2BFPQ-CVN-T10Wireless Charging Module for Smart Tag

T10 User Manual Tag Wireless Charger How to USE 2.The power turns on and the yellow LED indicator blinks approximately 3 to 5 times. 3. Place the tag device you want to charge on the high-speed wireless charging stand. 4.When wireless charging is activated, the red charging/charging complete green LED lights up Foreign Object Detection(F.O.D) Foreign oblect detection mode When the red LED blinks, a foreign object has been detected. Remove foreign substances (foreign substances: metal, credit cards, other strongly magnetic substances) 1.Connect 12V, 1A power to the 2 ports on the bottom of the product (Caution: When using the product, 12V, 1A power and USB C type power should not be connected at the same time) T10 User Manual Safety rules Do not leave the product in a wet place or near fire or high heat where there is a risk of fire. Do not apply strong shock or pressure to the product. Be careful not to let any foreign matter enter the product terminal except for the purpose of connecting the charging power. The product may generate a slight amount of heat during charging, but this is a normal charging process. To maintain the product, do not use alcohol-based detergent or water. Do not use products with strong magnetism magnets, metal, credit cards, etc.) close to them Do not store the product in low or high temperatures and high humidity. Do not disassemble, modify, or assemble the product arbitrarily If the product is damaged by intentionally applying physical force to the product, you will not be eligible for quality warranty service. Charging status indicator LED Charging status indicator LED 2P Power (12V, 1A) Parts Components T10 User Manual FCC COMPLIANCE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION : Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines as this equipment has very low levels of RF energy. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Certification designating a U.S. Agent for service of process: As required by section 2.911(d)(7), the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. In either scenario, the designation of the U.S. agent for service of process should be provided as an attachment to the equipment authorization application. The applicant must provide a written certification, which must: i. Be signed by both the applicant and designated agent for service of process, if the agent is different from the applicant. ii. Acknowledge the applicant’s consent and the designated agent’s obligation to accept service of process. iii. Provide a physical U.S. address and email for the designated agent. iv. Acknowledge the applicant’s acceptance to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Unofficial information provided by FCC personnel on February 14, 2023, via the monthly call with the TCB Council: The Agent for Process of Service: • cannot be a TCB or affiliated with a TCB (e.g. could not be a person who works for a TCB or a company that owns or is owned by the TCB) • cannot be a [FCC recognised] Lab or affiliated with a test lab (e.g. could not be a person who works for a Lab or a company that owns or is owned by the Lab) • Agent can be Individual Entity or a Company Entity • Agent Entity must be located in US, US address/phone • Entity acting as Agent must have FRN (best practice, put FRN on Agent Letter) • Agent letter does not have to be FCC ID specific, can be general Agent for Grantee For devices being marketed or for which marketing has ceased for less than 1 year, if the Agent for Process of Service changes, then for every TC Number the TCB must request the FCC to put application into Audit Mode and Agent Letter needs to be updated (superseded). NOTE: The U.S. Agent for Service of Process should not be confused with the authorized agent used for signing the 731 form, other cover letters within the application, and/or the agent who may interface with the TCB. U.S. Agent Designation for Service of Process ATTENTION: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA REGARDING: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Approve-IT, Inc. Contact Name: Nathan Grinager Street Address: 8011 34 th Ave South, Suite 342 City/Province/Zip: Bloomington, MN 55425 Telephone No: 651-247-1678 Email: [email protected] FRN #: 0027533835 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: May 27, 2024 Signed by (Printed Name/Title): Nathan Grinager / Co-President *This letter is valid indefinitely for all applications submitted within the period of 05/27/2024 – 05/26/2025 The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Hyundai Autoever Corp. Grantee FRN: 0035236199 Grantee Code: 2BFPQ Contact Name: Yun Su Shim Street Address: 510 Teheran-ro City/Province/Zip: Gangnam-gu, Seoul, South Korea, 06179 Telephone No: +82-10-9636-1981 Email: [email protected] Applicant Signature: Date: May 24, 2024 Signed by (Printed Name/Title): Yun Su Shim, Professional

Date: August 29, 2024 Certification Attestation Statements Attn: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA To Whom It May Concern: FCC ID : 2BFPQ-CVN-T10 47 CFR section 2.911(d)(5)(i) Attestation Statement Hyundai Autoever Corp. certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: - 47 CFR section 2.911(d)(5)(ii) Attestation Statement Hyundai Autoever Corp. (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☐ - is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Thank you, Signature Name: Yun Su Shim Title: Professional Company: Hyundai Autoever Corp. Tel # : +82-10-9636-1981 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

Rev 11/20/07 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID : 2BFPQ-CVN-T10 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block diagram Schematics Schematics_PCB Layout Parts list Operational description Block Diagram.pdf Schematics.pdf Schematics_PCB Layout.pdf Part List.pdf Operational Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, NAME: Yun Su Shim Applicant: Hyundai Autoever Corp.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date : August 21, 2024 SUBJECT: FCC Application for (FCC ID : 2BFPQ-CVN-T10) To Whom It May Concern: We, the undersigned, hereby authorize Bongjun, Jang at CTK on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by CTK on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, NAME: Yun Su Shim Applicant: Hyundai Autoever Corp.

