2BCLX-D2303DOG HOUSE HEATER

·Please read this manual carefully before use. ·The company reserves the right to interpret the instructions. ·The appearance of the product is subject to the actual product. DOG HOUSE HEATER User Manual - 02 - In order to prevent the occurrence of danger, please make sure that the heater is not covered by other objects when using. In order to serve you better, please read this manual carefully before use and keep it properly for future maintenance. It is normal for the peculiar smell to start up for the first time, and it will volatilize within a few minutes after starting up. Please feel free to use it. *This Dog House Heater can ONLY be used with the voltage specified on the heater's nameplate(120V~60HZ). *DO NOT alter the heater or cord in any way, this greatly increases your risk of fire and voids all warranty. *When installing, placing, and using the electric heater, please DO NOT cover the air outlet and inlet of the electric heater, and ensure that the flammable materials are more than 1 meter away from the electric heater to avoid the electric heater from overheating and causing a fire. *Please DO NOT place the electric heater close to other heat sources. *Please DO NOT use this electric heater in the following places: near natural gas or gas pipelines, near the use and storage of paint or other flammable liquids. *In order to avoid burns during or after use of this heater, please DO NOT let your bare skin touch it; if you need to move it, please turn it off and wait for its surface to cool down. *Please DO NOT cover the heater with clothing or other items. *Please DO NOT put any foreign objects or metal objects into the air inlet or outlet of the dog house heater, as this may cause electric shock, fire, or damage to the heater. *Please DO NOT immerse the heater in water or let water enter the inside of the electric heater, which may cause electric shock. *If the heater fails, please contact us in time or send it to a qualified service station. *Please DO NOT touch the electric heater when your hands are wet. *The most common cause of overheating of the electric heater is the accumulation of dust or fluff. Please make sure to clean the electric heater regularly when it is not powered on. *Please DO NOT install electric heaters next to windows with curtains to prevent electric shock or fire. Warning: - 03 - *Please DO NOT use frosted materials to clean the electric heater. The electric heater can be cleaned with a cloth soaked in hot soapy water and wrung out. Before cleaning the heater, make sure that the heater is POWER OFF. *Please DO NOT switch on the power supply before the heater is fully installed or adjusted. *This dog house heater is not suitable for use in exposed outdoor or humid places. *Please DO NOT use next to bathtubs, showers, swimming pools or other liquids. *Fix the electric heater on the wall or install it in the correct position, also keep the heater upright. *Please DO NOT wind up the power cord during use to avoid heat build-up in the power cord, which may cause danger. *The power extension cord is not recommended for this electric heater. *Please make sure to cut off the power supply when the heater is not in use. *Please keep the power cord and fixed cables away from the high temperature surface of the heater. *Please DO NOT wrap the power cord somewhere or twist the power cord into a bundle, which may cause the insulator of the power cord to weaken or fail. Please make sure that the power cord does not come into contact with any sharp objects. *Please DO NOT store the heater without cooling. *Please DO NOT install the electric heater under the electrical outlet. *To avoid the possibility of electric shock or fire, please ensure that the power cord and electric heater are not exposed or immersed in rain or any other liquid. *Please use the heater in accordance with these instructions. To avoid causing fire, electric shock or injury, do not use other manufacturer's product instructions for use with this dog house heater. - 04 - Product Specifications Product List 9.1*6.4*4.7 in 230*163*118mm Safety Bolts Inlet Air Filter (Removable for cleaning) Model Number: D2303Rated Power:500W Product DimensionsRated Voltage:120V/60Hz Heater Screws Controller Hanging board Anti-fall fixing bracket Front Case Air Outlet Controller connector Temperature control probe: need to be fixed inside of the Dog house by yourself, used to detect the temperature of the dog house Temperature control probe - 05 - A D E C A: First, use the screws in the accessory bag to fix the pegboard parallel to the pre-installed position of the equipment. It is recommended that the optimal height for installation is greater than the height of the pet. D: Installation of the controller power cord: connect the power cord with the host power hole, and then tighten the nut on the power cord clockwise. E: Hang the equipment according to the corresponding holes, and the heating device can be used normally after the power is turned on. B B: Choose the best location on the wall (near the end of the power cord) and drill a hole at least 20 mm in diameter to ensure that the power cord can pass through this hole. C: Please pass the power cord through the drilled hole, and then hang the controller in a suitable place. Then hang the controller in a suitable place (the controller is waterproof to IP55, try to avoid long-term use in the rain). - 06 - Product Features Smart Wifi Function HeatingShutdown Timer Temperature Adjustment LED "+Temp." +"-Temp." Child Lock Long press to switch to C/F Short press 0-24 timing Long press WiFi reset -Temp +Temp Short press: Power switch 1, WIFI 2, Child Lock 3, Work Instructions 4, Timing - 07 - 1. Power button " " 1)In standby mode, press the power button "" (quick response) to enter the working state, the digital screen shows the ambient temperature. 2)In the working state, press the power button "" (response after release) and then enter the shutdown state. 2.Temperature …

Text truncated - open the document above for the full version.

