2BDLE-HT-10A2.4G radio remote control
Shenzhen HOTRC Technology Co., Ltd
Click to zoom
Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Sep 30, 2025
- Application Purpose
- Original Equipment
- Equipment Note
- 2.4G radio remote control
- Frequency Range
- 2402.00000000 - 2480.00000000
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harm full interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specific Absorption Rate (SAR) information: This Device meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: Device has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the device kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain an 0mm separation distance between the user's body and the back of the device. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.
External Photos
FCC ID:2BDLE-HT-10A External Photos of the EUT FCC ID:2BDLE-HT-10A FCC ID:2BDLE-HT-10A
ID Label/Location Info
Label and Location Size: L: 4.0cm*W: 2.0cm Label and Location FCC ID:2BDLE-HT-10A
Internal Photos
FCC ID:2BDLE-HT-10A Internal Photos of the EUT FCC ID:2BDLE-HT-10A FCC ID:2BDLE-HT-10A FCC ID:2BDLE-HT-10A ANT FCC ID:2BDLE-HT-10A FCC ID:2BDLE-HT-10A
RF Exposure Info
Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] S T L A B S SAR Dipole Performance Measurement Report EUT Type： SAR Validation Dipole and Waveguide Model Name： DIP2G450 Brand Name: SATIMO Test Conclusion： Pass Test Date： 11 Dec. 2024&03 Jul. 2025 Date of Issue： 03 Jul. 2025 Testing Engineer : (Xin.Liu) Technical Manager : (Shifan. Long) Authorized Signatory : (Bovey Yang) ISSUED BY Shenzhen STS Test Services Co., Ltd. Kind of Equipment Manufacturer Type No. Serial No. Last Calibration Calibrated Until PC Acer N/A N/A N/A N/A E-Field Probe MVG SSE2 SN 08/21 EPGO352 2024.09.18 2025.09.17 Dielectric Probe Kit MVG SCLMP SN 32/14 OCPG67 2024.09.18 2025.09.17 Phantom1 MVG SAM SN 32/14 SAM115 N/A N/A Phantom2 MVG SAM SN 32/14 SAM116 N/A N/A Attenuator Agilent 99899 DC-18GHz N/A N/A Directional coupler Narda 4226-20 3305 N/A N/A Network Analyzer Agilent E5071C MY46520378 2024-09-25 2025-09-26 Multi Meter Keithley Multi Meter 2000 4050073 2024-09-25 2025-09-26 Signal Generator Agilent N5182A MY50140530 2024-09-25 2025-09-26 Power Amplifier DESAY ZHL-42W 9638 2024-09-25 2025-09-26 Power Meter R&S NRP 100510 2024-09-25 2025-09-26 Power Sensor R&S NRP-Z11 101919 2024-09-25 2025-09-26 Power Sensor Keysight U2021XA MY56280002 2024-09-25 2025-09-26 Temperature hygrometer SuWei SW-108 N/A 2024.10.15 2025.10.14 Thermograph Elitech RC-4 S/N EF7176501537 2024.10.15 2025.10.14 ISSUED BY Shenzhen STS Test Services Co., Ltd. 2. <Justification of the extended calibration> Referring to KDB 865664 D01, if dipoles are verified in return loss<-20dB, (within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head 2450 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2023.07.04 -26.03 - 46.3 - 2024.07.01 -26.42 1.50 47.25 2.05 2025.07.03 -26.91 3.38 47.4 2.37 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 2450 MHz
RF Exposure Info
!!"#$% &# '()$*+ %& ,-$ +".! !/0 .$'12 !",3 , "0& 456789:;<7=<8>?@AB?CA:@DE8FDE8:CD?8< G ,!"G"0 &" G !H) %&/ "* 0%"#I2J(-'/,"KL- !MNOPQMRSTMRG , # #TSNMUVOWRSTXTOMPNS SYZWVU[NS*QS\R QVO\S]-1LM^SWXS0NS_O\TS VYZVW -1-J2/%"+ 0H) 0! !MNOPQMROVWTMRSI21('J(-2-` aab cdefedghijklm agn fofdpfqp ghrrrag bfa b ZSX\SVsRZS!VsQMYPQMWTMWTRZSMYYQSTORMROVWQSsSQSWYS\O\UQVZOPORSTsQVtMWuQSUQVTXYROVW# vwxxyz {|dicga}~ henb i heie| ~ e|gcfhcb i}pei bg~fhfaab cde c gid~ ebdakd pc bgq afpdqbfedghn b gb~ cfe }idhe| e ieq ha| gb}i rde|f iie ~ghp{| e ieb i}peiago b cqfaab cdefedghfb ebfa fqp ege| he bhfedghfp ie ~g hdei !"G "0 H)OSNT/QVPS!MNOPQMROVW SUVQR !"