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT External Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com

CVN-T10 LabelLocation (Back of product) FCCID:2BFPQ-CVN-T10 Smart oneCo.,Ltd. Country of Origin : KR

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT Internal Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com [Antenna]

TEST REPORT CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02328 Page (1) / (10) Pages [QF-QP15-07] Ver.01 R112 1. Applicant ◦ Name : Hyundai Autoever Corp. ◦ Address : 510, Teheran-ro, Gangnam-gu, Seoul, Republic of Korea ◦ Date of Receipt : 2024-06-28 2. Manufacturer ◦ Name : TEIA Co.,Ltd ◦ Address : Suite B-303/304, 33 Gwacheon-daero 7-gil, Gwacheon-si, Gyeonggi-do, Republic of Korea 3. Use of Report : For FCC Certification 4. Test Sample / Model : Wireless Charging Module for Smart Tag / CVN-T10 (HAE-CM-WL-ST-02) 5. Date of Test : 2024-08-19 6. Test Standard(method) used : FCC 47 CFR part 1 subpart I 1.1310 7. Testing Environment: Temp.: (24 ± 1) °C, Humidity: (39 ± 3) % R.H 8. Test Results : Compliance 9. Location of Test : Permanent Testing Lab On Site Testing (Address : 5, Dongbu-ro 221beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This report cannot be reproduced or copied without the written consent of CTK. Approval Tested by Bong-jun Jang: (Signature) Technical Manager Young-taek Lee: (Signature) 2024-08-20 CTK Co., Ltd. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02328 Page (2) / (10) Pages [QF-QP15-07] Ver.01 R112 REPORT REVISION HISTORY Date Revision Page No 2024-08-20 Issued (CTK-2024-02328) all This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02328 Page (3) / (10) Pages [QF-QP15-07] Ver.01 R112 CONTENTS 1. General Description .................................................................................................... 4 1.1 Client Information .............................................................................................. 4 1.2 Product Information ............................................................................................ 4 2. Accreditations ........................................................................................................... 5 2.1 Laboratory Accreditations and Listings .................................................................. 5 2.2 Calibration Details of Equipment Used for Measurement .......................................... 5 3. RF Exposure Assessment ............................................................................................ 6 3.1 Maximum Permissible Exposure ............................................................................ 6 APPENDIX A – Test Equipment Used For Tests ................................................................. 10 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02328 Page (4) / (10) Pages [QF-QP15-07] Ver.01 R112 1. General Description 1.1 Client Information Company Hyundai Autoever Corp. Contact Point 510 Teheran-ro, Gangnam-gu, Seoul, Republic of Korea Contact Person Name : Yun Su Shim E-mail : [email protected] 1.2 Product Information FCC ID 2BFPQ-CVN-T10 Product Description Wireless Charging Module for Smart Tag Model name CVN-T10 (HAE-CM-WL-ST-02) Variant Model name - Charging Frequency 128 kHz Power Transfer Method Magnetic induction and only single primary coil coupling secondary coil Output power from each primary coil 8 W That may have multiple primary coils No Antenna Type Loop Coil Charging Method Directly contact Power Source DC 12 V CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02328 Page (5) / (10) Pages [QF-QP15-07] Ver.01 R112 2. Accreditations 2.1 Laboratory Accreditations and Listings Country Agency Registration Number USA FCC 805871 CANADA ISED CN : 8737A CAB ID : KR0025 KOREA NRRA KR0025 2.2 Calibration Details of Equipment Used for Measurement Test equipment and test accessories are calibrated on regular basis. The maximum time between calibrations is one year or what is recommended by the manufacturer, whichever is less. All test equipment calibrations are traceable to the Korea Research Institute of Standards and Science (KRISS), therefore, all test data recorded in this report is traceable to KRISS. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02328 Page (6) / (10) Pages [QF-QP15-07] Ver.01 R112 3. RF Exposure Assessment 3.1 Maximum Permissible Exposure Limit Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *100 6 3.0-30 1842/f 4.89/f *900/f 2 6 30-300 61.4 0.163 1.0 6 300-1,500 - - f/300 6 1,500-100,000 - - 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1,500 - - f/1500 30 1,500-100,000 - - 1.0 30 Note 1 : f = frequency in MHz; *Plane-wave equivalent power density Note 2 : For the applicable limit, see FCC 1.1310 Test method a) Performed aggregate both leakage E-field and H-field at surrounding the device from all simultaneous transmitting coils. b) During testing, the EUT was placed on a non-conductive table top and the ancillary equipment (e.g., WPT Load) was placed on the EUT for charging. Maximum E-field and H- field measurement were tested 15cm from …

Text truncated - open the document above for the full version.

