2BDOG-TAC-150Fast Wireless Charging Holder

Instructions Fast Wireless Charging Holder Please read the instructions carefully before using Parameters: Magnetic charging head Attentions 1. Please use the product correctly according instructions. 4. Please do not put wireless charger close to cards with magnetic stripes or chips (ID card,credit card etc.) to avoid demagnetization 5. Please keep wireless charger at least 20 CM distance away from implantable medical device (heart pacemaker, Implantable cochlea etc.) to avoid potential interferences. 6. Please do safekeeping, do not let your kids treat wireless charger as toy to avoid unwanted accidents. The pictures only supplies the reference, please take the actual product as the standard. 2. Please do not disassemble the product or throw it to re and water, to avoid leakage that caused by electrical short circuit. 3. Please do not use wireless charger in high temperature, wet, corrosive environment, to avoid leakage that caused by damaged circuit. FCC Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. Any changes or modications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC ID: 2BDOG-TAC-150 FCC WARNING:This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The equipment complies with FCC Radiation exposure limit set forth for an uncontrolled environment. The equipment should be installed and operated with a minimum distance of 20cm between the product and your body. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Features:Product specication: Magnetic charging head: 115K - 205KHZ 2BDOG-TAC-150 15W (Max) 5V/2A 9V/2.2A Voltage Output FCC ID Charging frequency 1-3mm Induction Distance Instructions: 1. Insert the adjuster into ball joint of air vent mount, insert the ball into the socket at the back of bracket, turn the adjuster to tighten. 2. Insert the hook into the car air outlet vane and tighten to lock. when you hear 'clatter' sounds, it means the mount has been xed tightly. 4. Place your device into the bracket, and grip clamp arms to lock it tightly. 3. Connect the charging cable to the charging interface, press the release buttons in the back side, the clamp arms open automatically; Manually pull out the foot support depending on the size of your device. LED Mode: Working state LED light color Power transfer Standby mode Red light keeps on Charging Blue light keeps on FOD Warning Red light keeps ashing Blue, red, blue red light ash once, then o Charging Indicator : Turn red when charging Sunken Design, No blocking key 56 - 98 mm Release button Type C charging interface Charging Cable Air vent mount 32 mm Car holder with wireless charging function, charges your phone conveniently when driving. Power output 5W/7.5W/10W/15W, compatible with all phones with QI standard. Full 360 degrees rotation for perfect viewing angle. Start charging once as the phone contact with the holder, no need plug cable in the phone. Adjustable foot support makes easy to align to the charging center. (Require receiver compliant with WPC Qi standard to match). Compatible devices: Qi disabled devices with wireless receiver or wireless charging case. Work well with all Qi enabled devices including: iPhone 15, iPhone15 Pro Max, iPhone15 Pro, iPhone 14, iPhone14 Pro Max, iPhone14 Pro, iPhone 13, iPhone13 Pro Max, iPhone13 Pro, iPhone13 mini, iPhone 12, iPhone12 Pro Max, iPhone12 Pro, iPhone12 mini, Samsung Note 8, Note 9, iPhone XS MAS, Huawei P30 Pro, MIUI9, Samsung S10+, iPhone 8PLus, Samsung S9+, Samsung S8+, iPhone XR, Samsung S10, Samsung S7edge, Samsung S8, iPhone XS, iPhone X, Samsung S9, iPhone 8, iPhone 11, iPhone SE, Samsung S24, Samsung S23, Samsung S22, Samsung S21, Samsung S20
