2BCMG-BRAVE8LITEAction Camera

V77_V2.0 USER MANUAL ACTION CAMERA 01050607 0809101112131415 1617181920212223 2526272829303132 3435363738394041 4344454647484950 5253545556575859 60616201 42 33 51 24 020304 EN Brave 8 Lite Important Messages ------------------------------------------------------------------ 04 Micro SD Card Use -------------------------------------------------------------------- 05 IPX8 Waterproof Rating -------------------------------------------------------------- 06 Notes on Using the Waterproof Housing ------------------------------------------- 06 1. Specifications ----------------------------------------------------------------------- 08 2. What’s in the Box------------------------------------------------------------------- 09 3. Your Brave 8 Action Camera -------------------------------------------------------10 4. First Use ------------------------------------------------------------------------------ 11 (1) Installing the Battery------------------------------------------------------------- 11 (2) Charging the Camera ----------------------------------------------------------- 11 (3) Installing the Memory Card----------------------------------------------------- 12 (4) Formatting the Memory Card -------------------------------------------------- 12 5. Getting Started ----------------------------------------------------------------------13 (1) Powering on and off ------------------------------------------------------------- 13 (2) Preview Screen------------------------------------------------------------------- 13 (3) Button Operation Overview ---------------------------------------------------- 14 (4) Indicator Overview -------------------------------------------------------------- 14 (5) Using the Shutter Button ------------------------------------------------------- 15 (6) Quickly Switching Capture Modes--------------------------------------------- 15 (7) Switching Screens --------------------------------------------------------------- 16 (8) Zooming in or out---------------------------------------------------------------- 16 (9) Turning Audio Recording on or off--------------------------------------------- 17 (10) Accessing Quick Capture Settings -------------------------------------------- 17 (11) Accessing the Album ----------------------------------------------------------- 19 (12) Quick Operation Guide-------------------------------------------------------- 20 Contents 01050607 0809101112131415 1617181920212223 2526272829303132 3435363738394041 4344454647484950 5253545556575859 60616201 42 33 51 24 020304 6. Accessing the Quick Menu ---------------------------------------------------------21 (1) Using Voice Control-------------------------------------------------------------- 21 (2) Using Screen Lock ---------------------------------------------------------------22 (3) Adjusting Screen Brightness----------------------------------------------------22 (4) Adjusting the Volume Level ----------------------------------------------------23 (5) Using Grid ------------------------------------------------------------------------23 (6) Using the Device’s Wifi----------------------------------------------------------23 (7) Using Orientation Lock ----------------------------------------------------------24 (8) Using One-Click Quick Shot ----------------------------------------------------24 (9) Selecting Metering Mode-------------------------------------------------------24 (10) Turning Wind Reduction on or off --------------------------------------------24 (11) Turning Distortion Calibration on or off---------------------------------------25 (12) Using Timed Capture -----------------------------------------------------------25 (13) Turning Driving Mode on or off -----------------------------------------------25 (14) Accessing System Settings ----------------------------------------------------25 7. Recording Video -------------------------------------------------------------------- 26 (1) Switching Video Modes ---------------------------------------------------------26 (2) Overview of Video Modes ------------------------------------------------------26 (3) Video Settings -------------------------------------------------------------------27 (4) Video Settings Menu ------------------------------------------------------------32 8. Taking Photos ----------------------------------------------------------------------- 34 (1) Switching Photo Modes -------------------------------------------------------- 34 (2) Overview of Photo Modes ----------------------------------------------------- 34 (3) Photo Settings -------------------------------------------------------------------35 (4) Photo Settings Menu ------------------------------------------------------------37 9. Customizing Your Brave 8 Lite-------------------------------------------------- 38 (1) Configuring System Settings -------------------------------------------------- 38 (2) Configuring General Settings -------------------------------------------------- 41 01050607 0809101112131415 1617181920212223 2526272829303132 3435363738394041 4344454647484950 5253545556575859 60616201 42 33 51 24 020304 EN 10. Album ------------------------------------------------------------------------------- 43 (1) Accessing the Album ------------------------------------------------------------43 (2) Overview of the Album Screen-------------------------------------------------43 (3) Playing Back Files on the Camera --------------------------------------------- 44 (4) Deleting Files on the Camera ------------------------------------------------- 44 11. Data Transmission------------------------------------------------------------------ 46 (1) Transferring Files to a Computer ---------------------------------------------- 46 (2) Using Brave 8 as a Web Camera ---------------------------------------------- 46 12. Using the Camera’s Wifi & AKASO App----------------------------------------- 47 (1) Features of the Camera’s Wifi -------------------------------------------------- 4…

Text truncated - open the document above for the full version.