TEST REPORT CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02327 Page (1) / (18) Pages [QF-QP15-07] Ver.01 R108 1. Applicant ◦ Name : Hyundai Autoever Corp. ◦ Address : 510, Teheran-ro, Gangnam-gu, Seoul, Republic of Korea ◦ Date of Receipt : 2024-06-28 2. Manufacturer ◦ Name : TEIA Co.,Ltd ◦ Address : Suite B-303/304, 33 Gwacheon-daero 7-gil, Gwacheon-si, Gyeonggi-do, Republic of Korea 3. Use of Report : For FCC Certification 4. Test Sample / Model : Wireless Charging Module for Smart Tag / CVN-T10 (HAE-CM-WL-ST-02) 5. Date of Test : 2024-07-12 to 2024-08-28 6. Test Standard(method) used : FCC 47 CFR part 15 subpart C 15.209 7. Testing Environment: refer to 8 pages to 17 pages 8. Test Results : Compliance 9. Location of Test : Permanent Testing Lab On Site Testing (Address : 5, Dongbu-ro 221beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This report cannot be reproduced or copied without the written consent of CTK. Approval Tested by Bong-jun Jang: (Signature) Technical Manager Young-taek Lee: (Signature) Remark. This report is not related to KOLAS accreditation and relevant regulation. 2024-08-29 CTK Co., Ltd. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02327 Page (2) / (18) Pages [QF-QP15-07] Ver.01 R108 REPORT REVISION HISTORY Date Revision Page No 2024-08-29 Issued (CTK-2024-02327) all This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. Personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. Will constitute fraud and shall nullify the document. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02327 Page (3) / (18) Pages [QF-QP15-07] Ver.01 R108 CONTENTS 1. General Description .................................................................................................... 4 1.1 Client Information .............................................................................................. 4 1.2 Product Information ............................................................................................ 4 1.4 Antenna Information ........................................................................................... 4 2. Accreditations ........................................................................................................... 5 2.1 Laboratory Accreditations and Listings .................................................................. 5 2.2 Calibration Details of Equipment Used for Measurement .......................................... 5 3. Test Specifications ..................................................................................................... 6 3.1 Standards.......................................................................................................... 6 3.2 Mode of operation during the test ......................................................................... 6 3.3 Peripheral Devices .............................................................................................. 7 3.4 Measurement Uncertainty .................................................................................... 7 3.5 Test Software ..................................................................................................... 7 4. Technical Characteristic Test ........................................................................................ 8 4.1 Emission Bandwidth ............................................................................................ 8 4.2 Radiated emissions ........................................................................................... 10 4.3 AC Power Line Conducted Emissions ................................................................... 16 APPENDIX A – Test Equipment Used For Tests ................................................................. 18 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02327 Page (4) / (18) Pages [QF-QP15-07] Ver.01 R108 1. General Description 1.1 Client Information Company Hyundai Autoever Corp. Contact Point 510 Teheran-ro, Gangnam-gu, Seoul, Republic of Korea Contact Person Name : Yun Su Shim E-mail : [email protected] 1.2 Product Information FCC ID 2BFPQ-CVN-T10 Product Description Wireless Charging Module for Smart Tag Model name CVN-T10 (HAE-CM-WL-ST-02) Variant Model name - Charging Frequency 128 kHz RF Output Power 93.1 dBuV/m @ 3m Power Transfer Method Magnetic induction and only single primary coil coupling secondary coil Output power from each primary coil 8 W That may have multiple primary coils No Antenna Type Loop Coil Charging Method Directly contact Power Source DC 12 V 1.4 Antenna Information Integral antenna (antenna permanently attached) Temporary RF connector provided No temporary RF connector provided Transmit chains bypass antenna and soldered temporary RF connector provided for connected measurement. In case of conducted measurements the transmitter shall be connected to the measuring equipment via a suitable attenuator and correct for all losses in the RF path. External antenna (dedicated antennas) CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2024-02327 Page (5) / (18) Pages [QF-QP15-07] Ver.01 R108 2. Accreditations 2.1 Laboratory Accreditations and Listings Country Agency Registration Number USA FCC 805871 CANADA ISED CN : 8737A CAB ID : KR0025 KOREA NRRA KR0025 2.2 Calibra…

Text truncated - open the document above for the full version.

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Setup Photographs and Configuration Radiated emissions CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com AC Power Line conducted emissions CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com RF exposure