#$ %&'( )*+,-./*0123455546477489:;4<==>?02@8@=13 ABCD* E8 FGHI JKLMN#OP IG!QQ OKP R# S#TSKJML#JU #VL#TP HO WMQQ KS HO T!SPU XHPGKMP PG# XSHPP#O !TTSKY!Q KW Z[\] FG# HOWKSN!PHKO LKOP!HO#J G#S#HO HI PK R# MI#J KOQ^ WKS PG# TMSTKI# WKS XGHLG HP HI IMRNHPP#J !OJ HI OKP PK R# S#Q#!I#J HO XGKQ# KS T!SP XHPGKMP XSHPP#O !TTSKY!Q KW Z[\] _!N# `MOLPHKO a!P# bH"O!PMS# S#T!S#J R^ $ cdef ghi jklgemno lpfnlhqr st tu vG#Lw#J x !TTSKY#J R^$ yze{m |g} ~}nh}kr jknke st tu MPGKSH#J R^$ knn ~fgokhn |kqfekofe he}ofe vMIPKN#S _!N# aHIPSHRMPHKO $ nin ~ ~lo eh}l f |od IIM# _!N# a!P# ZKJHWHL!PHKOI cdef ghi st tu nhohkr erkl ¡ ¢£££¤ ¥¦¦ !"#$ %&'( )*+,-./*0123455546477489:;4<==>?02@8@=13 ABCD* E8 FGHI JKLMN#OP IG!QQ OKP R# S#TSKJML#JU #VL#TP HO WMQQ KS HO T!SPU XHPGKMP PG# XSHPP#O !TTSKY!Q KW Z[\] FG# HOWKSN!PHKO LKOP!HO#J G#S#HO HI PK R# MI#J KOQ^ WKS PG# TMSTKI# WKS XGHLG HP HI IMRNHPP#J !OJ HI OKP PK R# S#Q#!I#J HO XGKQ# KS T!SP XHPGKMP XSHPP#O !TTSKY!Q KW Z[\] _ `abc d efg hij kglfmcj ` icgbnjble _ oe gpq relgspjble ttttttttttttttttttttttttttttttttttttttttttttttttttttttt u vpimgs ej vjwlf u_ ei bjbabjx ttttttttttttttttttttttttttttttttttttttttttttttttttttttttttttttt u ybe pgbjx tttttttttttttttttttttttttttttttttttttttttttttttttttttttttttttttt z uu riljg lnx ttttttttttttttttttttttttttttttttttttttttttttttttttttttttttttttttt z u lm efpgx cj tttttttttttttttttttttttttttttttttttttttttttttttttttttttttt z uz kgl{ vlfmqpjble inlei ttttttttttttttttttttttttttttttttttttttttttttttttt vpimgs ej decgjpbejx z pqb{gpjbl e imqji z_ pqb {gpjble be pbg tttttttttttttttttttttttttttttttttttttttttttttttttttttttttt z pqb {gpjble be qb|mbf ttttttttttttttttttttttttttttttttttttttttttttttttttttttt } ~gbbcpjb le imqji } ybij l | mbnsej !"#$ %&'( )*+,-./*0123455546477489:;4<==>?02@8@=13 ABCD* E8 FGHI JKLMN#OP IG!QQ OKP R# S#TSKJML#JU #VL#TP HO WMQQ KS HO T!SPU XHPGKMP PG# XSHPP#O !TTSKY!Q KW Z[\] FG# HOWKSN!PHKO LKOP!HO#J G#S#HO HI PK R# MI#J KOQ^ WKS PG# TMSTKI# WKS XGHLG HP HI IMRNHPP#J !OJ HI OKP PK R# S#Q#!I#J HO XGKQ# KS T!SP XHPGKMP XSHPP#O !TTSKY!Q KW Z[\] _ ` a bcdefc ghicj kclm nopq rst uvu nu wv rw xw yn zu v{|}{q~} v v p{ } zu z}q~ |p~p| | } x}|qs {| z p~{|q r npt {~ ||q~ npt v npt v npt v a y w xuvrwu ¡ ¢££¤¥¦ § ̈©ª«¬ ® ̄°ª¡ ±®ª °²©«³ © ́ ±μμ ̄®¬± ́μª ³ ̄ ³¶ª w w {| x ·n n ~{|{ ̧¹º»¼ _ ½ Z[\ ¾¿Z¿ÀÁ ÃKIHN#PSHL Ä WH#QJ SKR# z y| ~ y|~ w|pop}{ npt v{Åp} Å~|{ p{~ z rpt Å~|{ np{~ np~{|q ~| pt t Å~p~s Æ a Ç r w w {| x ·n n ~{|{ top q| t{q~pq ~ t q{p {~p|È p|q}p| ~ t{|q q{{q~p~pq p|~~ {| ~ s pq ~ { ~p q~ q{p{~p| {}|~ t ~ ~ |~p| ~{|{ wrwwrÉ r |p~pop~s {q~ ~ ~ pt ~p| }p| { ~ ~t q{p{~p| ~ {p {| ~p} p }{~p| p}p }p| {o}p { }~p| p| ~ ~{|{ }|qs {| v {| }p| ~ q{p~ q ~ ~{| ~ { }~p| p| ~ ~{|{ }|qs v …
Text truncated - open the document above for the full version.
RF Exposure Info
The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. SAR Test Report Report No.: STS2509109H01 Issued for Shenzhen HOTRC Technology Co., Ltd 2nd Floor, Building 3, Yibaolai Industrial City, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Product Name: 2.4G radio remote control Brand Name: N/A Model Name: HT-10A Series Model(s): F-10A FCC ID: 2BDLE-HT-10A Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 (2.1093) IEEE Std. 1528-2013 Max. Report SAR (1g) Body: 1.115 W/kg Page 2 of 38 Report No.: STS2509109H01 TEST REPORT CERTIFICATION Applicant’s name ................. : Shenzhen HOTRC Technology Co., Ltd Address ................................. : 2nd Floor, Building 3, Yibaolai Industrial City, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Manufacturer's Name .......... : Shenzhen HOTRC Technology Co., Ltd Address ................................. : 2nd Floor, Building 3, Yibaolai Industrial City, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Product description Product name ........................ : 2.4G radio remote control Brand name ......................... : N/A Model name ......................... : HT-10A Series Model(s) : .................... F-10A Standards ............................. : ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 (2.1093) IEEE Std. 1528-2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 06 Sep. 2025 Date of Issue .......................................... : 23 Sep. 2025 Test Result.............................................. : Pass Testing Engineer : (Xin.Liu) Technical Manager : (Shifan. Long) Authorized Signatory : (Bovey Yang) Page 3 of 38 Report No.: STS2509109H01 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test Standards and Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 14 5.1 Validation System 14 5.2 Validation Result 14 6. SAR Evaluation Procedures 15 7. EUT Antenna Location Sketch 16 7.1 SAR test exclusion consider table 17 8. EUT Test Position 20 8.1 Body-worn Position Conditions 20 9. Uncertainty 21 9.1 Measurement Uncertainty 21 10. Conducted Power Measurement 24 10.1 Test Result 24 11. EUT and Test Setup Photo 25 11.1 EUT Photo 25 11.2 Setup Photo 28 12. SAR Result Summary 31 12.1 Body SAR 31 12.2 Repeated SAR 32 12.3 Repeated SAR measurement 32 13. Equipment List 33 Appendix A. System Validation Plots 34 Appendix B. SAR Test Plots 36 Appendix C. Probe Calibration and Dipole Calibration Report 38 Page 4 of 38 Report No.: STS2509109H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 23 Sep. 2025 STS2509109H01 ALL Initial Issue Page 5 of 38 Report No.: STS2509109H01 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name 2.4G radio remote control Brand Name N/A Model Name HT-10A Series Model F-10A Model Difference The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. Sample number 250915010-1 Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version V1.0 Software Version V1.0 Frequency Range 2.4G: 2402 MHz ~ 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance: Body:0mm Band Mode Body Worn (W/kg) DSS 2.4G 1.115 Limit 1.6W/kg FCC Equipment Class Part 15 Spread Spectrum Transmitter (DSS) Antenna Specification: 2.4G: External antenna Hotspot Mode Not Support DTM Mode Not Support Page 6 of 38 Report No.: STS2509109H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory ShenZhen STS Test Services Co.,Ltd. 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub- District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration No.: 625569 IC Registration No.: 12108A A2LA Certificate No.: 4338.01 Page 7 of 38 Report No.: STS2509109H01 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 IEEE Std C95.1, 2019 IEEE Standard for Safety Levels with Respect to Human Exposure to Electric,Magnetic, and Electromagnetic Fields,0 Hz to 300 GHz. It specifies the maximum exposure limit of 1.6 W/kg as averaged over any 1 gram of tissue for portable devices being used within 20 cm of the user in the uncontrolled environment. 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial- Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D04 v01 RF Exposure Procedures and Equipment Authorization Policies for Mobile and Portable Devices 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r02 RF Exposure Reporting 7 FCC KDB 941225 D07 v01r02 UMPC Mini Tablet (A). Limits for Occupational/Con…
Text truncated - open the document above for the full version.