Shenzhen Cnest Electronic Technology Co., Ltd. Covered Equipment Certification Attestation Letter 1/30/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BCMG-BRAVE8LITE Shenzhen Cnest Electronic Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Shenzhen Cnest Electronic Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Shenzhen Cnest Electronic Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). <Signature>: Name: lijunfu Title: Manager Company: Shenzhen Cnest Electronic Technology Co., Ltd. Date: 1/30/2026

Shenzhen Cnest Electronic Technology Co., Ltd. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 1/30/2026 TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTN.: Reviewing Engineer FCC ID: 2BCMG-BRAVE8LITE FRN of applicant: 0034161513 Per section 2.911(d)(7) of the FCC rules, [Shenzhen Cnest Electronic Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Herland International Trading Inc FCC Registration Number (FRN): 0036324101 Physical U.S. Company Address: 1370 Valley Vista Dr Ste 200 Diamond Bar, CA 91765 Contact Person: Jianfeng Gao Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: lijunfu Title: Manager Company Name: Shenzhen Cnest Electronic Technology Co., Ltd. Date: 1/30/2026 Agent Signed (if different from Applicant): Signed: Printed name: Jianfeng Gao Title: Manager Company Name: Herland International Trading Inc Date: 1/30/2026

Shenzhen Cnest Electronic Technology Co., Ltd. FCC ID: 2BCMG-BRAVE8LITE Product Similarity Declaration Applicant: Shenzhen Cnest Electronic Technology Co., Ltd. Address: Room 701, Building 3, Shenzhen New Generation Industrial Park, 136 Zhongkang Road, Futian District, Shenzhen, Guangdong, China Manufacturer: Shenzhen Cnest Electronic Technology Co., Ltd. Address: Room 701, Building 3, Shenzhen New Generation Industrial Park, 136 Zhongkang Road, Futian District, Shenzhen, Guangdong, China Product Name: Action Camera Trade Mark: AKASO Model Number: Brave 8 Lite, Brave 4, Brave 4 Sport, Brave 7 LE Sport, Brave 8, Brave 8 Sport, EK7000 Sport, EK7000 Pro Sport, V50 Elite, V50 X, V50 Pro, Brave 7 We (Shenzhen Cnest Electronic Technology Co., Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), All models are the same as the samples except for the model name, appearance color. <Signature>: Name: lijunfu Title: Manager Company: Shenzhen Cnest Electronic Technology Co., Ltd.

Shenzhen Cnest Electronic Technology Co., Ltd. 2026-01-30 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen DL Testing Technology Co., Ltd.（101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China）to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Shenzhen Cnest Electronic Technology Co., Ltd.（Room 701, Building 3, Shenzhen New Generation Industrial Park, 136 Zhongkang Road, Futian District, Shenzhen, Guangdong, China） <Signature>: Name: lijunfu Title: Manager Company: Shenzhen Cnest Electronic Technology Co., Ltd.

Shenzhen Cnest Electronic Technology Co., Ltd. 2026-01-30 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature>: Name: lijunfu Title: Manager Company: Shenzhen Cnest Electronic Technology Co., Ltd.

Shenzhen Cnest Electronic Technology Co., Ltd. 2026-01-30 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BCMG-BRAVE8LITE Product Name: Action Camera Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>: Name: lijunfu Title: Manager Company: Shenzhen Cnest Electronic Technology Co., Ltd.

