XbotGo Falcon AI SPORTS CAMERA M1 M2 M3 User Manual XbotGo Falcon AI SPORTS CAMERA || 1 Table of Contents Preface 3 Precautions 4 Package Contents and Optional Accessories 6 Package Contents ·····················································································6 Optional Accessories ·················································································6 Product Overview 7 Understanding the XbotGo Falcon Camera Buttons and Functions ················································································7 Preparation Before Use 16 1. Charging the Product ·············································································16 2. Download and Install the XbotGo App ·······················································17 Getting Started 19 1. Connecting Your Phone ··········································································19 2. Viewing the Device List ···········································································20 3. Changing Connected Devices ··································································21 4. Installing a microSD (TF) Card ·································································22 5. Installing the Tripod ················································································24 6. XbotGo RC1 Remote Control ···································································25 2 || XbotGo Falcon AI SPORTS CAMERA Table of Contents Shooting Instructions 33 Selecting Shooting Locations ·····································································33 Application Guide 35 XbotGo App ····························································································35 Firmware Upgrade 57 Upgrade Process ·····················································································57 Technical Specifications 59 FAQ 61 1. Why is my XbotGo Falcon having tracking issues? ······································61 2. Can my XbotGo Falcon track a specific athlete? ··········································62 3. My XbotGo Falcon won't turn on. What should I do?·····································62 4. My phone's Bluetooth is unable to connect to my XbotGo Falcon. How do I resolve this? ············································································63 5. What's the general troubleshooting process for any issue? ···························65 XbotGo Falcon AI SPORTS CAMERA || 3 Preface Thank you for choosing the XbotGo Falcon camera. The XbotGo Falcon camera is an AI-powered smart imaging device that integrates intelligent tracking, event live streaming, score recording, video editing, sports analysis, and cloud storage functions into one system. The product supports BLE (Bluetooth Low Energy) and Wi-Fi connectivity, featuring a dual-lens system de- sign with the main camera as an independent HD module. It enables intelligent auto-tracking shooting. This device is designed for both team and individual sports scenarios, offering powerful image processing capabilities, flexible tilt adjustment, and multi-camera collaboration support. Whether for personal training, professional game recording, or high-quality live broadcasting, the Falcon precisely captures every highlight mo- ment on the field. We hope that the XbotGo Falcon delivers an outstanding shooting experience and inspires you to explore new possibilities in sports and creative endeavors. This manual includes important information regarding product usage, precautions, and maintenance. Please read it carefully before use to ensure safe, efficient op- eration and optimal performance. The images and descriptions in this manual are for reference only. Please refer to the actual product for accuracy. The copyright of this manual belongs to Suzhou Deep Foresight Technology Co., Ltd. Without the company’s written permission, no organization or individual may copy, distribute, or modify any part of this manual in any form, nor use it for commercial purposes. As the company continuously improves its products, specifications are subject to change without prior notice. 4 || XbotGo Falcon AI SPORTS CAMERA Precautions In this manual, important information is categorized using the following symbols. Please read them carefully to better understand and use this manual. Warning Failure to follow instructions may result in personal injury or death. Caution Failure to follow instructions may result in equipment dam- age, performance degradation, or injury. Note Helpful tips and operational guidance for using this product effectively. Before using this product, read the following precautions carefully: • During startup, ensure your XbotGo Falcon camera can rotate freely without any interference. • Before starting the product, ensure that it is securely mounted on a tripod to prevent falls, impacts, or compression that may damage the device. • Handle with care to avoid drops or impacts, as this may affect normal operation. • Do not use non-designated chargers, power adapters, or USB Type-C data cables to avoid damage to the product. XbotGo Falcon AI SPORTS CAMERA || 5 • Do not disassemble, repair, or modify this product yourself, as it may cause malfunctions. • Extended use may cause the device's motor to heat up. Handle with caution to avoid burns. • Store your XbotGo Falcon in a cool, dry environment. • Keep your XbotGo Falcon away from heat sources like stoves or heaters. Avoid storing in high-temperature areas (e.g., hot cars or rooms). • Keep the product out of reach of children and pets. • Avoid overcharging to prevent damage to the battery. • Use your XbotGo Falcon within the temperature range of 0°C to 40°C. 6 || XbotGo Falcon AI SPORTS CAMERA Package Contents and Optional Accessories Package Contents Main DeviceUSB Type-C Data Cable Carrying Case Quick Start Guide Quick-release Plate Cleaning Cloth Optional Accessories Weather Protection Umbrella XbotGo NT4 Tripod If any accessories are missing or damaged, please contac…