Test Report
1. Antenna Description: Antenna type External antenna Model HT-10A Frequency range 2400-2500MHz Manufacturer Shenzhen HOTRC Technology Co., Ltd Address 2nd Floor, Building 3, Yibaolai Industrial City, Qiaotou Community, Fuhai Street, Bao'an District, Shenzhen, China ANT Peak Gain 2.0 dBi 2. Antenna Photo: 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz
Test Report
Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. ........................................... : CTA25052301901 2BDLE-HT-10A Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Sep. 10, 2025 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ........................... : Shenzhen HOTRC Technology Co., Ltd Address ............................................ : 2nd Floor, Building 3, Yibaolai Industrial City, Qiaotou Community, Fuhai Street, Bao'an District, Shenzhen, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : 2.4G radio remote control Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen HOTRC Technology Co., Ltd Model/Type reference ...................... : HT-10A Listed Models ................................... : F-10A Modulation ....................................... : GFSK Frequency ......................................... From 2402MHz to 2480MHz Ratings ............................................. : 6.0V 0.5A (4X1.5VAA dry batteries) Result ............................................... : PASS Report No.: CTA25052301901 Page 2 of 28 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : 2.4G radio remote control Model /Type : HT-10A Listed Models : F-10A Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. Applicant : Shenzhen HOTRC Technology Co., Ltd Address : 2nd Floor, Building 3, Yibaolai Industrial City, Qiaotou Community, Fuhai Street, Bao'an District, Shenzhen, China Manufacturer : Shenzhen HOTRC Technology Co., Ltd Address : 2nd Floor, Building 3, Yibaolai Industrial City, Qiaotou Community, Fuhai Street, Bao'an District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25052301901 Page 3 of 28 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS .......................................................................................................................................... 4 2 SUMMARY ........................................................................................................................................................ 5 2.1 General Remarks .................................................................................................................................... 5 2.2 Product Description ................................................................................................................................. 5 2.3 Equipment Under Test ............................................................................................................................ 5 2.4 Short description of the Equipment under Test (EUT) ............................................................................ 5 2.5 EUT configuration .................................................................................................................................... 5 2.6 EUT operation mode ............................................................................................................................... 6 2.7 Block Diagram of Test Setup .................................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) .............................................................................................................. 6 2.9 Modifications ........................................................................................................................................... 6 3 TEST ENVIRONMENT ...................................................................................................................................... 7 3.1 Address of the test laboratory ................................................................................................................. 7 3.2 Test Facility ..............................................................…
Text truncated - open the document above for the full version.