(LesoRocity (Shenzhen) Industrial Co., Ltd) (September 11, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BCLX-D2303) [LesoRocity (Shenzhen) Industrial Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Jason Long (LesoRocity (Shenzhen) Industrial Co., Ltd) (September 11, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BCLX-D2303) [LesoRocity (Shenzhen) Industrial Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Jason Long

LesoRocity (Shenzhen) Industrial Co., Ltd (September 11, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (DOG HOUSE HEATER / D2303/ FCC ID: 2BCLX-D2303) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: Jason Long Title: Project director

LesoRocity (Shenzhen) Industrial Co., Ltd (September 11, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: Jason Long Title: Project director

External Photos

FCC ID LABEL: Label Location:

Internal Photos ANT

FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2BCLX-D2303 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna,R=20cm Test Result of RF Exposure Evaluation Modes& Channel Freq. (MHz) Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW / cm2 ) Result BLE GFSK& LCH 6±1 7 5.0119 1.4791 (1.7dBi) 0.0015 1 Pass 2.4G WIFI 802.11b&2 437 14±1 15 31.6228 1.4791 (1.7dBi) 0.0093 1 Pass

Product specification Quick Reference Date Antenna module on the system board Frequency2.45GHz *1 Ant. Port Input Pwr. (dBm ) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr . (dBm) -2.3 (Input pwr – loss pwr) Peak EIRP(dBm) 1.3 Directivity (dBi) 1 (all direction antenn a) Efficiency (dB) -2.3 (58.5%) Gain (dBi) 1.7 Maximu m Power (dBm) 1.3 (XY-plane) Minimu m Power (dBm) -4(XY-plane) Avg. Power (dBm ) -0.5(XY-plane) Max/Min Ra tio (dB) 5.3(XY-plane) Max/Avg Ratio (dB) 1.8(XY-plane) Min/Avg Ratio (dB) -3.5(XY -plane) Average Gain (dB) -0.5 (A vg Gain XY-plane) All the technical data and information contained herein are subject to change without prior notice Antenna layout on the Module board Antenna Gain Gain Ta ble Unit in dBi @2.44GHz XY-plane XZ-plane YZ-plane Ef ficiency PeakA vg. Peak Avg. Peak Avg. Module board 1.3 -0.5 1.7 -3.8 1.1 -3.0 58.5% Return Loss The Environment of Antenna Radiation Pattern 3D radiation pattern diagram XY-plane XZ-plane YZ-plane Manufacturer: Dongguan Daozong Electronic Technology Co.,Ltd Manufacturer's address: Room 202, Building 1, 16 Dongkeng Avenue North, Dongken g Town, Dongguan City, Guangdong Province, China

Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230907016RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 35 TEST REPORT Compiled by: Reviewed by: Approved by: Zhou Kui Arron Liu Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Product Name: DOG HOUSE HEATER FCC ID: 2BCLX-D2303 Trademark: N/A Model Number: D2303 Prepared For: LesoRocity (Shenzhen) Industrial Co., Ltd Address: Rm A5-02, LiJia Rd 108th, Hengang Str, Longgang, Shenzhen, China Manufacturer: Dongguan Daozong Electronic Technology Co.,Ltd Address: Room 202, Building 1, 16 Dongkeng Avenue North, Dongkeng Town, Dongguan City, Guangdong Province, China Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Aug. 21, 2023 Sample tested Date: Aug. 21, 2023 to Sep. 07, 2023 Issue Date: Sep. 07, 2023 Report No.: CTB230907016RFX Test Standards FCC Part15.247 ANSI C63.10:2013 Test Results PASS Remark: This is Bluetooth radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230907016RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 35 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ........................................................................................................................................ 3 2. TEST SUMMARY ........................................................................................................................... 4 3. MEASUREMENT UNCERTAINTY ................................................................................................. 5 4. PRODUCT INFORMATION AND TEST SETUP ............................................................................ 6 4.1 Product Information .......................................................................................................................... 6 4.2 Test Setup Configuration .................................................................................................................. 6 4.3 Support Equipment........................................................................................................................... 6 4.4 Channel List ..................................................................................................................................... 7 4.5 Test Mode ........................................................................................................................................ 7 4.6 Test Environment ............................................................................................................................. 7 5. TEST FACILITY AND TEST INSTRUMENT USED ....................................................................... 8 5.1 Test Facility ...................................................................................................................................... 8 5.2 Test Instrument Used ....................................................................................................................... 8 6. AC POWER LINE CONDUCTED EMISSION ................................................................................ 10 6.1 Block Diagram Of Test Setup ......................................................................................................... 10 6.2 Limit ................................................................................................................................................ 10 6.3 Test procedure ............................................................................................................................... 10 6.4 Test Result ..................................................................................................................................... 12 7. RADIATED SPURIOUS EMISSION ............................................................................................. 14 7.1 Block Diagram Of Test Setup ......................................................................................................... 14 7.2 Limit ................................................................................................................................................ 14 7.3 Test procedure ............................................................................................................................... 15 7.4 Test Result ..................................................................................................................................... 16 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS ............................................... 23 8.1 Block Diagram Of Test Setup ......................................................................................................... 23 8.2 Limit ................................................................................................................................................ 23 8.3 Test procedure ............................................................................................................................... 23 8.4 Test Result ..................................................................................................................................... 24 9. COUDUCTED OUTPUT POWER ................................................................................................. 26 9…

Text truncated - open the document above for the full version.

Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230907017RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 54 TEST REPORT Compiled by: Reviewed by: Approved by: Zhou Kui Arron Liu Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Product Name: DOG HOUSE HEATER FCC ID: 2BCLX-D2303 Trademark: N/A Model Number: D2303 Prepared For: LesoRocity (Shenzhen) Industrial Co., Ltd Address: Rm A5-02, LiJia Rd 108th, Hengang Str, Longgang, Shenzhen, China Manufacturer: Dongguan Daozong Electronic Technology Co.,Ltd Address: Room 202, Building 1, 16 Dongkeng Avenue North, Dongkeng Town, Dongguan City, Guangdong Province, China Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Aug. 21, 2023 Sample tested Date: Aug. 21, 2023 to Sep. 07, 2023 Issue Date: Sep. 07, 2023 Report No.: CTB230907017RFX Test Standards FCC Part15.247 ANSI C63.10:2013 Test Results PASS Remark: This is WIFI-2.4GHz band radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230907017RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 54 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ........................................................................................................................................ 3 2. TEST SUMMARY ........................................................................................................................... 4 3. MEASUREMENT UNCERTAINTY ................................................................................................. 5 4. PRODUCT INFORMATION AND TEST SETUP ............................................................................ 6 4.1 Product Information .......................................................................................................................... 6 4.2 Test Setup Configuration .................................................................................................................. 6 4.3 Support Equipment........................................................................................................................... 6 4.4 Channel List ..................................................................................................................................... 7 4.5 Test Mode ........................................................................................................................................ 7 4.6 Test Environment ............................................................................................................................. 7 5. TEST FACILITY AND TEST INSTRUMENT USED ....................................................................... 8 5.1 Test Facility ...................................................................................................................................... 8 5.2 Test Instrument Used ....................................................................................................................... 8 6. AC POWER LINE CONDUCTED EMISSION ................................................................................ 10 6.1 Block Diagram Of Test Setup ......................................................................................................... 10 6.2 Limit ................................................................................................................................................ 10 6.3 Test procedure ............................................................................................................................... 10 6.4 Test Result ..................................................................................................................................... 12 7. RADIATED SPURIOUS EMISSION ............................................................................................. 14 7.1 Block Diagram Of Test Setup ......................................................................................................... 14 7.2 Limit ................................................................................................................................................ 14 7.3 Test procedure ............................................................................................................................... 15 7.4 Test Result ..................................................................................................................................... 16 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS ............................................... 33 8.1 Block Diagram Of Test Setup ......................................................................................................... 33 8.2 Limit ................................................................................................................................................ 33 8.3 Test procedure ............................................................................................................................... 33 8.4 Test Result ..................................................................................................................................... 34 9. COUDUCTED OUTPUT POWER ...............................................................................................…

Text truncated - open the document above for the full version.

Radiated Emission Below 1G Above 1G Conducted emissions