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) Model Number: Brave 8 Lite Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size: 20*30mm Model.: Brave 8 Lite FCC ID: 2BCMG-BRAVE8LITE Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) Model Number: Brave 8 Lite Shenzhen DL Testing Technology Co., Ltd. ANT Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

FCC ID: 2BCMG-BRAVE8LITE RF Exposure Evaluation According to KDB 447498 D01 V06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, BLE Peak Output Power (dBm) Max tune-up (mW) Frequency (MHz) Min. distance(mm) Calc. thresholds limit -2.48 0.6 2440 5 0.18 3.0 WiFi 2.4G Peak Output Power (dBm) Max tune-up (mW) Frequency (MHz) Min. distance(mm) Calc. thresholds limit 5.94 3.9 2462 5 1.23 3.0 WiFi 5G Peak Output Power (dBm) Max tune-up (mW) Frequency (MHz) Min. distance(mm) Calc. thresholds limit 5.19 3.3 5240 5 1.51 3.0 For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits =0.18/3 + 1.23/3 + 1.51/3 = 0.97< 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations. So a SAR test is not required

Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251211027R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 45 FCC Part 15C Test Report FCC ID: 2BCMG-BRAVE8LITE Applicant: Shenzhen Cnest Electronic Technology Co., Ltd. Address: Room 701, Building 3, Shenzhen New Generation Industrial Park, 136 Zhongkang Road, Futian District, Shenzhen, Guangdong, China Manufacturer: Shenzhen Cnest Electronic Technology Co., Ltd. Address: Room 701, Building 3, Shenzhen New Generation Industrial Park, 136 Zhongkang Road, Futian District, Shenzhen, Guangdong, China Product Name: Action Camera Trade Mark: AKASO Model Number: Brave 8 Lite, Brave 4, Brave 4 Sport, Brave 7 LE Sport, Brave 8, Brave 8 Sport, EK7000 Sport, EK7000 Pro Sport, V50 Elite, V50 X, V50 Pro, Brave 7 Date of Receipt: Dec. 11, 2025 Test Date: Dec. 11, 2025 - Dec. 30, 2025 Date of Report: Dec. 30, 2025 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2020 Test Result: Pass Report Number: DLE-251211027R Prepared (Test Engineer): Randy Xie Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251211027R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 45 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 22 3.3.1 TEST REQUIREMENT: 22 3.3.2 TEST PROCEDURE 22 3.3.3 DEVIATION FROM TEST STANDARD 23 3.3.4 TEST SETUP 23 3.3.5 EUT OPERATING CONDITIONS 23 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 27 3.4.1 APPLICABLE STANDARD 27 3.4.2 TEST PROCEDURE 27 3.4.3 DEVIATION FROM STANDARD 27 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251211027R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 45 Table of Contents Page 3.4.4 TEST SETUP 27 3.4.5 EUT OPERATION CONDITIONS 27 3.4.6 TEST RESULTS 27 4 . AVERAGE OUTPUT POWER 31 4.1 APPLIED PROCEDURES / LIMIT 31 4.1.1 TEST PROCEDURE 31 4.1.2 DEVIATION FROM STANDARD 31 4.1.3 TEST SETUP 31 4.1.4 EUT OPERATION CONDITIONS 31 4.1.5 TEST RESULTS 32 5 . POWER SPECTRAL DENSITY TEST 35 5.1 APPLIED PROCEDURES / LIMIT 35 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 35 5.1.4 EUT OPERATION CONDITIONS 35 5.1.5 TEST RESULTS 36 6 . 6DB BANDWIDTH TEST 39 6.1 APPLIED PROCEDURES / LIMIT 39 6.1.1 TEST PROCEDURE 39 6.1.2 DEVIATION FROM STANDARD 39 6.1.3 TEST SETUP 39 6.1.4 EUT OPERATION CONDITIONS 39 6.1.5 TEST RESULTS 40 7 . ANTENNA REQUIREMENT 45 7.1 STANDARD REQUIREMENT 45 7.2 EUT ANTENNA 45 8 . TEST SEUUP PHOTO 45 9 . EUT PHOTO 45 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251211027R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 45 1.. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.205, 15.209, 15.247(d) Radiated Spurious Emission PASS 15.209, 15.205 Band Edge Emission PASS 15.247(d) Conducted Spurious Emissions PASS 15.247(b) Average Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1. MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2% 9 Power Spectral Density ±2.45dBm Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251211027R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 45 2.. GENERAL INFORMATION 2.1. GENERAL DESCRIPTION OF EUT Product Name: Action Camera Trade Mark: AKASO Model Number: Brave 8 Lite, Brave 4, Brave 4 Sport, Brave 7 LE Sport, Brave 8, Brave 8 Sport, EK7000 Sport, EK7000 Pro Sport, V50 Elite, V50 X, V50 Pro, Brave 7 Test Model: Brave 8 Lite Model Difference: All models are sa…