Test Report
1 FCC Appendix RF Test Data FCC ID : 2BDLE-HT-10A Company : Shenzhen HOTRC Technology Co., Ltd EUT : 2.4G radio remote control Model Number : HT-10A Report No. : CTA25052301901 Reviewed By : Eric Wang 2 Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Freq(MHz) 20dB EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 2.4G Ant1 2402 0.948 2401.550 2402.498 --- --- 2441 0.951 2440.544 2441.495 --- --- 2480 0.963 2479.541 2480.504 --- --- 3 Test Graphs 2.4G_Ant1_2402 2.4G_Ant1_2441 2.4G_Ant1_2480 4 5 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 2.4G Ant1 2402 0.87524 2401.5702 2402.4455 --- --- 2441 0.87827 2440.5701 2441.4484 --- --- 2480 0.87212 2479.5708 2480.4429 --- --- 6 Test Graphs 2.4G_Ant1_2402 2.4G_Ant1_2441 2.4G_Ant1_2480 7 8 Appendix C: Maximum conducted output power Test Result Peak Test Mode Antenna Freq(MHz) Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict 2.4G Ant1 2402 14.76 ≤20.97 PASS 2441 14.57 ≤20.97 PASS 2480 14.49 ≤20.97 PASS 9 Appendix D: Carrier frequency separation Test Result TestMode Antenna Freq(MHz) Result[MHz] Limit[MHz] Verdict 2.4G Ant1 Hop 0.992 ≥0.963 PASS 10 Test Graphs 2.4G_Ant1_Hop 11 Appendix E: Time of occupancy Test Result TestMode Antenna Freq(MHz) BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict 2.4G Ant1 Hop 2.890 98 0.283 ≤0.4 PASS 12 Test Graphs 2.4G_Ant1_Hop 13 Appendix F: Number of hopping channels Test Result TestMode Antenna Freq(MHz) Result[Num] Limit[Num] Verdict 2.4G Ant1 Hop 79 ≥15 PASS 14 Test Graphs 2.4G_Ant1_Hop 15 Appendix G: Band edge measurements Test Result TestMode Antenna ChName Freq(MHz) RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 2.4G Ant1 Low 2402 14.30 -42.65 ≤-5.7 PASS High 2480 14.18 -49.11 ≤-5.82 PASS Low Hop_2402 13.18 -49.58 ≤-6.82 PASS High Hop_2480 14.19 -51.93 ≤-5.81 PASS 16 Test Graphs 2.4G_Ant1_Low_2402 2.4G_Ant1_High_2480 2.4G_Ant1_Low_Hop_2402 17 2.4G_Ant1_High_Hop_2480 18 Appendix H: Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 2.4G Ant1 2402 Reference 13.91 13.91 --- PASS 30~1000 13.91 -56.94 ≤-6.09 PASS 1000~26500 13.91 -27.92 ≤-6.09 PASS 2441 Reference 14.44 14.44 --- PASS 30~1000 14.44 -56.55 ≤-5.56 PASS 1000~26500 14.44 -28.43 ≤-5.56 PASS 2480 Reference 13.51 13.51 --- PASS 30~1000 13.51 -55.69 ≤-6.49 PASS 1000~26500 13.51 -30.21 ≤-6.49 PASS 19 Test Graphs 2.4G_Ant1_2402_0~Reference 2.4G_Ant1_2402_30~1000 2.4G_Ant1_2402_1000~26500 20 2.4G_Ant1_2441_0~Reference 2.4G_Ant1_2441_30~1000 21 2.4G_Ant1_2441_1000~26500 2.4G_Ant1_2480_0~Reference 2.4G_Ant1_2480_30~1000 22 2.4G_Ant1_2480_1000~26500 23 Appendix I: Duty Cycle Test Result TestMode Antenna Freq(MHz) ON Time [ms] Period [ms] DC [%] xFactor Limit Verdict 2.4G Ant1 2402 2.91 3.75 77.60 1.10 --- --- 2441 2.91 3.75 77.60 1.10 --- --- 2480 2.91 3.75 77.60 1.10 --- --- 24 Test Graphs 2.4G_Ant1_2402 2.4G_Ant1_2441 2.4G_Ant1_2480 25
Test Setup Photos
FCC ID:2BDLE-HT-10A Test Setup Photos of the EUT
Test Setup Photos
SAR Setup photos Body Back Side Antenna Horizontal (separation distance is 0mm) BodyTop SideAntenna Vertical (separation distance is 0mm) Body Back Side Antenna Vertical (separation distance is 0mm) BodyTop Side Vertical (separation distance is 0mm)
Contact Information
Applicant
Linlin Xi(Manager)
[email protected]Fax: /
Test Firm
SHENZHEN CTA TESTING TECHNOLOGY CO., LTD.Eric Wang
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 29.90 mW |
