 20, 2024 Feb. 19, 2025 NOTE: 1. The calibration interval of the above test instruments is 12 months. 2.4 Test Mode Test Item Te s t mode Description MPE Test Cases Mode 1AC/DC Adapter+ EUT + Mobile Phone (Battery Status: <1%) Mode 2AC/DC Adapter+ EUT + Mobile Phone (Battery Status: <50%) Mode 3AC/DC Adapter+ EUT + Mobile Phone (Battery Status: >95%) Note: 1. All modes and configurations above have been tested, Only the result of the worst case was recorded in the report, the worst-case configuration is Mode 1. 2. For Radiated Emission, 3axis were chosen for testing for each applicable mode. 3. The Mobile Phone provided by Lab. 4. According to the manufacturer's design principle, the wireless charging power will reach its maximum when the client device's battery level is between 1% and 10%. Page 5 of 11 Report No.: HK2408224862-2E 3. Maximum Permissible Exposure Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180 / f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1 30 Note 1: f = frequency in MHz; *Plane-wave equivalent power density. Note 2: For the applicable limit, see FCC 1.1310, 680106 D01 Wireless Power Transfer v04. Note 3: Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. Page 6 of 11 Report No.: HK2408224862-2E 4. Test Procedure a. For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of (H-field & E- field strengths for all sides is 20cm). E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 20 cm measured from the center of the probe(s) to the edge of the device. 4.1 Test Se…

Text truncated - open the document above for the full version.

Page 1 of 22 Report No.: HK2408224862-1E FCC Test Report Test Report On Behalf of DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD For Wireless Car Charger Mount Model No.: WH05, FlexDrive-Qi2 FCC ID: 2BBZE-WH05 Prepared For: DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, China Prepared By: Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Aug. 22, 2024 ~ Sept. 03, 2024 Date of Report: Sept. 03, 2024 Report Number: HK2408224862-1E Page 2 of 22 Report No.: HK2408224862-1E Test Result Certification Applicant’s Name ................. : DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD Address.................................. : 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, China Manufacturer's Name .......... : DONGGUAN JINCHI ELECTRONIC TECHNOLOGY CO., LTD Address.................................. : 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, China Product Description Trade Mark ................................ : A2C Product Name ........................... : Wireless Car Charger Mount Model and/or Type Reference: WH05, FlexDrive-Qi2 Standards ............................. : FCC CFR 47 PART 18 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of Performance of Tests ............ : Aug. 22, 2024 ~ Sept. 03, 2024 Date of Issue ........................................... : Sept. 03, 2024 Test Result ............................................... : Pass Testing Engineer Len Liao Technical Manager Sliver Wan Authorized Signatory Jason Zhou Page 3 of 22 Report No.: HK2408224862-1E Table of Contents Page 1 . Test Summary 5 1.1 . Test Procedures and Results 5 1.2 . Information of the Test Laboratory 5 1.3 . Measurement Uncertainty 5 2. General Information 6 2.1. General Description of EUT 6 2.2. Carrier Frequency of Channels 7 2.3. Operation of EUT during Testing 7 2.4. Description of Test Setup 8 2.5. Description of Support Units 9 2.6. Measurement Instruments List 10 3. Conducted Emission Test 11 3.1. Block Diagram of Test Setup 11 3.2. Conducted Power Line Emission Limit 11 3.3. Test Procedure 11 3.4. Test Result 12 4. Radiated Emissions 14 4.1. Block Diagram of Test Setup 14 4.2. Rules and Specifications 15 4.3. Test Procedure 15 4.4. Test Result 16 5. Antenna Requirement 19 6. Photographs of Test 20 7. Photos of the EUT 22 Page 4 of 22 Report No.: HK2408224862-1E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release Sept. 03, 2024 Jason Zhou Page 5 of 22 Report No.: HK2408224862-1E 1. Test Summary 1.1. Test Procedures and Results Description of Test Section Number Result Conducted Emissions Test 18.307 COMPLIANT Radiated Emission Test 18.305 COMPLIANT Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 1.2. Information of the Test Laboratory Shenzhen HUAK Testing Technology Co., Ltd. Add.: 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Testing Laboratory Authorization： A2LA Accreditation Code is 4781.01. FCC Designation Number is CN1229. Canada IC CAB identifier is CN0045. CNAS Registration Number is L9589. 1.3. Measurement Uncertainty Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.71dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.90dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 3.90dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.28dB, k=2 Page 6 of 22 Report No.: HK2408224862-1E 2. General Information 2.1. General Description of EUT Equipment: Wireless Car Charger Mount Model Name: WH05 Series Models: FlexDrive-Qi2 Model Difference: All model’s the function, software and electric circuit are the same, only with product model named different. Test sample model: WH05. Trade Mark: A2C FCC ID: 2BBZE-WH05 Antenna Type: Coil Antenna Antenna Gain: 0dBi Operation Frequency: 112KHz~205KHz Test Frequency: 128KHz Number of Channels: 1 Modulation Type: ASK Power Source: Input: DC5V/3A, 9V/2.22A Output: 15W Power Rating: Input: DC5V/3A, 9V/2.22A Output: 15W Note: 1. The transfer system includes one coils, 1 coils can work individually or can work at the same time. All situations have been tested, only the worst situation was recorded in the report. 2. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 3. The cable loss data is obtained from the supplier. 4. The test results in the report only apply to the tested sample. Page 7 of 22 Report No.: HK2408224862-1E 2.2. Carrier Frequency of Channels Operation Frequency each of channel Channel Frequency Middle CH 128KHz 2.3. Operation of EUT during Testing Test Item Test mode Description Radiated & Conducted Test Cases Mode 1 AC/DC Adapter+ EUT + Mobile Phone (Battery Status: <1%) Mode 2 AC/DC Adapter+ EUT +Mobile Phone (Battery Status: <50%) Mode 3 AC/DC Adapter+ EUT +Mobile Phone (Battery Status: >95%) Note: 1. All modes and configurations above have been tested, Only the result of the worst case was recorded in the report, the worst-case configuration is Mode 1. 2. For Radiated Emission, 3axis were chosen for testing for each ap…
